- Page 1 Read this manual carefully before operating this vehicle. OWNER’S MANUAL XVS950AA 27B-28199-22...
- Page 2 EAU46090 Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold.
- Page 3 EAU10102 Welcome to the Yamaha world of motorcycling! As the owner of the XVS950AA, you are benefiting from Yamaha’s vast experience and newest technology regarding the design and manufacture of high-quality products, which have earned Yamaha a reputation for dependability.
-
Page 4: Important Manual Information
IMPORTANT MANUAL INFORMATION EAU10132 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. - Page 5 IMPORTANT MANUAL INFORMATION EAU10200 XVS950AA OWNER’S MANUAL ©2010 by Yamaha Motor Co., Ltd. 1st edition, May 2010 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd. is expressly prohibited. Printed in Japan.
-
Page 6: Table Of Contents
TABLE OF CONTENTS LOCATION OF IMPORTANT Sidestand ........4-17 Cast wheels ......... 7-15 LABELS ..........1-1 Ignition circuit cut-off system ..4-18 Adjusting the clutch lever free play ........... 7-15 SAFETY INFORMATION ....2-1 FOR YOUR SAFETY – Adjusting the brake lever free PRE-OPERATION CHECKS ..... - Page 7 TABLE OF CONTENTS Replacing the tail/brake light bulb ...........7-28 Replacing a turn signal light bulb ...........7-29 Replacing a license plate light bulb ...........7-30 Replacing an auxiliary light bulb ...7-31 Supporting the motorcycle ....7-31 Troubleshooting ......7-32 Troubleshooting chart ....7-33 MOTORCYCLE CARE AND STORAGE ..........8-1 Matte color caution ......8-1 Care ..........8-1...
-
Page 8: Location Of Important Labels
Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement label is available from your Yamaha dealer. - Page 9 TIRE INFORMATION TESTED 87 dB(A) 3000 r/min Cold tire normal pressure should be set as follows. SILENCING SYSTEM : YAMAHA • Up to 90 kg (198 lbs) load IDENTIFICATION : 26P FRONT : 225 kPa, (2.25 kgf/cm²), 33 psi REAR : 250 kPa, (2.50 kgf/cm²), 36 psi...
- Page 10 LOCATION OF IMPORTANT LABELS...
- Page 11 LOCATION OF IMPORTANT LABELS WARNING BEFORE YOU OPERATE THIS VEHICLE, READ THE OWNER’S MANUAL AND ALL LABELS. ALWAYS WEAR AN APPROVED MOTORCYCLE HELMET, eye protection, and protective clothing. 5GK-2118K-00...
-
Page 12: Safety Information
SAFETY INFORMATION EAU10287 Safe Riding • Ride where other motorists can Perform the pre-operation checks each see you. Avoid riding in another time you use the vehicle to make sure it motorist’s blind spot. Be a Responsible Owner is in safe operating condition. Failure to Many accidents involve inexperi- As the vehicle’s owner, you are respon- inspect or maintain the vehicle properly... - Page 13 SAFETY INFORMATION due to excessive speed or under- This motorcycle is designed for on- A passenger should also observe cornering (insufficient lean angle road use only. It is not suitable for the above precautions. for the speed). off-road use. • Always obey the speed limit and Avoid Carbon Monoxide Poisoning never travel faster than warrant- Protective Apparel...
- Page 14 Yamaha accessories, which are avail- of the motorcycle is changed. To avoid to minimize imbalance or instabili- able only from a Yamaha dealer, have the possibility of an accident, use ex- been designed, tested, and approved treme caution when adding cargo or Shifting weights can create a sud- by Yamaha for use on your vehicle.
- Page 15 • Accessories fitted to the handle- Use caution when adding electri- genuine Yamaha accessories, recog- bar or the front fork area can cal accessories. If electrical acces- nize that some aftermarket accessories...
- Page 16 SAFETY INFORMATION Check that the fuel cock (if equipped) is in the “OFF” position and that there are no fuel leaks. Point the front wheel straight ahead on the trailer or in the truck bed, and choke it in a rail to pre- vent movement.
