Summary of Contents for Volvo 2001 V70

Page 1 This manual deals with the operation and care of your Volvo. Welcome to the worldwide family of Volvo owners. We trust that you will enjoy many years of safe driving in your Volvo, an automobile designed with your safety and comfort in mind. To help ensure your satisfaction with this vehicle, we encourage you to familiarize yourself with the equipment descriptions, operating instructions and maintenance requirements/ recommendations in this manual.
Page 2 2001 Volvo V70 Contents Chapter 1 - Safety Chapter 2 - Instruments, switches and controls Chapter 3 - Climate control system Chapter 4 - Interior Chapter 5 - Keys, Locks, Alarm Chapter 6 - Starting and driving Chapter 7 - Wheels and tires...
Page 3 Volvo and the environment Volvo is committed to the well being of our customers. As a natural part of this commitment, we care about the environment in which we all live. Caring for the environment means an everyday involvement in reducing our environmental impact.
Page 4 For additional information regarding the environmental activities in which Volvo Cars of North America, Inc. and Volvo Car Corporation are involved, visit our Internet Home Page at: http://www.volvocars.com Top of Page...
Page 5: Table Of Contents
Volvo also believes no child should sit in the front seat of a car.
Page 6 2001 VOLVO V70 To buckle: Pull the belt out far enough to insert the latch plate into the receptacle until a distinct click is heard. The seat belt retractor is normally "unlocked" and you can move freely, provided that the shoulder belt is not pulled out too far. The...
Page 7: Center Head Restraint
Never repair the belt on your own; have this work done by an authorized Volvo retailer only. Any device used to induce slack into the shoulder belt portion of the three-point belt system will have a detrimental effect on the amount of protection available to you in the event of a collision.
Page 8 As an enhancement to the three-point seat belt system, your Volvo is equipped with a Supplemental Restraint System (SRS). The Volvo SRS consists of an airbag (2) on both the driver's and passenger's sides and seat belt tensioners in both front door pillars (4). The system is designed to supplement the protection provided by the three-point seat belt system.
Page 9 There is no maintenance to perform on the SRS yourself. The month and year shown on the decal on the door pillar indicate when you should contact your Volvo retailer for specific servicing or replacement of airbags and seat belt tensioners.
Page 10 2001 VOLVO V70 Rockleigh, New Jersey 07647-0914 800-663-8255 800-458-1552 pg. 6 Front airbags - SRS WARNING! Do not use child safety seats or child booster cushions/backrests in the front passenger's seat. We also recommend that occupants under 4 feet 7 inches (140 cm) in height who have outgrown these devices sit in the rear seat with the seat belt fastened.
Page 11 Collisions can occur where only one of the airbags deploys. NOTE: Volvo's dual-stage air bags:If the impact is less severe, but severe enough to present a clear injury risk, the dual-stage airbags are triggered at just 70% of its total capacity. If the impact is more severe, the dual-stage airbags are triggered with full capacity.
Page 12: Side Impact Airbags (Sips)
Seat belts - the heart of the Volvo safety system The heart of the Volvo safety system is the three-point seat belt (a Volvo invention)! In order for the SRS system to provide the protection intended, seat belts must be worn at all times by everyone in the car. The SRS system is a supplement to the seat belts.
Page 13 This may cause airbag deployment which could result in personal injury. Have the car towed to an authorized Volvo retailer for repairs. pg. 9 Volvo Inflatable Curtain (VIC)
Page 14: Volvo Inflatable Curtain (Vic)
The IC system is a supplement to the Side Impact Protection System. It is not designed to deploy during collisions from the front or rear of the car or in most rollover situations. Never try to open or repair any components of the IC system. This should be done only by an authorized Volvo service technician.
Page 15: Whiplash Protection System (Whips)
If your car has been involved in a collision, the front seat backrests must be inspected by an authorized Volvo retailer even if the seats appear to be undamaged. Certain components in the WHIPS system may need to be replaced.
Page 16 2001 VOLVO V70 Contents Top of Page http://new.volvocars.com/ownersdocs/2001/2001_V70/01v70_01a.htm[4/4/2013 10:38:06 PM]...
Page 17: Instruments, Switches And Controls
2001 VOLVO V70 2 0 0 1 VOLVO Chapter 2 - Instruments, switches and controls pg. 21 Instruments, switches and controls Interior 22 Exterior 23 Instruments 24 Instrument panel 25 Indicator and warning lights 26 Text information window 28 Switches in the center console 29...
