FUNAI FL11.3 Service Manual
  1. Manuals
  2. Brands
  3. FUNAI Manuals
  4. LCD TV
  5. FL11.3
  6. Service manual
FUNAI FL11.3 Service Manual

FUNAI FL11.3 Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
26" LCD TV

SERVICE MANUAL

TYPE A
LC260EM2
EMERSON
LC260SS2
SYLVANIA
26MF301B/F7
MAGNAVOX
26MF301B/F7
MAGNAVOX
This service manual contains information of different types of models.
Make sure to refer to the section describing your model.
© 2011 Funai Electric Co., Ltd.
All rights reserved. No part of this manual may be reproduced, copied, transmitted, disseminated, transcribed,
downloaded or stored in any storage medium, in any form or for any purpose without the express prior written
consent of Funai. Furthermore, any unauthorized commercial distribution of this manual or any revision hereto
is strictly prohibited.
Information in this document is subject to change without notice. Funai reserves the right to change the content
herein without the obligation to notify any person or organization of such changes.
with the
design is a registered trademark of Funai Electric Co., Ltd and may not be used in any way
without the express written consent of Funai. All other trademarks used herein remain the exclusive property of
their respective owners. Nothing contained in this manual should be construed as granting, by implication or
otherwise, any license or right to use any of the trademarks displayed herein. Misuse of any trademarks or any
other content in this manual is strictly prohibited. Funai shall aggressively enforce its intellectual property rights
to the fullest extent of the law.
chassis FL11.3
Contents
(Serial No.: DS1)
(Serial No.: DS1)
(Serial No.: DS1)
(Serial No.: DS2)
110414

Advertisement

Table of Contents
loading

Related Manuals for FUNAI FL11.3

Summary of Contents for FUNAI FL11.3

  • Page 1: Service Manual

    Funai. Furthermore, any unauthorized commercial distribution of this manual or any revision hereto is strictly prohibited. Information in this document is subject to change without notice. Funai reserves the right to change the content herein without the obligation to notify any person or organization of such changes.

  • Page 2: Important Safety Notice

    It also is important to understand that these CAUTIONS and NOTICES ARE NOT EXHAUSTIVE. Funai could not possibly know, evaluate and advice the service trade of all conceivable ways in which service might be done or of the possible hazardous consequences of each way.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Specifications ................1-1 Important Safety Precautions .

  • Page 4: Specifications

    SPECIFICATIONS < TUNER / NTSC > ANT. Input ---------------------- 75 Ω Unbal., F type Description Condition Unit Nominal Limit 1. AFT Pull-In Range ±2.3 ±2.1 TV.ch.4 dBµ 2. Synchronizing Sens. CA.ch.31 dBµ CA.ch.87 dBµ < TUNER / ATSC > Description Condition Unit Nominal...

  • Page 5: Important Safety Precautions

    IMPORTANT SAFETY PRECAUTIONS Prior to shipment from the factory, our products are strictly inspected for recognized product safety and electrical codes of the countries in which they are to be sold. However, in order to maintain such compliance, it is equally important to implement the following precautions when a set is being serviced.
  • Page 6 3. Design Alteration Warning - Do not alter or add 7. Product Safety Notice - Some electrical and to the mechanical or electrical design of this TV mechanical parts have special safety-related receiver. Design alterations and additions, characteristics which are often not evident from including, but not limited to circuit modifications visual inspection, nor can the protection they give and the addition of items such as auxiliary audio...
  • Page 7 Precautions during Servicing A. Parts identified by the # symbol are critical for safety. Replace only with part number specified. B. In addition to safety, other parts and assemblies are specified for conformance with regulations applying to spurious radiation. These must also be replaced only with specified replacements.
  • Page 8 Safety Check after Servicing Examine the area surrounding the repaired location for damage or deterioration. Observe that screws, parts and wires have been returned to original positions. Afterwards, perform the following tests and confirm the specified values in order to verify compliance with safety standards. 1.