-
Page 17: Description
DESCRIPTION EAU10410 Left view 2,3,4 5 1. Headlight (page 7-27) 9. Shift pedal (page 4-10) 2. Main fuse (page 7-26) 10.Engine oil filler cap (page 7-9) 3. Fuse box (page 7-26) 4. Fuel injection system fuse (page 7-26) 5. Owner’s tool kit (page 7-2) 6. -
Page 18: Right View
DESCRIPTION EAU10420 Right view 1. License plate light (page 7-30) 9. Rear brake light switch (page 7-17) 2. Tail/brake light (page 7-28) 10.Brake pedal (page 4-11) 3. Battery (page 7-24) 4. Rider seat lock (page 4-14) 5. Air filter element (page 7-12) 6. -
Page 19: Controls And Instruments
DESCRIPTION EAU10430 Controls and instruments 1. Clutch lever (page 4-10) 2. Left handlebar switches (page 4-8) 3. Multi-function meter unit (page 4-5) 4. Main switch/steering lock (page 4-2) 5. Front brake fluid reservoir (page 7-18) 6. Right handlebar switches (page 4-8) 7. -
Page 20: Instrument And Control Functions
Do not expose any key to exces- a Yamaha dealer to have them re-reg- sively high temperatures. istered. Do not use the key with the red Do not place any key close to bow for driving. -
Page 21: Main Switch/Steering Lock
INSTRUMENT AND CONTROL FUNCTIONS Keep other immobilizer system EAU10472 EAU48420 Main switch/steering lock keys away from the main switch All electrical circuits are supplied with as they may cause signal inter- power; the meter lighting, taillight, li- ference. cense plate lights and auxiliary light come on, and the engine can be start- ed. - Page 22 INSTRUMENT AND CONTROL FUNCTIONS EAU10683 To unlock the steering ECA11020 LOCK NOTICE The steering is locked, and all electrical Do not use the parking position for systems are off. The key can be re- an extended length of time, other- moved.
-
Page 23: Indicator Lights And Warning Lights
The oil level warning high beam of the headlight is switched light will flash ten times, then go off for 2.5 seconds. If this occurs, have a Yamaha dealer check the EAU11254 Oil level warning light “ ” vehicle. -
Page 24: Multi-Function Meter Unit
The electrical circuit of the indicator then go off for 3.0 seconds. If this oc- light can be checked by turning the key curs, have a Yamaha dealer check the to “ON”. The indicator light should vehicle. come on for a few seconds, and then go off. - Page 25 INSTRUMENT AND CONTROL FUNCTIONS two tripmeters (which show the Speedometer Odometer, tripmeters, fuel reserve distance traveled since they were tripmeter and clock last set to zero) a fuel reserve tripmeter (which shows the distance traveled on the fuel reserve) a clock a self-diagnosis device a brightness control mode 1.
- Page 26 To reset a tripmeter, select it by push- 4. Push the “RESET” switch to set code number, and then have a Yamaha ing the “SELECT” switch, and then the minutes. dealer check the vehicle.
-
Page 27: Handlebar Switches
To set the brightness key and both standard keys to a 1. Turn the key to “OFF”. Yamaha dealer and have the stan- 2. Push and hold the “SELECT” dard keys re-registered. switch. 3. Turn the key to “ON”, and then re-... - Page 28 INSTRUMENT AND CONTROL FUNCTIONS Right position. To cancel the turn signal EAU12733 Hazard switch “ ” lights, push the switch in after it has re- With the key in the “ON” or “ ” posi- turned to the center position. tion, use this switch to turn on the haz- ard lights (simultaneous flashing of all EAU12500...
