McCulloch 2316av Pasts List

PARTS LIST NO.
545014311
DATE Replaces
3/04/08 545014311 -- 5/31/07
41
42
43
56
57 58
59
60
61
62
63
64
65
Part No.
Ref. Description
1. 530059667 Assy.- -Isolator
2. 530047608 Limiter Strap
3. 530059668 Spring- -Isolator
4. 530015158 Washer
5. 530016018 Screw
6. 530015843 Screw
7. 530047583 Front Handle
8. 530015940 Screw
9. 530015814 Screw
10. 530044915 Bar - - 16"
11. 538248288 Chain - - 16"
12. 530014381 Kit- -Spike (Incl. 13)
13. 530016439 Screw
14. 530016132 Screw
15. 530038238 Plate- -Bar Mount.
16. 530015814 Screw
17. 530029850 Chain Catcher
18. 530016133 Bolt- -Bar
19. 530057236 Assy- -Oil Cap
20. 530071666 Kit- -Oil Vent
21. 530016134 Nut- -Flywheel
22. 530016080 Screw
23. 530037817 Starter Pulley
24. 530055723 Baffle- -Air
25. 530015892 Screw
26. 530056333 Housing- -Fan
27. 530069232 Kit - - Rope
=
n NEW PART NUMBER FOR THIS IPL
Note: Illustration may differ from actual model due to design changes
40
39
38
47
44 45 46
48
49
50
51
52
53
54
55
66
67
68
Ref. Part No.
28. 530056402
29. 530027531
30. 530015920
31. 530015127
32. 530039187
33. 530047192
34. 530023877
35. 530069216
36. 530016149
37. 530015775
38. 530047581
39. 530015886
40. 530015906
41. 530036098
42. 530036097
43. 530047582
44. 530071958
45. 530015875
46. 530059668
47. 530057473
48. 530057474
49. 530049005
50. 530015922
51. 530058733
52. 530015907
=
REFER TO THE SERVICE REFERENCE INDICATED FOR MORE INFORMATION. (LOCATED AT END OF IPL)
K
PARTS LIST
TYPE 1
WARNING
All repairs, adjustments and maintenance not
37
described in the Operator's Manual must be
36
35
performed by qualified service personnel.
34
33
31
32
18
17
16
15
14
13
12
9
11
10
Description
Handle- -Starter
Spring- -Recoil
Screw
Washer- -Flywheel
Assy- -Flywheel
Assy- -Fuel Cap
Fitting- -fuel line
Kit- -Fuel line (large)
Spring- -Switch
Screw
Cover- -Rear Handle
Screw
Screw
Throttle Lockout
Trigger- -Throttle
Handle - - Rear
Kit- -Isolator (Upper)
Screw
Spring- -Isolator
Lever- -Switch
Lever- -Choke
Grommet- -Knob
Nut- -"U"- -Type
Assy.- -Chassis
fuel lines and caps )
Washer- -Thrust
CHAIN SAW MODEL(s)
Mac2316AV
PAGE NO.
29
30
24
23
22
21
Kit- -Oil Vent
19
20
7
8
5
6
Description
Ref. Part No.
53. 530047061 Assy.- -Clutch Drum
w/bearing
54. 530015611 Washer- -Clutch
55. 530014949 Assy. Clutch
56. 530071259 Kit - - Oil Pump
(incl. 57,58,60)
57. 530037820 Gear- -Worm Spring
58. 530049477 Elbow- -Oil Pickup
59. 530016064 Screw
60. 530019206 Seal Block
61. 530047663 Assy- -Oil Pick- -up
(Incl. 62,63)
62. 530038373 Pick- -up Oiler
63. 530056533 Filter- -Oil
64. 530054739 Assy.- -Chain Brake
65. 530015917 Nut- -Bar Mounting
66. 530015826 Pin- -Bar Adjust
67. 530038593 Retainer
68. 530069611 Kit- -Bar Adjusting
(incl. # 66,67)
1
28
27
26
25
2
3
4
1
