Summary of Contents for Clevo P770DM

  • Page 1 P770DM / P771DM / P770DM-G / P771DM-G...
  • Page 3 Preface Notebook Computer P770DM / P771DM / P770DM-G / P771DM-G Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
  • Page 5 This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the P770DM / P771DM series notebook PC.
  • Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 7: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...

  • Page 8: Power Safety

    Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data.  Take care when using peripheral devices. Removal Warning Use only approved brands of Unplug the power cord before When removing any peripherals.

  • Page 9: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.

  • Page 10: System Startup

    Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on Disc This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. System Startup 1.

  • Page 11: Table Of Contents

    Preface Contents Introduction ..........1-1 Top ....................A-3 Bottom ..................A-4 Overview ..................1-1 LCD ....................A-5 External Locator - Top View with LCD Panel Open ......1-4 MB ....................A-6 External Locator - Front & Right side Views .........1-5 HDD ....................A-7 External Locator - Left Side &...
  • Page 12 P750DM LID Switch Board ............B-58 M.2 PCIE4X SSD1 & SSD2 ............B-27 P750DM Finger Sensor Board ............B-59 Realtek ALC892 ................B-28 P770DM Charge LED Board ............B-60 PCM1861 + TAS5766DCA ............B-29 P750DM BOT LED Board ............B-61 Subwoofer ..................B-30 P775DM Power LED Board ............B-62 Audio Jack ..................

  • Page 13: Introduction

    Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the P770DM / P771DM / P770DM-G / P771DM-G series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual.

  • Page 14: Specifications

    Introduction Specifications Processor Options Keyboard Intel® Core™ i7 Processor Full Color Illuminated Full-size Winkey Keyboard (with numeric keypad and anti-ghost keys) i7-6700K (4.00GHz)* Audio 8MB L3 Cache, 14nm, DDR4-2133MHz, TDP 91W  Intel® Core™ i5 Processor High Definition Audio Compliant Interface i5-6600K (3.50GHz)* S/PDIF Digital Output Latest Specification Information...
  • Page 15 Introduction Interface Environmental Spec One USB 3.1 Port/Thunderbolt Port Temperature ° ° Three USB 3.0 Ports Operating: 10 C - 35 One eSATA/Powered 3.0 USB Port Non-Operating: -20°C - 60°C One HDMI-Out Port Relative Humidity Two DisplayPorts (1.2) Operating: 20% - 80% One S/PDIF Out Jack Non-Operating: 10% - 90% One Headphone/Speaker-Out Jack...

  • Page 16: External Locator - Top View With Lcd Panel Open

    Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. PC Camera 2. PC Camera LED 3. Built-In Microphone 4. LCD 5. Speakers 6. Power Button 7. LED Lock Indicators 8. Keyboard 9. TouchPad and Buttons 10.

  • Page 17: External Locator - Front & Right Side Views

    Introduction External Locator - Front & Right side Views Figure 2 Front Views 1. Light Bar 2. LED Power Indicators Front Figure 3 Right Side Views 1. USB 3.0 Port 2. S/PDIF-Out Jack 3. Headphone Jack Right 4. Microphone Jack 5.

  • Page 18: External Locator - Left Side & Rear View

    Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. RJ-45 LAN Jack 2. USB 3.0 Ports 3. USB 3.1 Port 4. Multi-in-1 Card Left Reader 5. Combined eSATA/ Powered USB 3.0 Port Figure 5 Rear View 1.

  • Page 19: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Vent 2. Battery 3. Sub Woofer 4. HDD Bay  Overheating To prevent your com- puter from overheating make sure nothing blocks the vent/fan in- takes while the com- puter is in use.

  • Page 20: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. Memory Slots DDR3L SO-DIMM 2. Platform Controller Hub 1 - 8 Mainboard Overview - Top (Key Parts)

  • Page 21: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. KBC ITE IT8587 2. VGA-Card Connector 3. CPU Socket (no CPU installed) 4. Memory Slots DDR3L SO-DIMM (Primary) 5. Hard Disk Connector Mainboard Overview - Bottom (Key Parts) 1 - 9...

  • Page 22: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. RJ-45 LAN Jack 2. USB 3.0 Port 3. USB 3.1 Port 4. Multi-in-1 Card Reader 5. USB 3.0 Port / e-SATA 6. KB LED Connector 7. WLAN Card Connector 8.

  • Page 23: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. HDMI-Out Port 2. Display Port 3. DC-In Jack 4. VGA Fan Cable Connector 5. 3G / SSD Connector 6. CMOS Battery 7. SSD Connector 8. CPU Fan Cable Connector Mainboard Overview - Bottom (Connectors) 1 - 11...
  • Page 24 Introduction 1 - 12...

  • Page 25: Disassembly

    Disassembly Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the P770DM / P771DM / P770DM-G / P771DM-G series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicat- ed). We suggest you completely review any procedure before you take the computer apart.

  • Page 26: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 27: Maintenance Precautions

    Disassembly Maintenance Precautions  The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 28: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove and install the Processor: 1. Remove the battery page 2 - 5 1.

  • Page 29: Removing The Battery

    Disassembly Removing the Battery Figure 1 1. Turn the computer off, and turn it over. Battery Removal 2. Slide the latch in the direction of the arrow (Figure 1a 3. Slide the latch in the direction of the arrow, and hold it in place (Figure 1a 4.

  • Page 30: Removing And Installing The Hard Disk Drive

    Disassembly Removing and Installing the Hard Disk Drive Figure 2 HDD Assembly The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 7mm/ Removal 9.5mm (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as out- lined in Chapter 4 of the User’s Manual) when setting up a new hard disk.
  • Page 31 Disassembly 4. Lift the hard disk bay cover off the computer (Figure 3c Figure 3 5. Slightly lift and pull the HDD-1 assembly in the direction of the arrow to remove the hard disk assembly (Fig- HDD Assembly ure 3d Removal (cont’d.) 6.
  • Page 32 Disassembly Hard Disk Installation Process Figure 4 HDD Assembly 1. Turn off the computer, and remove the battery (page 2 - Installation 2. Insert the HDD-2 assembly (if available) in the direction of the arrow to install the it (Figure 3a 3.
  • Page 33 Disassembly Hard Disk Size Note (Foam Rubber Insert) Note that the hard disks pictured on the following pages are all 9.5mm(H) hard disk drives. In some cases 7mm(H) hard disk drives will be installed. Figure 5 Foam Rubber Insert for 7mm(H) HDDs HDD-2 HDD-1...

  • Page 34: Removing The M.2 Ssd Module

    Disassembly Removing the M.2 SSD Module Figure 6 Note that the SSD (if installed) is beside the HDD bay. M.2 SSD Module Removal 1. Turn off the computer, and turn it over, remove the battery (page 2 - 2. Remove the screw from the SSD (Figure 6a a.

