Page 3 Your Mercedes-Benz represents the efforts of many skilled engineers and craftsmen. To ensure your pleasure of ownership, and for your safety and that of your passengers, we ask you to make a small investment of your time: •...
Page 4: Table Of Contents
Introduction Choosing global or selective Heated seats ........52 mode on remote control ..... 33 Rear seat head restraints ....53 Product information ......7 Opening and closing windows Seat belts and integrated Operator’s manual ......8 and sliding / pop-up roof restraint system ......56 Where to find it ........
Page 5 Contents Trip and main odometer Rear window wiper / washer ..146 Manual tuning ........ 168 and sub menu ......100 Hazard warning flasher Seek tuning ........168 Audio systems ........ 102 switch ......... 147 Scan tuning ........168 Radio ..........102 Automatic climate control ....
Page 6 General notes on CD mode ... 174 Searching and selecting Interior ..........194 phone book entries CD changer installed ..... 175 Storage compartments by number ........180 and armrests ......194 Loading/emptying Placing a call ........180 the CD magazine ....... 175 Glove box ........
Page 7 Contents Driving Snow chains ....... 259 Supplemental restraint system (SRS) indicator lamp ....281 Winter driving Control and operation of instructions ........ 260 Fuel reserve warning ....282 radio transmitters .....226 Deep water ........262 ABS malfunction The first 1 000 miles indicator lamp ......283 Passenger compartment ...
Page 8 ELEC. STABIL. PROG. Practical hints Spare wheel ........323 (Electronic stability program) ..292 Spare wheel bolts .......323 First aid kit ........306 COOLANT Changing wheels ......324 Stowing things in the vehicle ..307 (coolant level) ......293 Tire inflation pressure ....329 Fuses ..........307 COOLANT Battery ..........330 (coolant temperature) ....294...
Page 9 Contents Vehicle care Leather upholstery ....359 Index Hard plastic trim items ..... 359 Cleaning and care of the vehicle .354 Index ..........376 Plastic and rubber parts ... 359 Power washer ......355 Tar stains ........355 Technical data Paintwork, painted body Spare parts service .......
Page 10: Introduction
Use of such parts and accessories could adversely affect the safety, performance or reliability of your vehicle. Please do not use them. Mercedes-Benz original parts as well as conversion parts and accessories approved by us are available at your authorized Mercedes-Benz Center where you will receive comprehensive information, also on permissible technical modifications, and where proper installation will be performed.
Page 11: Operator's Manual
Ignoring them could result in damage to the vehicle or personal injury to you or others. Vehicle damage caused by failure to follow instructions is not covered by the Mercedes-Benz Limited Warranty. Your vehicle may have some or all of the equipment described in this manual. Therefore, you may find explanations for optional equipment not installed in your vehicle.
Page 12 Mercedes-Benz USA, LLC in writing of the...
Page 13 Introduction Roadside assistance The Mercedes-Benz Roadside Assistance Program provides factory trained technical help in the event of a breakdown. Calls to the toll-free Roadside Assistance number: 1-800-FOR-MERCedes (in the USA) 1-800-387-0100 (in Canada) will be answered by Mercedes-Benz Customer Assistance Representatives 24 hours a day, 365 days a year.
Page 14 • gasoline may have a considerably lower octane rating, and improper fuel can cause engine damage. Certain Mercedes-Benz models are available for delivery in Europe under our European Delivery Program. For details, consult your authorized Mercedes-Benz Center or write to:...
Page 15 If there are any equipment details that are not shown or described in this Operator’s Manual, your authorized Mercedes-Benz Center will be glad to inform you of correct care and operating procedures. The Operator’s Manual and Service Booklet are important documents and should be kept with the vehicle.
Page 16: Where To Find It
Where to find it The Operator’s Manual is divided into eight sections: • Instruments and controls: An overview of all the controls that can be operated from the driver’s seat. • Operation: Information on the vehicle’s equipment and its operation. •...
Page 17 If you should experience a problem with your vehicle, particularly one that you believe may affect its safe operation, we urge you to immediately contact your authorized Mercedes-Benz Center to have the problem diagnosed and corrected if required. If the matter is not handled to your...
Page 18: Reporting Safety Defects
If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign. However, NHTSA cannot become involved in individual problems between you, your dealer, or Mercedes-Benz USA, LLC.
Page 20: Instruments And Controls
Instruments and controls Instruments and controls ....18 Door control panel .......20 Overhead control panel ....21 Dashboard ........22 Center console ......24 Contents - Instruments and controls Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data...
Page 21: Instruments And Controls
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Instruments and controls Instruments and controls P68.10-2583-29...
Page 22 Door control panel, see page 20 Dashboard, see page 22 Overhead control panel, see page 21 Center console, see page 24 Instruments and controls Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data...
Page 23: Door Control Panel
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Instruments and controls Door control panel Door handle, pull to open, see page 36 Memory function (for storing seat, steering wheel and exterior rear view mirror settings), see page 89 Front seat adjustment switch, see page 46 Steering wheel adjustment switch, see page 83 Power window switch, see page 185...
Page 24: Overhead Control Panel
Overhead control panel Interior lighting, see page 191 Tele Aid cover (emergency call system), see page 228 Sliding/pop-up roof, see page 188 Hands-free microphone for Tele Aid and optional telephone with voice recognition system Rear view mirror, see page 84 Garage door opener, see page 221 Instruments and controls Instruments...
Page 25: Dashboard
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Instruments and controls Dashboard P68.10-2493-29...
Page 26 Hood lock release, see page 311 Multifunction steering wheel, see page 96 Horn (with electronic key in starter switch Parking brake pedal, see page 252 position 1 or 2) Parking brake release, see page 252 Instrument cluster, see page 92 Exterior lamp switch, see page 137 Voice recognition system switch, see separate Combination switch, see page 142...
Page 27: Center Console
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Instruments and controls Center console Left front seat heater switch, see page 52 Rear window wiper/washer, see page 146 ESP (electronic stability program) control switch, see page 270 Hazard warning flasher switch, see page 147 Central locking switch, see page 38...
Page 29 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Contents - Operation Operation Emergency unlocking Safety guidelines for the seat the tailgate ........41 belt, emergency tensioning Vehicle keys ........28 retractor and airbag ....75 Closing the tailgate ..... 42 Start lock-out ........30 Infant and child Antitheft alarm system ....
Page 30 Coolant temperature gauge ..131 Operation Audio and telephone ...161 Parcel net in front passenger footwell ..203 Flexible service system Operating safety ......161 (FSS) ..........132 Ski sack ...........203 Operating and display elements ..162 Engine oil level indicator ....135 Parcel net in trunk ......208 Button and soft key operation ..164 Engine oil consumption ....
Page 31: Vehicle Keys
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Central locking system Vehicle keys Warning! Included with your vehicle are 2 electronic keys with When leaving the vehicle always remove the integrated radio frequency and infrared remote controls electronic key from the starter switch, and lock plus removable mechanical key.
Page 32 The mechanical key (2) works only in the driver’s door, system requiring a special key manufacturing process. tailgate, and glove box lock. For security reasons, replacement keys can only be obtained from your authorized Mercedes-Benz Center. Central locking system Instruments Instrument...
Page 33: Start Lock-Out
Contact an switch. There could be a slight delay until the authorized Mercedes-Benz Center or call 1-800-FOR- electronic key can be turned in the starter switch. MERCedes (in the USA), or 1-800-387-0100 (in Canada).
Page 34: Central Locking System
Central locking system Radio frequency and infrared remote control The electronic key has an integrated radio frequency and infrared remote control. Due to the extended operational range of the remote control, it could be possible to unintentionally lock or unlock the vehicle by pressing the transmit button. If one of the transmit buttons is pressed, the battery check lamp lights up briefly –...
Page 35 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Central locking system P80.30-2139-26 P80.30-2140-26 Infrared receiver in driver’s door handle Infrared receiver in front passenger door handle...
Page 36: Locking And Unlocking
Locking and unlocking with remote control If within 40 seconds of unlocking with the remote control, neither door or tailgate is opened, the electronic key is not inserted in the starter switch, or the central Unlocking: locking switch is not activated, the vehicle will Press transmit button Œ.
Page 37: Opening And Closing Windows And Sliding / Pop-Up Roof From Outside
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Central locking system Opening and closing windows and To interrupt closing procedure, release transmit button. sliding/pop-up roof from outside Ensure that all side windows and the sliding/pop-up (summer opening/convenience feature) roof are properly closed before leaving the vehicle.
Page 38: Panic Button
Panic button Note: For operation in the USA only: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 39: Doors
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Central locking system Doors Opening – pull handle Individual door from inside: Push lock button down to lock. Unlocking driver’s door Front door from inside: Locking driver’s door Pull handle to unlock.
Page 40 If the vehicle has previously been locked from the To unlock, pull inside door handles or turn mechanical outside, opening a door from the inside will trigger the key in driver’s door lock to position 2. alarm. When opening a front door while the central Rear doors can only be opened from inside by first locking system is in the: pulling up the door lock button.
Page 41: Central Locking Switch
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Central locking system Central locking switch If the vehicle was previously locked with the central locking switch, while in the global remote control mode, the complete vehicle is unlocked when a door is opened from the inside.
Page 42: Automatic Central Locking
Automatic central locking Important! With the automatic central locking system activated, the When towing the vehicle, or with the vehicle on a doors and tailgate are locked at vehicle speeds of dynamometer test stand, please, note the following: approximately 9 mph (15 km/h) or more. The fuel filler With the automatic central locking activated and the flap remains unlocked.
Page 43: Tailgate
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Central locking system Tailgate Opening the tailgate The handle is located above the rear license plate recess. The tailgate can be opened if the vehicle was previously centrally unlocked.
Page 44: Emergency Unlocking The Tailgate
Emergency unlocking the tailgate In case of a malfunction in the central locking system the locked tailgate can be unlocked individually. To unlock, turn mechanical key in lock to position 1, hold and pull handle to open. When opening the tailgate completely, always make sure that there is sufficient overhead clearance.
Page 45: Closing The Tailgate
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Central locking system Closing the tailgate Warning! To prevent possible personal injury, always keep hands and fingers away from the tailgate opening when closing the tailgate. Be especially careful when small children are around.
Page 46: Antitheft Alarm System
Antitheft alarm system Operation: Once the alarm system has been armed, the exterior vehicle lamps will flash and an alarm will sound when someone: • opens a door, • opens the tailgate, • opens the hood, • attempts to raise the vehicle. The alarm will last approximately 3 minutes in form of flashing exterior lamps.
Page 47: Tow-Away Alarm
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Tow-away alarm Tow-away alarm The alarm will last approximately 3 minutes in form of flashing exterior lamps. At the same time an alarm will sound for 30 seconds. The alarm will stay on even if the vehicle is immediately lowered.
Page 48: Easy-Entry/Exit Feature
Easy-entry/exit feature Warning! (only vehicles with memory function) You must ensure that no one can become trapped With the easy-entry/exit feature activated, the steering or injured by the moving steering wheel when the wheel tilts upwards and the driver’s seat moves easy-entry/exit feature is activated and the driver’s door is being opened or the electronic key rearwards.
Page 49: Front Seat Adjustment
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Seats Front seat adjustment When leaving the vehicle always remove the electronic key from the starter switch, and lock your vehicle. Warning! The power seats can also be operated with the Do not adjust the driver’s seat while driving.
Page 50 Power seat Seat adjustment, fore/aft Press the switch (fore/aft direction) until a comfortable seating position is reached that still allows you to reach the accelerator/brake pedal safely. The position should be as far rearward as possible, consistent with ability to properly operate controls.
Page 51 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Seats Storing seat positions: The head restraint, steering wheel and exterior rear view mirror position are stored together with the seat position. See page 89 for notes on the memory function. For recalling a stored seat/head restraint/steering wheel/ and exterior rear view mirror position see page 90.
Page 52 Prior to operating the vehicle, the driver should check Children 12 years old and under must never ride in and adjust if necessary the seat height, seat position the front seat, except in a Mercedes-Benz authorized BabySmart compatible child seat,...
Page 53: Removal And Installation Of Front Seat Head Restraints
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Seats Removal and installation of front seat head Note: restraints Tilt the backrest rearward for easier removal and installation of the head restraints. Power seat To remove: Press switch (1) upwards and hold until the head restraint is fully extended.
