Panasonic PT-AE1000E Remote Control Operating Manual

Panasonic PT-AE1000E Remote Control Operating Manual

Panasonic lcd projector remote control operating guide pt-ae1000e
Hide thumbs Also See for PT-AE1000E:
Table of Contents

Advertisement

Quick Links

Download this manual
Features
Multiple home theatre system devices can be
operated.
Devices such as projectors, DVD
players/recorders, video decks, TVs,
amplifiers, lighting device and electronic
screens can be operated.
Remote control signals for other home theatre
system devices can be set into this remote
control.
Remote control signals for other home theatre
system devices can be easily learnt.
Remote control signals for other home
theatre system devices can be easily
learnt for each corresponding button on
this remote control.
Device codes can be entered
You can enter device codes to register
several remote control signals all at once.
Home theatre system devices with
unknown device codes can also be set.
The search function lets you search for
device codes to use for setting.
Macro function makes operation even easier.
Using the operation macro function
A single button operation can invoke a
maximum of 16 keypresses to carry out
a total of 6 different operations for
home theatre system devices.
Using the power supply macro function
A single button operation can turn the
power supply for up to 8 different
devices on and off at the same time.
Frequently-used functions can be programmed
into function buttons.
Functions that you use often can be
assigned to function buttons, so that
these buttons can be used easily as
shortcut buttons.
Customised display of frequently-used functions on
the LCD is possible.
You can edit the characters that are used to
indicate function buttons in the LCD, and
you can also edit the device selection
This remote control can be used to carry out simple setting operations for your home theatre system in addition to operating
the projector (PT-AE1000E).
Be sure to read this Remote Control Operating Guide carefully in order to use the devices safely.
Also be sure to read the instructions for the projector and the home theatre system carefully when using the remote control.
After reading this Operating Guide, keep it in a safe place for later reference
Remote Control Operating Guide
Contents
P.3
Selecting and entering device codes
Equipment code list
Learning remote control signals directly from home
theatre system devices
P.6
do not know the device code
P.7
Deleting button functions one by one
P.8
P.10
Setting the power supply macro function
P.12
Editing the function button characters on the LCD
P.13
Do not use the remote control to operate any other
equipment apart from your home theatre system.
It may not be possible to operate some devices using
P.14
this remote control.
LCD P rojector
PT-AE1000E
Model No.
(DELETE)
R
２
３
５
９
TQBJ0211

Advertisement

Table of Contents
loading

Related Manuals for Panasonic PT-AE1000E

Summary of Contents for Panasonic PT-AE1000E

  • Page 1: Table Of Contents

    This remote control can be used to carry out simple setting operations for your home theatre system in addition to operating the projector (PT-AE1000E). Be sure to read this Remote Control Operating Guide carefully in order to use the devices safely.

  • Page 2: Display

    Names and functions of each part Buttons shown in this colour are buttons that can be used for learnt functions. Buttons that cannot be used for learnt functions Buttons that cannot be used for learnt functions when using a projector (PJ) If you press any of the buttons marked as Remote control emitter Projector function only...

  • Page 3: Operation Quick Guide

    (Example: When playback is selected) Note: At the time of purchase, the remote control is programmed with remote control signals for Panasonic products. If the devices you are using cannot be operated by using the default settings, refer to “Setting remote control signals for home theatre systems”...
  • Page 4 4 - E NGLISH Equipment code list Manufacturer Manufacturer Equipment code name name <CBL> Cable Converter <DVD> DVD/DVD-R Panasonic 0490, 0503, 0703, 1010, Panasonic 1011, 1362, 1462, 1490, 1762, 1834, 1908 Fujitsu DENON 0490, 1634 0522, 0717 Motorola HITACHI...

  • Page 5: Learning Remote Control Signals Directly From Home

    Setting remote control signals for home theatre systems This remote control is programmed with remote control signals for Panasonic products at the time of purchase. If you would like to operate devices from other manufacturers, or if your Panasonic products cannot be operated, the following setting operations will be required.
  • Page 6 Setting remote control signals for home theatre systems Learning remote control signals directly from home theatre system devices Operations can be learnt for buttons one by one. Note: Remote control signals that are not infrared-type (wave format) signals cannot be recorded. It may not be possible to record some types of signal.
  • Page 7 Selecting and entering device codes You can have all remote control signals for a home theatre system device learnt all at once by entering the device code for that device. Note: For device codes which have a remote control signal for controlling the power supply, the remote control signal for the power supply will be transmitted when the device code is selected.
  • Page 8 Setting remote control signals for home theatre systems Setting home theatre system devices when you do not know the device code When recording remote control signals for a home theatre system device when you do not know the device code for that device, you canuse the search function to make the settings. Turn the power on for the home theatre system device that you would like to set.

  • Page 9: Deleting Home Theatre Equipment Remote Control Signals

    Deleting home theatre equipment remote control signals You can use one of two methods to delete remote control signals that have been learnt, either by deleting the settings one by one (DELETE) or by deleting all of the settings at once (OPS RESET). Deleting settings for each button one by one (DELETE) Press "DEVICE", use the tilt button to...

  • Page 10: Operating Home Theatre System Devices With A Single Button Press (Operation Macro Function)

    Operating home theatre system devices with a single button press (operation macro function) You can assign a sequence of up to 16 keypresses for a total of 6 different home theatre system operations which have been programmed into this remote control to a single button, so that these operations can be carried out all at once.

  • Page 11: Using The Operation Macro Function

    Using the operation macro function Note: If the distance between the remote control and the home theatre equipment being operated is too far, or if the remote control receivers of the home theatre system devices are obstructed, the home theatre system devices may not work correctly.

  • Page 12: Turning The Power For Home Theatre System Devices On And Off At Once (Power Supply Macro Function)

    Turning the power for home theatre system devices on and off at once (power supply macro function) You can use the projector's remote control to turn the power on and off for home theatre system devices that have been registered by the remote control. Note: At the time of purchase, a macro for turning the power on and off for PJ, DVD, VCR and AMP all at once is set.

  • Page 13: Using The Function Buttons

    Using the function buttons Function buttons [1], [2] and [3] can be used as quick shortcut buttons by assigning operations that are frequently used to them. Setting method -Use the projector's menu to make the settings Press "MENU" on either the remote control or the projector's operation panel.

  • Page 14: Editing Displays On The Lcd

    Editing displays on the LCD When remote control signals for a home theatre system device have been learnt for the USER 1-3 function buttons, you can change the "-A-, -B-, - C-" displays on the LCD to your preferred displays. List of characters that can be displayed List of characters that can be displayed Upper-case letters: A-Z...

  • Page 15: Appendices

    Appendices LCD display list Selected device displays Corresponding device Selected device display Projector (PT-AE1000E) DVD player/DVD recorder Video deck TV/TNR TV/Cable converter/Satellite receiver Audio amplifier/Receiver DVD, VCR, TV/TNR, AMP, other device ( May include USER1/2/3 devices that cannot be learnt)

  • Page 16: Remote Control Function List

    Appendices Remote control function list - ： No signals are sent in the corresponding mode. Selected device Device code at time of shipment POWER (PROJECTOR) POWER (SYSTEM) LIGHT Backlight Function A Function B Function C LEARN Learn システム 機器 SETUP Setup DVD Channel + Channel +...