  • Page 35: Removing The Primary System Memory (Ram)

    Disassembly Removing the Primary System Memory (RAM) Figure 7 RAM Module The computer has four memory sockets for 204 pin Small Outline Dual In-line (SO-DIMM) DDR 3L type memory modules. Removal The total memory size is automatically detected by the POST routine once you turn on your computer. a.
  • Page 36 Disassembly 4. Lift the component bay cover off the computer case. The modules will be visible at point (Figure 8c Figure 8 5. Gently pull the two release latches ( ) on the sides of the memory socket(s) in the direction indicated below &...

  • Page 37: Removing The System Memory (Ram) From Under The Keyboard

    Disassembly Removing the System Memory (RAM) from Under the Keyboard Figure 9 Keyboard The computer has four memory sockets for 204 pin Small Outline Dual In-line (SO-DIMM) DDR 3L type memory modules. Removal The total memory size is automatically detected by the POST routine once you turn on your computer. a.
  • Page 38 Disassembly 5. Carefully lift the keyboard up, being careful not to bend the keyboard ribbon cables Figure 10 6. Disconnect the keyboard ribbon cables from the locking collar socket by using a small flat-head screw- RAM Module driver to pry the locking collar pins away from the base (Figure 10d).

  • Page 39: Removing And Installing The Processor

    Disassembly Removing and Installing the Processor Figure 11 Processor Processor Removal Procedure Removal 1. Turn off the computer, remove the battery (page 2 - 5), and component bay cover (page 2 - 11). Procedure 2. Remove screws from the heat sink unit in the order indicated on the label (i.e screw first through to screw last...
  • Page 40 Disassembly 4. Press down and hold the latch (with the latch held down you will be able to release it). 5. Move the latch and bracket fully in the direction indicated to unlock the CPU(Figure 12c). Figure 12 6. Carefully (it may be hot) lift the CPU up out of the socket (Figure 12d).
  • Page 41 Disassembly Processor Installation Procedure Figure 13 Processor 1. Insert the CPU ; pay careful attention to the pin alignment (Figure 13a), it will fit only one way (DO NOT FORCE Installation IT!). 2. Move the bracket and latch fully in the direction indicated to lock the CPU. 3.

  • Page 42: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module Figure 14 Wireless LAN 1. Turn off the computer, remove the battery (page 2 - 5) and the keyboard (page 2 - Module Removal 2. The Wireless LAN module will be visible at point under the keyboard (Figure 14a).

  • Page 43: Wireless Lan, Combo Module Cables

    Disassembly Wireless LAN, Combo Module Cables Note that the cables for connecting to the antennae on WLAN, WLAN & Bluetooth Combo, 3G and LTE modules are not labelled. The cables/covers (each cable will have either a black or transparent cable cover) are color coded for iden- tification as outlined in the table below.

  • Page 44: Removing The M.2 Sata Module

    Disassembly Removing the M.2 SATA Module Figure 15 M.2 SATA Module 1. Turn off the computer, remove the battery (page 2 - 5), and component bay cover (page 2 - 11). Removal 2. Locate the module; it is visible at point Figure 15a 3.
  • Page 45 Disassembly M.2 SATA Installation Procedure Figure 16 1. Place the thermal pad on the computer as shown (Figure 16a). M.2 SATA Module 2. Insert the module in the computer. Make sure that the hexagonal screw is in the correct location Figure Installation 3.

  • Page 46: Removing And Installing The Video Card

    Disassembly Removing and Installing the Video Card Figure 17 Video Card Video Card Removal Procedure Removal Procedure Turn off the computer, turn it over and remove the battery (page 2 - 5) and component cover (page 2 - Remove screws from the heat sink unit in the order indicated on the label (i.e screw first through to a.
  • Page 47 Disassembly Installing a New Video Card Figure 18 Prepare to fit the video card into the slot by holding it at about a 30° angle (Figure 18e). Installing a New The card needs to be fully into the slot, and the video card and socket have a guide-key and pin which align to Video Card allow the card to fit securely (Figure...
  • Page 48 Disassembly 2 - 24...

  • Page 49: Part Lists

    Part Lists Appendix A: Part Lists This appendix breaks down the P770DM / P771DM / P770DM-G / P771DM-G series notebook’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 50: Part List Illustration Location

    Part Lists Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table A- 1 Part List Illustration Location Parts page A - 3 Bottom page A - 4 page A - 5 page A - 6 page A - 7 A - 2 Part List Illustration Location...

  • Page 51: Top

    Part Lists Figure A - 1 Top A - 3...

  • Page 52: Bottom

    Part Lists Bottom Figure A - 2 Bottom A - 4 Bottom...

  • Page 53: Lcd

    Part Lists Figure A - 3 LCD A - 5...
  • Page 54 Part Lists Figure A - 4 A - 6 MB...

  • Page 55: Hdd

    Part Lists Figure A - 5 HDD A - 7...
  • Page 56 Part Lists A - 8...

  • Page 57: Schematic Diagrams

    Schematic Diagrams Appendix B: Schematic Diagrams This appendix has circuit diagrams of the P770DM / P771DM / P770DM-G / P771DM-G notebook’s PCB’s. The fol- lowing table indicates where to find the appropriate schematic diagram. Diagram - Page Diagram - Page...

  • Page 58: Block Diagram

    Display PortB PAGE 2,3,4,5,6 SHEET 40 SHEET 56 SYSTEM SMBUS P750DM CHARGER LED BOARD SHEET 13 SHEET 38,39 SHEET 59 P770DM CHARGER LED BOARD HDMI DMI*4 USB3.1 & DPA 7.1 channel P750DM LID SWITCH BOARD SHEET 14 25 MHz TYPE C <=8"...

  • Page 59: Processor 1/5

    Schematic Diagrams Processor 1/5 SKYLAKE-S Processor 1/5 ( DMI,FDI,PEG ,RSVD) 3.3V PLACE NEAR CPU MXM SIDE U39C U39C SKL_S_CPU SKL_S_CPU MXM SIDE LGA1151 LGA1151 P/N 6-17-10320-731 C589 C589 0.22u_10V_X5R_04 0.22u_10V_X5R_04 C538 C538 0.22u_10V_X5R_04 0.22u_10V_X5R_04 PEG_RX_0 PEG_TX_0 TH05-3H103FR TH05-3H103FR PEG_RX0 PEG_TX0 PEG_RXP[0] PEG_TXP[0] C588...