Page 54: Multicontour Seat
Multicontour seat (optional) Some models may be equipped with driver’s multicontour seat. These seats have movable seat cushions and inflatable air cushions built into the backrest to provide additional lumbar and side support. The seat cushion movement and amount of backrest cushion height and curvature can be continuously varied with regulators (1, 2 and 3) after turning the electronic key in starter switch to position 2.
Page 55: Heated Seats
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Seats Heated seats (optional) Press switch to turn on seat heater: Normal seat heating mode. One indicator lamp in the switch lights up. Rapid seat heating mode. Both indicator lamps in the switch light up.
Page 56: Rear Seat Head Restraints
Note: Rear seat head restraints When in operation, the seat heater consumes a large amount of electrical power. It is not advisable to use the seat heater longer than necessary. The seat heaters may automatically switch off if too many power consumers are switched on at the same time, or if the battery charge is low.
Page 57 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Seats Place head restraints upright Important! For safety reasons, always drive with the rear head restraints in the upright position when the rear seats are occupied. Keep the area around head restraints clear of articles (e.g.
Page 58 Head restraint height Raising: Pull up on head restraint. Lowering: Push button (2) and push down on head restraint. Adjust head restraint to support the back of the head approximately at ear level. The head restraint inclination can also be adjusted manually. Note: The center rear seat head restraint cannot be adjusted or removed.
Page 59: Seat Belts And Integrated Restraint System
Your vehicle is equipped with seat belts for all seats, Children 12 years old and under must never ride in emergency tensioning retractors for all outboard seat the front seat, except in a Mercedes-Benz belts, dual front airbags, door mounted side impact authorized BabySmart...
Page 60: Seat Belt Nonusage Warning System
Seat belt nonusage warning system Warning! With the electronic key in starter switch position 2, a Never ride in a moving vehicle with the backrest warning sounds for a short time if the driver’s seat belt reclined. Sitting in an excessively reclined position can be dangerous.
Page 61 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Restraint systems Warning! Warning! Failure to wear and properly fasten and position Never let more people ride in the vehicle than there your seat belt greatly increases your risk of are seat belts available.
Page 62 Fastening seat belts The lap belt should be positioned as low as possible on your hips and not across the abdomen. Warning! Always fasten your seat belt before driving off. Always make sure your passengers are properly restrained – even those sitting in the rear. Tighten the lap portion to a snug fit by pulling shoulder portion up.
Page 63 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Restraint systems Seatbelt height adjustment - front seats: Button for Seatbelt height adjustment - rear seats, left and belt outlet height adjustment right: Button for belt outlet height adjustment. There are four separate positions.
Page 64 Operation of seat belts Warning! The inertia reel stops the belt from unwinding during USE SEAT BELTS PROPERLY. sudden stops or when quickly pulling on the belt. • Seat belts can only work when used properly. The locking function of the reel may be checked by Never wear seat belts in any other way than as quickly pulling out the belt.
Page 65 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Restraint systems • Never wear the shoulder belt under your arm, • Pregnant women should also use a lap- against your neck or off your shoulder. In a shoulder belt.
Page 66 A booster seat may be necessary to achieve Children 12 years old and under must never ride in proper belt positioning. the front seat, except in a Mercedes-Benz authorized BabySmart compatible child seat, which operates with the BabySmart...
Page 67: Babysmart Tm Airbag Deactivation System
The BabySmart airbag deactivation system will for use with the Mercedes-Benz system and available at ONLY work with a special child seat designed to any authorized Mercedes-Benz Center are required for operate with it. It will not work with child seats which are not BabySmart compatible.
Page 68: Supplemental Restraint System (Srs)
Supplemental Restraint System (SRS) Seat belt fastened Airbags are intended as a supplement to seat belts. • first threshold exceeded: ETR activates Airbags alone cannot protect as well as airbags plus • second threshold exceeded: airbag also activates seat belts in impacts for which the airbags were designed to operate, and do not afford any protection Seat belt not fastened whatsoever in crashes for which the airbags are not...
Page 69: Emergency Tensioning Retractor (Etr)
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Restraint systems Emergency tensioning retractor (ETR) They remove slack from the belts in such a way that the seat belts fit more snugly against the body restricting its The seat belts for the front and rear outer seats are forward movement as much as possible.
Page 70: Airbags
Airbags Driver airbag Front airbags Front passenger airbag The most effective occupant restraint system yet developed for use in production vehicles is the seat belt. In some cases, however, the protective effect of a seat belt can be further enhanced by an airbag. In conjunction with wearing the seat belts, the driver and front passenger airbags can provide increased protection for the driver and front passenger in certain...
Page 71 For your safety, we strongly recommend that you visit an authorized undergo a self-check: crash-sensor(s), airbag ignition Mercedes-Benz Center immediately to have the circuits, front seat belt buckles, emergency tensioning system checked; otherwise the “SRS” may not be retractors, seat sensor.
Page 72 The driver and passenger front airbags are designed to Note: activate only in certain frontal impacts exceeding a The front passenger airbag deploys only if the front preset threshold. passenger seat is occupied and the ü indicator lamp in the center console is not illuminated. Heavy objects on the front passenger seat can appear to the “SRS”...
Page 73 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Restraint systems Side impact airbags, window curtain airbags The side impact airbag for the front passenger deploys only if the front passenger seat is occupied. Side impact airbags operate best in conjunction with a properly positioned and fastened seat belt.
Page 74 Important! Warning! Airbags are designed to activate only in certain Airbags are designed to reduce the potential of frontal (front airbags) impacts, or side (side impact injury in certain frontal (front airbags) impacts, or side (side impact and head protection window and head protection window curtain airbags) curtain airbags) impacts which may cause impacts which exceed preset thresholds.
Page 75 Mercedes-Benz Center. passenger to always be in a properly seated • Do not lean with your head or chest close to the position and to wear your seat belt.
Page 76 BabySmart will not, however, turn Mercedes-Benz authorized Baby Smart off the vehicle’s side impact airbag. compatible child seat, which operates with the It should be noted that with respect to both front...
Page 77 This could result in serious accomplished upon your written election to do so at injuries or death should the side airbag be your authorized Mercedes-Benz Center at an activated; (2) always sit upright, properly use the additional cost. Please contact your local...
Page 78: Safety Guidelines For The Seat Belt, Emergency Tensioning Retractor And Airbag
Use only belts installed or supplied by an electronic equipment on or near “SRS” authorized Mercedes-Benz Center. components and wiring. Keep area between • Airbags and “ETR’s” are designed to function airbags and occupants free from objects (e.g.
Page 79 • In addition, through improper work there is a an “SRS” by alerting them to the applicable section in risk of rendering the “SRS” inoperative or the Operator’s Manual. causing unintended airbag deployment. Work on the “SRS” must therefore only be performed by an authorized Mercedes-Benz Center.
Page 80: Infant And Child Restraint Systems
Infant and child restraint systems Important! We recommend all infants and children be properly The use of infant or child restraints is required by law in restrained at all times while the vehicle is in motion. All all 50 states and all Canadian provinces. lap-shoulder belts except the driver seat belt have Infants and small children should be seated in an special seat belt retractors for secure fastening of child...
Page 81 During an Children 12 years old and under must never ride in accident, they could be crushed between the the front seat, except in a Mercedes-Benz occupant and seat belt. authorized BabySmart compatible child seat,...
Page 82 Installation of infant and child restraint systems Prior to installing a tether strap, note the following steps: 1. Roll up retractable luggage cover and partition net, see page 210. 2. Fold backrest forward (page 213), guide tether strap through head restraints. Be carefully that the tether strap is not twisted.
Page 83 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Restraint systems To secure a tether strap to the anchorage, securely fasten the hook (3), which is part of the tether strap, to the anchorage ring (2). For safety, please make sure that the hook has attached to the ring beyond the safety catch, as illustrated.
Page 84 Child seat mounts - “LATCH” type To install a “LATCH” type child seat, the mounts (1) must be folded forward until they lock in place. To do so, grip inner side of mounts and fold forward. Install child seat according to the manufacturer’s instructions. The child seat must be firmly attached in the right and left side mounting fittings (1).
Page 85 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Restraint systems Warning! Damaged or impact damaged child seats or child seat mounting fittings must be replaced. The “LATCH” mounting fittings are intended for children up to 50 lbs (22 kg) in weight. Do not leave children unattended in the vehicle, even if the children are secured in a child restraint Children too big for child restraint systems must...
Page 86: Steering Wheel Adjustment (Electrical)
Steering wheel adjustment (electrical) Warning! Do not adjust the steering wheel while driving. Adjusting the steering wheel while driving could cause the driver to lose the control of the vehicle. When leaving the vehicle always remove the electronic key from the starter switch and lock your vehicle.
Page 87: Rear View Mirrors
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Rear view mirrors Rear view mirrors Note: The automatic antiglare function does not react, if incoming light is not aimed directly at sensors in the Inside rear view mirror mirror.
Page 88 Exterior rear view mirrors Exterior rear view mirror adjustment Turn the electronic key in starter switch to position 1 or 2. Push button to select mirror to be adjusted: Driver’s side – Push button (1). Passenger side – Push button (2). Push the adjustment button (3) up, down, left or right according to the setting desired.
Page 89 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Rear view mirrors Parking position exterior rear view mirror Note: (only vehicles with memory function) For activating the mirror adjustment, see under individual setting menu “CONVENIENCE” – “MIRROR The passenger side exterior mirror can be adjusted and SETTING WHEN PARKING”, on page 128.
Page 90 To store passenger mirror parking position: Note: One stored parking position is available for each of the 1. The vehicle must be stationary. two electronic keys. Turn the electronic key in starter switch to This is only possible if you select “ON” in the menu position 1 or 2.
Page 91 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Rear view mirrors Driver’s side exterior rear view mirror, Warning! antiglare mode In the case of an accident liquid electrolyte may With the electronic key in starter switch position 2, the escape the mirror housing when the mirror glass breaks.
Page 92 Memory function Warning! Do not activate the memory function while driving. Activating the memory function while driving could cause the driver to lose control of the vehicle. Together with the driver’s seat position you can store the positions for steering wheel and exterior rear view mirrors.
Page 93 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Memory function Storing positions into memory: Recalling positions from memory: With the electronic key in starter switch position 1 or 2 To recall a seat /steering wheel/exterior rear view or with the relevant door open and the electronic key mirror position, turn button (2) to selected memory inserted in the starter switch.
Page 94 Prior to operating the vehicle, the driver should check Children 12 years old and under must never ride in and adjust if necessary the seat height, seat position the front seat, except in a Mercedes-Benz authorized BabySmart compatible child seat,...
Page 95: Instrument Cluster
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Instrument cluster Instrument cluster...
Page 96 Knob for instrument cluster illumination, Indicator lamp without function. It illuminates with see page 94 the electronic key in starter switch position 2. It Reset knob for trip odometer, see page 95 and should go out when the engine is running. individual settings, see page 115 Multifunction display, see page 96.
Page 97 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Instrument cluster Activating instrument cluster display Display illumination, changing basic settings for driving at dusk or in darkness: The instrument cluster is activated by: Rotate adjusting knob (1) clockwise – instrument lamp •...
Page 98 (e.g. bank signs etc.). engine damage that is not covered by the Adaption to ambient temperature takes place in steps Mercedes-Benz Limited Warranty. and depends on the prevailing driving conditions (stop- To help protect the engine, the fuel supply is interrupted and-go or moderate, constant driving) and amount of if the engine is operated within the red marking.
Page 99: Multifunction Steering Wheel, Multifunction Display
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display Multifunction steering wheel, multifunction display P54.30-4452-29...
Page 100 Depending on your vehicle’s equipment, you may use Navigation system, see page 110 the buttons on the multifunction steering wheel to call Malfunction message memory, see page 113 up, control and set the following systems in the multifunction display: Individual settings, see page 115 Trip computer, see page 111 Trip odometer and main odometer, see page 95 and page 100...
Page 101 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display Note: Warning! The displays in the multifunction display can be set to A driver’s attention to the road must always be his/ German, English, French, Italian or Spanish language.
Page 102 Press button: è for next system ÿ for previous system j for next display in system k for previous display in system æ to increase the volume, see page 130 ç to decrease the volume, see page 130 í to dial a telephone number, see page 105 ì...
Page 103: Trip And Main Odometer And Sub Menu
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display Trip and main odometer and sub menu P54.30-4453-29...
