Panasonic WV-NP240 Specifications

MPEG-4 & JPEG Dual Stream. Plus, PoE (Power over Ethernet) for Easy Installation.
Panasonic introduces the new WV-NP240 Series network
camera that is both MPEG-4 and JPEG dual stream compatible.
MPEG-4 makes viewing video smooth and seamless, and is
multicast/unicast switchable to fit your application. When
using JPEG, 640 x 480 (VGA) images can be transmitted at
up to 30 fps. Plus, with progressive scan in both MPEG-4 and
JPEG modes, images of moving subjects are captured in high
fidelity. With the optional F1.2 lens, these cameras operate in
lighting as low as 1.1 lux. In addition electronic sensitivity
can be increased up to 16 times, while a 3x digital zoom
allows you to view subjects' up-close. A built-in high
sensitivity microphone with on/off functionality provides
clear audio capabilities.
The WV-NP240 Series is equipped with PoE (Power over
Ethernet) IEEE802.3af, allowing power and signals to be
transmitted over the same cable, thus eliminating the need to
install a separate power source for each camera. This feature
makes installation as simple as plugging the cable into the
HUB. Using the multi screen display mode, up to 8 cameras
can be monitored from a single browser. The digital motion
detector feature transmits an alarm signal when moving
subjects enter the scene. When combined with the optional
Network Disk Recorder; WJ-ND300, these cameras make it
incredibly easy to construct an automatic video surveillance
system. Plus, the SD memory card slot allows you to back up
images on an SD memory card in case of network failure.
Network Security Colour Cameras
WV-NP240 Series
So handy and so reliable, the WV-NP240 Series is ideal for
an endless variety of networked surveillance applications.
KEY FEATURES
•
Built-in MPEG-4 and JPEG digital signal output at VGA image size
with up to 30 fps.
•
Also MPEG-4/JPEG dual stream output for simultaneous live
monitoring and high resolution recording.
•
Power over Ethernet (PoE) IEEE 802.3af.
•
Progressive scan type CCD image sensor.
•
Internet Protocol: TCP/IP, UDP/IP, HTTP, FTP, SMTP, DHCP, DNS,
DDNS, NTP and SNMP.
•
Image refresh rate: 0.1 fps - 30 fps
•
Bandwidth control: 64 / 128 / 256 / 512 / 1,024 / 2,048 / 4,096 kbps and unlimited.
•
Built-in network interface (10Base-T / 100Base-TX) for remote monitoring by PC.
•
Sensitivity of 1.1 lux at F1.2 optional lens.
•
Built-in SD Memory card slot for FTP backup.
•
Multi screen display (4 screens x 2 groups).
•
Built-in Alarm function for external security devices.
•
Built-in digital motion detector.
•
Built-in electronic zoom function (1x, 1.5x, 2x, 2.5x and 3x).
•
Automatic electronic sensitivity enhancement.
•
Built-in microphone (G.726).
1/3-type Variable Focal Lenses (optional)
WV-LZA61/2S
(3.8 - 8 mm)
Lens : optional
(See the Frame Rate Chart for details).
WV-LZ62/8S
(5 - 40 mm)