  • Page 60: Processor 2/5

    Schematic Diagrams Processor 2/5 SKYLAKE-S Processor 2/7 (JTAG,CLK,CFG ,DISPLAY) U39E U39E SKL_S_CPU SKL_S_CPU LGA1151 LGA1151 *1K_04 *1K_04 CFG0 PCH_CPU_BCLK_DP BCLKP CFG[0] PCH_CPU_BCLK_DN BCLKN CFG[1] CFG2 *1K_04 *1K_04 CFG[2] PCH_CPU_PCIBCLK_DP PCI_BCLKP CFG[3] CFG4 *1K_04 *1K_04 PCH_CPU_PCIBCLK_DN PCI_BCLKN CFG[4] CFG5 *1K_04 *1K_04 VCCST_VCCPLL CFG[5] CFG6...

  • Page 61: Processor 3/5

    Schematic Diagrams Processor 3/5 SKYLAKE-S Processor 3/5 ( DDR4 ) M_A_DQ[63:0] M_B_DQ[63:0] 10,9 SKL_S_CPU SKL_S_CPU SKL_S_CPU SKL_S_CPU U39A U39A U39B U39B LGA1151 LGA1151 LGA1151 LGA1151 M_A_DQ0 AE38 AW18 M_B_DQ0 AD34 AM20 M_A_CK0 M_B_CK0 DDR0_DQ[0] DDR0_CKP[0] DDR1_DQ[0]/DDR0_DQ[16] DDR1_CKP[0] AE37 AV18 AD35 AM21 M_A_DQ1 M_B_DQ1...

  • Page 62: Processor 4/5

    Schematic Diagrams Processor 4/5 SKYLAKE-S Processor 4/5 ( POWER ) 4.2A 4.2A VCORE VCORE SKL_S_CPU SKL_S_CPU VCCSA SKL_S_CPU SKL_S_CPU VDDQ U39G U39G U39I U39I LGA1151 LGA1151 LGA1151 LGA1151 AT18 VCCSA VDDQ AT21 DESIGN NOTE: VCCSA VDDQ AU13 VCCSA VDDQ VCCSA AU15 DESIGN NOTE: PLACE CAPS IN SOCKET EDGE BOTTOM/TOP...

  • Page 63: Processor 5/5

    Schematic Diagrams Processor 5/5 SKYLAKE-S Processor 5/5 ( GND ) U39L U39L SKL_S_CPU SKL_S_CPU U39K U39K U39F U39F SKL_S_CPU SKL_S_CPU VCCGT U39H U39H SKL_S_CPU SKL_S_CPU VCCGTX SKL_S_CPU SKL_S_CPU LGA1151 LGA1151 AK29 AA34 4/30 AC33 VCCGT VCCGTX AK30 AA35 VSS_NCTF AB39 VCCGT VCCGTX AK36...

  • Page 64: Ddr4 Cha So-Dimm_0

    Schematic Diagrams DDR4 CHA SO-DIMM_0 0.6V JDIMM1A JDIMM1A 1.2V VDDQ VTT_MEM M_A_CK0 CK0_T M_A_DQ5 JDIMM1B JDIMM1B CHA DIMM0 M_A_CK#0 M_A_DQ0 CK0_C M_A_CK1 CK1_T M_A_DQ2 M_A_CK#1 M_A_DQ3 CK1_C VDD19 2.5V M_A_DQ1 VDD18 M_A_CKE0 CKE0 M_A_DQ4 VDD17 M_A_CKE1 M_A_DQ6 CKE1 VDD16 VPP2 M_A_DQ7 VDD15 VPP1...

  • Page 65: Ddr4 Cha So-Dimm_1

    Schematic Diagrams DDR4 CHA SO-DIMM_1 JDIMM2A JDIMM2A VDDQ VTT_MEM JDIMM2B JDIMM2B M_A_CK2 M_A_DQ5 CK0_T CHA DIMM1 M_A_CK#2 CK0_C M_A_DQ0 VDD19 2.5V M_A_CK3 M_A_DQ2 CK1_T VDD18 M_A_CK#3 CK1_C M_A_DQ3 VDD17 M_A_DQ1 VDD16 VPP2 M_A_CKE2 CKE0 M_A_DQ4 VDD15 VPP1 M_A_CKE3 M_A_DQ6 CKE1 VDD14 M_A_DQ7 VDD13...

  • Page 66: Ddr4 Chb So-Dimm_0

    Schematic Diagrams DDR4 CHB SO-DIMM_0 VDDQ VTT_MEM JDIMM3A JDIMM3A JDIMM3B JDIMM3B M_B_CK0 CK0_T M_B_DQ0 10,4 M_B_CK#0 M_B_DQ4 10,4 CK0_C VDD19 2.5V M_B_CK1 M_B_DQ7 10,4 CK1_T VDD18 M_B_CK#1 M_B_DQ3 10,4 CK1_C VDD17 CHB DIMM0 M_B_DQ5 10,4 VDD16 VPP2 M_B_CKE0 M_B_DQ1 10,4 CKE0 VDD15 VPP1...

  • Page 67: Ddr4 Chb So-Dimm_1

    Schematic Diagrams DDR4 CHB SO-DIMM_1 JDIMM4A JDIMM4A VDDQ VTT_MEM JDIMM4B JDIMM4B M_B_CK2 M_B_DQ0 CHB DIMM1 CK0_T M_B_CK#2 CK0_C M_B_DQ4 VDD19 2.5V M_B_CK3 M_B_DQ7 CK1_T VDD18 M_B_CK#3 CK1_C M_B_DQ3 VDD17 M_B_DQ5 VDD16 VPP2 M_B_CKE2 CKE0 M_B_DQ1 VDD15 VPP1 M_B_CKE3 M_B_DQ2 CKE1 VDD14 M_B_DQ6 VDD13...

  • Page 68: Panel, Inverter, Crt

    Schematic Diagrams Panel, Inverter, CRT PANEL CONNECTOR (For coaxial cable) PANEL POWER PLVDD LVDS J_LCD1 J_LCD1 *OPEN_2A *OPEN_2A EVEN --> U Q39A Q39A --> L LVDS 1u_6.3V_X5R_04 1u_6.3V_X5R_04 MTS3572G6 MTS3572G6 VLED 3.3VS 4/30 LVDS-U0N LVDS-U0P C597 C597 C598 C598 C593 C593 LVDS-U1N MTN7002ZHS3...

