- Page 1 17 Inch Flat Screen TFT Professional Monitor Model: DM17TS Installation / User Manual Digimerge Technologies Inc.
- Page 2 CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER FOR SERVICE TO QUALIFIED SERVICE PERSONNEL. WARNING: To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture The lightning flash with arrowhead symbol, within an equatorial...
-
Page 3: Table Of Contents
Table of Contents General Precautions ....................4 Introduction ......................6 Features ........................6 Installation ........................ 6 Start Up Operation ....................7 Front Controls ......................8 Adjusting the Video using the OSD ................ 9 Specifications......................10 Limited Warranty....................11... -
Page 4: General Precautions
General Precautions 1. Read Instructions. All of the safety and operating instructions should be read and understood before the product is used. 2. Retain Instructions. The safety and operating instructions should be retained for future reference. 3. Heed Warnings. All warnings on the product and the instruction manual should be followed. - Page 5 a. When the power supply cord or plug is damaged b. If objects have fallen into the product c. If the product has been exposed to rain or liquids d. If the product does not operate normally by following the instruction manual. e.
-
Page 6: Introduction
Introduction The DM17TS is a 17-inch, Flat Screen thin-film transistor (TFT) LCD color monitor. Capable of resolutions up to 1280 x 1024, this advanced monitor produces crisp, clear pictures and brilliant colors. The monitor provides installation flexibility with 2 BNC Video In/Out connectors, S-Video In/Out as well as VGA In from a PC. -
Page 7: Start Up Operation
Figure 1.0 BNC Video & RCA Audio S-Video & RCA Audio VGA IN (PC) Start Up Operation 1. After all connections have been made as shown above, toggle the main power switch on the side of the monitor to ON. 2. -
Page 8: Front Controls
Front Controls DISPLAY ON/OFF POWER MENU MODE ENTER AUTO CONFIG MUTE LEFT VOLUME RIGHT CH SELECT POWER This button is used to power ON/Off the display. 2. MENU This button brings up the On Screen Display (OSD) Menu to allow for changes to Brightness, Contrast, H-Position, and V-Position. -
Page 9: Adjusting The Video Using The Osd
When in the VGA mode, this button allows you to adjust the BRIGHTNESS. 7. PIP When in the VGA mode, this button will allow you to bring up one of the NTSC channels in a PIP window. Upon bringing up the PIP window, use the CH SELECT button to switch between CH 1, CH 2, and S-VIDEO. -
Page 10: Specifications
Adjusts size, brightness, and contrast to optimal settings. Factory Reset Resets all data back to it’s default settings. Info Displays the current resolution and refresh rate. Specifications Model DM17TS LCD Panel: Type 17-inch TFT color Colors 16.7M colors Viewable Size 13.3 (H) x 10.6 (V) inches (337.9 x 270.3 mm) -
Page 11: Limited Warranty
Digimerge, be repaired or replaced without charge. Any products repaired or replaced within the warranty period, shall be warranted by Digimerge to the initial end-user purchaser for 90 days from the return shipment date, or the remainder of the warranty term, whichever is longer, and if outside of the warranty period then for 90 days from the return shipment date. - Page 12 Digimerge Technologies Inc. 300 Alden Road Markham Ontario L3R 4C1 www.digimerge.com rev01...
