Understanding Your Detector - Escort Max 360 Owner's Manual

Understanding Your Detector

Interpreting Alerts
Although ESCORT Max 360 has a comprehensive
warning system, only experience will teach you what
to expect from your detector and how to interpret
what it tells you.
Alert
Detector begins to sound slowly with front arrow
displayed. Rate of alert increases until it becomes a
solid tone. The signal meter ramps accordingly.
Detector emits short alerts for a few seconds with
front arrow displayed then falls silent, only to briefly
alert and fall silent again.
Detector suddenly sounds a continuous tone for the
appropriate band received.
Detector sends a brief laser alert with all direction
arrows displayed.
Detector receives weak signals with rear direction
arrow displayed. Signals may be a little stronger as
you pass large, roadside objects. Signals increase
in frequency.
Detector alerts slowly for a while with front direction
arrow displayed then abruptly jumps to a strong alert.
Detector alerts intermittently with front direction
arrow displayed. Rate and strength of alerts may be
consistent or vary wildly.
Detector alerts intermittently with front direction
arrow displayed. Rate and strength of signal increases
with each alert.
Detector gives an X band alert intermittently with the
front direction arrow quickly changing to side arrows
then to the rear direction arrow.
CAUTION: Overconfidence in an unfamiliar area can be
dangerous. Likewise, if an alert in a commonly
traveled area is suddenly stronger or on a different band
than usual, speed radar may be set up nearby.
The specific type of radar being used, the type of
transmission (continuous or instant-on) and the
location of the radar source affect the alerts you
receive. The following examples will give you an
introduction to understanding your detector's
warning system for radar and laser alerts.
Explanation
You are approaching a continuous radar source
aimed in your direction.
An instant-on radar source is being used ahead
of you and out of your view.
An instant-on radar or laser source is being used
nearby. This kind of alert requires immediate
attention.
Laser is being used in the area. Because laser is
inherently difficult to detect, any laser alert may
indicate a source very close by
A moving patrol car with continuous radar is
overtaking you from behind. Because these
signals are reflected (reflections are increased by
large objects), they may or may not eventually
melt into a solid point, even when the patrol car
is directly behind you.
You are approaching a radar unit concealed by a hill
or an obstructed curve
A patrol car is traveling in front of you with a
radar source aimed forward. Because signals are
sometimes reflected off of large objects and
sometimes not, the alerts may seem inconsistent.
A patrol car is approaching from the other
direction, sampling traffic with instant-on radar.
Such alerts should be taken seriously.
You are driving through an area populated with
radar motion sensors (e.g., door openers or
burglar alarms). Since these transmitters are
usually contained inside buildings or aimed
toward or away from you, they are typically not
as strong or lasting as a real radar encounter.
How Radar Works
Traffic radar, which consists of microwaves, travels in
straight lines and is easily reflected by objects such
as cars, trucks, and even guardrails and overpasses.
Radar works by directing its microwave beam down
the road. As your vehicle travels into range, the
microwave beam bounces off your car, and the radar
antenna looks for the reflections. Using the Doppler
principle, the radar equipment then calculates your
speed by comparing the frequency of the reflection
of your car to the original frequency of the beam
sent out.
Traffic radar has limitations, the most significant of
these being that it typically can monitor only one
target at a time. If there is more than one vehicle
within range, it is up to the radar operator to decide
which target is producing the strongest reflection.
Since the strength of the reflection is affected by both
the size of the vehicle and its proximity to the
antenna, it is difficult for the radar operator to
determine if the signal is from a sports car nearby or a
semi truck several hundred feet away.
Radar range also depends on the power of the radar
equipment itself. The strength of the radar unit's
beam diminishes with distance. The farther the radar
has to travel, the less energy it has for speed
detection.
Because intrusion alarms and motion sensors often
operate on the same frequency as X and K band
radar, your detector will occasionally receive non-
police radar signals. Since these X band transmitters
are usually contained inside of a building or aimed
toward the ground, they will generally produce much
weaker readings than will a true radar encounter. As
you become familiar with the sources
of these pseudo alarms in your daily
driving, they will serve as
confirmation that the device's radar
detection abilities are fully
operational.
How POP Works
POP works by transmitting an extremely short burst,
within the allocated band, to identify speeding
vehicles in traffic. Once the target is identified, or
"popped," the gun is then turned to its normal
operating mode to provide a vehicle tracking history
(required by law).
NOTE: According to radar gun manufacturers, tickets
should not be issued in pop mode.
How Laser Works
Laser speed detection is actually light detection and
ranging (LIDAR). Laser guns project a beam of
invisible infrared light. The signal is a series of very
short infrared light energy pulses that move in a
straight line, reflecting off your car and returning to
the gun. Laser uses these light pulses to measure
the distance to a vehicle. Speed is then calculated by
measuring how quickly these pulses are reflected,
given the known speed of light.
Laser is a newer technology whose use is not as
widespread as conventional radar; therefore, you may
not encounter it on a daily basis. And unlike radar
detection, laser is not prone to false alarms. Because
laser transmits a much narrower beam than does
radar, it is much more accurate in its ability to
distinguish between targets and is also more difficult
to detect. As a result, even the briefest laser alert
should be taken seriously.
There are limitations to laser, however. Laser is much
more sensitive to weather conditions than radar,
and a laser gun's range will be decreased by anything
affecting visibility, such as rain, fog or smoke. A
laser gun cannot operate through glass, and it must
be stationary to get an accurate reading. Because
laser must have a clear line of sight and is subject to
cosine error (an inaccuracy that increases as the
angle between the gun and the vehicle increases),
police typically use laser equipment parallel to the
road or from an overpass. Laser can be used day or
night.
