Summary of Contents for SMC Networks SMC1233A-TX
- Page 1 EZ Connect Fast Ethernet Lan Card 10/100Mbps PCI Quick Start Guide SMC1233A-TX...
-
Page 2: Package Checklist
To Begin Operating systems This network card is compatible and comes with drivers for the following operating systems: • Microsoft Windows for Workgroup 3.11 • Microsoft Windows® 95 / 98 / NT / 2000 • Netware 4.11, 5.0, FreeBSD 3.0, Linux Computer A PC with an available PCI slot. - Page 3 Install SMC 10/100Mbps Fast Ethernet LAN Card Make sure that all computers are turned OFF and disconnected from power cord. Before installing cards in your computers, make sure you have the operating system installation disks or CD-ROM (especially for Windows based computer) and the installation CD provided in the SMC package.
-
Page 4: Driver Installation
Browse and select driver folder from your CDRom drive. 6. Screen will display “SMC1233A-TX 10/100Mbps PCI NIC.” Click “OK”. 7. Your device will be recognised as a “SMC1233A-TX 10/100Mbps PCI NIC”. Click “Next”. You may be prompted to restart your machine after the installation is complete. -
Page 5: Windows Xp Installation
Windows XP Installation Windows XP has a built in driver for the SMC1233A-TX card. Follow the installation instructions on page 4 and when you restart your PC, the card will automatically be installed with a Generic Macronix driver. Updating Windows XP Generic driver to the SMC1233A-TX driver 1. - Page 6 Copyright Information furnished by SMC brand is believed to be accurate and reliable. However, no responsibility is assumed by SMC for its use, nor for any infringements of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent or patents by SMC.
- Page 7 SMC1233A-TX Model IEEE 802.3, 10BASE-T Standards IEEE 802.3u, 100BASE-TX PCI Local Bus Specication, rev. 2.0 or later RJ-45 for 10BASE-T and Interface 100BASE-TX +5 VDC @ 120mA (Standby); Power @ 160mA (Transmit) 10 Half 150mA 10 Full 160mA 100 Half...
