Page 3: Precautions For Safety
Also, make sure the equipment is properly earthed. • Appliance shall be installed in accordance with national wiring regulations. If you detect any damage, do not install the unit. Contact your Carrier dealer immediately. CAUTION • Exposure of unit to water or other moisture before installation could result in electric shock. -
Page 4: Installation Diagram Of Indoor And Outdoor Units
INSTALLATION DIAGRAM OF INDOOR AND OUTDOOR UNITS INSTALLATION DIAGRAM OF INDOOR AND OUTDOOR UNITS For the rear left and left piping Hook Installation plate Wall Insert the cushion between the indoor unit and wall, and tilt the indoor unit for better operation. Do not allow the drain hose to get slack. -
Page 5: Indoor Unit
INDOOR UNIT INDOOR UNIT Mounting the installation plate Installation Place Anchor bolt holes • A place which provides the spaces around the indoor unit as 82.5 shown in the diagram Hook • A place where there are no obstacles near the air inlet and outlet •... -
Page 6: Wiring Connection
Earth line 60 mm CAUTION 10 mm • This appliance can be connected to the mains in either of Connecting cable the following two ways. (1) Connection to fi xed wiring: 10 mm A switch or circuit breaker which disconnects all poles 50 mm and has a contact separation of at least 3 mm must be Stripping length of the connecting cable... -
Page 7: Indoor Unit Fixing
How to remove the drain cap CAUTION Clip the drain cap by needle-nose pliers and • Bind the auxiliary pipes (two) and connecting cable with pull out. facing tape tightly. In case of leftward piping and rear- leftward piping, bind the auxiliary pipes (two) only with How to fi... -
Page 8: Outdoor Unit
3. When connecting extension drain hose, insulate the con- This air conditioner has the structure Wall necting part of extension drain hose with shield pipe. designed to drain water collected Drain from dew, which forms on the back guide Shield pipe of the indoor unit, to the drain pan. - Page 9 Packed valve handling precautions Half union Flare nut • Open the valve stem all the way out, but do not try to open it Externally Internally threaded side threaded side beyond the stopper. • Securely tighten the valve stem cap with torque in the following Use a wrench to secure.
-
Page 10: Test Operation