-
Page 29: Clutch Lever
INSTRUMENT AND CONTROL FUNCTIONS EAU42535 EAU12820 EAU12881 “RESET” switch Clutch lever Shift pedal This switch is used to reset the tripme- ters, to set the clock and to set the brightness control mode of the multi- function meter unit. See “Multi-function meter unit” on page 4-5 for detailed information. -
Page 30: Brake Lever
INSTRUMENT AND CONTROL FUNCTIONS EAU12890 EAU12941 EAU13121 Brake lever Brake pedal Fuel tank cap 1. Brake lever 1. Brake pedal 1. Fuel tank cap lock cover 2. “ ” mark The brake lever is located at the right The brake pedal is on the right side of 3. -
Page 31: Fuel
INSTRUMENT AND CONTROL FUNCTIONS 2. Turn the key counterclockwise to EAU13221 Fuel the original position, remove it, and Make sure there is sufficient gasoline in then close the lock cover. the tank. EWA10881 WARNING The fuel tank cap cannot be installed unless the key is in the lock. -
Page 32: Fuel Tank Breather/Overflow Hose
Your Yamaha engine has been de- signed to use regular unleaded gaso- line with a research octane number of 91 or higher. If knocking (or pinging) oc-... -
Page 33: Catalytic Converter
INSTRUMENT AND CONTROL FUNCTIONS EAU13433 ECA10701 EAU42750 Catalytic converter Rider seat NOTICE This model is equipped with a catalytic Use only unleaded gasoline. The use converter in the exhaust system. To remove the rider seat of leaded gasoline will cause unre- 1. -
Page 34: Helmet Holder
INSTRUMENT AND CONTROL FUNCTIONS EAU14322 To release the helmet from the hel- Helmet holder met holder Remove the rider seat, remove the hel- met from the helmet holder, and then install the seat. 1. Projection 2. Seat holder 1. Helmet holder 2. -
Page 35: Adjusting The Shock Absorber Assembly
INSTRUMENT AND CONTROL FUNCTIONS EAU48380 ECA10101 Adjusting the shock absorber NOTICE assembly To avoid damaging the mechanism, do not attempt to turn beyond the 5 6 7 8 1 2 3 4 maximum or minimum settings. Adjust the spring preload as follows. 1. -
Page 36: Sidestand
EAU15304 this system regularly and have a Sidestand open the cylinder assembly. Yamaha dealer repair it if it does not The sidestand is located on the left side Do not subject the shock ab- function properly. of the frame. Raise the sidestand or... -
Page 37: Ignition Circuit Cut-Off System
INSTRUMENT AND CONTROL FUNCTIONS EAU44892 Ignition circuit cut-off system The ignition circuit cut-off system (com- prising the sidestand switch, clutch switch and neutral switch) has the fol- lowing functions. It prevents starting when the trans- mission is in gear and the side- stand is up, but the clutch lever is not pulled. - Page 38 INSTRUMENT AND CONTROL FUNCTIONS WARNING With the engine turned off: 1. Move the sidestand down. If a malfunction is noted, have a Yamaha 2. Make sure that the engine stop switch is set to “ ”. dealer check the system before riding.
-
Page 39: For Your Safety - Pre-Operation Checks
• If necessary, add recommended oil to specified level. • Check vehicle for oil leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check lever free play. • Adjust if necessary. Front brake •... - Page 40 • Make sure that operation is smooth. • Check throttle grip free play. Throttle grip 7-13, 7-20 • If necessary, have Yamaha dealer adjust throttle grip free play and lubricate cable and grip housing. • Make sure that operation is smooth. Control cables 7-20 •...
- Page 41 FOR YOUR SAFETY – PRE-OPERATION CHECKS ITEM CHECKS PAGE • Check operation of ignition circuit cut-off system. Sidestand switch 4-17 • If system is not working correctly, have Yamaha dealer check vehicle.