  • Page 9: Standard Notes For Servicing

    STANDARD NOTES FOR SERVICING Circuit Board Indications How to Remove / Install Flat Pack-IC 1. The output pin of the 3 pin Regulator ICs is 1. Removal indicated as shown. With Hot-Air Flat Pack-IC Desoldering Machine: Top View 1. Prepare the hot-air flat pack-IC desoldering Bottom View machine, then apply hot air to the Flat Pack-IC Input...
  • Page 10 3. The flat pack-IC on the CBA is affixed with glue, so With Soldering Iron: be careful not to break or damage the foil of each 1. Using desoldering braid, remove the solder from pin or the solder lands under the IC when all pins of the flat pack-IC.
  • Page 11 2. Installation With Iron Wire: 1. Using desoldering braid, remove the solder from 1. Using desoldering braid, remove the solder from all pins of the flat pack-IC. When you use solder the foil of each pin of the flat pack-IC on the CBA flux which is applied to all pins of the flat pack-IC, so you can install a replacement flat pack-IC more you can remove it easily.
  • Page 12 Instructions for Handling Semi- conductors Electrostatic breakdown of the semi-conductors may occur due to a potential difference caused by electrostatic charge during unpacking or repair work. 1. Ground for Human Body Be sure to wear a grounding band (1 MΩ) that is properly grounded to remove any static electricity that may be charged on the body.

  • Page 13: Cabinet Disassembly Instructions

    CN3902, Shield Box, Jack Holder(D) 3(S-7), (S-8), CL701A, Jack CBA PCB Holder, Jack Holder(A) Power 8(S-9), CN101, Supply CN201, CN631, CN801, CN802 Stand D2 2(S-10), 2(S-11) Holder Inverter 6(S-12), CN1201, CN1202, CN1203 Module D2 --------------- Assembly 4(S-13), Hook, Speaker Speaker Holder(L,R) FL11.3-A_DC...
  • Page 14 (S-2) (S-2) (S-2) [2] Rear Cabinet (S-3) (S-2) (S-2) [1] Stand Assembly (S-1) Fig. D1 FL11.3-A_DC...
  • Page 15 [10] Function CBA [4] Jack CBA (S-5) [9] Speaker Speaker (S-4) (S-8) Holder(L) Jack Holder(A) (S-7) PCB Holder [8] LCD Module Assembly (S-9) (S-12) [5] Power (S-10) Supply (S-9) [7] Inverter CBA (S-9) (S-11) (S-12) [6] Stand Holder Fig. D2 FL11.3-A_DC...
  • Page 16 To LCD Module Assembly Assembly Digital Main Power Supply CBA CBA Unit CN201 CN3902 CN301 CN3701 CN631 CN302 CN3702 CN1201 WH1001 CL701A CN1202 CN801 CN802 CN101 CL701B CN1203 To Speaker To Speaker Jack CBA Inverter CBA CL104B Function CBA Fig. D3 FL11.3-A_DC...

  • Page 17: Electrical Adjustment Instructions

    ELECTRICAL ADJUSTMENT INSTRUCTIONS General Note: “CBA” is abbreviation for How to set up the service mode: “Circuit Board Assembly.” Service mode: Note: Electrical adjustments are required after 1. Turn the power on. replacing circuit components and certain mechanical parts. It is important to perform 2.
  • Page 18 1. Purity Check Mode 2. VCOM Adjustment This mode cycles through full-screen displays of red, Test Point Adj. Point green, blue, and white to check for non-active pixels. [CH X/Y ] Screen 1. Enter the Service mode. buttons 2. Each time the [7] button on the remote control unit M.

  • Page 19: White Balance Adjustment

    The White Balance Adjustment should be 5. [CUTOFF] Press [1] button to select “COR” for Red Cutoff performed when replacing the LCD Panel adjustment. Press [3] button to select “COB” for or Digital Main CBA. Blue Cutoff adjustment. [DRIVE] 3. White Balance Adjustment Press [4] button to select “DR”...

  • Page 20: How To Initialize The Lcd Tv

    HOW TO INITIALIZE THE LCD TV The purpose of initialization is to place the set in a new out of box condition. The customer will be prompted to select a language and program channels after the set has been initialized. To put the program back at the factory-default, initialize the LCD TV using the following procedure.

  • Page 21: Firmware Renewal Mode

    FIRMWARE RENEWAL MODE Equipment Required The appearance shown in *1 is described as follows. Appearance State a. USB storage device Downloading the firmware from b. Remote Control Unit Downloading... the USB storage device. Firmware Update Procedure Writing the downloaded firmware Writing...