Page 18 2001 VOLVO V70 pg. 23 Instruments, switches and controls pg. 24 Instruments, switches and controls http://new.volvocars.com/ownersdocs/2001/2001_V70/01v70_02a.htm[4/4/2013 10:38:21 PM]...
Page 19 2001 VOLVO V70 pg. 25 Instruments, switches and controls 1 Turn signals 2 Text window 3 Temperature gauge The pointer should be approximately midway on the gauge when driving. Do not drive the car if the warning light is on. The text window will provide you with additional information.
Page 20 2001 VOLVO V70 8 High beam indicator light 9 Tachometer Indicates engine speed in thousands of rpm. Do not drive for long with the needle in the red section. The engine has an built-in function preventing too high an engine speed. When this function operates, you may discern some pulsation, which in that case is quite normal.
Page 21: Oil Pressure Warning Light
130. If the light stays on after restart, have the car towed to the nearest authorized Volvo retailer. After hard driving, the light may come on occasionally when the engine is idling. This is normal, provided it goes off when the engine speed is increased.
Page 22: Rear Fog Light
If the light comes on (or stays on after the vehicle has started), the engine diagnostic system has detected a possible fault in the emission control system. Although driveability may not be affected, see an authorized Volvo retailer as soon as possible for inspection. Canadian models are equipped with this warning light: NOTE: If the fuel filler cap is not closed tightly or if the engine is running when the is refueled, the Malfunction Indicator Lamp may indicate a fault.
Page 23 STOP SAFELY ASAP: Stop and switch off the engine - to help prevent serious risk of damage. SERVICE URGENT: Take your car to an authorized Volvo retailer for inspection as soon as possible. SERVICE REQUIRED: Take your car to an authorized Volvo retailer for inspection at your convenience (but preferably before the next scheduled maintenance service).
Page 24 This 12 volt socket can be used to plug in certain accessories such as cellular telephones, etc. The ignition key must be in position 1 (or higher) for the auxiliary socket to function. NOTE: The auxiliary sockets can also be used for cigarette lighters, which are available at your Volvo retailer. WARNING! Please be aware that the car's handling characteristics may be affected if Dynamic Stability Traction Control (DSTC) is switched off.
Page 25: Trip Computer
2001 VOLVO V70 pg. 30 Instruments, switches and controls Trip computer The trip computer stores information gathered from several systems in your car and has four menus that can be displayed in the text window. Driving distance on current fuel reserve...
Page 26 2001 VOLVO V70 Contents Top of Page http://new.volvocars.com/ownersdocs/2001/2001_V70/01v70_02a.htm[4/4/2013 10:38:21 PM]...
Page 27: Climate Control System
2001 VOLVO V70 2 0 0 1 VOLVO Chapter 3 - Climate control system pg. 41 Climate control system Ventilation 42 Climate control system - general information 43 Electronic Climate Control (ECC) 44 pg. 42 Ventilation Air vents (dash) A Open...
Page 28: Air Flow
2001 VOLVO V70 Air flow The air that is drawn into the passenger compartment is distributed from 14 ventilation points. Air vents in door pillars A Open B Closed C Horizontal air flow D Vertical air flow Direct the air vents toward the rear side windows to demist.
Page 29: Cabin Air Filter
The air conditioning is momentarily disengaged during full-throttle acceleration. ECC maintenance All maintenance on the climate control systems should be carried out by an authorized Volvo service technician only. Refrigerant Volvo cares about the environment. The air conditioning system in your car contains a CFC-free refrigerant - R134a.
Page 30 2001 VOLVO V70 pg. 45 Electronic Climate Control (ECC) AUTO This function automatically regulates the Electronic Climate Control system so that the selected temperatures are maintained. The blower, heating, air distribution (air flow) and air conditioning are controlled. If you prefer to manually set any of these functions, the remaining functions will still be controlled automatically.
Page 31: Interior
2001 VOLVO V70 Heated rear window/sideview mirrors This function demists/de-ices the rear window and sideview mirrors. The LED in the switch will light up to indicate that the heating function is engaged. See page 36 for additional information on this function.
Page 32 2001 VOLVO V70 Press AUTO to automatically regulate air flow or press any combination of the controls shown in the illustration to manually adjust air flow. An LED in the switch will light up if an air flow control has been pressed.