-
Page 42: Operation And Important Riding Points
Yamaha dealer. The transmission is in the neutral gine in case of a turnover. In this position. -
Page 43: Shifting
The neutral indicator with the engine off, and do not light should come on. If not, ask a tow the motorcycle for long dis- Yamaha dealer to check the elec- tances. The transmission is trical circuit. properly lubricated only when 3. -
Page 44: Tips For Reducing Fuel Consumption
Since the engine is brand new, do not gine speeds during acceleration. immediately have a Yamaha dealer put an excessive load on it for the first Do not rev the engine while shifting check the vehicle. -
Page 45: Parking
OPERATION AND IMPORTANT RIDING POINTS EAU17213 Parking When parking, stop the engine, and then remove the key from the main switch. EWA10311 WARNING Since the engine and exhaust system can become very hot, park in a place where pedestri- ans or children are not likely to touch them and be burned. -
Page 46: Periodic Maintenance And Adjustment
– possibly leading to pending on the weather, terrain, geo- that is certified (if applicable). Yamaha death. See page 2-1 for more in- graphical location, and individual use, dealers are trained and equipped to... -
Page 47: Owner's Tool Kit
If you do not have the tools or experi- ence required for a particular job, have a Yamaha dealer perform it for you. -
Page 48: Periodic Maintenance Chart For The Emission Control System
From 50000 km (30000 mi), repeat the maintenance intervals starting from 10000 km (6000 mi). Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technical skills. -
Page 49: General Maintenance And Lubrication Chart
PERIODIC MAINTENANCE AND ADJUSTMENT EAU1770C General maintenance and lubrication chart ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) √ Air filter element •... - Page 50 PERIODIC MAINTENANCE AND ADJUSTMENT ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) • Check belt condition. • Replace if damaged. 10 * Drive belt •...
- Page 51 PERIODIC MAINTENANCE AND ADJUSTMENT ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) √ √ √ √ Rear suspension re- •...
- Page 52 PERIODIC MAINTENANCE AND ADJUSTMENT Hydraulic brake service • Regularly check and, if necessary, correct the brake fluid level. • Every two years replace the internal components of the brake master cylinders and calipers, and change the brake fluid. • Replace the brake hoses every four years and if cracked or damaged.
-
Page 53: Removing And Installing The Panel
Do not attempt to diagnose such problems yourself. Instead, have To remove the panel a Yamaha dealer check the vehicle. Remove the bolt, and then pull the pan- If a spark plug shows signs of electrode el off as shown. -
Page 54: Engine Oil And Oil Filter Cartridge
PERIODIC MAINTENANCE AND ADJUSTMENT Before installing a spark plug, the spark EAU47112 Engine oil and oil filter car- plug gap should be measured with a If a torque wrench is not available when tridge wire thickness gauge and, if necessary, installing a spark plug, a good estimate The engine oil level should be checked adjusted to specification. - Page 55 PERIODIC MAINTENANCE AND ADJUSTMENT 5. If the engine oil is at or below the minimum level mark, add sufficient The engine oil should be between the oil of the recommended type to minimum and maximum level marks. raise it to the correct level. 6.
- Page 56 PERIODIC MAINTENANCE AND ADJUSTMENT Recommended engine oil: See page 9-1. An oil filter wrench is available at a Oil quantity: Yamaha dealer. Without oil filter cartridge replace- ment: 5. Apply a thin coat of clean engine 3.70 L (3.91 US qt, 3.26 Imp.qt)
-
Page 57: Replacing The Air Filter Element
The engine should never off and have a Yamaha dealer check be operated without the air filter the vehicle. element installed, otherwise the 10. -
Page 58: Checking The Throttle Grip Free Play
To prevent this cle, note the following points regarding from occurring, the valve clearance the specified tires. must be adjusted by a Yamaha dealer at the intervals specified in the periodic Tire air pressure maintenance and lubrication chart. - Page 59 Yamaha dealer immediately and edge and experience to do so. have the tire replaced. Ride at moderate speeds after...