  • Page 22: Troubleshooting

    TROUBLESHOOTING [ Power Supply Section ] FLOW CHART NO.1 The power cannot be turned on. Is the fuse (F601) normal? See FLOW CHART No.2 <The fuse blows out.> Check if there is any leak or short-circuiting on the primary circuit component, and service it if defective. (C605, C606, D601, D602, D603, D604, Q601, Q602, T601) Is the INV+35V line voltage normal?
  • Page 23 FLOW CHART NO.6 LCD+24V is not output. FLOW CHART NO.7 LCD+13V is not output. FLOW CHART NO.8 P-ON+7V is not output. FLOW CHART NO.9 P-ON+5V is not output. (LCD+13V is outputted normally.) Replace Q641. FL11.3TR...

  • Page 24: Flow Chart No

    FLOW CHART NO.10 TUNER+5V is not output. (LCD+13V is outputted normally.) Replace Q640. FLOW CHART NO.11 AL+13V is not output. Is approximately +13V voltage supplied to the cathode of D641 and D642? FLOW CHART NO.12 P-ON+3V is not output. FLOW CHART NO.13 P-ON+3.3V is not output.

  • Page 25: Flow Chart No

    FLOW CHART NO.14 P-ON+9V is not output. (LCD+13V is outputted normally.) Replace Q642. FLOW CHART NO.15 AL+3.3V is not output. FLOW CHART NO.16 LCD-6V is not output. Replace Q211. FL11.3TR...

  • Page 26: Flow Chart No

    [ Video Signal Section ] FLOW CHART NO.1 The key operation is not functioning. Re-install the switches (SW101, SW103~SW107) correctly or replace the poor switch. Check the switches (SW101, SW103~SW107) and their periphery circuit, and service it if defective. Replace Digital Main CBA Unit. FLOW CHART NO.2 No operation is possible from the remote control unit.

  • Page 27: Flow Chart No

    FLOW CHART NO.4 Picture does not appear normally.(Tuner input) FLOW CHART NO.5 Picture does not appear normally.(S-Video input) Pin(6): S-VIDEO-C Pin(8): S-VIDEO-Y FLOW CHART NO.6 Picture does not appear normally.(Y/Pb/Pr input) Pin(15): VIDEO-Y Pin(17): VIDEO-Pb Pin(19): VIDEO-Pr FL11.3TR...
  • Page 28 [ Audio Signal Section ] FLOW CHART NO.1 Audio is not outputted normally.(Audio input) Check the line between Pin(2, 15) of IC771 and input terminal(JK753, JK754), and service it if defective. Pin(6) : AMP(L)-OUT Pin(8) : AMP(R)-OUT Pin(2) : AUDIO(L)-OUT Pin(4) : AUDIO(R)-OUT CN801: SP(L)
  • Page 29 FLOW CHART NO.2 Audio is not outputted normally.(Component Audio input) Check the line between Pin(4, 11) of IC771 and input terminal(JK741, JK742), and service it if defective. Pin(6) : AMP(L)-OUT Pin(8) : AMP(R)-OUT Pin(2) : AUDIO(L)-OUT Pin(4) : AUDIO(R)-OUT CN801: SP(L) Check SP801,SP802 and their periphery circuit, CN802: SP(R) and service it if defective.
  • Page 30 FLOW CHART NO.3 Audio is not outputted normally.(HDMI Audio input) Check the line between Pin(5, 14) of IC771 and input terminal(JK721, JK722), and service it if defective. Pin(6) : AMP(L)-OUT Pin(8) : AMP(R)-OUT Pin(2) : AUDIO(L)-OUT Pin(4) : AUDIO(R)-OUT CN801: SP(L) Check SP801,SP802 and their periphery circuit, CN802: SP(R) and service it if defective.
  • Page 31 FLOW CHART NO.4 Audio is not outputted normally.(Tuner input) Check TU301 and their periphery circuit, and service it if defective. Pin(6) : AMP(L)-OUT Pin(8) : AMP(R)-OUT Pin(2) : AUDIO(L)-OUT Pin(4) : AUDIO(R)-OUT CN801: SP(L) Check SP801,SP802 and their periphery circuit, CN802: SP(R) and service it if defective.

