Panasonic KX-TCD150E Operating Instructions Manual

Panasonic digital cordless phone operating instructions model no. kx-tcd150e
Hide thumbs
Table of Contents

Advertisement

Quick Links

TCD150E(E).book Page 1 Wednesday, May 25, 2005 4:58 PM
Charge the batteries for about
7 hours before initial use.
You must subscribe to Caller ID service to use this
feature.
Caller ID
Please read these operating instructions before using the unit and save them for future reference.
Operating Instructions
Digital Cordless Phone
Model No.

Table of Contents

Introduction ............................................................ 2
Preparation ............................................................. 3
Making/Answering Calls ........................................ 8
Phonebook.............................................................. 9
Useful Telephone Settings .................................. 10
Caller ID Service ................................................... 13
Useful Information................................................ 14
KX-TCD150E

Advertisement

Table of Contents
loading

Related Manuals for Panasonic KX-TCD150E

Summary of Contents for Panasonic KX-TCD150E

  • Page 1: Table Of Contents

    You must subscribe to Caller ID service to use this feature. Caller ID Please read these operating instructions before using the unit and save them for future reference. Operating Instructions Digital Cordless Phone KX-TCD150E Model No. Table of Contents Introduction ... 2 Preparation ... 3 Making/Answering Calls ... 8 Phonebook...

  • Page 2: Introduction

    L In the event of problems, you should contact your equipment supplier in the first instance. Declaration of Conformity: L Panasonic Communications Co., Ltd. declares that this equipment is in compliance with the essential requirements and other relevant provisions of Radio & Telecommunications Terminal Equipment (R&TTE) Directive 1999/5/EC.

  • Page 3: Preparation

    TCD150E(E).book Page 3 Wednesday, May 25, 2005 4:58 PM Preparation Important information General L Use only the AC adaptor included with this product, noted on page 2. L Do not connect the AC adaptor to any AC outlet other than a standard 220–240 V AC outlet.
  • Page 4 TCD150E(E).book Page 4 Wednesday, May 25, 2005 4:58 PM Preparation incoming calls before holding the phone to your ear. Information on Disposal for Users of Waste Electrical & Electronic Equipment (private households) This symbol on the products and/or accompanying documents means that used electrical and electronic products should not be mixed with general household waste.

  • Page 5: Battery Installation

    We therefore recommend you also connect a standard telephone to the same telephone line using a T-adaptor. Your Panasonic sales shop can offer you more information about connection possibilities. L To turn the power on, press {ih} for about 1 second.
  • Page 6 TCD150E(E).book Page 6 Wednesday, May 25, 2005 4:58 PM Preparation Controls Handset A Receiver B Display C {k} (Phonebook) D {C} (Talk) E Navigator ({e}/{v}/{>}/{<}) F {R} (Redial/Pause) G {R} (Recall) H Charge contacts I Microphone J {j/OK} (Menu/OK) K {ih} (Off/Power) L {C} (Clear) M {INT} (Intercom) Base unit...

  • Page 7: Setting The Date And Time

    TCD150E(E).book Page 7 Wednesday, May 25, 2005 4:58 PM Symbols used in this manual These are the symbols that will navigate through these operating instructions. Symbol Meaning Press {j/OK}. {j/OK} Proceed to the next operation. “ ” Press {e} or {v} to select the words in quotations shown on the display.

  • Page 8: Making/Answering Calls

    TCD150E(E).book Page 8 Wednesday, May 25, 2005 4:58 PM Making/Answering Calls Making/Answering Calls Making calls Dial the phone number. i {C} When finished talking, press {ih} or place the handset on the base unit. Answering calls Press {C} to answer the call. L You can also answer a call by pressing any dial key from {0} to {9}, {*}, {#}, or {INT}.

  • Page 9: Phonebook

    TCD150E(E).book Page 9 Wednesday, May 25, 2005 4:58 PM Phonebook Adding entries to the phonebook The phonebook allows you to make calls without having to dial manually. You can add 20 names and phone numbers to the phonebook. {j/OK} 2 times Enter the party’s phone number (24 digits max.).

  • Page 10: Useful Telephone Settings

    TCD150E(E).book Page 10 Wednesday, May 25, 2005 4:58 PM Useful Telephone Settings Useful Telephone Settings Guide to handset settings To customise the handset: {j/OK} i “SETTING HS” i {>} Select the desired item in the handset settings menu ({v}). i {>} Select the desired item in sub-menu ({v}).

  • Page 11: Guide To Base Unit Settings

    *4 If you change the PIN, please write down your new PIN as the unit will not reveal the PIN to you. If you forget your PIN, consult your nearest Panasonic service centre. *5 Auto talk feature allows you to answer calls simply by lifting the handset off the base unit.
  • Page 12 *2 If you change the PIN, please write down your new PIN as the unit will not reveal the PIN to you. If you forget your PIN, consult your nearest Panasonic service centre. *3 Call restriction feature restricts the handset from dialling certain phone numbers. You can assign up to 10 phone numbers (memory locations 0–9) to be restricted.

  • Page 13: Caller Id Service

    TCD150E(E).book Page 13 Wednesday, May 25, 2005 4:58 PM Caller ID Service Using Caller ID service Important: L This unit is Caller ID compatible. To use Caller ID features (such as displaying caller phone numbers), you must subscribe to Caller ID service. Consult your service provider for details.

  • Page 14: Useful Information

    TCD150E(E).book Page 14 Wednesday, May 25, 2005 4:58 PM Useful Information Useful Information Troubleshooting If you still have difficulties after following the instructions in this section, disconnect the AC adaptor and turn off the handset, then reconnect the AC adaptor and turn on the handset. Problem w is flashing.
  • Page 15 TCD150E(E).book Page 15 Wednesday, May 25, 2005 4:58 PM Problem The handset will not turn on. A busy tone is heard when {C} is pressed. Static, sound cuts in/out, fades. Interference from other electrical units. Noise is heard during a call. Pressing {R} does not display/ dial the last number dialled.
  • Page 16 TCD150E(E).book Page 16 Wednesday, May 25, 2005 4:58 PM Useful Information Specifications Standard: DECT (Digital Enhanced Cordless Telecommunications) Number of channels: 120 Duplex Channels Frequency range: 1.88 GHz to 1.9 GHz Duplex procedure: TDMA (Time Division Multiple Access) Channel spacing: 1,728 kHz Bit rate: 1,152 kbit/s Modulation: GFSK (Gaussian Frequency Shift Keying)

  • Page 17: Conditions Of Guarantee

    8. The guarantee period applicable to this product shall be 12 months. Please keep these operating instructions with your receipt. Panasonic Business Systems U.K. Receipt No. Model No. Helpline Tel. No.: U.K. 08700 100 076 R.O.I. 01289 8333...
  • Page 18 TCD150E(E).book Page 18 Wednesday, May 25, 2005 4:58 PM...
  • Page 19 TCD150E(E).book Page 19 Wednesday, May 25, 2005 4:58 PM...
  • Page 20 L Or go on line through our Internet Accessory ordering application at www.panasonic.co.uk L Most major credit and debit cards accepted. L All enquiries transactions and distribution facilities are provided directly by Panasonic UK Ltd. L It couldn ’ t be simpler! L Also available through our Internet is direct shopping for a wide range of finished products, take a browse on our website for further details.