Page 104 Press è or ÿ button repeatedly until the trip Trip odometer and main odometer See page 95 for instructions on resetting the trip odometer and main odometer display (1) appears. odometer. Press the j or k button repeatedly until the required display (2, 3, 4, 5, 1) appears.
Page 105: Audio Systems
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display Audio systems Audio system is switched off. Radio The radio is switched on. Wave band setting and memory location number, where appropriate.
Page 106: Cd Player
CD player Radio system is switched off. The CD player is switched on. The number of the CD currently playing is displayed if you are using a CD changer. Track number. “TITLE” appears on vehicles with COMAND system. “TRACK” appears on vehicles with audio system. The radio must be switched on.
Page 107: Cassette Player
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display Cassette player Audio system is switched off. The cassette player is switched on. Side being played. The radio must be switched on. The cassette player must be switched on.
Page 108: Telephone
Telephone The telephone is switched off. Telephone book The vehicle is currently outside the transmitter or receiver range. The telephone is ready for use. Name selected from the telephone book. Number for the name selected. The dialing commences. Dialing is completed. The name is displayed. The display remains for the duration of the call.
Page 109 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display Press the í button when the name you require The telephone must be switched on. appears in the display (4). The telephone number (5) is Press the è...
Page 110 Redialing The telephone is ready for use. Number or name stored in the redial memory. Number in the redial memory — redialing has commenced. Dialing is completed and the name stored in the telephone book is displayed or the number dialed will remain displayed if no name has been store.
Page 111 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display Press the í button when the required number or The telephone must be switched on. name appears in the display (2). Press the è...
Page 112 Press the í button to answer the call. Incoming call Press the ì button to hang up or if you do not wish to answer the incoming call. The telephone must be switched on. “CALL” — you are being called. Signal strength: Vehicles with audio system (in top right corner): the higher the number, the stronger the phone...
Page 113: Navigation System
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display Navigation system The navigation system is switched off. The navigation system is switched on but no destination has been specified. The navigation system is switched on and destination guidance is active.
Page 114: Trip Computer
Trip computer “AFTER START” — short distance memory “AFTER RESET” — long distance memory Estimated range remaining Distance covered “AFTER START” or “AFTER RESET” Elapsed time “AFTER START” or “AFTER RESET” Average speed “AFTER START” or “AFTER RESET” Average fuel consumption “AFTER START” or “AFTER RESET”...
Page 115 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display To reset the short “AFTER START” (1) or long Note: “AFTER RESET” distance memory (2): The “AFTER START” trip odometer reading is Call up the relevant display (1 or 2) using the j or automatically reset after four hours of electronic key not k button and press the reset knob on the instrument...
Page 116: Malfunction/Warning Message Memory
Malfunction/warning message memory There are no messages stored in the system. Number of messages stored in the system. There are messages stored in the system. Press the è or ÿ button repeatedly until the message memory (1 or 2) is displayed. Press the j or k button if display (2) appears.
Page 117 Mercedes-Benz Center to address the malfunction and warning messages. See page 285, for malfunction and warning messages.
Page 118: Individual Settings
Individual settings Preliminary display of the individual settings. “SETTINGS” – the requested menu can be called up in this options menu: “INSTRUMENT CLUSTER”, see page 118. “LIGHTING”, see page 122. “VEHICLE”, see page 125. “CONVENIENCE”, see page 128. The four menus contain additional submenus. Individual settings can be selected in these submenus.
Page 119 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display Press the è or ÿ button repeatedly until the Note: individual setting preliminary display (1) appears. These settings may only be performed with the Press the j or k button until the setting menu electronic key in starter switch position 1 or 2.
Page 120 To return menu “SETTINGS” (2) to its factory Note: setting: For safety reasons, the individual setting “LIGHT CIRCUIT HEADLAMP MODE” in menu “LIGHTING” • Call up the individual setting preliminary cannot be reset while driving, see page 124. If an display (1) or display (2).
Page 121 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display “INSTRUMENT CLUSTER” P54.30-4455-29...
Page 122 Preliminary display of the individual settings “SELECT DISPLAY” – The selection “SPEED DISP.” respectively “OUTSIDE TEMPERATURE” is “SETTINGS” – the individual setting menu permanently displayed in the multifunction display. “INSTRUMENT CLUSTER” can be called up in this “SPEED DISP.” can be used to display, for instance, options menu.
Page 123 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display Press the è or ÿ button repeatedly until the Press the j or k button until the required individual setting preliminary display (1) appears. display (3 to 9) is displayed.
Page 124 To return menu “INSTRUMENT CLUSTER” (5 to 9) to its factory setting: • Call up one of the setting menus(3 to 9). • Press the reset knob on the instrument cluster, see page 92, for approximately 3 seconds. Display (10) will appear.
Page 125 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display “LIGHTING” P54.30-4456-29...
Page 126 Press the è or ÿ button repeatedly until the Preliminary display of the individual settings individual setting preliminary display (1) appears. “SETTINGS” – in this options menu you can call up Press the j or k button until the setting menu the individual setting menu “LIGHTING”.
Page 127 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display To return menu “LIGHTING” (3 to 6) to its factory Note: setting: For safety reasons, the individual setting “LIGHT CIRCUIT HEADLAMP MODE” in menu “LIGHTING” •...
Page 128 “VEHICLE” (audio and central locking system) P54.30-4457-29 Multifunction steering wheel, multifunction display Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data...
Page 129 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display Press the è or ÿ button repeatedly until the Preliminary display of the individual settings individual setting preliminary display (1) appears. “SETTINGS”...
Page 130 To return menu “VEHICLE” (3 and 4) to its factory setting: • Call up menu (3 or 4). • Press the reset knob on the instrument cluster (see page 92) in the instrument cluster for approximately 3 seconds. Display (5) will appear. •...
Page 131 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display “CONVENIENCE” (vehicles with memory function) P54.30-4458-29...
Page 132 Press button æ or ç until the individual setting Preliminary display of the individual settings menu “CONVENIENCE” is selected by the selection “SETTINGS” – in this options menu you can call up marker. the individual setting menu “CONVENIENCE”. Press the j or k button until the required Pressing button æ...
Page 133: Setting The Audio Volume
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Multifunction steering wheel, multifunction display To return menu “CONVENIENCE” (3 to 5) to its Setting the audio volume factory setting: You can only adjust the volume of the system currently in use.
Page 134: Coolant Temperature Gauge
The engine should not be operated with the coolant temperature above 120 ° C. Doing so may cause serious engine damage which is not covered by the Mercedes-Benz Limited Warranty. Warning! • Driving when your engine is badly overheated can cause some fluids which may have leaked into the engine compartment to catch fire.
Page 135: Flexible Service System (Fss)
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Flexible service system Flexible service system (FSS) The message is displayed for approximately 10 seconds (service indicator) when turning the electronic key in starter switch to position 2, or while driving when reaching the service warning threshold.
Page 136 FSS can be added by your Calling up service indicator manually: Mercedes-Benz Center. Turn the electronic key in starter switch to position 1 The interval between services is determined by the type or 2.
Page 137 Flexible service system Following a completed A or B service the Mercedes-Benz The multifunction display will show the question: Center sets the counter mileage to 10 000 miles “DO YOU WANT TO RESET SERVICE INTERVAL? –...
Page 138: Engine Oil Level Indicator
Engine oil level indicator • with engine not at operational temperature up to approximately 30 minutes. The engine oil level check can be repeated after a short time. Turn the electronic key in starter switch to position 2. To call up the trip odometer and main odometer, press button è...
Page 139: Engine Oil Consumption
During the break-in period, cause damage to the engine and catalytic converter not higher oil consumption may be noticed and is normal. covered by the Mercedes-Benz Limited Warranty. Frequent driving at high engine speeds results in increased consumption.
Page 140: Exterior Lamp Switch
ˆ Standing lamps, right (turn left one stop) Exterior lamp switch ‚ Standing lamps, left (turn left two stops) ‡ Front fog lamps (pull out one stop) with parking lamps and/or low beam headlamps on. Green indicator in lamp switch comes on. †...
Page 141: Headlamp Mode
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Exterior lamp switch Headlamp mode Automatic headlamp mode Turn exterior lamp switch to position U. Manual headlamp mode • Electronic key in starter switch position 1: The low beam headlamps and parking lamps can be switched on and off with the exterior lamp switch.
Page 142 Daytime running lamp mode • USA only: The high beam headlamps can also be activated Turn exterior lamp switch to position M or U. when driving with the daytime running lamp mode activated and exterior lamp switch in position M. When the engine is running, the low beam headlamps are automatically switched on.
Page 143: Night Security Illumination
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Exterior lamp switch Night security illumination Notes: Within 10 minutes after closing the last door the night At low ambient light conditions and with the engine security illumination can be reactivated by opening a having been switched off, the exterior lamps (fogs lamps door.
Page 144: Locator Lighting
Locator lighting Headlamp cleaning system After unlocking the vehicle with the electronic key during darkness the fog lamps and parking lamps switch on for approximately 40 seconds. The exterior lamps will be switched off when opening the driver’s door. See the individual setting menu “LIGHTING” – “LOCATOR LIGHTING”...
Page 145: Combination Switch
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Combination switch Combination switch To signal minor directional changes, such as changing lanes on a highway, move combination switch briefly to the point of resistance only and release. The turn signals blink three times.
Page 146 Intermittent wiping Vehicles with optional rain sensor: One initial wipe, pauses between wipes are automatically controlled by a rain sensor monitoring the wetness of the windshield. This will not occur with a front door open. Notes: With switch in this position, one wipe occurs when turning the electronic key in starter switch from position 0.
Page 147 I or III, turn combination switch to wiper setting II. Have the system checked at your authorized For safety reasons before removing ice or snow, remove Mercedes-Benz Center as soon as possible. electronic key from starter switch. Remove blockage. Activate combination switch again (electronic key in...
Page 148 Windshield wipers smear Windshield and headlamp washer fluid mixing ratio If the windshield wipers smear the windshield, even For temperatures above freezing: during rain, activate the washer system as often as MB Windshield Washer Concentrate “S” and water. necessary. The fluid in the washer reservoir should be 1 part “S”...
Page 149: Rear Window Wiper/Washer
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Rear window wiper/washer Rear window wiper/washer The rear window wiper will also automatically engage if the windshield wiper is engaged and the gear selector lever is placed in “R” Reverse. P54.25-2533-26 The switch is located at the center console.
Page 150: Hazard Warning Flasher Switch
Hazard warning flasher switch To activate hazard warning flasher, press switch once. To deactivate, press switch again. Note: With the hazard warning flasher activated, the combination switch in position for either left or right turn, and the electronic key in starter switch position 1 or 2, only the respective left or right side turn signals will operate.
Page 151: Automatic Climate Control
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Automatic climate control Automatic climate control P83.20-2144-29...
Page 152 Display and controls Air volume control for right center air outlet Air volume control for left center air outlet Air volume control and air outlet on dashboard top center Center air outlet, left, adjustable Air volume control for side air outlet Thumbwheel for adding outside air at air outlets for center, left and right sides, as well as dashboard top Side air outlet, adjustable...
Page 153 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Automatic climate control Display and controls Temperature control, right, raising Temperature control, right, lowering Rear window defroster, see page 158 Economy mode, see page 157 Residual engine heat utilization, see page 157 Air volume control + switch on system...
Page 154 Automatic climate control The system is always at operational readiness, except when manually switched off. The automatic climate control only operates with the engine running. The temperature selector should be left at the desired temperature setting. The temperature selected is reached as quickly as possible.
Page 155 The automatic blower will be activated place. Economy mode S cannot be switched off. Have at the same time. the air conditioner checked by a Mercedes-Benz Center should this happen. We recommend to set the temperature switches on the left and right to 72 °...
Page 156 Special settings (use only for short duration) Air volume, manual Seven blower speeds are available. Air distribution, manual Press right Q or left M side of air volume control Press left or right U button. The button pops out, the switch until the requested blower speed is attained.
Page 157 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Automatic climate control Defrosting Windows fogged up on the inside Press the P button. The indicator lamp in the button Switch off the economy mode, if selected: illuminates.
Page 158 Air recirculation Switching off air recirculation and activating convenience opening: Select air recirculation: The indicator lamp in the button O is illuminated. The indicator lamp in the button O is not Press button O for more than 2 seconds, the side illuminated.