  • Page 69: Display Port A

    Schematic Diagrams Display Port A DISPLAY PORT A 3.3VS_FUSE 3.3VS VOUT 10u_6.3V_X5R_06 10u_6.3V_X5R_06 14,15,44,46 SUSB UP7549UMA5-20 UP7549UMA5-20 *10u_6.3V_X5R_06 *10u_6.3V_X5R_06 PCB Footprint = M-SOT23-5A PCB Footprint = M-SOT23-5A 4/30 HCB1005KF-121T20 HCB1005KF-121T20 1K_04 1K_04 DPA_DHPD_R DP_A_HPD 3.3VS_FUSE 220p_50V_NPO_04 220p_50V_NPO_04 SHIELD6 GND4 3.3VS_FUSE BAV99 RECTIFIER BAV99 RECTIFIER COMMON...

  • Page 70: Display Port B

    Schematic Diagrams Display Port B DISPLAY PORT B PLEASE CLOSE TO CONNECTOR 4/30 HCB1005KF-121T20 HCB1005KF-121T20 1K_04 1K_04 DPB_DHPD_R DP_B_HPD 3.3VS_FUSE 220p_50V_NPO_04 220p_50V_NPO_04 SHIELD6 GND4 3.3VS_FUSE BAV99 RECTIFIER BAV99 RECTIFIER COMMON COMMON *100K_1%_04 *100K_1%_04 SHIELD5 GND3 3.3VS BAT54CW(lision) BAT54CW(lision) 3.3VS_FUSE PWR_RET *100K_04 *100K_04 DPB_AUX#_R...

  • Page 71: [14] Hdmi

    Schematic Diagrams HDMI HDMI CONNECTOR 4/30 *0.5_1%_04 *0.5_1%_04 FOR NV HDMI_5VS_A HCB1005KF-121T20 HCB1005KF-121T20 For ESD *RB551V-30S2 *RB551V-30S2 *0.5_1%_04 *0.5_1%_04 R505 R505 1K_04 1K_04 HDMI_HPD-C C505 C505 HDMI_5VS 220p_50V_NPO_04 220p_50V_NPO_04 J_HDMI1 J_HDMI1 VOUT BAV99 RECTIFIER BAV99 RECTIFIER BAV99 RECTIFIER BAV99 RECTIFIER BAV99 RECTIFIER BAV99 RECTIFIER 12,15,44,46...

  • Page 72: Mxm Pci-E

    Schematic Diagrams MXM PCI-E 3.3VS PWR_SRC PWR_SRC MXM 3.0 J_MXM1A J_MXM1A E1-1 E2-1 3.3VS PWR_SRC PWR_SRC E1-2 E2-2 R506 R506 J_MXM1B J_MXM1B E1-3 PWR_SRC PWR_SRC E2-3 CLK_PCIE_MXM# PWR_SRC PWR_SRC PEX_REFCLK# CLK_REQ# E1-4 E2-4 10K_04 10K_04 *10mil_short *10mil_short MXM_RST# *0.1u_16V_Y5V_04 *0.1u_16V_Y5V_04 PWR_SRC(10A)--7-20V CLK_PCIE_MXM PWR_SRC...

  • Page 73: Lynix Point 1/7

    Schematic Diagrams Lynix Point 1/7 Lynx Point - M (SPI,GPP) 3.3VS VCCPGPPA SKL_PCH_H SKL_PCH_H U16A U16A C715 C715 0.1u_10V_X7R_04 0.1u_10V_X7R_04 MC74VHC1G08DFT2G MC74VHC1G08DFT2G R238 R238 10K_04 10K_04 PME# BD17 BB27 PLT_RST# GPP_A11/PME# GPP_B13/PLTRST# PLT_RST# 15,42 AG15 BUF_PLT_RST# 25,26,31,32,36,38,41 RSVD R755 R755 1K_04 1K_04 PCH_SPI_IO3...

  • Page 74: Lynix Point 2/7

    Schematic Diagrams Lynix Point 2/7 3.3VS Lynx Point -CLINK/FAN/SATA/HOST R148 R148 10K_04 10K_04 FB_CLAMP_PCH R690 R690 10K_04 10K_04 DGPU_PWRGD R705 R705 *10K_04 *10K_04 SKL_PCH_H SKL_PCH_H R142 R142 10K_04 10K_04 SCI# U16C U16C R691 R691 10K_04 10K_04 GPU_EVENT#_R R147 R147 10K_04 10K_04 GPIO2_FB_TGL_REQ_PCH CL_CLK1...

  • Page 75: Lynix Point 3/7

    Schematic Diagrams Lynix Point 3/7 IF SAMPLED HIGH,FLASH SPT-H (HDA,SMB,JTAG,GPIO) DVDDIO_AUDIO DESCRIPTOR SECURITY IS OVERIDEN R852 R852 *1K_04 *1K_04 AZA_SDO D02 C245=CODEC >? 05/21 SKL_PCH_H SKL_PCH_H 3.3VA U16D U16D D02 ./NET C245 C245 22p_50V_NPO_04 22p_50V_NPO_04 D02 RTC CLEAR CMOS FCM1005KF-600T03 FCM1005KF-600T03 05/15 BB17 R237...

  • Page 76: Lynix Point 4/7

    Schematic Diagrams Lynix Point 4/7 SPT-H (CLK,REQ,GPP,DDP) D02 1 TEST SETUP MENU TABLE 5/20 BOARD STYLE SKL_PCH_H SKL_PCH_H U16G U16G DISABLED (DEFAULT) C836 C836 PCH_XDP_CLK_R_DN CLKOUT_ITPXDP 15p_50V_NPO_04 15p_50V_NPO_04 3.2*2.5 TP_CLKOUT_48 AR17 PCH_XDP_CLK_R_DP TEST SETUP MENU ENABLED GPP_A16/CLKOUT_48 CLKOUT_ITPXDP_P PCH_CPU_NSSC_CLK_DP CLKOUT_CPUNSSC_P CLKOUT_CPUPCIBCLK PCH_CPU_PCIBCLK_DN DESIGN NOTE:...

  • Page 77: Lynix Point 5/7

    Schematic Diagrams Lynix Point 5/7 SPT-H (DMI,PCIe,USB,LPC) SKL_PCH_H SKL_PCH_H U16B U16B DMI_TXN0 DMI_RXN0 DMI_TXP0 USB_PN1 DMI_RXP0 USB2N_1 USB3 PORT3 (J_USB3_3) USB_PP1 DMI_RXN0 DMI_TXN0 USB2P_1 DMI_RXP0 USB_PN2 DMI_TXP0 USB2N_2 USB_PP2 FINGER DMI_TXN1 DMI_RXN1 USB2P_2 USB_PN3 DMI_TXP1 DMI_RXP1 USB2N_3 AG10 PCI-E x1 Usage NGFF 3G DMI_RXN1...

