QUICK REFERENCE Wired remote controller BRC2E52C7 BRC3E52C7... -
Page 2: Table Of Contents
General safety precautions ............... 1 interior parts may result in electric shocks or fire. Consult Features and functions ..............1 your Daikin dealer or authorized contractor for internal Name and function of switches ............2 inspections and adjustments. Name and function of icons .............. 2 Description of the operation modes .......... -
Page 3: Name And Function Of Switches
By default, the display method is Single Setpoint mode. To enable Dual Setpoint mode, refer to the Installation Manual. DEFROST/HOT START (HRV only) Indicates that the Defrost/Hot Start operation is active. BRC2E52C7+BRC3E52C7 Quick reference Wired remote controller 4P368040-1 – 2014.02... -
Page 4: Description Of The Operation Modes
VENTILATION (HRV only) The ventilation mode is used on Heat Reclaim Ventilation units when cooling or heating is unnecessary; refer to the HRV manual for more details. Quick reference BRC2E52C7+BRC3E52C7 Wired remote controller 4P368040-1 – 2014.02... -
Page 5: Description Of The Items In The Main Menu
In case of a simultaneous operation system, the system is controlled by The schedule will not be available when a centralised controller or the the sensing sensor mounted in the master indoor unit. BRP7A51 Digital Input Adapter is connected. BRC2E52C7+BRC3E52C7 Quick reference Wired remote controller 4P368040-1 – 2014.02... -
Page 6: Quick Start (Skyair Only)
Push to display to set the holiday. Schedule Holidays Multiple Selection Sun Mon Tue Wed Thu Fri Sat Return Setting Push to display the confirmation screen. to select Yes and push Quick reference BRC2E52C7+BRC3E52C7 Wired remote controller 4P368040-1 – 2014.02... -
Page 7: Configuration
Year, Month, to move the highlighted item and Day and time. Date & Time Year 2014 Month Wednesday 0:00 Setting Return Push to display the confirmation screen. to select Yes and push BRC2E52C7+BRC3E52C7 Quick reference Wired remote controller 4P368040-1 – 2014.02... -
Page 8: Installation
Keep this manual in a handy place for future reference. This is an option to be used in combination with Daikin units. Refer to the Installation and Operation Manual of the units for installation and operation instructions. -
Page 9: Attach The Upper Case
For easy wiring, it’s better to keep ±10 mm difference between the length of the 2 wires. Wiring outlet Top outlet ±150 mm Top center outlet ±200 mm BRC2E52C7+BRC3E52C7 Quick reference Wired remote controller 4P368040-1 – 2014.02... -
Page 10: Enable/Disable The Menu/Enter And Cancel Button
WARNING Be sure to stop the operation of the air conditioner and turn power supply breaker when performing maintenance. Failure to do so may result in electric shocks or injury. Quick reference BRC2E52C7+BRC3E52C7 Wired remote controller 4P368040-1 – 2014.02... -
Page 11: Appendix
Filter Auto Clean (14) Maintenance Information (15) Configuration (16) Draft Prevention Display Display Contrast Adjustment Display Mode Display Item Current Settings (17) Clock & Calendar (18) Date & Time 12H/24H Clock Language (19) BRC2E52C7+BRC3E52C7 Quick reference Wired remote controller 4P368040-1 – 2014.02... - Page 12 4P368040-1 2014.02...