Page 159 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Automatic climate control Activated charcoal filter The activated charcoal filter should be switched off when windows fog up on the inside, or if the passenger An activated charcoal filter markedly reduces bad odors compartment needs to be quickly heated or cooled and removes pollutants from air entering the passenger...
Page 160 Economy mode To switch the automatic climate control on again, press the U or P button, or set air volume control The function of this setting corresponds to the switch to any speed. automatic mode. However, because the air conditioning compressor will not engage (fuel savings), it is not possible to air condition in this setting.
Page 161 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Automatic climate control Rear window defroster The rear window defroster uses a large amount of power. To keep the battery drain to a minimum, turn off the Turn the electronic key in starter switch to position 2.
Page 162: Front Center Console Storage Compartment Ventilation
Front center console storage compartment The air volume is dependent on the setting of: ventilation • air distribution control, • air volume control, • air outlets in the dashboard. The air temperature is about the same as that of the dashboard air outlets.
Page 163: Rear Passenger Compartment Adjustable Air Outlets
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Automatic climate control Rear passenger compartment adjustable air outlets Center air outlet, left Air volume control for center air outlets To open: Turn the wheel upward. Center air outlet, right Note: The temperature at the air outlets for the rear passenger...
Page 164: Operation Audio And Telephone
Audio and telephone operation Operating safety These instructions are intended to help you become Warning! acquainted with your Mercedes-Benz audio system. They contain useful tips and a detailed description of Any alterations made to electronic components can the user functions.
Page 165: Operating And Display Elements
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Audio system Operating and display elements On/off, volume, see page 164 Radio mode selector, see page 167 Telephone mode selector, see page 178 Manual tuning, see page 168 and 168 Fast Forward/Reverse (tape), see page 172 Seek tuning, see page 168, Fast Forward/Reverse (CD), see page 177...
Page 166 Display panel Scan tuning (Radio, see page 168) The cassette slot is located behind the display panel. Tape track search, see page 172 CD, see page 168 For notes on playing cassettes, see page 170 Alpha-numeric keypad for Function button, see page 170 and 178 station storage and frequency entry, see page 170 Soft keys for optional telephone, see page 178...
Page 167: Button And Soft Key Operation
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Audio system Button and soft key operation Operation In these instructions, the alpha-numeric keypad (right side of radio face) and the function buttons (left side of Switching on and off the radio face) are referred to as “buttons”...
Page 168: Adjusting The Volume
Adjusting the volume Bass Turning the control knob clockwise will increase the Press the “AUD” key volume, counterclockwise will decrease the volume. repeatedly until “BASS” appears on the display. Note: Press the “+” key to increase The volume setting can be selected separately for the or the “-”...
Page 169: Balance
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Audio system Fader Centering all audio functions Press the “AUD” key Push and hold down the repeatedly until “FADER” “AUD” key. All audio appears on the display. Press functions (bass, treble, the “R”...
Page 170: Audio System Tone Level Selection
Audio system tone level selection Radio mode To select the tone level settings for radio, cassette, Selecting radio mode and CD operation press the Press button. key “AUD”. The tone level settings menu is now displayed. Press key “EXT”, and “SOUND” appears on Selecting the band the display.
Page 171: Manual Tuning
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Audio system Manual tuning Seek tuning Press either the Press either the button. The radio will tune button. Step-by-step station to the next receivable station. tuning in ascending or descending order of Scan tuning...
Page 172: Weather Band
Weather Band Storing stations automatically (Autostore) Press the “WB” key. The last weather band station is Press the “AS” key until the tuned in. word “SEARCH” is displayed. The ten strongest stations are Use buttons to select a different station. If PQRS stored automatically, with the station cannot be received, the next available station...
Page 173: Storing Stations
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Audio system Storing stations Cassette mode Hold the desired number button down for approximately 2 seconds. The currently displayed Playing cassettes frequency is stored on the selected station button. The Press the button.
Page 174: Cassette Eject
The system will switch to Cassette eject cassette mode. Track 1 will be Press the button. The display will fold down and played and “SIDE 1” the cassette will be ejected. Remove the cassette, then displayed. Track 1 is the side fold the display back up manually.
Page 175: Track Selection
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Audio system Track selection Note: The beginning of a track can only be located if there is a Press the track selection break of at least 4 seconds between tracks. “TRK”...
Page 176: Scanning
Scanning Dolby NR (noise reduction system) Press the SC # button. “SEEK To enable optimum sound FWD” will appear on the reproduction of cassettes display. Each track will be recorded using the Dolby B played for 8 seconds in system, press the “NR” key so ascending order.
Page 177: Cd Mode
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Audio system CD mode Only use CDs, which bear the label shown and that conform to the compact disc digital audio General notes on CD mode standard (IEC 60908).
Page 178: Cd Changer Installed
CD changer installed Loading/emptying the CD magazine Slide the changer door to the right until it latches open and press the eject button . The magazine will be ejected. Remove the magazine. Pull out the CD tray to its stop and place the CDs in the recess of the tray, label side up.
Page 179: Playing Cds
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Audio system Skipping tracks forward/backward Playing CDs Press the button. The next track on the CD will be Press the button. When the changer is used for the first time after removing/inserting a magazine, play played.
Page 180: Fast Forward/Reverse
Fast forward/reverse Random play/repeat function Press and hold the button for audible fast forward. The tracks of the current CD are played in random order when the random feature (RDM) is selected. Press the Press and hold the button for audible reverse. “RDM”...
Page 181: Direct Track Selection
Audio system Direct track selection Telephone operation Various functions of the Mercedes-Benz integrated Tracks can be selected directly using the buttons on the alpha-numeric keypad. Press the “ function button, portable cellular telephone can be performed and displayed via the system.
Page 182: Adjusting The Volume
Adjusting the volume Calling up the telephone book Turning the control knob clockwise will increase the The numbers stored in the telephone number memory volume, counterclockwise will decrease the volume. can be called up via either name or number entries. The memory contents from the portable telephone must contain numbers and names in at least one memory Note:...
Page 183: Searching And Selecting
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Audio system Searching and selecting telephone book entries by Searching and selecting telephone book entries by name number Press the “ABC” key. The Press the “NUM” key. The current name is shown on the current number is shown on display.
Page 184: Manual Repeat Dialing (Redial)
Manual repeat dialing (redial) Abbreviated dialing from previously stored telephone numbers The last number entered can be re-selected by pressing the “SND” key once, and the call can be placed by Quick-dialing pressing the “SND” key a second time. The last dialed telephone number is shown on the display.
Page 185: Turbo-Dialing
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Audio system Express-dialing Accepting incoming call in telephone mode With an incoming call, a Press one of the number buttons for more than 1 second. ringing tone can be heard and the message “CALL”...
Page 186: Terminating Call
Failure of one of the components can lead to malfunctions of the other components. Please contact Muting a call your authorized Mercedes-Benz Center or call the Pressing the “MUT” key will Mercedes-Benz Customer Assistance Center (in the silence the call. The caller can USA) at 1-800-FOR-MERCedes, or Customer Service (in no longer hear you.
Page 187 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Audio system Emergency call Emergency calls may not be possible with all telephone networks or if certain network services and/or Important! telephone functions are active. Check with your local network operating company.
Page 188: Power Windows
Power windows Switches for: left, front right, front left, rear right, rear There are individual switches in the front passenger door and the rear doors for the respective windows. Turn electronic key in starter switch to position 1 or 2. Opening the windows: Press the switch to resistance point.
Page 189 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Interior equipment Express opening and closing Warning! Press or pull switch past resistance point and release – When closing the windows, be sure that there is no window opens or closes completely.
Page 190 Blocking of rear door window operation Synchronizing power windows If the power supply was interrupted, (battery disconnected or low), the windows cannot be opened or closed by the express feature. To resynchronize the express feature, pull switch until the window is completely closed and hold for approximately 1 second.
Page 191: Sliding/Pop-Up Roof
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Interior equipment Sliding/pop-up roof Turn the electronic key in starter switch to position 1 or 2. To open, close, raise or lower the sliding/pop-up roof: Move the switch to resistance point in the required direction.
Page 192 Opening or closing the sliding/pop-up roof With the roof closed or tilted open, a screen can be slid automatically into the roof opening to guard against sun rays. When sliding the roof open, the screen will also retract. Move the switch past resistance point in the direction The sliding/pop-up roof can also be opened and closed required and release.
Page 193 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Interior equipment Synchronizing the sliding/pop-up roof The sliding/pop-up roof must be resynchronized if the power supply has been interrupted (battery disconnected or low), the sliding/pop-up roof has been closed manually or the sliding/pop-up roof does not open smoothly or malfunctions.
Page 194: Interior Lighting
Interior lighting The interior lighting remains switched off, even when centrally unlocking the vehicle or opening a door or the electronic key is removed from the starter switch. To select automatic function: Press the rocker switch to the center position. Interior lamps are switched on in darkness, when unlocking the vehicle, opening a door or removing the electronic key from starter switch.
Page 195 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Interior equipment Notes: Door entry lamps The time delay for the interior light to switch off after The appropriate entry lamp switches on if a door is the electronic key is removed from the starter switch opened in darkness and if the interior lighting is can be adjusted in the individual setting menu...
Page 196: Sun Visors
Sun visors Vanity mirrors Illuminated vanity mirror Swing sun visors (2) down (arrow 3) to protect against sun glare. With the visor engaged in its inner mounting (2), If sunlight enters through a side window, disengage sun the lamp (4) can be switched on by opening the visor (2) from the inner mounting (1) and pivot to the cover (3).
Page 197: Interior
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Interior equipment Interior Storage compartments and armrests Warning! Warning! To help avoid personal injury during a collision or Keep compartment lids closed. This will help to sudden maneuver, exercise care when stowing prevent stored objects from being thrown about things.
Page 198: Glove Box
Glove box Notes: Prior to closing the glove box, close the compartment for glasses first. The glove box can be locked and unlocked with the mechanical key. See page 29 for instructions on how to remove the mechanical key from the electronic key (e.g. for valet parking service).
Page 199 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Interior equipment Storage compartment in front of armrest To open: Slide cover (5) rearward. To close: Slide cover (5) forward. Note: The compartment contains a lighter (see page 202), a coin holder, and a cup holder (see page 198).
Page 200 Storage compartment below the front armrest To change inclination of armrest: Pull up on armrest. To lower armrest: Pull handle (7). Notes: The storage compartment can be heated or cooled, see page 159. The compartment can get very warm due to its confined space.
Page 201: Cup Holder
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Interior equipment Cup holder P68.00-2715-26 P68.00-2715-26 Cup holder in front seat armrest Close cup holder: Push (arrow) until cup holder engages. Open cup holder: Push button (1) the cup holder slides out. Warning! Keep the cup holder closed while traveling.
Page 202 To open: Push front of sliding compartment – the cup holder slides out. To close: Push the sliding compartment back until it engages. Warning! Keep the cup holder closed while traveling. Place only containers that fit into the cup holder to prevent spills.
Page 203: Ashtrays
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Interior equipment Ashtrays Center console To open: Briefly touch the mark on the cover, the ashtray opens automatically. To remove ashtray insert from center console: Warning! Remove front ashtray only with vehicle standing still.
Page 204 Rear seats To open ashtray: Pull at top of cover. To remove insert: Press latch (2) and remove insert. To replace insert: Install insert and close the ashtray. Interior equipment Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data...
Page 205: Lighter
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Interior equipment Lighter Turn the electronic key in starter switch to position 1 or 2. Push in lighter in (1); it will pop out automatically when hot.
Page 206: Parcel Net In Front Passenger Footwell
Parcel net in front passenger footwell Ski sack (optional) A small convenience parcel net is located in the front passenger footwell. It is for small and light items, such as road maps, mail, etc. Warning! Do not place heavy or fragile objects, or objects having sharp edges, in the parcel net.
Page 207 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Interior equipment 3. Open hook and loop strap (2) and pull ski sack into 4. Open flap in trunk by pulling handle (3). passenger compartment and unfold.
Page 208 5. From trunk, slide skis into ski sack 6. Wrap strap around ski sack and armrest. 7. Close clasp (arrows 4 and 5) and pull strap tight to Warning! immobilize skis. The ski sack is designed for up to four pairs of skis. Do not load the ski sack with other objects.
Page 209 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Interior equipment 8. Connect snap hook (6) of front strap to eye (7) Unloading and folding located on center tunnel in front of rear seat bench. 1.