  • Page 78: Lynix Point 6/7

    Schematic Diagrams Lynix Point 6/7 DESIGN NOTE: SPT -H (POWER) EDGE CAP FOR VCCMPHY_1P0 AND VCCDUSB_1P0 1.0VA 1.0VA 1.0VA SKL_PCH_H SKL_PCH_H U16H U16H DESIGN NOTE: C748 C748 C759 C759 AA23 1.0VA VCCPRIM_1P0 PLACE HOLDER FOR VCCAUSB_1P0 AND VCCAAZPLL_1P0 FILTER AA26 1u_6.3V_X5R_04 1u_6.3V_X5R_04 22u_6.3V_X5R_08...

  • Page 79: Lynix Point 7/7

    Schematic Diagrams Lynix Point 7/7 SPT -H (RSVD,GND) U16I U16I SKL_PCH_H SKL_PCH_H U16L U16L SKL_PCH_H SKL_PCH_H AC18 AB11 AN10 AB14 BE14 AB31 BE18 AE29 AB32 BE23 AB38 BE28 AE42 BE32 AF18 BE37 AF20 BE40 AF21 AC20 AF23 AC21 AF25 AC25 AF26 Sheet 22 of 62 AC29...

  • Page 80: Usb + Esata, Usb Charging

    Schematic Diagrams USB + eSATA, USB Charging USB3.0 PORT5 USB3.0 PORT4 + eSATA USBVCC3.0_5 100 mil VOUT C646 C646 C159 C159 3.3VS C168 C168 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 *0.1u_16V_Y5V_04 *0.1u_16V_Y5V_04 eSATA1B_RXP_C eSATA1B_RXP_J eSATA1B_RXN_C eSATA1B_RXN_J 10u_6.3V_X5R_06 10u_6.3V_X5R_06 UP7549UMA5-20 UP7549UMA5-20 R996 R996 *0_04 *0_04 R997 R997 0_04...

  • Page 81: [24] Ccd,Usb Port3

    Schematic Diagrams CCD, USB Port3 *0_06 *0_06 CCD_PWR 48 mil 0_06 0_06 3.3VS VOUT 1u_6.3V_X5R_04 1u_6.3V_X5R_04 *0.1u_16V_Y5V_04 *0.1u_16V_Y5V_04 uP7553 uP7553 2.2u_6.3V_X5R_04 2.2u_6.3V_X5R_04 CCD_EN From KBC default HI Port 5 J_CCD1 J_CCD1 *0_04 *0_04 INT_MIC USB_PN10 USB_PP10 47p_50V_NPO_04 47p_50V_NPO_04 HCB1005KF-121T20 HCB1005KF-121T20 3.3VS MIC_DATA_L MIC_DATA...

  • Page 82: Usb & Wlan+Bt

    Schematic Diagrams M.2 3G+USB & WLAN+BT HUAWEI MU736PIN1.8V LEVEL HI: Present CONNECTORGNORMAL CLOSED( GND) 3G CARD / USB3  GHIJKLMN&!PULL HIGH,OP@QPULL HIGH: SATAT9 CURRENT2A ,DON'T DROP BELOW 3.135V 3G_3.3V 80 mils W/O 3G J_3G1 J_3G1 C880 C880 EEFCX0J221YR EEFCX0J221YR W/O 3G - / 3G_CONFIG2 C911 C911...

  • Page 83: Pcie4X Ssd1 & Ssd2

    Schematic Diagrams M.2 PCIE4X SSD1 & SSD2 1st M2 NGFF (PCIE 4X) 3.3VS >120 mil R260 R260 R261 R261 3.3VS UVPCH WMulti PCIE OR SATA SSD 10K_04 10K_04 10K_04 10K_04 C474 C474 C473 C473 C926 C926 J_SSD1 J_SSD1 M.2_SSD1_DET_N 0.1u_10V_X7R_04 0.1u_10V_X7R_04 0.1u_10V_X7R_04 0.1u_10V_X7R_04...

  • Page 84: [27] Realtek Alc892

    Schematic Diagrams Realtek ALC892 C208 C208 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 C207 C207 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 Layout Note: C823 C823 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 U43 pin 1 ~ pin 11 and pin 47 and pin 48 are Digital signals. C287 C287 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 The others are Analog signals. C389 C389 0.1u_16V_Y5V_04...

  • Page 85: Pcm1861+Tas5766Dca

    Schematic Diagrams PCM1861 + TAS5766DCA AUDIO AMP FOR SPEAKER AMP_PWR AMP_3.3VS AUDG_5766 AUDG_5766 C636 C636 C115 C115 C114 C114 C639 C639 C149 C149 NEAR 5766 PIN6/PIN7 R103 R103 *22_04 *22_04 15,31,33 SMD_VGA_THERM R638 R638 22_04 22_04 1u_25V_X5R_06 1u_25V_X5R_06 10u_25V_X5R_08 10u_25V_X5R_08 10u_25V_X5R_08 10u_25V_X5R_08 10u_25V_X5R_08...

  • Page 86: Subwoofer

    Schematic Diagrams Subwoofer AMP POWER 10V MP8715DN MP8715DN PR215 PR215 PC148 PC148 AMP_PWR PU11 PU11 4.7_06 4.7_06 0.1u_10V_X7R_04 0.1u_10V_X7R_04 BCIHP-0730 4R7M BCIHP-0730 4R7M 4.7UH_6.8*7.3*3.5 4.7UH_6.8*7.3*3.5 10V/6A PJ52 PJ52 PCB Footprint = BCIHP0735A PCB Footprint = BCIHP0735A OPEN-5mm OPEN-5mm PR217 PR217 EN/SYNC R735 R735...

  • Page 87: Audio Jack

    Schematic Diagrams Audio Jack USB3.0 PORT4 & AUDIO JACK D03 ./ 6/30 P750ZM & P770ZM % C956 C956 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 FOR Audio JACK BOARD C390 C390 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 FOR P750ZM$ H6_0B3_7D3_7 H6_0B3_7D3_7 H6_0B3_7D3_7 H6_0B3_7D3_7 R984 R984 10_04 10_04 HP_AUDG C771 C771 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04...

  • Page 88: Ec It8587

    IT8587 VDD3 VDD3 MODEL_ID PROJECT NAME KBC_AVDD V1.0 P750DM HCB1005KF-121T20 HCB1005KF-121T20 R657 R657 R656 R656 R723 R723 *10mil_short *10mil_short V1.0 P770DM VDD3 VDD3 Q13A Q13A 2.2K_04 2.2K_04 2.2K_04 2.2K_04 C641 C641 C691 C691 C651 C651 C643 C643 C166 C166 C170 C170 V1.0...

