Maintenance
FT9.9DMH 370.0 cm
(13.05 Imp.oz)
Tightening torque for engine:
Spark plug:
18.0 Nm (13.3 ft-lb) (1.84 kgf-m)
Propeller nut:
F13.5AMH 17.0 Nm (12.5 ft-lb)
(1.73 kgf-m)
F15AE 17.0 Nm (12.5 ft-lb)
(1.73 kgf-m)
F15AEH 17.0 Nm (12.5 ft-lb)
(1.73 kgf-m)
F15AEP 17.0 Nm (12.5 ft-lb)
(1.73 kgf-m)
F15AMH 17.0 Nm (12.5 ft-lb)
(1.73 kgf-m)
F9.9CE 17.0 Nm (12.5 ft-lb)
(1.73 kgf-m)
F9.9CMH 17.0 Nm (12.5 ft-lb)
(1.73 kgf-m)
FT9.9DE 21.0 Nm (15.5 ft-lb)
(2.14 kgf-m)
FT9.9DMH 21.0 Nm (15.5 ft-lb)
(2.14 kgf-m)
Engine oil drain bolt:
28.0 Nm (20.7 ft-lb) (2.86 kgf-m)
Engine oil filter:
18.0 Nm (13.3 ft-lb) (1.84 kgf-m)
EMU28222
Transporting and storing
outboard motor
EWM00690
WARNING
Leaking fuel is a fire hazard. When
G
transporting and storing the outboard
motor, close the air vent screw and fuel
cock to prevent fuel from leaking.
USE CARE when transporting fuel tank,
G
whether in a boat or car.
DO NOT fill fuel container to maximum
G
capacity. Gasoline will expand consid-
45
3
(12.51 US oz) erably as it warms up and can build up
pressure in the fuel container. This can
cause fuel leakage and a potential fire
hazard.
EWM00700
WARNING
Never get under the lower unit while it is
tilted, even if a motor support bar is used.
Severe injury could occur if the outboard
motor accidentally falls.
ECM00660
CAUTION:
Do not use the tilt support lever or knob
when trailering the boat. The outboard
motor could shake loose from the tilt sup-
port and fall. If the motor cannot be trail-
ered in the normal running position, use
an additional support device to secure it
in the tilt position.
The outboard motor should be trailered and
stored in the normal running position. If there
is insufficient road clearance in this position,
then trailer the outboard motor in the tilt po-
sition using a motor support device such as
a transom saver bar. Consult your Yamaha
dealer for further details.
EMU28235

Clamp screw mounting models

When transporting or storing the outboard
motor while removed from a boat, keep the
outboard motor in the attitude shown.