-
Page 60: Cast Wheels
After extensive tests, only the tires list- fore each ride. If any damage is ed below have been approved for this found, have a Yamaha dealer re- model by Yamaha Motor Co., Ltd. place the wheel. Do not attempt even the smallest repair to the Front tire: wheel. -
Page 61: Adjusting The Brake Lever Free Play
PERIODIC MAINTENANCE AND ADJUSTMENT decrease the clutch lever free play, decrease the clutch lever free play, EAU22093 Adjusting the brake lever free turn the adjusting bolt in direction turn the adjusting nut in direction play (b). (b). 7. Tighten the locknut at the clutch cable, and then slide the rubber If the specified clutch lever free play covers to their original positions. -
Page 62: Brake Light Switches
Front brake pads presence of air in the hydraulic system. If there is air in the hy- draulic system, have a Yamaha 1. Rear brake light switch dealer bleed the system before 2. Rear brake light switch adjusting nut operating the motorcycle. -
Page 63: Checking The Brake Fluid Level
EAU22580 Before riding, check that the brake fluid Checking the brake fluid level peared, have a Yamaha dealer replace is above the minimum level mark and the brake pads as a set. replenish if necessary. A low brake fluid... -
Page 64: Changing The Brake Fluid
EAU23040 Changing the brake fluid Drive belt slack ter the brake fluid reservoir when Have a Yamaha dealer change the The drive belt slack should be checked refilling. Water will significantly brake fluid at the intervals specified in and adjusted at the intervals specified... -
Page 65: Checking And Lubricating The Cables
A belt tension gauge is available at a bles and cable ends should be lubricat- Yamaha dealer at the intervals speci- Yamaha dealer. ed if necessary. If a cable is damaged fied in the periodic maintenance chart. -
Page 66: Checking And Lubricating The Brake And Shift Pedals
PERIODIC MAINTENANCE AND ADJUSTMENT EAU44272 EAU23142 Recommended lubricant: Checking and lubricating the Checking and lubricating the Lithium-soap-based grease brake and shift pedals brake and clutch levers Brake pedal Brake lever Shift pedal Clutch lever The operation of the brake and shift The operation of the brake and clutch pedals should be checked before each levers should be checked before each... -
Page 67: Checking And Lubricating The Sidestand
The operation of the sidestand should The swingarm pivots must be lubricat- be checked before each ride, and the ed by a Yamaha dealer at the intervals sidestand pivot and metal-to-metal specified in the periodic maintenance contact surfaces should be lubricated if and lubrication chart. -
Page 68: Lubricating The Rear Suspension
The pivoting points of the rear suspen- face and hold it in an upright posi- fork does not operate smoothly, sion must be lubricated by a Yamaha tion. WARNING! To avoid injury, have a Yamaha dealer check or re- dealer at the intervals specified in the securely support the vehicle so pair it. -
Page 69: Checking The Steering
If any free (Valve Regulated Lead Acid) battery. the wheel bearings. play can be felt, have a Yamaha There is no need to check the electro- dealer check or repair the steering. lyte or to add distilled water. However, the battery lead connections need to be checked and, if necessary, tightened. - Page 70 To charge the battery once a month and fully charge it if Have a Yamaha dealer charge the bat- necessary. tery as soon as possible if it seems to 3. Fully charge the battery before in- have discharged.
-
Page 71: Replacing The Fuses
PERIODIC MAINTENANCE AND ADJUSTMENT EAU47134 Replacing the fuses The main fuse, the fuel injection system fuse, and the fuse box, which contains the fuses for the individual circuits, are located under the rider seat. (See page 4-14.) 1. Ignition fuse 1. -
Page 72: Replacing The Headlight Bulb
4. If the fuse immediately blows using a cloth moistened with al- again, have a Yamaha dealer cohol or thinner. check the electrical system. Headlight lens Do not affix any type of tinted film or stickers to the headlight 1. -
Page 73: Replacing The Tail/Brake Light Bulb
6. Install the headlight unit by install- ing the screws. 7. Have a Yamaha dealer adjust the headlight beam if necessary. 1. Headlight bulb holder 4. Place a new headlight bulb into po- sition, and then secure it with the bulb holder. -
Page 74: Replacing A Turn Signal Light Bulb
PERIODIC MAINTENANCE AND ADJUSTMENT EAU24212 Replacing a turn signal light bulb 1. Remove the turn signal lens by re- moving the screws. 1. Tail/brake light bulb 1. Turn signal light lens 2. Turn signal light bulb 3. Insert a new bulb into the socket, 3. -
Page 75: Replacing A License Plate Light Bulb
PERIODIC MAINTENANCE AND ADJUSTMENT EAU24324 6. Install the license plate light unit by Replacing a license plate light installing the rubber dampers, bulb washers and the nuts. 1. Remove the license plate light unit by removing the nuts, washers and rubber dampers. -
Page 76: Replacing An Auxiliary Light Bulb
PERIODIC MAINTENANCE AND ADJUSTMENT EAU45222 EAU24350 Replacing an auxiliary light Supporting the motorcycle bulb Since this model is not equipped with a centerstand, follow these precautions If the auxiliary light bulb burns out, re- when removing the front and rear place it as follows. -
Page 77: Troubleshooting
However, should your motorcycle require any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, experience, and know-how to service the motorcycle properly. -
Page 78: Troubleshooting Chart
Remove the spark plugs and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the battery. 4. Battery The engine turns over The battery is good. -
Page 79: Motorcycle Care And Storage
Rust and corrosion can develop matte colored finished parts. Be Cleaning even if high-quality components are sure to consult a Yamaha dealer for ECA10772 advice on what products to use be- used. A rusty exhaust pipe may go un- NOTICE fore cleaning the vehicle. - Page 80 MOTORCYCLE CARE AND STORAGE off any detergent residue using Test the product on a small hid- plenty of water, as it is harmful den part of the windshield to Salt sprayed on roads in the winter may to plastic parts. make sure that it does not leave remain well into spring.