Page 33 2001 VOLVO V70 Press to activate the Air quality sensor (normal setting). Or select one of three functions by pressing 1. Press : the LED AUT comes on. The Air quality sensor is now activated. 2. Press 3. Press : the LED MAN comes on. Recirculation is now activated.
Page 34 2001 VOLVO V70 2 0 0 1 VOLVO Chapter 4 - Interior pg. 49 Interior Front seats 50 Interior lighting 52 Storage compartments 53 Storage compartment, front/Vanity mirrors 54 Rear seat and cargo area 57 Spare tire 66 pg. 50 Front seats...
Page 35 2001 VOLVO V70 Electrically operated seats with memory function * WARNING! Because the driver's seat can be adjusted with the ignition off, children should never be left unattended in the car. Movement of the seat can be STOPPED at any time by pressing any button on the power seat control panel.
Page 36 2001 VOLVO V70 The passenger's seat can only be adjusted if the ignition key is in position I or II (see page 50). Driver's seat: The driver's seat can be adjusted if the ignition key is in position I or II (see page 50).
Page 37: Courtesy Light
The light may be switched off at any time by pressing the center button a second time. The courtesy light timer periods can be changed. Consult your Volvo retailer. Overriding the Interior Courtesy Lights Normally if a car door is left open with the engine turned off, the interior courtesy light will stay on for 10 minutes.
Page 38: Cup Holders
2001 VOLVO V70 Reading lights - front/rear The reading lights can be switched on or off by pressing the respective buttons. These lights switch off automatically after 10 minutes if the engine is not running. If the engine is running, the lights stay on indefinitely. The lights can be switched off at any time by pressing the button.
Page 39: Cup Holder
2001 VOLVO V70 Some models are equipped with cup holders for the front and rear seat occupants. You can also use the center console's storage compartment for cassette tapes, CD's etc. Coin compartment (option) To remove the coin compartment: Press the middle of the compartment while pulling it straight up.
Page 40: Vanity Mirrors
The side panel on the passenger side of your car has an opening for various accessories. You must pry off its cover before you can use it. You can fit a hook for a handbag, waste bin, tray for personal effects etc. Consult your Volvo retailer.
Page 41: Coat Hanger
2001 VOLVO V70 Coat hanger Use the coat hanger for clothes of normal weight. pg. 56 Waste bin, Folding Table in rear seat Waste bin / bottle holder in rear seat To change the waste bag: Open the holder. Using both hands, press out the lower part of the holder.
Page 42 2001 VOLVO V70 The waste bin can also be used as a holder for larger bottles, containers etc. NOTE: For safety's sake, never use glass bottles anywhere in the car. Folding Table (option) Pull the tab and fold the table section forward.
Page 43: Keys, Locks, Alarm
2001 VOLVO V70 2 0 0 1 VOLVO Chapter 5 - Keys, Locks, Alarm pg. 69 Keys, Locks, Alarm Keys, Exterior courtesy lights, Locking and unlocking the car 70 Remote keyless entry system 71 Unlocking the tailgate, Central locking buttons, "Trunk lock" function 73...
Page 44 The headlights, parking lights, license plate lights and the lights in the sideview mirrors will now come on and remain on for 30, 60 or 90 seconds (the time interval is at your discretion and can be changed by an authorized Volvo retailer).
Page 45: Remote Keyless Entry System
As an extra security precaution in certain situations (valet parking, etc.), Volvo recommends that the transmitter not be included when the keys are given to anyone. The service key can be used instead. If one of the transmitters is misplaced, contact your nearest authorized Volvo retailer for assistance.
Page 46 WARNING! Volvo does not recommend using the transmitter to lock the doors from inside the car. The alarm would be activated and would sound when one of the doors is opened. The doors must not be locked using the remote transmitter while the vehicle is occupied.
Page 47 2001 VOLVO V70 Unlocking the tailgate The tailgate lock is incorporated in the central locking system and is locked or unlocked when the driver's door is locked/unlocked. The tailgate can be unlocked by: Pressing UNLOCK on the remote control twice.
Page 48: Arming The Alarm
2001 VOLVO V70 Alarm The alarm is automatically armed whenever you lock your car. When armed, the alarm continuously monitors a number of points on the car. The following conditions will set off the alarm: The hood is forced open.
