Yamaha YZF-R1 Kit Manual page 11

4. Cut the shaded area off the LH side cover
(to provide an installation area for sixing
for BRKT., REGULATOR 1
5. Remove from the chassis the STD
rectifier/regulator that is installed on the
right side of the radiator.
Install the rectifier/regulator using the
bracket, regulator
, bolts and nuts
9
10
Face the bracket and regulator
and tighten them together with the shaped
side cover.
8
9
11
6. Replace the STD CORD COMP. (starter
motor lead wire) with the CORD COMP.
seat).
7
, grommets , spacers
7 8
.
11
inward
7
7
10
.
17
– 8 –
