Yamaha RX-V779 Supplement Manual

Remote control functions
1
2 SOURCE RECEIVER
HDMI
1 2 3 4
5
V-AUX
AV
3
1 2 3 4
5 6 AUDIO TUNER
BLUETOOTH USB NET PHONO
PARTY HDMI OUT
MAIN ZONE 2
4
SCENE
5
BD
TV NET RADIO
DVD
6
PROGRAM MUTE VOLUME
7
TOP MENU POP-UP/MENU
8
ON
OPTION
SCREEN
9
ENTER
RETURN DISPLAY
BAND
:
MODE
A
TUNING PRESET
B SUR. DECODE STRAIGHT
MOVIE MUSIC
ENHANCER PURE DIRECT
C
INFO SLEEP
D
1 2 3 4
E
5 6 7 8
MEMORY
9 0 10 ENT
TV
F INPUT
TV VOL TV CH
MUTE CODE SET
1
Remote control signal transmitter
Transmits infrared signals.
SOURCE z key
2
Turns on/off an external device.
SOURCE key
Sets the remote control to operate external devices (p.3).
This key lights up in green after pressed.
RECEIVER key
Sets the remote control to operate the unit (p.3). This key
lights up in orange after pressed.
RECEIVER z key
Turns on/off (standby) the unit.
G
3
Input selection keys
H
Select an input source for playback.
4
MAIN/ZONE2 switch
Changes the zone (main zone or Zone2) that is controlled by
the remote control.
I
5
SCENE keys
J Select the registered input source, sound program, and
various settings with one touch. Also, turns on the unit when
it is in standby mode.
K
6
PROGRAM keys
Select a sound program.
7
External device operation keys
L
Select menus for external devices.
8
ON SCREEN key
Displays the on-screen menu on the TV.
9
Menu operation keys
Cursor keys Select a menu or a parameter.
ENTER Confirms a selected item.
RETURN Returns to the previous screen.
0
MODE key
Switches the iPod operation modes.
A
Radio keys
Operate the FM/AM radio when "TUNER" is selected as the
M
input source.
BAND Switches between FM and AM radio.
PRESET Select a preset station.
TUNING Select the radio frequency.
Supplement for Remote Control
External device operation keys
Let you play back and perform other operations for external
devices when an input source other than "TUNER" is
selected.
B
Sound mode keys
Select a sound mode.
C
INFO key
Selects the information displayed on the front display.
D
SLEEP key
Switches the unit to standby mode automatically after a
specified period of time has elapsed (sleep timer). Press
repeatedly to set the time (120 min, 90 min, 60 min, 30 min, off).
E
Numeric keys
Let you enter numerical values, such as radio frequencies.
MEMORY key
Registers FM/AM radio stations as presets.
F
TV operation keys
Let you select TV input and volume, and perform other TV
operations.
G
HDMI OUT key
Selects HDMI OUT jacks to be used for video/audio output.
H
PARTY key
Turns on/off the party mode.
I
VOLUME keys
Adjust the volume.
J
MUTE key
Mutes the audio output.
K
OPTION key
Displays the option menu.
L
DISPLAY key
Displays status information on the TV.
M
CODE SET key
Registers remote control codes of external devices on the
remote control.
1
En