  • Page 32: Block Diagrams

    BLOCK DIAGRAMS 1. System Control Block Diagram FL11.3ABLS...
  • Page 33 2. Video Block Diagram FL11.3ABLV...
  • Page 34 3. Audio Block Diagram FL11.3ABLA...
  • Page 35 4. Digital Signal Process Block Diagram FL11.3ABLD...
  • Page 36 5. Inverter Block Diagram FL11.3ABLINV...
  • Page 37 6. Power Supply Block Diagram FL11.3ABLP...

  • Page 38: Schematic Diagrams / Cba And Test Points

    5. All voltages are DC voltages unless otherwise specified. 6. This schematic diagrams are masterized version that should cover the entire FL11.3 chassis models. Thus some parts in detail illustrated on this schematic diagrams may vary depend on the model within the FL11.3 chassis.
  • Page 39 LIST OF CAUTION, NOTES, AND SYMBOLS USED IN THE SCHEMATIC DIAGRAMS ON THE FOLLOWING PAGES: 1. CAUTION: CAUTION: FOR CONTINUED PROTECTION AGAINST RISK OF FIRE, REPLACE ONLY WITH SAME TYPE_A,_V FUSE. ATTENTION: UTILISER UN FUSIBLE DE RECHANGE DE MÊME TYPE DE_A,_V. 2.
  • Page 40 Power Supply 1 Schematic Diagram CAUTION ! NOTE: Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit. The voltage for parts in hot circuit is measured using CAUTION ! : For continued protection against risk of fire, If Main Fuse (F601) is blown , check to see that all components in the power supply hot GND as a common terminal.
  • Page 41 Power Supply 2 Schematic Diagram VIDEO SIGNAL AUDIO SIGNAL *Either TU301 is used for Power Supply CBA. TU301 TUNER UNIT TU301 TUNER UNIT CONTINUE POWER 1 AL+33V TUNER+5V 1 2 3 4 5 6 7 8 9 10 11 12 13 CONTINUE POWER 3 R303...
  • Page 42 Power Supply 3 & Jack Schematic Diagram POWER SUPPLY CBA BC841 BEAD C843 C844 0.01 10/16V R847 4.7K R846 C842 Q841 KTC3198-Y-AT/P R848 CONTINUE C841 R842 R844 4.7K (BUFFER) POWER 1 JK841 DIGITAL P-ON+3.3V AUDIO-OUT (COAXIAL) R841 R843 R845 P-ON+9V OPEN OPEN C771...
  • Page 43 Power Supply 4 Schematic Diagram AUDIO SIGNAL POWER SUPPLY CBA CONTINUE POWER 1 LCD+13V P-ON+3.3V LCD-6V CONTINUE LCD+24V POWER 1 PROTECT3 D422 1SS133 BACKLIGHT-SW R413 BACKLIGHT-ADJ VCOM-PWM R210 C201 C217 R218 P-ON-H1 C216 LCD-P-SAFETY 13.1 1000P INV+35V Q203 KTC3198-Y-AT/P R211 R208 (V-COM DRIVE) C210...
  • Page 44 Inverter Schematic Diagram INVERTER CBA CN1201 BACK C1201 LIGHT 10P/6.3KV D1227 BC1201 R1225 D1219 1SS133 C1023 C1024 BEAD 100K 1SS133 470/35V 470/35V R1003 R1004 R1101 T1201 C1101 C1202 C1214 R1226 OPEN 2.7K 5.1K INVERTER OPEN OPEN 1000P R1037 R1007 R1026 R1027 R1028 D1006...
  • Page 45 Function Schematic Diagram C104 R125 OPEN R124 R123 OPEN D105 D104 L-53HT 333GT/E R128 R127 3.3K STANDBY POWER RS102 KSM-712TH2E C112 C110 OPEN OPEN (REMOTE SENSOR) TO POWER SUPPLY CL104B CBA CN101 6 GND 5 REMOTE 4 AL+3.3V 3 LED1 R126 2 P-ON-H1 1 KEY-IN1...
  • Page 46 Digital Main 1 Schematic Diagram 1 NOTE: The order of pins shown in this diagram is different from that of actual IC3301. IC3301 is divided into six and shown as IC3301 (1/6) ~ IC3301 (6/6) in this Digital Main Schematic Diagram Section. CONTINUE DIGITAL 5 DIGITAL MAIN CBA UNIT...
  • Page 47 Digital Main 2 Schematic Diagram 1 NOTE: The order of pins shown in this diagram is different from that of actual IC3301. IC3301 is divided into six and shown as IC3301 (1/6) ~ IC3301 (6/6) in this Digital Main Schematic Diagram Section. CONTINUE DIGITAL 3 IC3301(2/6)
  • Page 48 Digital Main 3 Schematic Diagram 1 NOTE: The order of pins shown in this diagram is different from that of actual IC3301. IC3301 is divided into six and shown as IC3301 (1/6) ~ IC3301 (6/6) in this Digital Main Schematic Diagram Section. AUDIO SIGNAL DIGITAL MAIN CBA UNIT CONTINUE...
  • Page 49 Digital Main 4 Schematic Diagram 1 NOTE: The order of pins shown in this diagram is different from that of actual IC3301. IC3301 is divided into six and shown as IC3301 (1/6) ~ IC3301 (6/6) in this Digital Main Schematic Diagram Section. DIGITAL MAIN CBA UNIT IC3301(4/6) L3401...
  • Page 50 Digital Main 5 Schematic Diagram 1 NOTE: The order of pins shown in this diagram is different from that of actual IC3301. IC3301 is divided into six and shown as IC3301 (1/6) ~ IC3301 (6/6) in this Digital Main Schematic Diagram Section. (NO CONNECTION) CN3703 DIGITAL MAIN CBA UNIT...
  • Page 51 Digital Main 6 Schematic Diagram 1 NOTE: The order of pins shown in this diagram is different from that of actual IC3301. IC3301 is divided into six and shown as IC3301 (1/6) ~ IC3301 (6/6) in this Digital Main Schematic Diagram Section. CONTINUE L3701 HDMI-...
  • Page 52 Power Supply CBA & Jack CBA Top View Because a hot chassis ground is present in the power supply CAUTION ! CAUTION ! : For continued protection against risk of fire, circuit, an isolation transformer must be used when repairing. Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit.
  • Page 53 Power Supply CBA & Jack CBA Bottom View Because a hot chassis ground is present in the power supply CAUTION ! CAUTION ! : For continued protection against risk of fire, circuit, an isolation transformer must be used when repairing. Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit.
  • Page 54 Inverter CBA & Function CBA Top View Function CBA Not Used RS102 BA01A0F0103 2 STD BY POWER D105 D104 C7A3 R116 R115 R114 R113 R124 SW107 SW106 SW105 SW104 SW103 R125 R108 SW101 DOWN MENU R111 POWER DOWN CN1203 CN1202 CN1201 C1211 C1209...
  • Page 55 Inverter CBA & Function CBA Bottom View Function CBA Not Used RS102 POWER STD BY D105 D104 R114 R115 R116 R113 R124 SW104 SW107 SW101 R108 R125 SW103 DOWN R111 MENU POWER DOWN CN1203 CN1201 CN1202 H.V. CAUTION C1209 C1211 C1201 C1203 C1207...

