ParaBody 829 User Manual

Leg curl/extension
Hide thumbs Also See for 829:
Table of Contents

Advertisement

Quick Links

Download this manual
829 LEG CURL/EXTENSION
WARNING:
Read and follow all directions
for each step to insure proper
assembly of this product.
CLASS H
PART # 7302401
REV. A
USER'S GUIDE
1
Version: 829108
Revision: 06/13/02

Advertisement

Table of Contents
loading

Related Manuals for ParaBody 829

Summary of Contents for ParaBody 829

  • Page 1 829 LEG CURL/EXTENSION WARNING: Read and follow all directions for each step to insure proper assembly of this product. USER’S GUIDE CLASS H PART # 7302401 REV. A Version: 829108 Revision: 06/13/02...

  • Page 2: Important Safety Information

    7. Inspect cables and their connections before using machine. Pay particular attention to the cable ends. DO NOT attempt to fix. Notify your authorized ParaBody dealer before use and have repairs made by an authorized service technician. 8. Make sure all spring loaded pull pins are fully engaged in the adjustment position and fully tighten thumbscrew before use.

  • Page 3: Important Notes

    Please note: * Thank you for purchasing the ParaBody 829 LEG CURL/EXTENSION. Please read these instructions thoroughly and keep them for future reference. This product must be assembled on a flat, level surface to assure its proper function. * This product must be assembled on a flat, level surface to assure its proper function. DO NOT securely tighten any frame connections until the entire frame has been assembled, unless otherwise stated.
  • Page 4 1’ 2’ 3’ 4’ 5’ 1’ 2’ 3’ 4’ 5’ 6’ 1 Square = 1’ X 1’...

  • Page 5: Parts List

    PART # DESCRIPTION LEA6259109 FRONT SUPPORT TUBE LEA6625410 BACK PAD ADJUST TUBE LEA6625510 BACK PAD SUPPORT TUBE LEA6216710 1-3/4 SQ X 5" TUBE LEA6668210 1-3/4 SQ X 13-1/2" TUBE LEA6662010 LEG CURL/EXTENSION LEA6661221 BACK PAD ASSY LEA6661621 SEAT PAD ASSY LEA6662209 LEG EXT HANDLE RHT LEA6662309...
  • Page 6 STEP 1 Insert four COVER END CAPS (37) into the ends of REAR BASE LEG (12) and FRONT BASE SUPPORT (1). See FIGURE STEP 2 Slide two 1-1/4 x 5” GRIPS (36) over tubes on REAR BASE LEG (12). See FIGURE STEP 3 Securely assemble REAR BASE LEG (12) to LEG FRAME (11) using two 3/8 X 3”...
  • Page 7 STEP 6 Securely assemble RIGHT (9) & LEFT (10) LEG EXT HANDLES to LEG FRAME (11) using two 3/8 X 4” BOLTS (21), four 3/8” FLAT WASHERS (24) , and two 3/8” LOW HEIGHT NYLOCK NUTS (27). See FIG- URE 5. STEP 7 Insert two 3 X 2”...
  • Page 8 STEP 10 Securely assemble BACK PAD ADJUST TUBE (2) & BACK PAD SUPPORT TUBE (3) to LEG FRAME (11) using one 1/2 X 7” BOLT (23) and one 1/2” LOW HEIGHT NYLOCK NUT (26). (NOTE: SECURELY TIGHTEN BOLT THEN BACK NUT OFF 1/4 TURN TO ALLOW THE TWO PARTS TO ROTATE FREELY.) See FIGURE 8.
  • Page 9 STEP 13 Slide two HINGE TABS (31) over posts on LEG FRAME (11). See FIGURE 11. STEP 14 Securely attach the SEAT PAD (8) to the HINGE TABS (31) using two 3/8 X 1” BOLTS (19) and two 3/8” FLAT WASH- ERS (24).
  • Page 10 STEP 16 Attach eight 1-1/2” X 3/4” GLIDES (33) to 5” ROLLER PAD ADJUSTER (4) and attach eight 1-1/2” X 3/4” GLIDES (33) to 13-1/2” ROLLER PAD ADJUSTER (5) as shown in FIGURE 14. STEP 17 Securely assemble two 3/8” SPRING PIN AS- SEMBLIES (17) into the spring pin barrels on the LEG CURL/EXTENSION (6) as shown in FIGURE 15.
  • Page 11 Attach four ROLLER PADS (15) and four 2” OD PLASTIC WASHERS (38) to the LEG STEP 23 CURL/EXTENSION (6) using two 16” ROLLER PAD SHAFTS (13) and four STAR- LOCK COLLARS (35). See FIGURE 18. THIS CONCLUDES THE ASSEMBLY OF THE PARABODY 829 LEG CURL/EXTENSION FIGURE 17 FIGURE 18 26 LOW HEIGHT...

  • Page 12: Maintenance

    Please note: * We recommend cleaning your product (pads and frame) on a regular basis, using warm soapy water. Touch-up paint can be purchased from your ParaBody customer service representative at (800) 328-9714. * Inspect equipment daily. Tighten all loose connections are replace worn parts immediately.

  • Page 13: Limited Warranty

    ParaBody extends the following LIMITED WARRANTY to the original owner of the ParaBody products. The Warranty terms apply to IN HOME USE ONLY. 1. LIMITED WARRANTY ON FRAME AND WELDS. If the frame of the ParaBody product or a weld should crack or break, it will be repaired or replaced by ParaBody.
  • Page 14 Room 2610, Miramar Tower 132 Nathan Road, Tsimshatsui Kowloon, Hong Kong Phone: (852) 2891-6677 Fax: (852) 2575-6001 LIFE FITNESS www.parabody.com Life Fitness (UK) Ltd. Queen Adelaide Ely, Cambs CB7 4UB United Kingdom Phone CSS: (01353) 665507 Fax CSS: (01353) 666719 Life Fitness Benelux N.V.
