Owner's Manual
6.75 HORSEPOWER
22" REAR DISCHARGE
POWER PROPELLED
ROTARY LAWN MOWER
Model No.
944.360300
•
•
•
•
•
CAUTION:
Read and follow all
Safety Rules and Instructions
before operating this equipment
Sears Canada, Inc., Toronto, Ontario M5B 2B8
Printed in U.S.A.
Safety
Maintenance
®