  • Page 56: Waveforms

    WAVEFORMS WF1 ~ WF7 = Waveforms to be observed at Waveform check points. (Shown in Schematic Diagram.) Input: NTSC Color Bar Signal (with 1kHz Audio Signal) Pin 4 of CN302 Pin 17 of CN302 CVBS CVBS 0.2V 0.2V 20µs VIDEO-Pb VIDEO-Pb 0.2V 0.2V...

  • Page 57: Wiring Diagram

    WIRING DIAGRAM 12-1 FL11.3AWI...

  • Page 58: Exploded Views

    Digital Main CBA Unit CL3701 CL3702 CL3902 LC260EM2, LC260SS2 CL801 CL201 Jack CBA SP801 CL802 Function CBA SP802 LCD1 See Electrical Parts List for parts with this mark. Power Supply CBA AC601 Inverter CBA LC260SS2 Stand Assembly Stand Assembly 13-1 FL11.3-A_CEX...
  • Page 59 Packing Some Ref. Numbers are not in sequence. Tape Stand Assembly Fixlon Tape Packing Tape F R O Packing Tape 13-2 FL11.3PEX...

  • Page 60: Parts List

    PARTS LIST [LC260EM2 (Serial No.: DS1)] Mechanical Parts PRODUCT SAFETY NOTE: Products marked with a Ref. No. Description Part No. # have special characteristics important to safety. PACKING Before replacing any of these components, read CARTON A17A1UH 1EM434239 carefully the product safety notice in this service STYROFOAM TOP A17A1UH 1EM027565 manual.