Page 210 Removal of ski sack For removal of the ski sack we recommend that you contact an authorized Mercedes-Benz Center. Warning! Never drive vehicle with trunk lid open while the ski sack is removed. Deadly carbon monoxide (CO) gases may enter vehicle interior resulting in unconsciousness and death.
Page 211: Parcel Net In Trunk
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Interior equipment Parcel net in trunk There is a parcel net located on left side of the trunk. Dependent on the equipment of your vehicle, there is another parcel net located on right side of the trunk.
Page 212: Electrical Outlet
Electrical outlet Storage compartment under trunk floor P68.00-2480-26 The electrical outlet is located in the rear compartment. To open trunk floor: Electronic key in starter switch position 1 or 2. Press handle (1) on the recess and lift trunk cover. Flip up cover and insert electrical plug (cigar lighter The compartment can be used to store small, light or flat type).
Page 213: Retractable Luggage Cover And Partition Net
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Interior equipment To close trunk floor: Retractable luggage cover and partition net Lower the cover and lock by applying light pressure to The twin reel roller blind comprises a luggage cover and the handle (1).
Page 214 Partition net with rear seats folded up Partition net with rear seats folded down P68.00-2481-26 P68.00-2487-26 Eyelets on roof Eyelets on roof Pull out upper blind (safety net)by tabs (1) and engage Pull out upper blind (safety net) by tabs (1) until it into eyelets on the roof (2).
Page 215 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Interior equipment Luggage cover Removal, installation of twin-reel roller blind P68.00-2488-26 P68.00-2489-26 Handle The safety net and luggage cover must be retracted. To lock – pull luggage cover back by handle (1) until Removal: it locks into position.
Page 216: Split Rear Bench Seat
Split rear bench seat Folding the backrest forward The two sections can be folded down separately to enlarge the cargo area. Warning! When expanding the luggage compartment, always fold the seat cushions fully forward and always use the partition net when transporting cargo. Unless you are transporting cargo, the backrests must remain properly locked in the upright position.
Page 217 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Interior equipment Illustration: right-hand side of rear seat. Retract head restraints fully and fold rearward, see page 53. Slip seat belt webbing behind retainer (3). Pull release handle (4) on the left or right backrest as required.
Page 218 Folding the backrest rearward Fold the backrest (5) rearward until it engages. Fold the seat cushions (2) rearward until they lock into position. Interior equipment Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data...
Page 219 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Interior equipment Warning! If a red indicator is visible with the seatback up, then the seatback is not properly locked into position. Always lock backrest in its upright position when rear seat bench is occupied, or the extended cargo area is not in use.
Page 220: Loading Instructions
Loading instructions The handling characteristics of a fully loaded vehicle depend greatly on the load distribution. It is therefore recommended to load the vehicle according to the illustrations shown, with the heaviest items being placed towards the front of the vehicle. Always place items being carried against front or rear seat backrests, and fasten them as securely as possible.
Page 221: Cargo Tie-Down Rings
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Interior equipment Cargo tie-down rings Warning! Always fasten items being carried as securely as possible. In an accident, during hard braking or sudden maneuvers, loose items will be thrown around inside the vehicle and can cause injury to vehicle occupants unless the items are securely fastened in the vehicle.
Page 222: Cellular Telephone
Cellular telephone The vehicle is prepared for the installation of a cellular telephone. For further information and installation contact your authorized Mercedes-Benz Center. Warning! Some jurisdictions prohibit the driver from using a cellular telephone while driving a vehicle. Whether or not prohibited by law, for safety reasons, the driver should not use the cellular telephone while the vehicle is in motion.
Page 223: Telephone, General
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Interior equipment Telephone, general Bear in mind that at a speed of just 30 mph (approximately 50 km/h), your vehicle is covering a distance of approximately 50 feet (approximately Warning! 14 m) every second.
Page 224: Garage Door Opener
If you should experience difficulties with programming the transmitter, contact Signal transmitter keys your authorized Mercedes-Benz Center, or call Mercedes-Benz Customer Assistance Center (in the USA Indicator lamp only) at 1-800-FOR-MERCedes, or Customer Service (in Canada) at 1-800-387-0100.
Page 225 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Garage door opener For operation in the USA only: This device complies Programming or reprogramming the integrated with Part 15 of the FCC Rules. Operation is subject to remote control: the following two conditions: 1.
Page 226 3. Using both hands, simultaneously push the hand- Rolling code programming: held transmitter button and the desired integrated To train a garage door opener (or other rolling code remote control button. Do not release the buttons devices) with the rolling code feature, follow these until completing step 4.
Page 227 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Garage door opener Operation of remote control: 3. Firmly press and release the programmed integrated remote control transmit button. Press 1. Turn electronic key in starter switch to position 1 and release same button a second time to complete or 2.
Page 228 Driving Driving instructions ...... 253 Cruise control .........264 Drive sensibly – Save Fuel ..253 Brake assist system (BAS) ....267 Control and operation of Drinking and driving ....253 Antilock brake system radio transmitters .....226 (ABS) ...........268 Pedals .......... 253 The first 1 000 miles Electronic stability program Power assistance ......
Page 229: Control And Operation Of Radio Transmitters
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Control and operation of radio transmitters Control and operation of radio transmitters COMAND, radio and telephone Telephones and two-way radio Warning! Warning! Please do not forget that your primary Never operate radio transmitters equipped with a responsibility is to drive the vehicle.
Page 230: The First 1 000 Miles (1 500 Km)
We strongly recommend that you have your vehicle break-in period, the more satisfied you will be with its serviced by your authorized Mercedes-Benz Center, in accordance with the Service Booklet at the times called performance later on. Therefore, drive your vehicle during the first 1 000 miles (1 500 km) at moderate for by the FSS.
Page 231: Tele Aid
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Tele Aid Tele Aid The speaker volume of a Tele Aid call can be adjusted when using the volume control on the multifunction steering wheel, for raising press button æ and for Important! lowering press button ç.
Page 232 If a malfunction is indicated as outlined above, have the (determined by the GPS satellite location system), system checked at the nearest Mercedes-Benz Center as vehicle model, identification number and color are soon as possible.
Page 233 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Tele Aid The Tele Aid system is available if: Warning! • it has been activated and is operational. Activation If the indicator lamp in the “SOS” button is requires a subscription for monitoring services and illuminated continuously and there was no voice cellular air time...
Page 234 Initiating an emergency call manually Briefly press on cover (1) – the cover will open. Press the SOS button (2) briefly. The indicator lamp in the SOS button (2) will flash until the emergency call is concluded. Wait for a voice connection to the Response Center.
Page 235 The nature of the need for button. Carefully leave the vehicle and move to a assistance can then be described. The Mercedes-Benz safe location. The Response Center will Roadside assistance dispatcher will either dispatch a automatically contact local emergency officials with the vehicle’s approximate location if they...
Page 236 Roadside Assistance calls can be terminated using the operation of your vehicle, the nearest Mercedes-Benz ì button on the multifunction steering wheel. Center or Mercedes-Benz USA products and services is available to you. For more details concerning Tele Aid, please visit www.mbusa.com and use your ID and password, sent to...
Page 237 “SOS” button and the Roadside Assistance button •). initiate a call. Visit your Mercedes-Benz Center and have the system See system self-check on page 228 when the indicator checked or contact the Response Center at 1-800-756-...
Page 238 COMAND) is muted and the selected mode (radio, 1-800-756-9018 (in the USA) or 1-888-923-8367 (in tape or CD) pauses. The optional cellular phone (if Canada), or Mercedes-Benz Customer Assistance at installed) switches off. If you must use this phone, the 1-800-FOR-MERCedes (1-800-367-6372) in the USA or vehicle must be parked.
Page 239 In the case you have your vehicle locked unintentionally relevant cellular phone network is available. (e.g. key inside vehicle), and no other key is available, contact the Mercedes-Benz Response Center at The SOS button will flash and the message 1-800-756-9018 (in the USA) or 1-888-923-8367 (in “EMERGENCY CALL –...
Page 240 Select “Yes”. With the vehicle stopped in a safe to the police who will issue a numbered incident report. location press SVC, then select “View Info Service of Pass this number on to the Mercedes-Benz Response mm.dd.yyyy hh.mm”. Messages will be retained for Center.
Page 241: Catalytic Converter
Catalytic converter Catalytic converter Warning! Your Mercedes-Benz is equipped with monolithic type As with any vehicle, do not idle, park or operate catalytic converters, an important element in this vehicle in areas where combustible materials conjunction with the oxygen sensors to achieve...
Page 242: Emission Control
Mercedes-Benz Center authorized technicians. Engine and corrected immediately. If you must drive under adjustments should not be altered in any way. Moreover,...
Page 243: Starter Switch
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Starter switch Starter switch key or with the electronic key in starter switch position 0 or 1 the selector lever is locked in position “P”. Most electrical consumers can be operated.
Page 244 Important! Notes: A warning sounds when the driver’s door is opened If the electronic key is left in the starter switch with the electronic key is in starter switch position 1 position 0 for a extended period of time, it can no longer or 0.
Page 245: Starting And Turning Off The Engine
“P” or “N”. Turn electronic key in (-20 ° C) we recommend that an engine block heater be starter switch to position 2. installed. Your authorized Mercedes-Benz Center will advise you on this subject, see page 261. Starting Do not depress accelerator.
Page 246: Automatic Transmission
Automatic transmission The automatic transmission selects individual gears automatically, dependent upon • Selector lever position • Program mode selector • Accelerator position • Vehicle speed The gear shifting process is continuously adapted, dependent on the driving style, the driving situation and the road characteristics.
Page 247 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Automatic transmission Driving Important! The selector lever is automatically locked while in After selecting any driving position from “N” or “P”, position “P”. To move the selector lever out of wait a moment to allow the gear to fully engage before position “P”, the service brake pedal must be firmly accelerating, especially when the engine is cold.
Page 248 Stopping Rocking a vehicle free in this manner may cause the ABS or traction system malfunction indicator lamp to For brief stops, e.g. at traffic lights, leave the come on. Turn off and restart the engine to clear the transmission in gear and hold vehicle with the service malfunction indication.
Page 249 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Automatic transmission Selector lever position Program mode indicator, Light emitting gear range indicators see page 250 There is an additional indication of the current selector Gear range indicators lever position on the cover of the shifting-gate.
Page 250 “P”. With the electronic key removed, the transmission damage that is not covered by the selector lever is locked in position “P”. Mercedes-Benz Limited Warranty. Reverse gear The transmission automatically upshifts through 5th gear. Position “D” provides optimum driving...
Page 251 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Automatic transmission Gear selection for special circumstances Briefly press selector lever in the “D +” direction: The transmission will shift from the current gear range The transmission gear ranges for special circumstances to the next higher gear range.
Page 252 malfunction. However, neither the engine nor Gear ranges: transmission are negatively affected by this mode of Upshift through 4th gear only. Suitable for operation. performance driving. The delayed upshift is effective with vehicle speeds Upshift through 3rd gear only. Suitable for below 31 mph (50 km/h) at partial throttle and engine moderately steep hills.
Page 253 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Automatic transmission Program mode selector switch Standard mode Press switch. “S” is displayed in the gear range indicator display, see page 246. Use this mode for all regular driving.
Page 254 Have the transmission checked at your authorized Dependent on the program mode selector switch Mercedes-Benz Center as soon as possible. position “S” or “W” and the gear selector lever in position “R”, the ratio of power transmission changes.
Page 255: Parking Brake
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Parking brake Parking brake To engage, firmly depress parking brake pedal. When the electronic key is in starter switch position 2, the brake warning lamp in the instrument cluster should come on brightly.
Page 256: Driving Instructions
• avoid frequent acceleration and deceleration, Pedals • have all maintenance work performed at regular intervals by an authorized Mercedes-Benz Center. Warning! Keep driver’s foot area clear at all times. Objects Fuel consumption is also increased by driving in cold stored in this area may impair pedal movement.
Page 257: Power Assistance
It can also result in the brakes overheating thereby Have the brake system inspected at an authorized significantly reducing their effectiveness. It may Mercedes-Benz Center immediately. not be possible to stop the vehicle in sufficient time to avoid an accident.
Page 258: Driving Off
When starting off on a slippery surface, do not allow one drive wheel to spin for an extended period with the ESP switched off. Doing so may cause serious damage to the drive train which is not covered by the Mercedes-Benz Limited Warranty. Driving instructions...
