Oracle V Owner's Manual page 6

changing the position of the spring in its holder. The color coding is visible
from the inside at the wider end of the spring.
Note 2: The reference to clockwise or counter-clockwise is determined by viewing
the spring from above, unless otherwise mentionned.
Note 3: By hand the spring can only be rotated counterclockwise in its holder but,
using needle nose pliers, it can be held near the tip at the wider end. It is
then possible to move it clockwise. If this cannot be done, rotate the
spring counterclockwise until it comes out and reinsert it from under the
holder leaving more of the spring out.
Note 4: Before installing the spring back into the suspension housing, hold it with
one hand and pull on it at the wider end, this stretching will insure a
positive seating in the threads of the holder.
Step one Pre-loading the spring.
- Ajust the spring so three coils are showing below the holder.
Step two Preparing a spring module.
- Position the upper spring damper over the suspension stem.
- Install the sorbothane damper over the spring holder and seat it well
around the lip.
- Insert the spring assembly into the suspension housing.
- Install the suspension housing over the spring assembly.
Note 5: The factory standard settings
ALUMINIUM TOWERS:
Yellow, front left module
Red, rear left module
Green, right module
The blue spring is supplied as extra.
Note 6: The standard spring combination will accommodate most tonearms.
Step three Calibrating the suspension.
... calibrate the suspension...
Note 7: Before beginning this step the record clamp and an old record must be in
place over the platter. This will give a more accurate operational mass of the
sub chassis.
Note 8: Do not install the drive belt nor the phono lead so as to prevent any bias in
the interpretation of the calibration.
GOLD TOWERS:
Red, front left module
Green, rear left module
Blue, right module
The yellow spring is supplied as extra.
6
