5110831/04
INSTALLER AND OWNER GUIDE
Model 808
Electric Heater
This guide is intended to help you install and care for your Baxi Fires Division electric
heater. Please read carefully before installing and using your heater. However, if further
information is required, our Baxi Fires Division Technical Helpline will be pleased to
help.
Telephone 08706 061 065 (National call rates apply in the United Kingdom)
In the Republic of Ireland call 0044 8706 061 065
Important: Please keep your guide in a safe place for future reference
© Baxi Heating U.K. Ltd.

Advertisement

loading

Related Manuals for Baxi 808

Summary of Contents for Baxi 808

  • Page 1 Model 808 Electric Heater This guide is intended to help you install and care for your Baxi Fires Division electric heater. Please read carefully before installing and using your heater. However, if further information is required, our Baxi Fires Division Technical Helpline will be pleased to help.

  • Page 2: Customer Care

    Baxi Fires Division heaters are CE Approved and designed to meet the appropriate British Standards and Safety Marks. Quality and Excellence. All Baxi Fires Division heaters are manufactured to the highest standards of quality and excellence and are manufactured to ISO 9001. CUSTOMER CARE...

  • Page 3: Handling And Unpacking

    INSTALLER AND OWNER GUIDE HANDLING AND UNPACKING Before continuing any further with the installation of this heater please read the following: Important instructions. The lifting weight of the heater is as below: Model Weight (kg) Traditional 9kg. Traditional with spacer 10.5kg.
  • Page 4 Always make sure the heater is firmly secured to prevent it from being tipped over. Always use a fireguard when young children and infirm persons can come into contact with the heater. Always use genuine Baxi Fires Division spares. Never Never leave children unsupervised in a room where the heater is ON and unguarded.
  • Page 5 Some models are not supplied with a spacer frame kit. This optional spacer frame kit is obtainable either from the your heater supplier or direct from Baxi Fires Division Sales. The kit is: Models with traditional fascia - 75mm (3 inch) spacer kit (Kit number 05801T1).
  • Page 6 Figure 1. Removing and top. positioning the cable guide. If the mains cable is damaged, to avoid a hazard it must be replaced by a Figure 2. Removing the Baxi fires division fascia. authorised service agent, or Page 6...
  • Page 7 INSTALLER AND OWNER GUIDE similarly qualified person (See the last page of this guide for useful telephone numbers). All external wiring between the heater and the electrical supply shall comply with current IEE regulations. Removing the fascia on models fitted with a traditional fascia. 1.
  • Page 8 INSTALLER AND OWNER GUIDE Method A - Screw fixing Note - If fixing to marble it is recommended that Method B - ‘Wire fixing’ is used. Drilling marble without the correct tools and experience may result in the marble cracking. 1.
  • Page 9 INSTALLER AND OWNER GUIDE 8. Thread the other end of the wire through the remaining small hole on the left hand side of the heater. Continue to push the wire through this hole until there is only a small loop of wire at the front of the heater (See figure 6 - item 3).
  • Page 10 INSTALLER AND OWNER GUIDE 4. Remove the spacer frame from the fireplace and place away from the work area. 5. Drill the screw locations using a no. 12 masonry drill bit. 6. Insert the two wall plugs provided into the holes 7.
  • Page 11 INSTALLER AND OWNER GUIDE glove is provided with the coal pack). It is not necessary to use all the coal supplied. If the coal pieces are too large then a suitable tool can be used to break them. Important Note: The coals are for decorative purposes only.

  • Page 12: Using The Heater

    INSTALLER AND OWNER GUIDE 4. Lift the trims at the top outer edges. This will keep the trims together. Locate the trims to the heater as in figure 13. 5. Place the loose pebbles on top of the fuel support. It is not necessary to use all the pebbles supplied.

  • Page 13: Cleaning And Maintaining The Heater

    INSTALLER AND OWNER GUIDE CLEANING AND MAINTAINING THE HEATER How do I Clean my heater? The heater fascia, spacer frame and glass parts need only to be wiped clean with a dry soft cloth, do not use polishes or abrasive materials. Heaters with contemporary fascia may have finger prints on the fascia surface.
  • Page 14 4. I Have a problem that is different to those in the previous examples 1- 3. Below is a list of Useful Telephone numbers For general advice about your heater: BAXI FIRES DIVISION TECHNICAL HELPLINE 08706 061 065. To report faults or arrange for your heater to be serviced: BAXI FIRES DIVISION SERVICE 08706 090 081.