Page 259: Parking
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Driving instructions Parking Important! It is advisable to set the parking brake whenever Warning! parking or leaving the vehicle. In addition, move selector lever to position “P”. When parking on hills, To reduce the risk of personal injury as a result of always set the parking brake.
Page 260: Tires
Inspect the tires and under the vehicle for possible damage. If the vehicle or tires appear unsafe, have it towed to the nearest Mercedes-Benz Center or tire dealer for repairs. Warning! Tread wear indicators (TWI) are required by law. These indicators are located in six places on the tread Do not allow your tires to wear down too far.
Page 261 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Driving instructions Specified tire pressures must be maintained. This Tire traction applies particularly if the tires are subjected to high The safe speed on a wet, snow covered or icy road is loads (e.g.
Page 262: Snow Chains
Use only snow chains that are tested and recommended Your vehicle is factory equipped with “H”-rated tires, by Mercedes-Benz. Your authorized Mercedes-Benz which have a speed rating of 130 mph (210 km/h). Center will be glad to advise you on this subject.
Page 263 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Driving instructions Winter driving instructions If the vehicle is parked after being driven on salt treated roads, the braking efficiency should be tested as soon as The most important rule for slippery or icy roads is to possible after driving is resumed while observing the drive sensibly and to avoid abrupt acceleration, braking...
Page 264: Winter Driving
Have your vehicle winterized at your authorized antilock brake system (ABS) and electronic stability Mercedes-Benz Center before the onset of winter. program (ESP) can only be achieved with M+S rated • Change the engine oil if the engine contains an oil radial-ply tires and/or snow chains recommended by which is not approved for winter operation.
Page 265: Deep Water
If you must drive through deep water, drive slowly to prevent water from entering the engine compartment or passenger compartment, being ingested by the air intake, possibly causing damage to electrical components or wiring, to engine or transmission that is not covered by the Mercedes-Benz Limited Warranty.
Page 266: Passenger Compartment
Abroad, there is a widely-spread Mercedes-Benz service Warning! network at your disposal. If you plan to travel into areas which are not listed in the index of your Mercedes-Benz Always fasten items being carried as securely as Center directory, you should request pertinent possible.
Page 267: Cruise Control
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Driving systems Cruise control Accelerate and set: Lift lever briefly to set speed. Hold lever up to accelerate. Decelerate and set: Depress lever briefly to set speed. Hold lever down to decelerate.
Page 268 If the cruise control cancels by itself and remains position 1 or 0. inoperative until the engine is restarted, have the system checked at your authorized Mercedes-Benz Important! Center as soon as possible. Moving gear selector lever to position “N” switches the cruise control off.
Page 269 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Driving systems As soon as the grade eases, the automatic transmission Warning! shifts up again dependent on the selector lever position. Only use the cruise control if the traffic and weather conditions make it advisable to travel at a Nevertheless, in some cases you may have to step on the steady speed.
Page 270: Brake Assist System (Bas)
If a BAS warning message is displayed, have the BAS which could jeopardize the user’s safety or the checked at your authorized Mercedes-Benz Center as safety of others. soon as possible. The BAS is designed to maximize the vehicle’s braking...
Page 271: (Abs)
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Driving systems Antilock brake system (ABS) At the instant one of the wheels is about to lock up, a slight pulsation can be felt in the brake pedal, indicating that the ABS is in the regulating mode.
Page 272 The ABS malfunction indicator lamp - in the Mercedes-Benz Center as soon as possible. instrument cluster comes on with the electronic key in starter switch position 2 and should go out with the Warning! engine running.
Page 273: (Esp)
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Driving systems Electronic stability program (ESP) Important! If the ESP warning lamp v flashes: Warning! • During take-off apply as little throttle as possible. ESP cannot prevent the natural laws of physics •...
Page 274 In winter operation, the maximum effectiveness of the If the ESP warning message is displayed, a malfunction ESP is only achieved with Mercedes-Benz recommended has been detected in the system. Only partial engine M+S rated radial-ply tires and/or snow chains.
Page 275 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Driving systems ESP control switch To improve the vehicle’s traction when driving with snow chains, or starting off in deep snow, sand or gravel, switch off ESP by pressing the upper half (1) of the ESP switch.
Page 276 • During take-off, apply as little throttle as possible. by the Mercedes-Benz Limited Warranty. • While driving, ease up on the accelerator. The ESP warning lamp, located in the speedometer dial, starts to flash at any vehicle speed as soon as the tires lose traction and the wheels begin to spin.
Page 277: At The Gas Station
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data What you should know at the gas station What you should know at the gas station Open flap by pushing near front (arrow). Turn fuel cap to the left and hold on to it until possible pressure in Fuel supply tank has been released, then remove cap.
Page 278 Fuel tank capacity approximately 16.4 US gal (62.0 l). Spark plugs This includes approximately 2.1 US gal (8.0 l) reserve. Approved spark plugs, refer to “Technical Data”. Use premium unleaded gasoline: Posted Octane Index 91 (Average of 96 RON/86 MON). Air conditioner R-134a refrigerant and special PAG lubricant, refer to Engine oil...
Page 279: Before A Long Trip
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Check regularly and before a long trip Check regularly and before a long trip Vehicle lighting: Check function and cleanliness. For replacement of light bulbs, see “Exterior lamps” on page 339.
Page 280: Instrument Cluster Display
Instrument cluster display Malfunction and indicator COOLANT lamp in the center console ..284 (coolant temperature) ....294 Malfunction and indicator lamps in AIRBAG OFF indicator lamp ..284 ENGINE OIL LEVEL ....295 the instrument cluster .....278 Malfunction and warning STEERING GEAR OIL ....296 On-board diagnostic system ..278 messages in the LIGHTING SYSTEM ....297...
Page 281: On-Board Diagnostic System
Engine malfunction indicator lamp. If the therefore, be carried out only by authorized “CHECK ENGINE” malfunction indicator Mercedes-Benz Center qualified technicians. Engine lamp comes on when the engine is running, adjustments should not be altered in any way. Moreover, it indicates a malfunction of the fuel management...
Page 282 Mercedes-Benz Center as soon as possible. authorized Mercedes-Benz Center as soon as possible. If the “CHECK ENGINE” lamp comes on continuosly With some exceptions, the control module switches off and/or the vehicle is not driving normally (e.g.
Page 283: Brake Warning Lamp
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Malfunction and indicator lamps Brake warning lamp Warning! Driving with the brake warning lamp illuminated Except Canada can result in an accident. Have your brake system checked immediately if the brake warning lamp stays on.
Page 284: Supplemental Restraint System (Srs) Indicator Lamp
If no fault is detected, the lamp will go recommend that you visit an authorized out when the engine is running. Mercedes-Benz Center immediately to have the system checked; otherwise the “SRS” may not be The operational readiness of the airbag system is activated when needed in an accident, which could verified by the indicator lamp “SRS”...
Page 285: Fuel Reserve Warning
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Malfunction and indicator lamps Fuel reserve warning After refueling the vehicle, the message “1 MALFUNCTION” appears in the multifunction display when turning the electronic key in starter switch to position 2.
Page 286: Abs Malfunction Indicator Lamp
See page 268 for notes on antilock brake system (ABS). the operation of other systems (e.g. Navigation, Automatic transmission). Be guided accordingly with respect to the use of those systems and have the system checked at your authorized Mercedes-Benz Center as soon as possible. Malfunction and indicator lamps Instruments...
Page 287: Electronic Stability Program (Esp) - Warning Lamp
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Malfunction and indicator lamps Malfunction and indicator lamp in the center Electronic stability program (ESP) — warning lamp console The yellow ESP warning lamp in the speedometer dial comes on with the electronic key in starter switch position 2.
Page 288: Malfunction And Warning Messages In The Multifunction Display
Malfunction and warning messages in the Warning! multifunction display The BabySmart airbag deactivation system will Malfunction and warning messages for the following ONLY work with a special child seat designed to operate with it. It will not work with child seats systems will be displayed immediately in the which are not BabySmart compatible.
Page 289 Failure to repair condition noted may cause Temporary messages such as “HOOD OPEN!” will not be damage not covered by the Mercedes-Benz Limited stored in the malfunction message memory. Warranty, or result in property damage or personal...
Page 290: Display Defective
DISPLAY DEFECTIVE (engine control unit) DISPLAY DEFECTIVE (several systems) Line 1 Line 2 Line 1 Line 2 VISIT WORKSHOP! DISPLAY FAULTY VISIT WORKSHOP! DISPLAY FAULTY * C = Category, see page 285 * C = Category, see page 285 This message is displayed to indicate that the The displays for several systems have failed.
Page 291: Battery /Alternator
Do not continue to drive the vehicle with this message displayed. Doing so could result in serious engine damage that is Line 1 Line 2 not covered by the Mercedes-Benz Limited Warranty. BATTERY/ALTERNATOR VISIT WORKSHOP! * C = Category, see page 285...
Page 292: Antilock Brake System
ANTILOCK BRAKE SYSTEM BRAKE ASSIST Line 1 Line 2 Line 1 Line 2 ABS SYSTEM VISIT WORKSHOP! BRAKE ASSIST NOT AVAILABLE! DISPLAY DEFECTIVE VISIT WORKSHOP! BRAKE ASSIST VISIT WORKSHOP! DISPLAY DEFECTIVE VISIT WORKSHOP! * C = Category, see page 285 * C = Category, see page 285 See page 268 for notes on the antilock brake system (ABS).
Page 293: Brake Pad Wear
Driving with this message displayed can result in Have the brake system checked at your authorized an accident. Have your brake system checked Mercedes-Benz Center as soon as possible. immediately. Don’t add brake fluid before checking the brake system. Overfilling the brake fluid reservoir can result in spilling brake fluid on hot engine parts and the brake fluid catching fire.
Page 294: Parking Brake
PARKING BRAKE SEAT BELT SYSTEM Line 1 Line 2 Line 1 Line 2 PARKING BRAKE ENGAGE BRAKE! SEAT BELT SYSTEM VISIT WORKSHOP! PARKING BRAKE RELEASE BRAKE! PASSENGER SEAT BELT FASTEN SEAT BELT! DRIVER SEAT BELT FASTEN SEAT BELT! * C = Category, see page 285 * C = Category, see page 285 Malfunction and warning messages Instruments...
Page 295: Elec. Stabil. Prog
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Malfunction and warning messages ELEC. STABIL. PROG. (Electronic stability program) 1 The enhanced vehicle stability offered by ESP and the torque reduction feature are unavailable. 2 This message may be displayed if the power supply was interrupted (battery disconnected or empty).
Page 296: Coolant (Coolant Level)
Mercedes-Benz Limited Warranty. In cases of major or frequent minor coolant loss, have the cooling system checked at your authorized Mercedes-Benz Center as soon as possible. Note: Do not drive without coolant in the cooling system. The engine will overheat causing major engine damage.
Page 297: (Coolant Temperature)
Do not continue to drive the vehicle with this message displayed. Doing so could result in serious engine damage that is not covered by the Mercedes-Benz Limited Warranty. 2 The cooling fan for the coolant is faulty. Observe the coolant...
Page 298: Engine Oil Level
1 The engine oil level must be checked immediately. See Engine oil result in serious engine damage that is not covered by level indicator on page 135. the Mercedes-Benz Limited Warranty. 2 There is no oil in the engine. There is a danger of engine damage. Malfunction and warning messages...
Page 299: Steering Gear Oil
System without or with insufficient steering gear oil level. Danger of damage to steering gear exists. When this message appears, the steering gear oil level has dropped below the required level. Have the system checked by the nearest Mercedes-Benz Center as soon as possible.
Page 300: Lighting System
LIGHTING SYSTEM Line 1 Line 2 TURN SIGNAL F, R CHECK LAMPS! BRAKE LIGHT VISIT WORKSHOP! BRAKE LIGHT, L CHECK LAMPS! BRAKE LIGHT, R CHECK LAMPS! 3RD STOP LAMP CHECK LAMPS! HIGH BEAM, L CHECK LAMPS! Line 1 Line 2 HIGH BEAM, R CHECK LAMPS! LOW BEAM,L...
Page 301 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Malfunction and warning messages In the case of bulb failures in certain lamps, other lamps Line 1 Line 2 will substitute. See page 339 for instructions on replacing bulbs.
