Page 1: Installation Manual
INSTALLATION MANUAL Air-cooled condensing units ERAP110MBYNN ERAP150MBYNN ERAP170MBYNN... - Page 2 2PW37336-6F...
- Page 3 2PW37336-6F...
-
Page 4: Table Of Contents
ACCESSORIES COULD RESULT IN ELECTRIC SHOCK, SHORT- CIRCUIT, LEAKS, FIRE OR OTHER DAMAGE TO THE EQUIPMENT. Low ambient operation (–15°C) BE SURE ONLY TO USE ACCESSORIES MADE BY DAIKIN WHICH Liquid line solenoid valve ARE SPECIFICALLY DESIGNED FOR USE WITH THE EQUIPMENT Voltage free contacts AND HAVE THEM INSTALLED BY A PROFESSIONAL. -
Page 5: Operation Range
PERATION RANGE NSPECTING AND HANDLING THE UNIT At delivery, the unit should be checked and any damage should be reported immediately to the carrier claims agent. Outdoor temperature (°C DB) When handling the unit, take into account the following: Evaporating temperature (°C) (Suction dew point) Standard operation range Lift the unit preferably with a crane and belts in accordance with the instructions on the unit. -
Page 6: Important Information Regarding The Refrigerant Used
Make certain that the foundation surface is even and flat. NOTE To assure oil return to the compressor do not use Fix anchor bolts (1) into the concrete foundation. piping size above 2-1/8" for ERAP110 units or above When finally fixing the unit by means of these anchor bolts, 2-5/8"... -
Page 7: Field Wiring
Parts table After completion of procedure step 3, perform an “initial start” test: F1,2,3U ....Main fuses for the unit 4.1 Start the compressor and wait for the compressor to go through H1P ......Indication lamp general operation the star/delta. H2P ...... -
Page 8: Before Starting
If you operate the digital controller from a distance with a cable USTOMIZATION IN THE SERVICE MENU as specified above, close the hole in the switch box cover with the supplied polycarbonate plate. All customized settings must be done by a licensed Setting the adresses on the remote digital controller technician. -
Page 9: How To Continue
Defining of the changeable digital inputs and outputs Defining the BMS settings Besides locked digital inputs and outputs there are a number of The BMS parameters allowing communication between the unit and changeable digital inputs and outputs of which the function can be the supervisory system can be modified with the chosen from several possibilities. - Page 10 NNEX OTES Connection to an air handling installation with face and bypass register for control of the air temperature. ERAP Face register Bypass register Air cooled evaporator Thermostat sensor (R4T) Room thermostat (RT) ERAP unit Servo motor for face/bypass registers The thermostat sensor (R4T) delivered with the ERAP unit is to be mounted in a holder on the air cooled evaporator.
- Page 11 ..................................................................Phone Phone : ..................: ....................QUIPMENT TECHNICAL DATA Manufacturer : DAIKIN EUROPE ....Power supply (V/Ph/Hz/A) : ......... Model : ..........Maximum high pressure : .......29 bar Serial Number : ..........Charging weight (kg) R407C : .........
