- Page 1 Video Intercom System Sub Monitor Station Installation and Operation Guide VL-GM001A Model No. Thank you for purchasing a Panasonic Sub Monitor Station. Please read this Installation and Operation Guide before using the unit and save for future reference.
-
Page 2: Table Of Contents
Important Information Important Information FCC and Other Information ... 2 Important safety instructions ... 3 Additional safety information ... 4 For best performance ... 5 Introduction and Installation Included items ... 6 Location of controls ... 7 Before installation ... 8 Installing the sub monitor station ... -
Page 3: Important Information
The lightning flash with arrow head within a triangle is intended to tell the user that parts inside the product are a risk of electric shock to persons. Important safety instructions 1) Read these instructions. All the safety and operating instructions should be read before the appliance is operated. -
Page 4: Additional Safety Information
Important Information Additional safety information 1. Use only the power source marked on the unit. If you are not sure of the type of power supplied to your home, consult your dealer or local power company. 2. Use only the specified AC adaptor. 3. -
Page 5: For Best Performance
Important Information For best performance • If a power failure occurs, the unit will not function. • Do not place any object within 20 cm (8 inches) of the sub monitor station. This may cause communication errors or malfunction. -
Page 6: Introduction And Installation
Introduction and Installation Included items Item Sub Monitor station Wood screws AC adaptor Wood screws Power cord Power cable Sub Monitor Station: A Sub Monitor Station is an optional unit which, when used through the Monitor Station, operates just like the Monitor Station. Up to two of these units can be connected to the system. -
Page 7: Location Of Controls
Location of controls Front view Display (3.5-inch color LCD screen) Microphone • Speak into the microphone when talking to a visitor. SELECT (L) button / BRIGHT button SELECT (M) button / RECEIVE VOLUME button MENU button / PRESS TALK button MONITOR button •... -
Page 8: Before Installation
Introduction and Installation Before installation To avoid malfunction or communication disturbance, do not install the sub monitor station in the following locations: – Places where vibration or any other kind of impact occurs. – Places where echoing is frequent. – Places where a high concentration of dust, hydrogen sulfide, phosphorus, ammonia, sulfur, carbon, acid, or noxious fumes occur. - Page 9 Wiring schematic diagram All monitor stations and sub monitor stations should be connected by daisy chain wiring method. The connection of 2nd sub monitor station (the last end terminal) and monitor station is NOT required. Connect to terminals H11 and H12 of the monitor station.
-
Page 10: Installing The Sub Monitor Station
Introduction and Installation Installing the sub monitor station Remove the sub monitor station from the box, and then remove the padding material from between the front case and the bottom case. • The front case and the bottom case are not joined together, so be careful not to drop them when taking them out of the box. - Page 11 Introduction and Installation Install the bottom case to a wall using the wood screws ″ x 1 ″). (4 mm x 35 mm, • Before drilling, see page 8 for installation location. <Installation size>...
- Page 12 Introduction and Installation Attach the power cable to the terminal. See page 16 for details on how to attach the power cable. • If you want to use your own power cable, see page 9 for the type and distance. <Inside of main unit (bottom case)>...
- Page 13 Remove the sheet covering the connector. Next, after installing the terminal cover in the bottom case, attach the connector by tightening the connector screw. Next, align the lower portion of the bottom case with the lower portion of the front case and press on the panel area just above the screen until the tabs lock in place.
- Page 14 Introduction and Installation Take out the AC adaptor and the DC terminal from the case. • Push the arrow mark on the front case, then release from the rear case. • Take out the cardboard and wood screws. The wood screws are necessary when attaching the AC adaptor and the DC terminal to a wall (page 15).
- Page 15 To attach the AC adaptor and the DC terminal to a wall By placing the AC adaptor and the DC terminal in the case and mounting the case to the wall, you can protect the AC adaptor and the DC terminal from tampering and exposure.
- Page 16 Introduction and Installation Note: • To open the case again, push the bottom of the front case, then release from the rear case. To attach the power cable Sub Monitor station • While pressing on the button hard with a pointed object such as a screwdriver, insert the power cable into the terminal connector.
-
Page 17: Help
Cleaning Clean the unit with a soft, dry cloth when cleaning. For excessive dirt, wipe the unit with a slightly damp cloth. Important information: • Do not use anything containing alcohol, polish powder, powder soap, benzine, thinner, wax, petroleum, or boiling water. Also do not spray with insecticide, glass cleaner, or hair spray. -
Page 18: General Information
General Information Technical data about this product Sub Monitor station Power supply: Current consumption: Dimensions: Mass (Weight): Operating environment: Installation method: External material: Note: • To connect to a chime, make sure the chime is: – Normal open (Low active) –... - Page 20 00985, U.S.A. Copyright: • This material is copyrighted by Panasonic Communications Co., Ltd., and may be reproduced for internal use only. All other reproduction, in whole or in part, is prohibited without the written consent of Panasonic Communications Co., Ltd.