Page 49 LED flashes rapidly before the ignition is switched on - the alarm has been triggered Fault in the alarm system: If a fault has been detected in the alarm system, a message will be displayed in the text window. Contact a Volvo retailer. Automatic re-lock/re-arm system If the car is unlocked with the remote, the car will re-lock and the alarm will re-arm after 2 minutes unless a door or the tailgate has been opened.
Page 50 2001 VOLVO V70 Child safety locks - rear doors The controls are located on the rear door jambs. Use a screwdriver to adjust these controls. A The door cannot be opened from the inside. Normal operation from the outside. B The door lock functions normally.
Page 51: Fuel Requirements
2001 VOLVO V70 2 0 0 1 VOLVO Chapter 6 - Starting and driving pg. 77 Starting and driving Fuel requirements 78 Refueling 79 Starting the engine 80 Manual transmission 81 Automatic transmission (AW5) 82 Automatic transmission (Geartronic) 84 Driving economy 86...
Page 52 To meet seasonal air quality standards, some areas require the use of "oxygenated" fuel. Volvo allows the use of the following "oxygenated fuels; however, the octane ratings listed on this page must still be met.
Page 53: Refueling
* If the fuel filler cap is not closed tightly or if the engine is running when the car is refueled, the Check Engine light (malfunction indicator lamp) may indicate a fault. However, your vehicle's performance will not be affected. Use only Volvo original or approved fuel filler caps. pg. 80 Starting the engine...
Page 54: Starting The Engine
2001 VOLVO V70 Starting the engine 1. Fasten the seat belt. WARNING! Before starting, check that the seat, steering wheel and mirrors adjusted properly. Make sure the brake pedal can be depressed completely. Adjust the seat if necessary. See page 50.
Page 55: Manual Transmission
2001 VOLVO V70 If two of the keys to your car are close together, e.g., on the same key ring, when you try to start the car, this could cause interference in the immobilizer system and result in the car not starting. If this should occur, remove one of the keys from the key ring before trying to start the car again.
Page 56: Automatic Transmission Aw5
2001 VOLVO V70 WARNING! An extra mat on the driver's floor can cause the accelerator pedal and the clutch to catch. Check that the movement of the accelerator pedal and clutch is not impeded. Not more than one protective floor covering may be used at one time.
Page 57 2001 VOLVO V70 transmission will automatically switch to neutral. The transmission will automatically return to Drive when the brake pedal is released. This function has been added to help reduce emissions. 4 (Intermediate gear) The transmission will shift automatically between gears 4, 3, 2 or 1 from this position. The transmission cannot shift up to (D)rive from fourth gear.
Page 58: Automatic Transmission (Geartronic)
2001 VOLVO V70 Depressing the button on the front of the gear selector knob enables you to move the gear selector to positions P, R, N, D, 4, 3 and L. W Winter/Wet driving mode -enhanced vehicle traction Mode W will only function if the gear selector is in the (D)rive position.
Page 59 2001 VOLVO V70 WARNING! Never leave the car unattended when the engine is running. If, by mistake, the gear selector is moved from P, the car may start moving. R (Reverse) Never engage R while the car is moving forward.
Page 60: Driving Economy
2001 VOLVO V70 pg. 85 Automatic transmission (Geartronic) Manual shifting - Geartronic You can move the gear selector freely between the (MAN)ual and (D)rive positions while driving. Gears 2, 3, and 4 have a "lock-up" function which reduces engine speed and helps save fuel. The currently selected gear will be...
Page 61: Points To Remember
2001 VOLVO V70 your vehicle to immediate traffic conditions. Observe the following rules: Bring the engine to normal operating temperature as soon as possible by driving with a light foot on the accelerator pedal for the first few minutes of operation. A cold engine uses more fuel and is subject to increased wear.
Page 62 2001 VOLVO V70 Stopping the engine suddenly after high speed driving (so-called "after-boiling" can occur). To avoid overheating, the following rules should be followed: Do not drive for prolonged periods at engine speeds above 4500 rpm if you are towing a trailer in hilly terrain. Reduce speed when towing a trailer up long, steep inclines.
Page 63: Roof Racks/Load Carriers
88 Roof racks/Load carriers Load carriers (accessory) Load carriers are available as Volvo accessories. Observe the following points when in use: To avoid damaging your car and to achieve maximum safety when driving, we recommend using the load carriers that Volvo has developed especially for your car.
Page 64 2001 VOLVO V70 Position of load carriers Make sure that the wing-shaped load carriers are installed on the roof rails with the rounded edge forward (see the inset illustration above). The load carriers are identical and can be placed anywhere along the roof rails.