Page 302: Lamp Sensor
LAMP SENSOR DOOR Line 1 Line 2 Line 1 Line 2 LAMP SENSOR VISIT WORKSHOP! DOOR OPEN! * C = Category, see page 285 * C = Category, see page 285. The headlamps will be switched on automatically if the light sensor malfunctions.
Page 303: Trunk Open
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Malfunction and warning messages TRUNK OPEN HOOD Line 1 Line 2 Line 1 Line 2 TRUNK OPEN! HOOD OPEN! * C = Category, see page 285 * C = Category, see page 285.
Page 304: Telephone - Function
See page 228 for notes on the Tele Aid. If a malfunction is indicated as outlined above, have the system checked at the nearest Mercedes-Benz Center as soon as possible. Malfunction and warning messages Instruments...
Page 305: Washer Fluid
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Malfunction and warning messages WASHER FLUID When this message appears while the engine is running, the level of the reservoir has dropped to approximately of the total volume. The reservoir should be refilled with the prescribed mixture of MB Windshield washer concentrate and water or the concentrate and commercially available premixed...
Page 306: Restraint System
RESTRAINT SYSTEM Line 1 Line 2 Line 1 Line 2 RESTRAINT SYSTEM VISIT WORKSHOP! REPLACE KEY VISIT WORKSHOP! AUTOM. LIGHT ON REMOVE KEY! * C = Category, see page 285. * C = Category, see page 285. See page 56 for notes on the seat belts, and page 67 for notes on the airbags.
Page 307: Fuel Reserve
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Malfunction and warning messages FUEL RESERVE UNDERVOLTAGE Line 1 Line 2 Line 1 Line 2 RESERVE FUEL VISIT FILLING STATION! UNDERVOLTAGE ENGINE ON! UNDERVOLTAGE CONSUMER DEFECTIVE! * C = Category, see page 285.
Page 308 Practical hints Spare wheel, Towing the vehicle ......335 storage compartment ....318 Transmission selector lever, First aid kit ........306 Vehicle tools ........319 manually unlocking ....338 Stowing things in the vehicle ..307 Vehicle jack ........320 Exterior lamps ........339 Fuses ..........307 Wheels ..........321 Replacing bulbs ......339 Hood ..........
Page 309: First Aid Kit
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data First aid kit First aid kit The first aid kit is stored in the cargo area behind the Remove first aid kit (3). left hand trim panel (2). Note: To open trim panel: Check contents of first aid kit for completeness on a...
Page 310: Stowing Things In The Vehicle
Stowing things in the vehicle Fuses Most of your vehicle’s electrical components are fused Warning! with safety fuses. With the exception of the brake lights, all individual lighting system components are To help avoid personal injury during a collision or electronically fused.
Page 311 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Fuses Fuse box in the passenger compartment To gain access to fuse box, pull cover away from fuse box (arrow) and remove rearward. Fuse box in passenger compartment...
Page 312 Fuse box in engine compartment Cover Fuse box in engine compartment, left-hand side Screw Clamps Retainer To gain access to fuse box: Release clamps (6) and remove the cover. To remove cover: Twist screws (3) 90˚ counterclockwise. Pull up cover (2) To close the fuse box: and slide out retainer (4) and remove it by pulling cover Ensure that the sealing rubber is properly positioned...
Page 313 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Fuses Auxiliary fuse box in the trunk Button for unlocking the trim panel Auxiliary fuse box Trim panel Special fuse puller Spare fuses The auxiliary fuse box is located in the cargo area behind the left hand trim panel (2).
Page 314: Hood
Hood The engine is equipped with a transistorized ignition system. Because of the high voltage it is dangerous to touch any components (ignition coils, Warning! spark plug sockets, diagnostic socket) of the To help prevent personal injury, stay clear of ignition system moving parts when the hood is open and the engine •...
Page 315 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Engine compartment To open: Pull handle (2) to its stop out of radiator grill and open To unlock the hood, pull release lever (1) under the hood (do not pull up on the handle).
Page 316 To close: Lower the hood and let it drop into lock from a height of approximately 1 ft. (30 cm), assisting with hands placed flat on edges of hood (3). To avoid hood damage, please make sure that hood is fully closed.
Page 317: Adding Engine Oil
Re-install oil filler cap. Do not overfill the engine. Excessive oil must be drained or siphoned. It could cause damage to engine and catalytic converter not covered by the Mercedes-Benz Limited Warranty. See malfunction and warning messages on page 285 if an engine oil level display appears on the multifunction indicator when the engine is running.
Page 318: Automatic Transmission Fluid Level
Regular automatic transmission fluid level checks and changes are not required. For this reason the dipstick is omitted. If you notice fluid leaks or gear shifting malfunctions, have your authorized Mercedes-Benz Center check the transmission fluid level. P20.30-2133-26 Coolant expansion tank To check the coolant level, the vehicle must be parked on level ground and the engine stopped.
Page 319: Adding Coolant
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Engine compartment Adding coolant Windshield and headlamp washer system If coolant has to be added, a 50/50 mixture of water and MB anticorrosion/antifreeze should be added. Warning! •...
Page 320 Vehicles without headlamp cleaning system: Windshield and headlamp washer fluid mixing ratio Capacity approximately 3.2 US qt (3.0 l) For temperatures above freezing: Vehicles with headlamp cleaning system: MB Windshield Washer Concentrate “S” and water. Capacity approximately 6.4 US qt (6.0 l) 1 part “S”...
Page 321: Spare Wheel, Storage Compartment
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Spare wheel Spare wheel, storage compartment Open storage compartment under trunk floor, see page 209. To remove the spare wheel: Turn the luggage bowl counterclockwise and remove the spare wheel.
Page 322: Vehicle Tools
Vehicle tools The vehicle tools are stored in the cargo area behind the Vehicle tool kit, towing eye bolt, wheel bolts and left hand trim panel (2). jack, special fuse puller, spare fuses (3) To open trim panel: Press button (1) and fold down the panel (2). Vehicle tools Instruments Instrument...
Page 323: Vehicle Jack
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Jack Vehicle jack To prepare the jack for use: Storing the jack in the cargo area: Remove the jack from its compartment in cargo area. Before storing the jack, it should be fully collapsed, with handle folded in (storage position).
Page 324: Wheels
To help avoid personal injury, See your authorized Mercedes-Benz Center for further use the jack only to lift the vehicle during a wheel information.
Page 325: Rotating Wheels
Notes: When replacing rims, use only genuine Mercedes-Benz wheel bolts specified for the Thoroughly clean the inner side of the wheels any time particular rim type. Failure to do so can result in you rotate the wheels or wash the vehicle underside.
Page 326: Spare Wheel
Spare wheel Important! The spare wheel rim is mounted with a full size tire of the same type as on the vehicle, and is fully functional. For additional information, refer to page 366. Spare wheel bolts Warning! Be sure to use the original length wheel bolts when remounting the original wheel after it has been Wheel bolt for light alloy rims repaired.
Page 327: Changing Wheels
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Tires, Wheels Changing wheels Move vehicle to a level area which is a safe distance from the roadway. Warning! 1. Set parking brake and turn on hazard warning The jack is designed exclusively for jacking up the flasher.
Page 328 P40.10-2427-26 4. Remove the two-piece wheel wrench from the 6. Place jack on firm ground. Position jack (1) under vehicle tool kit and assemble (see page 320). the take-up bracket (2) so that it is always vertical (plumb-line) as seen from the side, even if the 5.
Page 329 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Tires, Wheels P40.10-2428-26 8. Unscrew upper-most wheel bolt and install Wheel bolt for light alloy rims alignment bolt (1) supplied in the tool kit. Remove Wheel bolt for steel rims the remaining bolts.
Page 330 P40.10-2429-26 P40.10-2430-26 11. Lower vehicle and remove jack. 10. Clean contact surfaces of wheel and wheel hub. Install wheel on wheel hub. Insert wheel bolts and tighten them slightly. To avoid paint damage, place wheel flat against hub and hold it there while installing first wheel bolt. Unscrew the alignment bolt to install the last wheel bolt.
Page 331 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Tires, Wheels Notes: Before storing the jack, it should be fully collapsed, with handle folded in. For proper storage of vehicle jack see page 318. Warning! Always replace wheel bolts that are damaged or rusted.
Page 332: Tire Inflation Pressure
A table (see fuel filler flap) lists the tire inflation conditions are taken into consideration. pressures specified for Mercedes-Benz recommended An underinflated tire due to a slow leak (e.g. due to a tires as well as for the varying operating conditions.
Page 333: Battery
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Battery Battery Therefore, we strongly recommend that you have the battery charge checked frequently, and corrected if necessary, especially if you use the vehicle less than Warning! approximately 200 miles (300 km) per month, Failure to follow these instructions can result in...
Page 334 After reconnecting the battery also set the clock (vehicles with COMAND: see COMAND operator’s manual) resynchronize the front seat head restraints, the express feature of the power windows, the sliding/ pop-up roof, and the electronic stability program (see individual settings on page 115, head restraints on page 50, power windows on page 185, synchronizing the sliding/pop-up roof on page 190 and electronic stability program on page 270).
Page 335: Jump Starting
Read all instructions before proceeding. by the Mercedes-Benz Limited Warranty. The battery is located in the engine compartment on the right hand side.
Page 336 Proceed as follows: 1. Position the vehicle with the charged battery so that the jumper cables will reach, but never let the vehicles touch. Make sure the jumper cables do not have loose or missing insulation. 2. On both vehicles: •...
Page 337 5. Start engine of the vehicle with the charged battery starting attempts, have it checked at the nearest and run at high idle. Make sure the cables are not authorized Mercedes-Benz Center. on or near pulleys, fans, or other parts that move Excessive unburned fuel may damage the catalytic when the engine is started.
Page 338: Towing The Vehicle
Towing the vehicle Important! When towing the vehicle, please, note the following: Warning! With the automatic central locking activated and the Prior to towing the vehicle with all wheels on the electronic key in starter switch position 2, the vehicle ground, make certain that the electronic key is in doors lock if the left front wheel as well as the right rear starter switch position 2.
Page 339 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Towing the vehicle Cover on right side of front bumper Cover on right side of rear bumper To remove cover: To remove cover: Press mark on cover in direction of arrow and lift cover Press mark on cover in direction of arrow and lift cover off to reveal threaded hole for towing eye bolt.
Page 340 We recommend that the vehicle be transported using Warning! flat bed equipment. This method is preferable to other With the engine not running, there is no power types of towing. assistance for the braking and steering systems. In this case, it is important to keep in mind that a Important! considerably higher degree of effort is necessary to brake and steer the vehicle.
Page 341: Transmission Selector Lever, Manually Unlocking
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Towing the vehicle Transmission selector lever, manually unlocking To do so, open storage compartment in front of center armrest. Using a small coin, release the coin holder (1) and swing it aside.
Page 342: Exterior Lamps
If the newly installed bulb does not light up, switch the Wear eye and hand protection. lamp off and on again. If the bulb still does not light up, have the system checked at an authorized Mercedes-Benz Center. Exterior lamps Instruments Instrument...
Page 343 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Exterior lamps Headlamp assembly Headlamp cover for low beam headlamp Bulb socket for turn signal lamp Headlamp cover for parking and standing lamp, and Electrical connector for low beam headlamp bulb high beam headlamp (Halogen type) Electrical connector for high beam headlamp bulb...
Page 344 Bulbs for high and low beam Turn signal lamp H7 (55 W) 1156 NA (26.9/5 W/32/4 cp) Open hood. Open hood. Press the clamp and remove headlamp cover (1 or 2). Twist bulb socket (3) counterclockwise and pull out. Push bulb into socket, turn counterclockwise and Pull electrical connector off.
Page 345 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Exterior lamps Taillamp assemblies Open tailgate. Squeeze tabs together (3) and remove bulb holder. Press the button (1) on the corresponding side and fold down the trim panel (2).
Page 346 To replace bulb, twist bulb socket counterclockwise, pull out socket and remove bulb. Insert new bulb into socket, insert socket and turn clockwise. Insert bulb holder and close trim panel. Stop lamp (P 21 W/32 cp bulb) Turn signal lamp (PY 21 W bulb [yellow]) Backup lamp (P 21 W/32 cp bulb) Rear fog lamp (driver’s side)/tail, parking, standing and side marker lamp (P 21/4 W)
Page 347 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Exterior lamps License plate lamp Side marker lamp, front (5 W/4 cp bulb) Loosen both securing screws (1), remove lamp and Carefully slide lamp towards rear (arrow 1), and remove replace tubular lamp (C 5 W/4 cp).
