NVE-N871A
DVD Car Navigation System
HARDWARE MANUAL
Please read before using this equipment.
R R

Advertisement

Table of Contents
loading

Related Manuals for Alpine NVE-N871A

Summary of Contents for Alpine NVE-N871A

  • Page 1 ALPINE ELECTRONICS OF CANADA, INC. Suite 203, 7300 Warden Ave. Markham, Ontario L3R 9Z6, Canada Tel.: 1-800-ALPINE-1 (1-800-257-4631) NVE-N871A 1-888-NAV-HELP (1-888-628-4357) ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD. 6-8 Fiveways Boulevarde Keysborough, DVD Car Navigation System Victoria 3173, Australia Tel.: (03) 9769-0000 ALPINE ELECTRONICS GmbH...

  • Page 2: Precautions

    PRECAUTIONS IMPORTANT INFORMATION, PLEASE READ CAREFULLY BE- FORE USING THIS PRODUCT. This product is intended to safely provide turn by turn instruction to get you to a desired destination. Please read the following precautions to ensure that you use this navigation system correctly. ✵...
  • Page 3 ✵ If there is anything in the manual which you do not understand or are uncertain about the operation of the navigation system, please contact your local Alpine authorized navigation dealer or 1-888-NAV-HELP before using the navigation system.

  • Page 4: Precautions

    Points to Observe for Safe Usage a Read this manual carefully before using this navigation system. It contains instructions on how to use this product in a safe and effective manner. Alpine cannot be responsible for problems resulting from failure to observe the instructions in this manual.

  • Page 5: Warning/Caution

    Warning DO NOT OPERATE ANY FUNCTION THAT TAKES YOUR ATTEN- TION AWAY FROM SAFELY DRIVING YOUR VEHICLE. Any function that requires your prolonged attention should only be per- formed after coming to a complete stop. Always stop the vehicle in a safe location before performing these functions.
  • Page 6 HALT USE IMMEDIATELY IF A PROBLEM APPEARS. Failure to do so may cause personal injury or damage to the product. Return it to your authorized Alpine dealer or the nearest Alpine Service Center for repairing. DO NOT MIX NEW BATTERIES WITH OLD BATTERIES. INSERT WITH THE CORRECT BATTERY POLARITY.

  • Page 7: Table Of Contents

    Table of Contents Precautions ................2 Precautions Points to Observe for Safe Usage ..........4 Warning/Caution ................ 5 Navigation Systems Overview ..........8 Preface Remote control (RUE-4119) Before Using This Names of Parts ............... 10 System Replacing the batteries ............11 Remote Control Holder Installation ........

  • Page 8: Preface

    Preface Navigation Systems Overview This navigation system uses three different sensing devices to determine the present location and to track the progress of the vehicle. These three sensors are: a GPS (Glo- bal Positioning System) sensor which uses satellites to determine the current position of the vehicle, a gyroscope which determines which direction the vehicle turns, and speedometer pulses which determine how far the vehicle has traveled.
  • Page 9 Gyroscope The gyroscope is a sensor that accurately gation system, the gyroscope is used to- measures the angle by which the direction of gether with the speed sensor, making it a vehicle or other moving body changes. possible to display the present position of the Gyroscopes are used in inertial navigation vehicle even in locations where GPS signals systems for airliners and ships.

  • Page 10: Before Using This System

    Before Using This System Remote control (RUE-4119) Names of the Parts Remote Control Transmitter indicator transmitter Lights up to show that a remote control function is being utilized. This section transmits the remote control signals. Aim the remote Rotary encoder control toward the display monitor This has multiple functions.

  • Page 11: Replacing The Batteries

    Remote control (RUE-4119) a Avoid dropping this remote control or placing it in pants pockets. Doing so may cause damage to the case or buttons, shorten battery life or cause the system to malfunction. a To clean this device, wipe it with a dry cloth. (If it is extremely dirty, wipe it with a wrung damp cloth.) Never use benzene, paint thinner or harsh chemicals which can cause Tips deterioration of the case or paint.

  • Page 12: Main Unit

    DVD-ROM with the ignition Eject button Press to key turned OFF. eject the DVD-ROM. a Do not insert any DVD Video discs or other non-Alpine DVD-ROMs. Inserting the DVD-ROM Removing the DVD-ROM Open the DVD-ROM Open the door.

  • Page 13: Operation

    Operation Turning the System On Turn the ignition key to the ACC or ON position. The opening screen appears on the monitor display. Insert your DVD-ROM. For instructions on inserting the DVD-ROM, see page 12. After completing the above steps, please refer to the DVD-ROM user's guide to learn more about your naviga- tion system software.

  • Page 14: Reference

    If you encounter a problem, please review the items in the following checklist. This guide will help you isolate the problem if the unit is at fault. Otherwise, make sure the rest of your system is properly connected or consult your authorized Alpine dealer. Symptom...

  • Page 15: Error Messages

    Error messages Various messages are displayed on the screen during operation. In addition to the messages telling you the current status or providing guidance for the next maneuver, the following error messages may appear. If one of these error messages is displayed, carefully follow the in- structions in the solution column.

  • Page 16: Specifications

    Reference Specifications Power requirement 14.4 VDC (11 – 16 V allowable) negative ground 14°F to 122°F (–10°C to +50°C) Operating temperature (main unit) Antenna type Micro-strip planar antenna 1575.42 ± 1 MHz Reception frequency Reception sensitivity –130 dB max. Reception method Parallel 8 channels Typical: 1.0 A Current consumption...
  • Page 17 Note...