Page 65 2001 VOLVO V70 Contents Top of Page http://new.volvocars.com/ownersdocs/2001/2001_V70/01v70_06a.htm[4/4/2013 10:38:53 PM]...
Page 66: Wheels And Tires
2001 VOLVO V70 2 0 0 1 VOLVO Chapter 7 - Wheels and tires pg. 99 Wheels and tires General information, Wear indicator, Tire economy, Flat spots 100 Wheels and tires - All Wheel Drive vehicles 101 Snow chains, Snow tires/studded tires 102...
Page 67: Types Of Tires
Unbalanced wheels impair tire economy and driving comfort. Volvo does not recommend rotating the tires. However, if tires are rotated, they must be kept on the same side of the car so that they revolve in the same direction as before rotation.
Page 68: Tire Replacement
2001 VOLVO V70 Tire Replacement When tire replacement is necessary, Volvo strongly recommends replacing all four tires at the same time with identical tires as explained above. Failure to do so can result in a circumference difference that may damage the transmission and all-wheel-drive system.
Page 69 Failure to do so could reduce traction to an unsafe level or adversely affect handling. Volvo does not recommend tire rotation. However, as with any other radial tires, if rotated, the tires must be kept on the same side of the car so that they revolve in the same direction as before rotation.
Page 70: Vehicle Loading
Vehicle loading The tires on your Volvo should perform to specifications at all normal loads when inflated as recommended on the tire informa-tion label. The label is located on the inside of the fuel filler door. The label lists both tire and vehicle design limits.
Page 71: Changing Wheels
2001 VOLVO V70 The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified govern-ment test course. For example, a tire graded 150 would wear one and one half (1 1/2) times as well on the government course as a tire graded 100.
Page 72 2001 VOLVO V70 Engage the parking brake. Put the gear selector in (P)ark. Remove the wheel cap (where applicable) using the lug wrench in the tool kit. With the car still on the ground, use the lug wrench to loosen the wheel bolts 1/2 - 1 turn. Turn the bolts counterclockwise to loosen.
Page 73 2001 VOLVO V70 NOTE: To avoid excessive wear and the necessity of rebalancing, mark and reinstall wheels in the same location and position as before removal. To lessen the chance of imbalance, each wheel hub is equipped with a guide stud to ensure that a removed wheel can be reinstalled in its original position (as when changing over to winter tires/wheels).
Page 74: Fuses
2001 VOLVO V70 2 0 0 1 VOLVO Chapter 8 - Maintenance/Servicing pg. 107 Maintenance/Servicing Fuses 108 Replacing bulbs 112 Paint touch up 118 Washing the car 119 Cleaning the upholstery 120 Maintenance service, Warranty 121 Maintenance schedule 122 Fuel/emissions systems 124...
Page 75: Replacing Fuses
If so, put in a new fuse of the same color and amperage (written on the fuse). Spare fuses are stored in the fuse box in the passenger compartment. If fuses burn out repeatedly, have the electrical system inspected by an authorized Volvo retailer. pg. 109 Fuses in the engine compartment...
Page 76 2001 VOLVO V70 10 Tailgate wiper 11 AC compressor, Ignition coils 12 Brake light switch 13 Windshield wipers 14 ABS 15 - 16 Windshield and headlight washers 17 Low beam 18 High beam 19 ABS 20 - 21 - 22 Starter motor...
Page 77 2001 VOLVO V70 11 Right high beam 12 Headlight wipers 13 Electric socket 12 V 14 Power passenger's seat 15 Audio system 16 Audio system 17 Radio amplifier 18 Front fog lights 19 VNS display (option) 20 Transport switch 21 Transmission module...
Page 78: Replacing Bulbs
2001 VOLVO V70 Ordinary fuses Location Amperage 1 Rear electrical module, Lighting cargo area 2 Rear fog light 3 Brake lights 4 Backup lights 5 Rear window heater, Relay 151 6 Opening tailgate, Unlocking tailgate 7 Auxiliary 12 volt socket in cargo area (option) 15A...
Page 79 Reinstall the plastic cover and turn it clockwise until it is correctly in place (4). "TOP" must be upward. NOTE: If the vertical aim of your headlights needs to be adjusted for any reason (e.g., towing a trailer for extended periods), this should be done by an authorized Volvo retailer. http://new.volvocars.com/ownersdocs/2001/2001_V70/01v70_08a.htm[4/4/2013 10:39:05 PM]...
