QUICK SET UP GUIDE
1
STEP
Locating the components
DVD Audio/Video Player
(SL-HDA800)
Stereo Cassette Deck
(RS-HDA800)
To stack the components vertically, refer to page 7 of the operating
instructions.
2
STEP
Flat
cables
EB
SC-HDA800
Stereo Tuner
(ST-HDA800)
Integrated Amplifier
(SE-HDA800)
Disconnecting
White
line
For operation and other details with regard to each
component, please refer to the operating instructions.
Check and identify the accessories shown at
the top of steps 3 to 5 before connection.
Placement of speakers
Center speaker
Front speaker (L)
(SB-PS800)
(SB-HDA800)
TV (not included)
Surround speaker
(SB-PS800)
Center and Surround speakers are exactly the same.
Front speaker (R)
(SB-HDA800)
Superwoofers
facing out
Subwoofer
(not included)
Surround speaker
(SB-PS800)
