I
I
NSTALLATION
NSTRUCTIONS FOR
*M(H,S)8 / GD(H,S)8 / GHS8 / GME8
ADS(H,S)8 / AMEH8 G
(CATEGORY I )
These furnaces comply with requirements embodied in
the American National Standard / National Standard of
Canada ANSI Z21.47·CSA-2.3 Gas Fired Central Furnaces.
ATTENTION INSTALLING PERSONNEL
As a professional installer, you have an obligation to know the
product better than the customer. This includes all safety pre-
cautions and related items.
Prior to actual installation, thoroughly familiarize yourself with
this Instruction Manual. Pay special attention to all safety warn-
ings. Often during installation or repair, it is possible to place
yourself in a position which is more hazardous than when the
unit is in operation.
Remember, it is your responsibility to install the product safely
and to know it well enough to be able to instruct a customer in
its safe use.
Safety is a matter of common sense...a matter of thinking before
acting. Most dealers have a list of specific, good safety
practices...follow them.
The precautions listed in this Installation Manual are intended
as supplemental to existing practices. However, if there is a
direct conflict between existing practices and the content of
this manual, the precautions listed here take precedence.
R
ECOGNIZE THIS SYMBOL
AS A SAFETY PRECAUTION
NOTE: Please contact your distributor or our website listed
below for the applicable Specification Sheet referred to in this
manual.
IO-446C
11/2015
F
AS
URNACE
Installer: Affix all manuals
adjacent to the unit.
5151 San Felipe Suite 500 • Houston, TX 77056
www.goodmanmfg.com • www.amana-hac.com
© 2011 - 2015 Goodman Manufacturing Company, L.P.
is a registered trademark of Maytag Corporation or its related companies and is used under license. All rights reserved.
TABLE OF CONTENTS
Safety Considerations ...................................................... 3
Additional Safety Considerations .................................... 4
Shipping Inspection .......................................................... 4
Electrostatic Discharge (ESD) Precautions ....................... 5
To The Installer .................................................................. 5
PRODUCT APPLICATION ............................................................ 5
LOCATION REQUIREMENTS AND CONSIDERATIONS .................. 6
Clearances and Accessibility ........................................... 7
Installation Positions ....................................................... 7
Horizontal Installation ..................................................... 7
Furnace Suspension .......................................................... 8
Existing Furnace Removal ................................................. 8
Thermostat Location ......................................................... 8
COMBUSTION AND VENTILATION AIR REQUIREMENTS ............. 8
CATEGORY I VENTING (VERTICAL VENTING) .............................. 9
(CATEGORY I FURNACES ONLY) ......................................... 10
Checklist Summary .......................................................... 10
Check 1 - Proper chimney termination .......................... 11
vented into this chimney channel .............................. 11
Check 3 - Chimney Crown Condition. .............................. 12
Check 4 - Debris in Cleanout ........................................... 12
Check 5 - Liner Condition. ............................................... 12
Check 6 - Dilution Air. ..................................................... 12
Check 7 - Complete the Installation. ............................... 12
Fix 1 - Liner Termination ................................................. 13
Fix 2 -Change Venting Arrangements .............................. 13
Fix 3 - Rebuild the Crown ................................................ 13
Fix 4 - Relining ................................................................ 13
ELECTRICAL CONNECTIONS ..................................................... 14
Wiring Harness ............................................................... 14
115 Volt Line Connections .............................................. 14
Fossil Fuel Applications ................................................. 14
Junction Box Relocation ................................................. 14
24 Volt Thermostat Wiring ............................................. 15
with 2-Stage Condenser Field Wiring ........................ 15
Setting the Heat Anticipator ............................................ 16
115 Volt Line Connection of Accessories ........................ 16
Electronic Air Cleaner ..................................................... 16
24 Vac Humidifier ........................................................... 16
GAS SUPPLY AND PIPING ........................................................ 16
High Altitude Derate ........................................................ 17
Propane Gas Conversion ................................................ 17
Gas Piping Connections .................................................. 17
Upflow Installations ....................................................... 18
Counterflow Installations .............................................. 18
Gas Piping Checks ........................................................... 18
Propane Gas Tanks and Piping ....................................... 19