  • Page 89: Second Ec It8587

    Schematic Diagrams Second EC IT8587 KBC_AVDD2 R183 R183 *10mil_short *10mil_short HCB1005KF-121T20 HCB1005KF-121T20 VDD3 VDD3 C663 C663 C640 C640 C649 C649 C181 C181 C665 C665 C664 C664 C666 C666 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 10u_10V_Y5V_08 10u_10V_Y5V_08 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 *0.1u_16V_Y5V_04 *0.1u_16V_Y5V_04 *0.1u_16V_Y5V_04 *0.1u_16V_Y5V_04 P770 ...

  • Page 90: Backlight Keyboard

    Schematic Diagrams Backlight Keyboard BACKLIGHT KEYBOARD 3.3VS 0_06: R421 R421 *15mil_short *15mil_short DEFAULT PJ11 SHORT R422 R422 *0_06 *0_06 KBZONE1_B J_KBLED_1 J_KBLED_1 LED0 KBZONE1_R KB_LED_PWR R230 R230 *28mil_06 *28mil_06 KBPWR_G 5VS_2 LED1 C439 C439 C440 C440 KBZONE1_G PJ12 PJ12 OPEN_2A OPEN_2A R229 R229...

  • Page 91: Lid Sw, Fan, Led Conn

    Schematic Diagrams LID SW, Fan, LED Conn POWER LED BOARD CONN (W/ LID) CPU FAN CONTROL 3.3VS 5VS_2 J_LED1 J_LED1 FON1# M_BTN# LID_SW# 11,31 VOUT C470 C470 C460 C460 AIRPLAN_LED# VSET LED_HDD# For EMI 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 AX995SA AX995SA LED_NUM# 4.7u_6.3V_X5R_06 4.7u_6.3V_X5R_06 CPU_FAN LED_CAP#...

  • Page 92: Tp, Fp, Multi-Con

    Schematic Diagrams TP, FP, Multi-Con FOR CLICK BOARD FOR HDD BOARD TP_VCC TP_VCC J_SATA2 J_SATA2 (TP (J_TP1) G5VS R366 R366 *0_04 *0_04 3.3VS R368 R368 R367 R367 C383 C383 SATA3_TXP 3.3VS 10K_04 10K_04 10K_04 10K_04 *10u_6.3V_X5R_06 *10u_6.3V_X5R_06 .TP (TM02706) G3.3VS SATA3_TXN R385 R385...

  • Page 93: Lan E2400

    Schematic Diagrams LAN E2400 Qualcomm LAN (E2400) LED_LINK_A If switch regulator applied, mount Ra If LDO applied, mount Rb VDD3 close to pin1 PR107 PR107 VDD33 VDD33 15mil_short_06 15mil_short_06 AVDDVCO_A 0603 VDD33 R461 R461 R464 R464 R463 R463 C361 C361 C362 C362 C400...

  • Page 94: Ps8338B + Ps8330B

    Schematic Diagrams PS8338B + PS8330B 3.3VS 3 Levels Input: Programmable input equalization levels; Internal pull down at 3.3VS AUX interception disable for Port y (y = 1, 2). Internal pull down at ~150K*, 3.3V I/O; L: Low ~150K*, 3.3V I/O. R611 R611 *4.7K_04...

  • Page 95: Tbt

    Schematic Diagrams NOTE: XTAL TBT_XTAL_25_OUT SNK0_DDC_data/clk ?connect to 2k PU only if SRC0 is connected and support HDMI (a.i HDMI or DP++ connector). Otherwise can be 100k PD. SNK1_DDC_data ?connect to 100k PD. If SRC0 support HDMI, connect as SNK0_CFG1 to GPU and/or appropriate AUX/DDC demux control TBT_XTAL_25_IN SNK1_DDC_clk ?connect to 100k PD.

  • Page 96: Power

    Schematic Diagrams Power VCC3V3_LC VCC3V3_SX_SYS VCC3V3_S0_SYS VCC0V9_DP 1uF VCC3V3_S0 C250 C250 5/12 C277 C277 C278 C278 C297 C297 C822 C822 C821 C821 C819 C819 C820 C820 1u_6.3V_X5R_04 1u_6.3V_X5R_04 1u_6.3V_X5R_04 1u_6.3V_X5R_04 C248 C248 C294 C294 C299 C299 C283 C283 C282 C282 C298 C298 C247...

  • Page 97: Tps65982

    Schematic Diagrams TPS65982 VCC5V0_SYS TBTA_VBUS FOOTPRINT C485 C485 C495 C495 C501 C501 C490 C490 4/30 80Ohm, 0.01Ohm DCR, 8A Idc TBTA_LDO_BMC 22u_6.3V_X5R_06 22u_6.3V_X5R_06 22u_6.3V_X5R_06 22u_6.3V_X5R_06 22u_6.3V_X5R_06 22u_6.3V_X5R_06 22u_6.3V_X5R_06 22u_6.3V_X5R_06 HCB2012KF-800T80 HCB2012KF-800T80 VCC1V8D_TBTA_LDO VCC1V8A_TBTA_LDO J_TYPEC1 J_TYPEC1 C451 C451 C457 C457 C448 C448 DX07S024JJ2 DX07S024JJ2...

  • Page 98: Cardreader Rts5250

    Schematic Diagrams Cardreader RTS5250 RTS5250 CARD READER SD_CARD SUPPORT UHS-II 3.3VS MDIO0~5 Q R S <200 mil LENGTH <2INCH R488 R488 | CLK - DATA | <= 100mils *10K_04 *10K_04 3V3AUX | DATA.x - DATA.y | <= 100mils 3.3VS R479 R479 10K_04 10K_04...

  • Page 99: [42] Tpm Slb9655Tt & Npct420

    Schematic Diagrams TPM SLB9655TT & NPCT420 W/O TPM -/$ & R225W SLB9655TT & NPCT420 COLAY SLB9665TT TPM_PWR QDU531 R107 R107 *0_04 *0_04 3.3V C157 C157 C158 C158 R110 R110 0_04 0_04 3.3VS 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 10u_6.3V_X5R_06 10u_6.3V_X5R_06 TMC:766 TMC:776 20,31,32 LPC_AD0 for W/ TPM LAD0 PIN5...

  • Page 100: [43] Vccio/1P0A

    Schematic Diagrams VCCIO / 1P0A 5.5A VCCIO OPTION DEFAULT SHORT VCCIO PJ46 PJ46 D02 1 1.0VA VOUT C625 C625 C626 C626 C635 C635 C632 C632 R630 R630 VOUT VCCIO VOUT VOUT M5938 M5938 6/16 VCCIO_EN VBIAS D02 VCCIO DEL 2"A R629 R629 *10K_04...

