Panasonic EVQQ7 Specification

7 mm Square SMD Stick Switches
EVQQ7
Type:
■
Features
●
External dimensions : 7.7 mm 7.7 mm, height 1.75 mm
●
Long life: One million operation times in each direction
●
Malfunction protected, Dust-proof structure, with
ground terminal
■
Explanation of Part Numbers
■
Specifi cations
Rating
Contact Resistance
Insulation Resistance
Electrical
Dielectric Withstanding Voltage
Bouncing
Operating Force
Mechanical
Travel
Leaning operation angle
Endurance Operating Life
Temperature Range
Minimum Quantity/Packing Unit
Quantity / Carton
■
Dimensions in mm (not to scale)
(φ4.4)
(φ3.6)
+0.02
2
–0.06
Ground terminal
Design and specifi cations are each subject to change without notice. Ask factory for the current technical specifi cations before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
1 2 3
E V Q Q
Product Code
Push
Leaning
Push
Leaning
(0.65)
Ground terminal
■
Rec om mend ed Applications
●
Operation switches for menu scrolling and confi rmation
for portable electronic equipment
(Mobile phones, Digital cameras, and PDAs)
4 5 6 7
7
Type Design No.
10 µA 2 Vdc to 20 mA 15 Vdc (Resistive load)
1000 pcs. Embossed Taping (Reel Pack)
Ground terminal
PWB land pattern for reference
– ES63 –
Multi Function Switches/EVQQ7
8 9
100 m max.
50 M min.
250 Vac min.
10 ms max.
20 ms max.
✽
2.6 N
✽
1.3 N
0.15 mm±0.1 mm
5 ° ± 2.5 °
1000000 cycles min.
–40 °C to +85 °C
5000 pcs.
✽ Operation force: Meets respective requirement
Com.
A
Ground terminal
Non patern area
C
Com.
D
E
Com.
B
Circuit diagram
00 Sep. 2010