Page 80 2001 VOLVO V70 pg. 113 Replacing bulbs To remove and install a high beam bulb (HB3): Switch off all lights and turn the ignition switch to position 0. Open the hood. Remove the cover by twisting it counter-clockwise. Twist the bulb holder counterclockwise, pull it out and fit a new bulb. Note its position.
Page 81 2001 VOLVO V70 Changing the bulb in the turn signals at the front corners Switch off all lights and turn ignition key to position 0. Pull out the bulb and its socket by twisting counterclockwise. Replace bulb. Press the bulb and its socket back into place.
Page 82 2001 VOLVO V70 Replacement of rear turn signal and brake light bulbs Switch off all lights and turn the ignition switch to position 0. Using a screwdriver, carefully pry off the speaker grille. Pull out the red tab in the speaker.
Page 83: License Plate Lights
2001 VOLVO V70 Side direction indicator Open the front door halfway. From the inside of the fender, push the lamp housing out. Turn the bulb holder 1/4 turn counter-clockwise and pull it out from the lens. Remove the defective bulb by pulling it straight out.
Page 84: Vanity Mirror Lights
2001 VOLVO V70 Door step courtesy lights The door step courtesy lights are located under the dash on the driver's and passenger's sides. To replace a bulb: Carefully insert a screwdriver and pry out the lens. Replace the defective bulb.
Page 85: Paint Touch Up
These bulbs may be difficult for you to replace yourself. We recommend that you let an authorized Volvo retailer replace these bulbs if necessary. NOTE: Other bulbs may be difficult for you to replace yourself. Let an authorized Volvo retailer replace these bulbs if necessary.
Page 86: Washing The Car
2001 VOLVO V70 Minor scratches on the surface If the stone chip has not penetrated down to the metal and an undamaged layer of paint remains, the touch-up paint can be applied as soon as the spot has been cleaned.
Page 87: Polishing And Waxing
Leather upholstery/suede-like upholstery (alcanteraª) can be cleaned with a soft cloth and mild soap solution. For more difficult spots, Volvo offers a leather care kit. Under no circumstances should gasoline, naphtha or similar cleaning agents be used on the plastic or the...
Page 88: Maintenance Service, Warranty
121 Maintenance service, Warranty Maintenance service Volvo advises you to follow the service program outlined in the Warranty and Service Records Information booklet. This maintenance program contains inspections and services necessary for the proper function of your car. The maintenance services contain several checks which require special instruments and tools and therefore must be performed by a qualified technician.
Page 89: Maintenance Schedule
2001 VOLVO V70 Corrosion Protection Limited Warranty Seat Belt and Supplemental Restraint Systems Limited Warranty Emission Design and Defect Warranty Emission Performance Warranty These are the Federal warranties; other warranties are provided as required by state law. Refer to your separate Warranty and Service Records Information booklet for detailed information concerning each of the warranties.
Page 90 2001 VOLVO V70 R = Replace I = Inspect (Correct or Replace if necessary) L = Lubricate Maintenance Operation thousand miles 7.5 15 22.5 30 37.5 45 52.5 60 67.5 75 82.5 (thousand km) (12) (24) (36) (48) (60) (72) (84) (96) (108) (120) (132) (144)
Page 91 6 Federal Motor Vehicle Safety Stan-dards (FMVSS) specifications (USA) and Ministry of Transport (CMVSS) standards (Canada) Your Volvo is designed to meet all applicable safety standards, as evidenced by the certification label on the facing side of the driver's door. For further informa-tion regarding these regulations, please consult your Volvo retailer.
Page 92 2001 VOLVO V70 * The Vehicle Identification Number (VIN) should always be quoted in all correspondence concerning your vehicle with the retailer and when ordering parts. All specifications are subject to change without prior notice. pg. 137 Dimensions and weights Dimensions Length 185.4 in.
Page 93: Engine Specifications
** The max permissible axle loads or the gross vehicle weight must not be exceeded. pg. 138 Engine/transmission specifications Engine specifications Designation: Volvo B 5234 T3 Output 247 hp at 5200 rpm (184 kW/87 rps) Max. torque 243 ft. lbs. at 2400-5200 rpm (330 Nm/42-87 rps) Number of cylinders 5 Bore 3.19"...