  • Page 101: Ddr 1.2V/0.6Vs/Vccpll_Oc

    Schematic Diagrams DDR 1.2V/0.6VS/VCCPLL_OC 1.2V/0.6VS MDU1516 MDU1516 PC79 PC79 PC77 PC77 PC78 PC78 1.2V ULTRASO-8 ULTRASO-8 PU12 PU12 PC147 PC147 RB0540S2 RB0540S2 G5616 G5616 VTT_MEM VDDQ VDDQ_R PC159 PC159 15u_25V_6.3*4.4 15u_25V_6.3*4.4 10u_10V_Y5V_08 10u_10V_Y5V_08 PC158 PC158 0.1u_10V_X7R_04 0.1u_10V_X7R_04 DEFAULT D03 PC157 C703 VLDOIN VBST VTT_MEM_R...

  • Page 102: Vdd3, Vdd5

    Schematic Diagrams VDD3, VDD5 VREF PR139 PR139 *0_04 *0_04 PR137 PR137 0_04 0_04 PC220 PC220 1u_10V_Y5V_06 1u_10V_Y5V_06 PR138 PR138 PR143 PR143 EN_3V EN_5V PC227 PC227 140K_1%_04 140K_1%_04 76.8K_1%_04 76.8K_1%_04 PC222 PC222 PC103 PC103 PC102 PC102 PC226 PC226 PC104 PC104 1000p_50V_X7R_04 1000p_50V_X7R_04 1000p_50V_X7R_04 1000p_50V_X7R_04...

  • Page 103: [46] 12V.5Vs,3.3Vs,3.3Va

    Schematic Diagrams 12V, 5VS, 3.3VS, 3.3VA VDD5 VDD5 C447 C447 EM5209 EM5209 C455 C455 VDD3 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 OUT1 OUT2 R262 R262 OUT1 OUT2 C464 C464 C461 C461 10K_04 10K_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 For CV test For CV test DD_ON# DD_ON# 23,24,30,44...

  • Page 104: 5Vs_2

    Schematic Diagrams 5VS_2 PR117 PR117 5VS_2 560K_1%_04 560K_1%_04 5VS_2 PU14 PU14 IMAX:4A PC191 PC191 PC202 PC202 OCP:8A PJ33 PJ33 PC91 PC91 0.1u_50V_Y5V_06 0.1u_50V_Y5V_06 15u_25V_6.3*4.4 15u_25V_6.3*4.4 1u_6.3V_X5R_04 1u_6.3V_X5R_04 PR114 PR114 PR126 PR126 PC86 PC86 10_04 10_04 5VS_2 0_06 0_06 PL14 PL14 PJ22 PJ22 PC211...

  • Page 105: Vcore / Vccgt

    Schematic Diagrams VCore / VCCGT Intel SKYLAKE IMVP8 POWER VCORE 4+0 PHASE PROG VCCST_VCCPLL PR168 PR168 CONFIGURATION 3.3VS 3.3VS 75K_1%_04 75K_1%_04 VCORE PR159 PR159 PR160 PR160 PC115 PC115 R500 R500 R499 R499 1u_6.3V_X5R_04 1u_6.3V_X5R_04 2.2_06 2.2_06 1K_1%_04 1K_1%_04 10K_04 10K_04 10K_04 10K_04 3.3VS...

  • Page 106: Vcore Output Stage

    Schematic Diagrams VCore Output Stage 03/20 VCORE OUTPUT STAGE for EMI PC59 PC59 PC46 PC46 PC53 PC53 PC235 PC235 PC236 PC236 PC237 PC237 PC238 PC238 PC239 PC239 PR36 PR36 PC23 PC23 D03 ./ 2.2_06 2.2_06 PR25 PR25 0603 2.2_06 2.2_06 6/30 0.22u_16V_X7R_06 0.22u_16V_X7R_06...

  • Page 107: Vccsa / Vccgt

    Schematic Diagrams VCCSA / VCCGT PC65 PC65 PC131 PC131 PC130 PC130 PR68 PR68 PC64 PC64 *2.2_06 *2.2_06 PR69 PR69 *2.2_06 *2.2_06 *0.22u_16V_X7R_06 *0.22u_16V_X7R_06 0V~1.2V/20A *NCP81151MNTBG *NCP81151MNTBG 0603 INS128959250 INS128959250 INS128959582 INS128959582 MLP08 MLP08 MLP08 MLP08 PR71 PR71 *1_06 *1_06 0.9m ohm COMMON COMMON COMMON...

  • Page 108: Power Charger, Dc-In

    Schematic Diagrams Power Charger, DC-In SMART CHARGER support GTXX 330W ADD MOSFET PC189 PC189 PR237 PR237 EMB20P03V EMB20P03V 0.1u_50V_Y5V_06 0.1u_50V_Y5V_06 470K_04 470K_04 PQ42 PQ42 PQ26 PQ26 EMB20P03V EMB20P03V EMB20P03V EMB20P03V EML1 EML1 HCB2012KF-800T80 HCB2012KF-800T80 V_BAT PC190 PC190 PC184 PC184 PR236 PR236 1500p_50V_04 1500p_50V_04...

  • Page 109: [52] P750Dm Hdd Board

    Schematic Diagrams P750DM HDD Board HJ_SATA1 HJ_SATA1 H_SATA_TXP1 0.01u_16V_X7R_04 0.01u_16V_X7R_04 HSATA_TXP1 H_SATA_TXN1 0.01u_16V_X7R_04 0.01u_16V_X7R_04 HSATA_TXN1 SATA PORT1 H_SATA_RXN1 0.01u_16V_X7R_04 0.01u_16V_X7R_04 HSATA_RXN1 H_SATA_RXP1 0.01u_16V_X7R_04 0.01u_16V_X7R_04 HSATA_RXP1 HJ_SATA2 HJ_SATA2 H_3.3VS H_3.3VS HSATA_TXP1 HC10 HC10 HC11 HC11 5/12 HSATA_TXN1 *0.01u_16V_X7R_04 *0.01u_16V_X7R_04 *10u_6.3V_X5R_06 *10u_6.3V_X5R_06 HSATA_RXN1 HGND H_5VS...

  • Page 110: P750Dm Power Led Board

    Schematic Diagrams P750DM Power LED Board L_3.3VS POWER SWITCH POWER BUTTON 20mil L_SW1 L_SW1 FOR 15" FOR 17" TJE-532-Q-T/R TJE-532-Q-T/R 1K_04 1K_04 LM_BTN# 20mil LJ_LED15_1 LJ_LED15_1 LJ_LED17_1 LJ_LED17_1 LM_BTN# LM_BTN# 20mil LED_GND LED_GND L_LID_SW# L_LID_SW# *0.1u_16V_Y5V_04 *0.1u_16V_Y5V_04 L_WLAN_AIRPLANE# L_WLAN_AIRPLANE# LED_GND 0.1u_50V_Y5V_06 0.1u_50V_Y5V_06 LSATA_LED#...