  • Page 61: Electrical Parts

    Electrical Parts PRODUCT SAFETY NOTE: Products marked with a Ref. No. Description Part No. # have special characteristics important to safety. C602# CAP METALIZED FILM 0.47µF/300V K 3.5MM CT2F474DC004 Before replacing any of these components, read C605 CAP ELECTROLYTIC 270µF/200V CEA271DYG005 carefully the product safety notice in this service C606...
  • Page 62 Ref. No. Description Part No. Ref. No. Description Part No. C811 CHIP CERAMIC CAP .(1608) B K 0.47µF/16V CHD1CK30B474 D208 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133 C815 CHIP CERAMIC CAP . F Z 1µF/10V CHD1AZ30F105 D209 DIODE ZENER 36BSB-T26 NDTB036BST26 C816 ELECTROLYTIC CAP . 10µF/50V M H7 CE1JMASSL100 D210 DIODE ZENER 5V6BSB-T26...
  • Page 63 Ref. No. Description Part No. Ref. No. Description Part No. RES CHIP 1608 1/10W J 1k Ω R202 RRJ102RYL002 RES CARBON FILM T 1/4W J 2.0k Ω R204 RCX4202T1001 IC201 IC TL3472CDR NSZBA0TTY115 RES CHIP 1608 1/10W J 1k Ω R206 RRJ102RYL002 IC601#...
  • Page 64 Ref. No. Description Part No. Ref. No. Description Part No. RES CARBON FILM T 1/4W J 1.5k Ω RES CHIP 1608 1/10W J 10 Ω R613 RCX4152T1001 R734 RRJ100RYL002 METAL OXIDE FILM RES. 2W J 0.27 Ω RES CHIP 1608 1/10W J 10 Ω R614# RN02R27ZU001 R735...
  • Page 65 INVERTER ASSEMBLY Ref. No. Description Part No. BC301 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030 Ref. No. Description Part No. BC601 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030 INVERTER ASSEMBLY A17A1M1V-001 BC602 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030 Consists of the following: BC801 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030 INVERTER CBA A17A1M1V-001-IV FUNCTION CBA A17A1M1V-001-FN...
  • Page 66 Ref. No. Description Part No. Ref. No. Description Part No. RES CHIP 1608 1/10W J 22k Ω D1002 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133 R1015 RRJ223RYL002 RES CHIP 1608 1/10W 0 Ω D1003 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133 R1016 RRZ000RYL002 RES CHIP 1608 1/10W J 4.7k Ω D1004 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133...
  • Page 67 Ref. No. Description Part No. RES CHIP 1608 1/10W F 47.0k Ω R1227 RTW4702HH008 RES CHIP 1608 1/10W F 47.0k Ω R1228 RTW4702HH008 RES CHIP 1608 1/10W F 33.0k Ω R1229 RTW3302HH008 RES CHIP 1608 1/10W F 33.0k Ω R1230 RTW3302HH008 MISCELLANEOUS BC1201...
  • Page 68 26MF301B/F7(A17A4UH)(Serial No.: DS2) 20110322 26MF301B/F7(A17A4UH)(Serial No.: DS2) Different parts from the original model LC260EM2(DS1) Parts No. Ref. No. Description MECHANICAL PARTS FRONT CABINET A17A0UH 1EM028145 A10! RATING LABEL A17A0UH ---------- POP LABEL A17A2UH ---------- Not used THERMOSTAR TS-500(12X12X3) XK1000TYG001 LCD MODULE CMO 6BIT NORMALGRADE UJ26MXA LCD１...

  • Page 69: Revision History

    REVISION HISTORY Chassis FL11.3 • 2011-03-15 LC260EM2 (Serial No. : DS1) added • TBD LC260SS2 (Serial No.: DS1) added • TBD 26MF301B/F7 (Serial No.: DS1) added • TBD 26MF301B/F7 (Serial No.: DS2) added 15-1 FL11.3REV...
  • Page 70 COMPARISON LIST OF MODEL NAME Chassis FL11.3 LC260EM2 (DS1) A17A1UH LC260SS2 (DS1) A17A2UH 26MF301B/F7 (DS1) A17A0UH (DS2) A17A4UH FL11.3COM...