-
Page 81: Storage
Contaminants on the brakes or tires of the presence of ammonia) can cause loss of control. Consult a Yamaha dealer for ad- and areas where strong chemi- Make sure that there is no oil or vice on what products to use. - Page 82 MOTORCYCLE CARE AND STORAGE 2. Fill up the fuel tank and add fuel e. Remove the spark plug caps stabilizer (if available) to prevent from the spark plugs, and then Make any necessary repairs before the fuel tank from rusting and the install the spark plugs and the storing the motorcycle.
-
Page 83: Specifications
SPECIFICATIONS Dimensions: Engine oil: Fuel reserve amount: 3.4 L (0.90 US gal, 0.75 Imp.gal) Overall length: Recommended brand: Fuel injection: 2435 mm (95.9 in) YAMALUBE Overall width: Type: Throttle body: 985 mm (38.8 in) SAE 10W-30, 10W-40, 10W-50, 15W-40, ID mark: Overall height: 20W-40 or 20W-50 5S71 00... - Page 84 SPECIFICATIONS 4th: Tire air pressure (measured on cold Operation: 34/27 (1.259) Right foot operation tires): 5th: Recommended fluid: Loading condition: 25/24 (1.042) DOT 4 0–90 kg (0–198 lb) Chassis: Front suspension: Front: Frame type: Type: 225 kPa (2.25 kgf/cm², 33 psi) Double cradle Telescopic fork Rear:...
- Page 85 SPECIFICATIONS Tail/brake light: Ignition fuse: 12 V, 5.0 W/21.0 W × 1 15.0 A Front turn signal light: Parking lighting fuse: 12 V, 21.0 W × 2 10.0 A Rear turn signal light: Fuel injection system fuse: 12 V, 21.0 W × 2 10.0 A Auxiliary light: Backup fuse:...
-
Page 86: Consumer Information
Record the vehicle identification num- ber and model label information in the spaces provided below for assistance when ordering spare parts from a Yamaha dealer or for reference in case the vehicle is stolen. VEHICLE IDENTIFICATION NUMBER: 1. Vehicle identification number 1. -
Page 87: Motorcycle Noise Regulation (For Australia)
CONSUMER INFORMATION EAU26570 Motorcycle noise regulation (for Australia) TAMPERING WITH NOISE CON- TROL SYSTEM PROHIBITED: Owners are warned that the law may prohibit: a. The removal or rendering inopera- tive by any person other than for purposes of maintenance, repair or replacement, of any device or element of design incorporated into any new vehicle for the pur-... - Page 88 INDEX Fuel level warning light ......4-4 Parking ............6-4 Fuel tank breather/overflow hose ..4-13 Part locations .......... 3-1 Air filter element, replacing ....7-12 Fuel tank cap ........4-11 Pass switch ..........4-9 Auxiliary light bulb, replacing ....7-31 Fuses, replacing ........
- Page 89 INDEX Turn signal switch........4-9 Valve clearance ........7-13 Vehicle identification number....10-1 Wheel bearings, checking ....7-24 Wheels..........7-15...
- Page 92 YAMAHA MOTOR CO., LTD. PRINTED ON RECYCLED PAPER PRINTED IN JAPAN 2010.05-0.3×1 CR...
