CONTENTS Intorduction ............2 What’s in the Box . -
Page 3: Intorduction
INTORDUCTION Thank you for your purchase of Orion's 7005 amplifier. Each Orion amplifier is designed to be the leader in its class offering ease of use, advanced features, and the most power. Orion amplifiers are designed as the best affordable high end car audio amplifier money can buy. -
Page 4: Warranty
WARRANTY Directed Electronics, Inc. promises to the original purchaser, to replace this product should it prove to be defective in workmanship or material under normal use, for a period of two years from the date of purchase by the dealer as indicated by the date code marking of the product PROVIDED the product was installed by an authorized Directed dealer. -
Page 5: Specifications
SPECIFICATIONS Amplifier Section Power Output 4W stereo (Watts)1 Power Output 2W stereo (Watts)2 Power Output 4W mono (Watts)1 Power Output 2W mono (Watts)2 Remote Gain Distortion - with all channels driven at rated power (20Hz to 20kHz) Frequency Response Linear Bandwidth Signal-to-Noise Ratio at Rated Power Damping Factor Slew Rate... -
Page 6: End Panel Layout
END PANEL LAYOUT Power LED - indicates that the amplifier is on. Front Low-Pass Crossover Switch - activates 2nd order low pass crossover. Front Low-Pass Frequency Control - adjusts the frequency of the low-pass crossover. Front Gain Control - continuously adjusts from 200mV to 5V for full power output. Front High-Pass Crossover Switch - activates 2nd order high pass crossover. -
Page 7: Signal Input And Output Level Controls
The 4CH / 2CH switch routes input from the front inputs to the rear section of the amplifi- er. This allows the Orion 7005 channel amplifier to utilize a single set of RCA's to feed sig- nal to the front and rear channels of the amplifier. -
Page 8: Subwoofer High-Pass
When using Orion loudspeakers, minor deviations from the recommended frequency ranges can provide superior results depending on your speaker locations and your vehicle acoustics. Setting crossover frequencies higher than recommended will not cause damage and may provide superior sonic results depending on your system's performance goals. Refer to your loudspeaker owner's manual for assistance in choosing the proper crossover frequencies for your system. -
Page 9: Infinite Baffle Example High-Pass Set At 30Hz
Enclosure Type Infinite Baffle Tune above Fs of woofer Sealed Tune above Fs of woofer Vented Tune to port frequency Sealed Band-pass Tune above Fs of woofer Vented Band-pass Tune to port frequency Aperiodic Set crossover to Fs of woofer Infinite Baffle Example High-Pass Set at 30Hz By removing low frequency signal that the woofer cannot produce, the woofer can play its capable range louder. -
Page 10: Sealed Example High-Pass Set At 20Hz
Sealed Example High-Pass Set at 20Hz This sealed example is the same 12-inch woofer in the recommended sealed enclosure. Up to 6 dB of boost is capable if 20 Hz was used. With +6dB of boost, the woofer has more out- put down to 15 Hz. -
Page 11: Remote Gain Operation
Orion 7005 amplifier. The RGC-1 plugs into the amplifier via the 1/8" mini jack plug. It can be installed in the front of the vehicle to control the amplifier gain level, and can be used as a bass level control on the subwoofer channel of the Orion 7005. AMPLIFIER WIRING... - Page 12 Three Channel Bridged Stereo Configuration Front and rear channels are configured for bridged two-channel operation Lowest recommended impedance for both front and rear channels is 4W Crossover and gain configurations are independently adjustable between the front, rear, and subwoofer channels. Two-channel operation is recommended for this operational mode.
-
Page 13: Amplifier Installation
AMPLIFIER INSTALLATION Choosing Mounting Locations The location of your amplifier will depend on several important issues. Due to the low pro- file size of the Orion amplifiers, there are many possible installation locations that will yield satisfactory amplifier performance. Always mount the amplifier in a place that protects the amplifier from the elements. -
Page 14: Tools Of The Trade
Power for systems with a single amplifier can be supplied by most automotive electrical sys- tems. Systems with multiple amplifiers may require a higher capacity battery, alternator or the use of a storage capacitor. We strongly recommend the use of a Directed Audio Essentials power capacitor with an extra battery in larger stereo systems. -
Page 15: Set Up And Troubleshooting
Step 6 Turn the vehicle's key switch to the off position. Step 7 Disconnect the vehicle's battery ground terminal. Step 8 Connect power wires to the amplifier (ground first, then 12 V(+) and RGC). Step 9 Connect the RCA and speaker wires to the amplifier. Check the quality of your speakers and signal connections. -
Page 16: Adjusting The Sound Of The System
Adjusting the Sound of the System Once you have checked the system's operation, adjust the sound of the system. Adjusting the sound of the system is accomplished by setting the level controls and adjusting the internal crossovers. Step 1 Turn the signal source volume control all the way down. Set any tone con- trols to their flat or defeated positions. -
Page 17: Troubleshooting Tips
Troubleshooting Tips Symptom Probable Cause No output Low or no remote turn-on Fuse blown Power wires not connected Check power wire and ground Audio input not connected Check RCA connections and Speaker wires not connected Speakers are blown Audio cycles on and off Thermal protection engages when amplifier heatsink... - Page 18 Symptom Probable Cause Distorted output Internal crossover not set properly for speakers Speakers are blown Poor bass response Speakers wired with wrong Check speaker polarity and fix polarity causing cancellation as needed. at low frequencies Crossover set incorrectly Impedance load at amplifier Check speaker impedance load, is too low Battery fuse blowing...
-
