Original BMW Accessories.

Installation Instructions.

Retrofit HiFi System Alpine
BMW 1 Series (E 81, E 82, E 87, E 88) built after 3/09
BMW 3 Series (E 90, E 91, E 92, E 93) built after 3/09
BMW X1 (E84)
Installation instructions not valid for vehicles with HiFi system
Retrofit kit No.:
Installation time
The installation time is approx. 2.0 hours. The installation time increases by 0.25 hours on vehicles with option
SA 662 built after 9/09. The specified time may vary depending on the vehicle's condition and equipment.
The total costs for the programming time should be taken into account when calculating retrofitting costs
(reimbursement through warranty is not permissible).
The installation time does not include the time required for programming/encoding which depends on the vehicle's
age and equipment.
Important information
These installation instructions are primarily designed for use within the BMW dealership organisation and by
authorised BMW service companies.
The target group of these installation instructions are technical personnel trained on BMW vehicles with
corresponding technical know-how.
All work must be completed using the latest BMW repair manuals, circuit diagrams, servicing manuals and work
instructions, in a rational order, using the specified tools (special tools) and observing current health and safety
regulations.
In the event of installation or functional problems, limit troubleshooting to 0.5 hours for mechanical
jobs and 1.0 hours for electrical jobs.
To avoid unnecessary work and costs, send a corresponding enquiry via the Aftersales Assistance Portal (ASAP)
using the technical parts support application.
Please quote the following:
- Vehicle identification number
- Part number of retrofit kit
- Exact description of the problem
- Work already carried out
Do not archive the hard copy of these installation instructions since daily updates are made by ASAP!
Pictograms
Denotes information that draws attention to specific requirements.
Denotes the end of an instruction text.
© BMW AG, Munich
65 41 2 163 268
Retrofit kit - HiFi System Alpine
65 41 2 167 061
Retrofit kit - HiFi System Alpine
01 29 2 167 319
3/2010
(Z/S)
1

Advertisement

Table of Contents
loading

Related Manuals for BMW 65 41 2 167 061

Summary of Contents for BMW 65 41 2 167 061

  • Page 1: Installation Instructions

    The target group of these installation instructions are technical personnel trained on BMW vehicles with corresponding technical know-how. All work must be completed using the latest BMW repair manuals, circuit diagrams, servicing manuals and work instructions, in a rational order, using the specified tools (special tools) and observing current health and safety regulations.
  • Page 2 Ensure that the cables/lines are not kinked or damaged as you install them in the car. Costs incurred as a result of incorrect installation will not be reimbursed by BMW AG. Additional cables and/or lines that you install must be secured with cable ties.

  • Page 3: Table Of Contents

    Customer information on HiFi System Alpine ........... . 16 © BMW AG, Munich...

  • Page 4: Parts Overview

    Central bass, right (not included in retrofit kit, only for vehicles with option SA 662 built after 9/09) Hexagon nut (2x, not included in retrofit kit, only for vehicles with option SA 662 built after 9/09) © BMW AG, Munich 01 29 2 167 319...

  • Page 5: Preparatory Work

    Remove central bass cover 65 12 050 Additionally for vehicles with option SA 662 built after 9/09 Open door disconnector, right Door pillar trim panel, bottom right 51 43 150 © BMW AG, Munich 01 29 2 167 319 3/2010 (Z/S)

  • Page 6: Connections Diagram

    SW 4-pin socket housing At central bass, right X10373 4-pin SW pin housing At vehicle-side connector of central bass, left X10372 SW 4-pin socket housing At central bass, left X10372 © BMW AG, Munich 01 29 2 167 319 3/2010 (Z/S)

  • Page 7: Connections Diagram, Diplexer

    BL 2-pin socket housing At pin housing G Pin contact BL/BR At door disconnector, right X256 PIN 33 0.5 mm Pin contact BL/SW At door disconnector, right X256 PIN 34 0.5 mm © BMW AG, Munich 01 29 2 167 319 3/2010 (Z/S)

  • Page 8: Installation And Cabling Diagram

    Ground terminal point X498 Battery (only E90, E91, E92, E93 vehicles) Battery (only E81, E82, E87, E88, E84 vehicles) Central bass, left, connector X10372 Central bass, right, connector X10373 © BMW AG, Munich 01 29 2 167 319 3/2010 (Z/S)

  • Page 9: Installing And Connecting Retrofit Kit

    Only E81, E82, E87, E88, E84 vehicles Route branch A4 to positive pin of battery terminal (1). Only E90, E91, E92, E93 vehicles Route branch A4 to rear fuse box (2). 087 1100 Z © BMW AG, Munich 01 29 2 167 319 3/2010 (Z/S)
  • Page 10 Connect branch A8 to central bass (1). 090 1509 Z Unplug connector X10373 from central bass, left (1) and connect to branch A5. Connect branch A6 to central bass (1). X10373 090 1517 Z © BMW AG, Munich 01 29 2 167 319 3/2010 (Z/S)
  • Page 11 Secure diplexer B to mid-range speaker D with screws (2). Connect branch B1 to mid-range speaker D. Connect branch B2 to tweeter E. Connect branch B3 to original socket housing for door speaker. 087 1102 Z © BMW AG, Munich 01 29 2 167 319 3/2010 (Z/S)
  • Page 12 Screw down branch A4 at terminal X10209 an rear fuse box (1). X10209 087 1038 Z All vehicles Screw down branch A3 at ground terminal X498 on X498 right-hand wheel arch. 087 1072 Z © BMW AG, Munich 01 29 2 167 319 3/2010 (Z/S)

  • Page 13: Finishing Off And Coding

    - Reassemble vehicle in reverse order of removal Customer information The "Customer Information on the HiFi System Alpine" at the end of the installation instructions should be printed out and handed over to the customer. © BMW AG, Munich 01 29 2 167 319 3/2010 (Z/S)

  • Page 14: Circuit Diagram

    Circuit diagram © BMW AG, Munich 01 29 2 167 319 3/2010 (Z/S)
  • Page 15 Amplifier Mid-range speaker Tweeter Fuse holder (20 amp) All designations marked * only apply to these installation instructions or this circuit diagram. Cable colours Blue Brown Black Green White © BMW AG, Munich 01 29 2 167 319 3/2010 (Z/S)

  • Page 16: Customer Information On Hifi System Alpine

    - Remove flap on right in luggage compartment trim panel - Check fuse in fuse holder (1) - If necessary, replace by a new 20 amp fuse 087 1046 Z © BMW AG, Munich 01 29 2 167 319 3/2010 (Z/S)