Page 94 3rd gear 1.19:1 4th gear 0.87:1 5th gear 0.70:1 Reverse 3.30:1 Designation: Volvo B 5244 T3 Output 197 hp at 6000 rpm (147 kW/100 rps) Max. torque 210 ft. lbs. at 1800-5000 rpm (285 Nm/30-83 rps) Number of cylinders 5 Bore 3.27"...
Page 95: Engine Oil
Engine Oil Meeting or exceeding ILSAC specification GF-2, including ACEA A1, API SJ, SJ/CF, and SJ/Energy Conserving. Oil additives must not be used unless advised by an authorized Volvo retailer. Volume: Capacity (including oil filter): 6.1 US qts. (5.8 liters) Capacity (including oil filter and oil cooler): 7.1 US qts.
Page 96: Fuel System
2001 VOLVO V70 All specifications are subject to change without prior notice. pg. 140 Fuel system, Distributor ignition system, Suspension Fuel system The engine is equipped with a multiport fuel injection system. Distributor ignition system Firing order: 1-2-4-5-3 Electronic ignition setting: Not adjustable Spark plugs: Champion RC8PYP 8 (or equivalent) Spark plug gap: 0.028-0.032"...
Page 97 Battery Voltage: 12 Volt, capacity: 600 A/115 min reserve capacity. The battery contains corrosive and poisonous acids. It is of the utmost importance that old batteries are disposed of correctly. Your Volvo retailer can assist you in this matter. Generator Rated output: max.
Page 98 These professional mechanics are fully able to analyze vehicle problems and perform the necessary service procedures to keep your Volvo at peak operating condition.
Page 99 2001 VOLVO V70 Contents Top of Page http://new.volvocars.com/ownersdocs/2001/2001_V70/01v70_09.htm[4/4/2013 10:39:07 PM]...
Page 100: Audio Systems
2001 VOLVO V70 2 0 0 1 VOLVO Chapter 10 - Audio systems pg. 143 Audio systems HU-413 overview 144 HU-613 overview 145 HU-803 overview 146 Functions 147 Specifications 159 General information 160 pg. 144 Audio system HU-413 - overview 1.
Page 101 2001 VOLVO V70 6. Cassette eject 7. Selector knob for: Stored radio frequencies CD changer - selecting disc 8. Cassette opening 9. Tape direction selector CD random play 10. On/off - press Volume - turn 11. Bass - press and turn Treble - press, pull and turn 12.
Page 102 2001 VOLVO V70 8. CD slot 9. CD random play 10. Active Sound Control (ON or OFF) 11. Scan function 12. Dolby B Noise Reduction 13. Automatic presetting of radio stations 14. Bass - press and turn Treble - press, pull and turn 15.
Page 103: Volume Control
2001 VOLVO V70 11. 2 channel stereo 12 3 channel stereo 13. CD slot 14. CD random play 15. Program type 16. News 17. Traffic information 18. Automatic presetting of radio stations 19. Display pg. 147 Audio systems HU-413/HU-613/HU-803 Switch on/off Press the knob to switch on or turn off the radio.
Page 104 2001 VOLVO V70 Band selector Turn "SOURCE" knob to select FM or AM. The station and band are displayed. You can also select cassette deck, CD, CD changer if connected, or the optional TV, with this knob. Active sound control (ASC) The ASC (Active Sound Control) automatically adapts volume to vehicle speed.
Page 105 2001 VOLVO V70 A - Setting station Press the left side of the button to select lower frequencies and the right side for higher frequencies. Set frequencies are displayed. B - Station seek up/down Press the left side (lower frequency) or right side (higher frequency) of the button to start the seek function. The radio seeks the next audible station and tunes it in.
Page 106 The RDS or Radio Data System operates in the FM band only, and the information transmitted is supplied exclusively by participating broadcasters. Volvo has no control over the accuracy of the data or information. Please refer to the following pages regarding specific descriptions and operation of these functions.
Page 107 2001 VOLVO V70 This feature may not be apply in your area and only functions with FM broadcasts. (See previous page) Push the "TP" button for traffic information from RDS stations. "TP" is displayed when the function is connected. When the unit is in Cassette or CD mode, the FM radio function will seek in the background for a station with a strong signal broadcasting traffic information.
Page 108 2001 VOLVO V70 2 0 0 1 VOLVO HomeLink® Universal Transceiver (option) pg. 161 HomeLink® Universal Transceiver (option) HomeLink® Universal Transceiver HomeLink® is an advanced system that can be programmed to learn the codes of three different remote controlled- devices (e.g., garage door openers, remote lighting, entry door lock). HomeLink®'s sun visor-mounted transceiver, powered by your car's electrical system, may then be used in place of your hand-held remote controls.
