IMPORTANT: Dry the Collector Cell thoroughly outside of
the Air Purifier before reinstalling it into the Air Purifier.
Ensure that all areas including corners and areas that may
trap water are dry before reinstalling into the Air Purifier.
If the power indicator light is red after replacing Collector
Cell, then the Collector Cell is still wet. Remove Collector
Cell and allow it to finish drying
Replacing The Charcoal Odor Absorber
(Optional)
In addition to air purification, your Oreck Air Purifier provides the
additional benefit of odor removal. The odor removal function is
optional. Your Oreck Air Purifier will continue to remove harmful
airborne particles with its permanent Electronic Collector Cell
even if you choose not to use the optional Charcoal Odor
Absorber.
Odor absorption effectiveness will gradually deteriorate over time
unless the Charcoal Odor Absorber is replaced. While every
environment is different, Oreck suggests that the Charcoal Odor
Absorber be replaced every two months or as needed.
IMPORTANT: DO NOT wash the Charcoal Odor Absorber.
Replace, if necessary.
Replacing Collector Cell After Cleaning
1. Snap in the Charcoal Odor Absorber (fig. 5).
2. Slide in the Pre-Filter (fig. 6).
3. Slide Collector Cell into cabinet, using handles (fig. 4).
4. Replace front grill. Unit is now ready for operation (fig. 3).
NOTE: An occasional "arcing" sound is normal when
operating the unit immediately after cleaning the Cell and
should stop after a few minutes of operation.
Replacing Fragrance Cartridge
1. Open Fragrance Cartridge compartment by sliding the
Fragrance compartment release switch (fig. 7).
2. Remove Fragrance Cartridge from center of the compartment
and replace with a new one (fig. 8).
3. Close compartment until it locks (fig. 9).
NOTE: One Fragrance Cartridge is included.
