Kyocera TASKalfa 180 Service Manual
Hide thumbs
Also See for TASKalfa 180:
- Operation manual (164 pages) ,
- Installation manual (2 pages) ,
- Quick manual (2 pages)
Related Manuals for Kyocera TASKalfa 180
Summary of Contents for Kyocera TASKalfa 180
-
Page 1: Service Manual
TASKalfa 180 TASKalfa 220 SERVICE MANUAL Published in October 2009 842KL113 2KLSM063 Rev.3... - Page 2 2KL/2KK CONTENTS 1-1 Specifications 1-1-1 Specifications........................1-1-1 1-1-2 Parts names..........................1-1-3 (1) Body ..........................1-1-3 (2) Operation panel.......................1-1-4 1-1-3 Machine cross section ......................1-1-5 1-2 Installation 1-2-1 Installation environment .......................1-2-1 1-2-2 Unpacking and installation ....................1-2-2 (1) Installation procedure ......................1-2-2 (2) Setting initial copy modes................
-
Page 3: Mechanical Construction
2KL/2KK-2 (4) How to tell a genuine Kyocera Mita toner container............1-5-2 1-5-2 Paper feed section ........................1-5-3 (1) Detaching and refitting the separation pulley ..............1-5-3 (2) Detaching and refitting the forwarding pulley and paper feed pulley.......1-5-6 (3) Detaching and refitting the paper conveying unit .......... - Page 4 2KL/2KK-2 (4) Others..............................2-2-5 2-3 Operation of the PWBs 2-3-1 Power source PWB..........................2-3-1 2-3-2 Main/engine PWB ...........................2-3-3 2-3-3 Cassette PWB............................2-3-11 2-3-4 Operation PWB .............................2-3-14 2-4 Appendixes Maintenance parts list ..........................2-4-1 Periodic maintenance procedures ......................2-4-2 Chart of image adjustment procedures....................2-4-5 Wiring diagram............................2-4-7 INSTALLATION GUIDE DOCUMENT PROCESSOR PAPER FEEDER...
- Page 5 2KL/2KK This page is intentionally left blank.
-
Page 6: Specifications
2KL/2KK 1-1-1 Specifications Type ..........Desktop Printing system ....... Indirect electrostatic system Supported original types ....Sheets, books and three-dimensional objects Maximum original size: A3/Ledger Original feed system ....... Fixed Paper weight........Cassette: 64 - 105 g/m MP tray: 45 - 160 g/m Paper type ........ - Page 7 2KL/2KK Charge erasing system....Exposure by cleaning lamp Fusing system......... Heat roller Heat source: Halogen heaters Abnormally high temperature protection devices: thermostats Main memory ........Standard: 32 MB Maximum: 160 MB Interface.......... USB interface connector: 1 (USB Hi-speed) Network interface: 1 (10 BASE-T/100 BASE-TX) Resolution........
-
Page 8: Parts Names
2KL/2KK 1-1-2 Parts names (1) Body 1 1 1 Original co 15. Toner container release lever Output tra 16. Toner container Operation panel 10. Slider 17. Charger cleaner rod Cassette 11. Contact glass 18. Waste toner box Paper width adjusting tab 12. -
Page 9: Parts List
TASKalfa 180 TASKalfa 220 PARTS LIST Published in May 2009 2KLPL070 842KL120 First Edition... - Page 10 Parts Name Machine Model Quantity 302KK34050 LABEL EMBLEM GDI 18 (18ppm) TASKalfa 180 302KK34040 LABEL EMBLEM GDI 22 (22ppm) TASKalfa 220 2. Symbols in the "Parts Number" column. • Parts with "•" are component parts or sub-assemblies of the assembly appearing immediately above them.
- Page 11 CONTENTS FIG. 1 Covers ..............2 FIG. 2 Frames 1 ..............4 FIG. 3 Frames 2 ..............6 FIG. 4 Paper Feed Section 1 ..........8 FIG. 5 Paper Feed Section 2 ..........10 FIG. 6 Paper Cassette ............12 FIG.
- Page 12 FIG. 1 Covers - 2 -...
- Page 13 Kyocera-Mita TASKalfa-180, TASKalfa-220 service manual Kyocera-Mita TASKalfa-180, TASKalfa-220 service manual Kyocera-Mita TASKalfa-180, TASKalfa-220 service manual Kyocera-Mita TASKalfa-180, TASKalfa-220 service manual Kyocera-Mita TASKalfa-180, TASKalfa-220 service manual Kyocera-Mita TASKalfa-180, TASKalfa-220 service manual Kyocera-Mita TASKalfa-180, TASKalfa-220 service manual Kyocera-Mita TASKalfa-180, TASKalfa-220 service manual...