  • Page 111: P750Dm Click Board

    Schematic Diagrams P750DM Click Board TTP_VCC TTP_VCC 3/16 TJ_TP3 TJ_TP3 TTP_VCC TJ_TP1 TJ_TP1 TJ_CLICK1 TJ_CLICK1 TTP_CLK 6PIN HIJ TTP_CLK TTP_DATA D021 TGND TTPBUTTON_L TTP_DATA TTPBUTTON_L FCM1005KF-121T03 FCM1005KF-121T03 TTPBUTTON_R TGND TTPBUTTON_R TTPBUTTON_L TGND TTPBUTTON_R TTP_SMB_CLK TJ_TP2 TJ_TP2 TTP_SMB_DATA FP226H-004S10M FP226H-004S10M FP225H-006S10M FP225H-006S10M FP225H-008S10M FP225H-008S10M TTP_DATA...

  • Page 112: P750Dm Audio Board

    Schematic Diagrams P750DM Audio Board A_3.3V A_USBVCC3.0_2 A_3.3V D03 *+R7 AR11 AR11 *4.7K_04 *4.7K_04 AR33 AR33 *0_04 *0_04 AR10 AR10 4.7K_04 4.7K_04 AR34 AR34 *0_04 *0_04 AR39 AR39 AR32 AR32 4.7K_04 4.7K_04 AR35 AR35 *0_04 *0_04 *4.7K_04 *4.7K_04 *4.7K_04 *4.7K_04 VOUT 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04...

  • Page 113: P750Dm Charge Led Board

    Schematic Diagrams P750DM Charge LED Board C_D1 C_D1 C_LED_ACIN C_R1 C_R1 220_04 220_04 CJ_LED1 CJ_LED1 C_LED_ACIN C_LED_PWR C_R2 C_R2 220_04 220_04 C_LED_PWR RY-SP195UHYUYG4 RY-SP195UHYUYG4 C_GND AC IN/POWER ON LED 6-52-55002-04E C_LED_BAT_FULL C_LED_BAT_CHG C_GND FP225H-006S10M FP225H-006S10M Sheet 56 of 62 PCB Footprint = fp225h-006xxxm PCB Footprint = fp225h-006xxxm C_D2 C_D2...

  • Page 114: P750Dm Lid Switch Board

    Schematic Diagrams P750DM LID Switch Board LID SWITCH IC Sheet 57 of 62 P750DM LID Switch LL_VDD3 Board LL_VDD3 LL_C4 LL_C4 100K_04 100K_04 LLJ_LID1 LLJ_LID1 LL_U1 LL_U1 LL_LID_SW# LL_LID_SW# 88266-03001 88266-03001 LL_C2 LL_C2 LL_C1 LL_C1 LL_C3 LL_C3 LL_GND *1u_10V_Y5V_06 *1u_10V_Y5V_06 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 *100p_50V_NPO_04...

  • Page 115: P750Dm Finger Sensor Board

    Schematic Diagrams P750DM Finger Sensor Board Finger Sensor Board D02 aZMQFIUGER SENSOR BOARD 4/30 NOTE: MODE MODE=HIGH (NC) , USB MODE MODE=LOW , SPI MODE EGND MODE FUSB_PP F3.3V AVDD Sheet 58 of 62 FUSB_PN FJ_FPB1 FJ_FPB1 F2.5V DVDD F2.5V F3.3V F3.3V VDDIO...

  • Page 116: P770Dm Charge Led Board

    [59] P770DM CHARGE LED BOARD Size Size Size Document Number Document Number Document Number 6-71-P77DE-D01 6-71-P77DE-D01 6-71-P77DE-D01 Date: Date: Date: Monday, August 03, 2015 Monday, August 03, 2015 Monday, August 03, 2015 Sheet Sheet Sheet B - 60 P770DM Charge LED Board...

  • Page 117: P750Dm Bot Led Board

    Schematic Diagrams P750DM BOT LED Board TP LED BOARD GG_5VS GGR4 GGR4 100_1%_06 100_1%_06 GG_G1 GGR3 GGR3 150_1%_06 150_1%_06 GG_R1 GGR1 GGR1 100_1%_06 100_1%_06 GG_B1 Sheet 60 of 62 GGD2 GGD2 FSL-3010040HPGRB-N8SNT1W2TJY FSL-3010040HPGRB-N8SNT1W2TJY GGR6 GGR6 100_1%_06 100_1%_06 P750DM BOT LED GGR5 GGR5 150_1%_06...

  • Page 118: P775Dm Power Led Board

    Schematic Diagrams P775DM Power LED Board S_3.3VS POWER SWITCH POWER BUTTON 20mil FOR P775DM S_SW1 S_SW1 TJE-532-Q-T/R TJE-532-Q-T/R 1K_04 1K_04 SM_BTN# 20mil SJ_LED775_1 SJ_LED775_1 SM_BTN# 20mil SLED_GND S_LID_SW# *0.1u_16V_Y5V_04 *0.1u_16V_Y5V_04 S_WLAN_AIRPLANE# SSATA_LED# SLED_GND 0.1u_50V_Y5V_06 0.1u_50V_Y5V_06 SLED_NUM# *V15AVLC0402 *V15AVLC0402 SLED_GND SLED_CAP# VARISTOR SLED_SCROLL# 6-24-30003-006...

  • Page 119: Power On Sequence

    Schematic Diagrams Power On Sequence DESIGN GUIDE# Power on VDDQ <25ms RTCRST# VCCST PWR_SW# DD_ON 218ms VCCST_PWRGD >1ms 3.3V 0.83ms PCH_PWROK >0 1.95ms VDD5 DDR_VTT_CNTL <100ns SLP_SUS# 30.65ms <35us DDR_VTT 3.3VA 0.35ms 5.33ms 1.0VA VCCIO >100ns 51ms RSMRST# (=DPWROK) VCCSA >100ns 81ms 123ms...
  • Page 120 Schematic Diagrams B - 64...

  • Page 121: Updating The Flash Rom Bios

    Download the BIOS computer model. 1. Go to www.clevo.com.tw and point to E-Services and click E-Channel. Note that BIOS versions 2. Use your user ID and password to access the appropriate download area (BIOS), and download the latest BIOS files...
  • Page 122 BIOS Update Use the flash tools to update the BIOS 1. Make sure you are not loading any memory management programs such as HIMEM by holding the F8 key as you see the message “Starting MS-DOS”. You will then be prompted to give “Y” or “N” responses to the programs being loaded by DOS.

This manual is also suitable for:

P771dm-gP770dm-gP771dm

Table of Contents