Page 348: Standby Bulb Function
Have the system checked at an authorized The respective fog lamp, dimmed, will act as a Mercedes-Benz Center if a malfunction occurs. replacement lamp, if the left or right standing lamp stops working. Notes: The multifunction display will indicate that a bulb has failed.
Page 349: Changing Batteries In The
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Electronic key Changing batteries in the electronic key P80.20-2200-26 P80.35-2028-26 Transmit buttons Changing batteries Lamp for battery check and function control Move locking tab (3) in direction of right arrow and remove mechanical key (4, left arrow).
Page 350 P80.35-2026-26 P80.35-2027-26 Insert mechanical key (4) in side opening (5) to open Change batteries (7), inserting new ones under contact spring (8) with plus (+) side facing up. latch. Press briefly (do not use mechanical key as lever) to release battery compartment. Return battery compartment into housing until locked Remove mechanical key from side opening.
Page 351: Synchronizing Remote Control
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Emergency engine shut-down Important! Emergency engine shut-down Batteries contain materials that can harm the If the engine can no longer be stopped using the environment if disposed of improperly. Recycling of electronic key, the engine can be turned off by removing batteries is the preferred method of disposal.
Page 352: Fuel Filler Flap, Manual Release
Fuel filler flap, manual release Emergency operation of sliding/pop-up roof Press button (1) and fold down trim panel (2). The sliding/pop-up roof can be opened or closed manually should an electrical malfunction occur. Reach inside through opening (3) and turn release knob (4) clockwise (arrow).
Page 353 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Emergency operation of sliding / pop-up roof Slide both locking tabs (2) in direction of arrow, lower Obtain crank (3) (supplied with vehicle) and insert rear of cover and remove.
Page 354: Replacing Wiper Blade Insert
Replacing wiper blade inserts For safety reasons, remove electronic key from starter switch before replacing the wiper blades, otherwise the motor can suddenly turn on and cause injury. Notes: Do not open engine hood with wiper arm folded forward. Do not allow the wiper arm to contact the windshield glass without a wiper blade inserted.
Page 355: Roof Rack
Replacing wiper blade insert Roof rack Attach the roof rack only to the roof rails. Use only those roof racks approved by Mercedes-Benz to avoid damage to the vehicle. Follow manufacturer’s installation instructions. Place wiper blade on firm support. Press down both tabs and slide (direction of arrow) the wiper blade insert out of the retainer claws.
Page 356 Vehicle care Vehicle washing ......356 Cup holder ........358 Ornamental moldings ....357 Seat belts ........359 Cleaning and care of the vehicle .354 Headlamps, taillamps, Headliner and Power washer ......355 turn signal lenses ...... 357 shelf below rear window ...359 Tar stains ........355 Window cleaning .......
Page 357: Cleaning And Care Of The Vehicle
Post-production treatment is neither necessary nor recommended by Mercedes-Benz Such damage is caused not only by extreme and varying because of the possibility of incompatibility between...
Page 358: Power Washer
The following topics deal with the cleaning and care of Paintwork, painted body components your vehicle and give important “how-to” information as well as references to Mercedes-Benz approved car-care Mercedes-Benz approved Paint Care should be applied products. when water drops on the paint surface do not “bead up”,...
Page 359: Engine Cleaning
Use only a mild car wash detergent, such as intrusion of water and cleaning agents. Mercedes-Benz approved Car Shampoo. Corrosion protection, such as MB Anticorrosion Wax Thoroughly spray the vehicle with a diffused jet of should be applied to the engine compartment after water.
Page 360: Ornamental Moldings
Note: Headlamps, taillamps, turn signal lenses For safety reasons, switch off wipers and remove Use a mild car wash detergent, such as Mercedes-Benz electronic key from starter switch before cleaning the approved Car Shampoo, with plenty of water. windshield, otherwise the wiper motor can suddenly To prevent scratches, never apply strong force and use turn on and cause injury.
Page 361: Light Alloy Wheels
Cleaning and care of the vehicle Light alloy wheels Instrument cluster Mercedes-Benz approved Wheel Care should be used for Use a gentle dishwashing detergent or mild detergent regular cleaning of the light alloy wheels. for delicate fabrics as a washing solution. Wipe with a cloth moistened in lukewarm solution.
Page 362: Seat Belts
Clean with soft bristle brush, or use a dry-shampoo MB Tex Upholstery cleaner in case of excessive dirt. Pour Mercedes-Benz approved Interior Care onto soft lint-free cloth and apply with light pressure. Hard plastic trim items Pour Mercedes-Benz approved Interior Care onto soft lint-free cloth and apply with light pressure.
Page 364 Technical data Engine oil additives ...... 370 Air conditioner refrigerant ..370 Spare parts service ......362 Brake fluid ........370 Warranty coverage ......362 Premium unleaded gasoline ..371 Identification labels .......363 Fuel requirements ......371 Layout of poly-V-belt drive ....364 Gasoline additives ......372 Technical data ........365 Coolants ..........
Page 365: Spare Parts Service
Replacement parts and accessories are covered by the Mercedes-Benz Spare Parts and Accessories warranties, Important! copies of which are available at any Mercedes-Benz The use of non-genuine parts and accessories not Center. authorized by Mercedes-Benz could damage the vehicle...
Page 366: Identification Labels
Identification labels Certification label Vehicle Identification Number (VIN) (below right front passenger seat) Technical data Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data...
Page 367: Layout Of Poly-V-Belt Drive
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Technical data Layout of poly-V-belt drive P01.00-2220-26 VIN, visible (lower edge of windshield) Automatic belt tensioner Engine number Crankshaft Emission control label Air conditioner compressor Information label, California version Generator (alternator) Vacuum line routing for emission control system...
Page 368: Technical Data
Maximum engine speed 6000 rpm Firing order 1-4-3-6-2-5 Poly-V-belt 2390 mm 1 The quoted data apply only to the standard vehicle. See an authorized Mercedes-Benz Center for the corresponding data of all special bodies and special equipment. Technical data Instruments Instrument Technical...
Page 369 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Technical data Rims — Tires Electrical system Model C 320 (203.264) Model C 320 (203.264) Rims (light alloy) 7J x 16 H2 Generator (alternator) 14 V/120 A Wheel offset: 1.46 in (37 mm) Starter motor...
Page 370 Main Dimensions Model C 320 (203.264) Overall vehicle length 178.9 in (4543 mm) Overall vehicle width 68.0 in (1728 mm) Overall vehicle height 57.7 in (1466 mm) Wheel base 106.9 in (2715 mm) Track, front 58.8 in (1493 mm) Track, rear 57.6 in (1464 mm) Technical data Instruments...
Page 371: Fuels, Coolants, Lubricants Etc. - Capacities
Fuels, coolants, lubricants etc. - capacities Vehicle components and their respective lubricants must match. Therefore use only brands tested and recommended by us. Please refer to the Factory Approved Service Products pamphlet, or inquire at your Mercedes-Benz Center. Capacity Fuels, coolants, lubricants etc.
Page 372 Capacity Fuels, coolants, lubricants etc. Air conditioner system R-134a refrigerant and special PAG lubricant (Never R-12) Windshield washer and Vehicles without headlamp MB Windshield washer concentrate headlamp cleaning system cleaning system: Capacity approx. 3.2 US qt (3.0 l) Vehicles with headlamp cleaning system: Capacity approx.
Page 373: Engine Oils
Damage or malfunctions resulting from blending oil It is recommended to use only brake fluid approved by additives are not covered by the Mercedes-Benz Limited Mercedes-Benz. Your authorized Mercedes-Benz Warranty. Center will provide you with additional information.
Page 374: Premium Unleaded Gasoline
Premium unleaded gasoline Fuel requirements Use only Premium unleaded meeting ASTM Caution! standard D 439: To maintain the engine’s durability and performance, The octane number (posted at the pump) must be premium unleaded gasoline must be used. If premium 91 min. It is an average of both the Research (R) octane unleaded is not available and low octane fuel is used, number and the Motor (M) octane number: (R+M)/2).
Page 375: Gasoline Additives
Gasoline additives Coolants A major concern among engine manufacturers is carbon The engine coolant is a mixture of water and build up caused by gasoline. Mercedes-Benz anticorrosion/antifreeze, which provides: recommends the use of only quality gasoline containing • corrosion protection, additives that prevent the build up of carbon deposits.
Page 376 If the coolant level is low, water and MB anticorrosion/ your vehicle to your authorized Mercedes-Benz Center antifreeze should be used to bring it up to the proper for service.
Page 377: Consumer Information
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Consumer information Consumer information may depart significantly from the norm due to variations in driving habits, service practices and This has been prepared as required of all manufactures differences in road characteristics and climate.
Page 378 Temperature Warning! The temperature grades are A (the highest), B, and C, The temperature grade for this tire is established representing the tire‘s resistance to the generation of for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or heat and its ability to dissipate heat when tested under excessive loading, either separately or in controlled conditions on a specified indoor laboratory...
Page 379: Index
Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Index Index Audio systems ..............102 Cassette player ............104 CD Player ..............103 Radio ................102 Automatic central locking ..........39 Adding engine oil ............314 Automatic climate control ..........148 Airbags ................
Page 380 General notes ...............30 Locking and unlocking with remote control ..33 BabySmart airbag deactivation system ..... 64 Mechanical keys ............35 Battery ................330 Obtaining replacement keys ........29 Block heater ..............262 Summer opening/convenience feature ....34 Brake assist system (BAS) ..........267 Vehicle keys ..............28 Bulbs Check regularly and before a long trip .......276 See Replacing bulbs ..........339...
Page 381 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Index Emergency unlocking the tailgate ......... 41 Engine oil consumption ..........136 Dashboard .................22 Engine oil level indicator ..........135 Door control panel ............20 Express opening and closing Door entry lamps ............
Page 382 First aid kit ..............306 Hazard warning flasher switch ........147 Flat tire Head restraints See Changing wheels ..........324 Rear seat ...............53 Flexible service system (FSS) ........132 Head restraints, front seats Front airbags ..............67 Removal and installation ...........50 Front center console storage Headlamp cleaning system ...........
Page 383 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Index Information call See Tele Aid ...............228 Lamps, exterior Instrument cluster ............92 Side marker lamp, front .......... 344 Instruments and controls ..........18 Lighter ................202 Center console .............24 Loading instructions ............
Page 384 Multifunction display ............96 Coolant temperature ..........100 Panic button ..............35 Engine oil level indicator ......... 100 Parcel net in front passenger footwell ....... 203 FSS ................100 Parcel net in trunk ............208 Individual settings .............115 Parking brake ..............252 Tire inflation pressure monitor ......
Page 385 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Index Replacement keys Selective locking Obtaining ..............29 See Central locking system ........31 Replacing bulbs ..............339 Setting the audio volume ..........130 Replacing wiper blade insert ........351 Side impact airbags ............70 Reporting Safety Defects ..........
Page 386 Storage compartment under trunk floor ....209 Telephone, general ............220 Storage compartments and armrests ......194 Telephones and two-way radios ........226 Storing mirror positions ..........85 The first 1 000 miles (1 500 km) ....... 227 Storing seat positions ............48 Tire inflation pressure ..........
Page 387 Instruments Instrument Technical Operation Driving Practical hints Car care Index and controls cluster display data Index Warning lamps See Malfunction and indicator lamps in the instrument cluster ........278 What you should know at the gas station ....274 Wheels ................321 Where to find it ..............
Page 388: Service And Literature
If you have any question about carrying out some service, turn to the advice of an authorized Mercedes-Benz Center.
Page 389 Order No. 6515 0088 13 Part No. 203 584 21 96 USA Edition B 2002...
Page 390 OOKSPINE for Operator’s Manual in. (1.6 cm) 3.5“ (8.9 cm) Operator’s Manual C-Class Please ensure the correct position of model code and model name...

Mercedes-Benz 2002 C 320 Owner's Manual

Introduction

Instruments and Controls

Operation

Driving

Instrument Cluster Display

Practical Hints

Vehicle Care

Technical Data

Quick Links

Related Manuals for Mercedes-Benz 2002 C 320

Summary of Contents for Mercedes-Benz 2002 C 320