Page 109 2001 VOLVO V70 5. If you are programming a rolling code-equipped device (e.g., garage door opener or entry door lock), refer to "Programming rolling codes" on the next page to complete the programming process. Repeat steps 3 and 4 to program the other two transceiver buttons.
Page 110 2001 VOLVO V70 programming the HomeLink® Universal Transceiver, call toll-free 1-800-355-3515 (Internet: www.HomeLink®.jci.com). Operating the HomeLink® Universal Transceiver Once programmed, the HomeLink® Universal Transceiver can be used in place of your hand-held transmitters. To operate, the key must be turned to the "accessory" position (II) or the engine must be running. Press the programmed HomeLink®...
Page 111 2001 VOLVO V70 2 0 0 1 VOLVO INDEX pg. 178 - 181 Index ABS - warning light Accessory lights Adjusting the steering wheel Advanced User Mode (AUM) - radio Air conditioning 44 - 47 Air pump system Air vents...
Page 112 2001 VOLVO V70 Automatic Locking Retractor (ALR) Automatic transmission Geartronic 84, 85 Kickdown 83, 84 Auxiliary socket Backrest (center) - 3-section rear seat Battery Battery maintenance 132, 133 Replacing the battery Ventilation hose Booster cushion bottle holder in rear seat...
Page 113 2001 VOLVO V70 Coin compartment Cold weather driving Combination filter Coolant Cooling system - general information Courtesy light Courtesy lights (front) - replacing Courtesy lights - exterior Cruise control Cup holder 53, 54 Detachable trailer hitch - installing Detachable trailer hitch - removing...
Page 114 2001 VOLVO V70 Exterior features - overview Extra seat Fog light - rear Fog lights - front Folding passenger's seat backrest Folding sideview mirrors Foldtable Four wheel drive - towing Front airbags - SRS 4 - 7 Front airbags - SRS - warning light...
Page 115 2001 VOLVO V70 Heated front seats Heated rear window Heated sideview mirrors Heating 44 - 47 Hoisting the car Holder for grocery bags Home Safe System HomeLink 161, 162, 163 Hood - opening Ignition switch Immobilizer (start inhibitor) Indicator lights...
Page 116 2001 VOLVO V70 Maintenance service Malfunction indicator lamp Manual transmission Memory function - front seats Mirrors Mirrors, sideview - folding Mirrors, sideview - memory function Net - cargo Nylon cargo net Occupant safety Octane rating Odometer Oil - engine , 96,...
Page 117: Seat Belts
2001 VOLVO V70 Replacing bulbs 112 - 117 Replacing fuses Replacing wiper blades Reporting safety defects Road assistance Roadholding Roof load - maximum Roof racks Safety defects - reporting Safety locks - child Seat belt maintenance Seat belts Seat belts - cleaning...
Page 118 2001 VOLVO V70 Supplemental Restraint System Suspension Switches in center console Tachometer Tailgate washer Tailgate wiper Tailgate wiper blade - replacing Temperature gauge Temporary spare tire Text window Three-way catalytic converters Tire information - All Wheel Drive Tire pressure Tires...
Page 119 2001 VOLVO V70 Washer fluid solvent Washing the car 119, 120 Waste bin Waxing Weight distribution Weights Wheels - changing 105, 106 Wheels and tires 100 -106 Whiplash Protection System (WHIPS) Windows - electrically operated Windshield washer solvent Windshield wiper blades - replacing...
Page 120 Your car is equipped with an accessory connector located under the dashboard on the driver's side. Please consult your Volvo retailer if you have any questions before connecting accessory or optional equipment to the vehicle's electrical system.
Page 121 2001 VOLVO V70 The following should be checked regularly: * 1 Washer fluid reservoir should be filled with water and solvent (wintertime: windshield washer anti-freeze). See page 127. 2 Power steering - When cold, the level must not be above the COLD mark and when hot it must not be above the HOT mark.
Page 122 2001 VOLVO V70 Bulbs Power Socket US no. Bulb Power Socket US no. 60 W HB 3 55 W 21 W BAU 15d - 21 W BA 15s 1156 55 W 5 W W 2.1x9.5d 1157NA 21/4 W BA 15d...
