- Page 1 Presentation Series HD Projection Display Installation and Setup Guide for System Installer Model PRO900X ® Presentation is a registered trademark of Zenith Electronics Corporation...
-
Page 2: Safety Warnings
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. -
Page 3: Table Of Contents
Safety Warnings Safety Warnings ......2 Installation Overview Installer’s Experience Level ....4 Installation Considerations . -
Page 4: Installation Overview
Installer’s Experience Level The PRO900X is a sophisticated Entertainment Machine . In addition to making the necessary connections, installation will most likely require a series of adjustments to ensure the projected image is not distorted. If these adjustments are not accu- rate, the operation of the PRO900X could be adversely affected. -
Page 5: Specifications
PRO900X Note: Specifications are subject to change without prior notice. Optical PROJECTION SYSTEM — CRT; 7-inch High Performance Liquid Cooled Tubes, 5-inch active phosphor area, 90 degree deflection angle, Super Oxide Cathodes. LENSES — High resolution color corrected multi-layered coating hybrid lens system. -
Page 6: Standard Connections
CONNECTING COMPUTER VIDEO SOURCES Connect a video source such as a computer: PC, Laptop, or Notebook type. To hook up a laptop or computer, use a cable with a 15-pin D-type connector on one end and BNC connectors on the other end. CONNECTING VIDEO AND S-VIDEO SOURCES Connect video sources with a tuner, (VCR) or other video sources such as a DVD player or satellite receiver. -
Page 7: Connector Pin Wiring Reference
STANDARD CONNECTIONS P A G E 7 3276-A... -
Page 8: Connection / Control Panel
CONNECTIONS / CONTROL PANEL SELECTS MENU OPTIONS REMOTE CONTROL WINDOW S-VIDEO INPUT JACK COMMUNICATIONS PORT INTER-CONNECT JACK (RJ-11) Loop Out, Loop In, Setup Switch (Set LOOP switch to “Out” if routing composite video to a second projector.) Selecting the Input Source The type of input signal determines which source is being viewed. -
Page 9: Remote Control
REMOTE CONTROL MBR3470T The MBR3470T remote control is used specifically for servicing and setup adjustment. It provides the special functions needed for geometry, convergence, and system setup that other remotes cannot perform. Red, Green, Blue Vertical and Horizontal Selects formats, sets Adjusts selected Floor/Ceiling or a specific geometry/convergence... -
Page 10: Product Overview
The PRO900X HD Projection Display system is a high reso- lution multiple signal format display monitor. It uses 7” high performance liquid cooled CRTs. Each CRT has a 5” active phosphor area and a 90 degree deflection angle. The CRTs use high-resolution color corrected multi-layered hybrid lens assemblies. -
Page 11: Monitor Rear View
Be sure to read and understand the setup section before you attempt to install a PRO900X system; you will find tables and examples of the required installation data for a successful installation. Also, the user Operating Guide and Vertical Active - vertical deflection yoke drive is present in the 9-1510 module. Video Enable - all conditions are ready for high voltage to turn on via the 9-1504 mo 3276-A REAR VIEW... -
Page 12: Monitor Top/ Inside View
TOP / INSIDE VIEW P A G E 1 2 3276-A... -
Page 13: Setup Remote Control Key Functions
The PRO900X will be supplied with the MBR3470T and a Universal customer remote control. For most servicing situ- ations the MBR3470T is required. The MBR3470T has the special functions needed for geometry/convergence adjust- ments and system setup functions which the Universal cus- tomer remote cannot perform. -
Page 14: Setup Mode Notes And Cautions
SETUP MODE NOTES AND CAUTIONS 1. When you enter the setup mode, the system is in the “Geometry Mode” (the shape controls adjust all three colors at the same time). To adjust an individual color (i.e. Red to adjust SKEW), you must press the “Red Select”... -
Page 15: Specifications For Rgb Sync Inputs
SPECIFICATIONS FOR RGB SYNC INPUTS I. SYNC INPUTS There are three Sync signal inputs for use with RGB sources: 1. SYNC-ON-GREEN (SOG) - - this is through the Green video input BNC jack, terminated 75 ohms. 2. HORIZONTAL/COMPOSITE (H / Comp) - - through a BNC jack on the 9-1515 Combo module, software switchable termination 2K/75 ohms. -
Page 16: Notes
NOTES P A G E 1 6 3276-A... -
Page 17: Screen Size Selection
Courtesy of Draper Shade & Screen One of the most important decisions in screen selection is to determine the correct size of screen based upon- 1. The dimensions of the audience area. 2. The projection format, or formats, to be used. In some situations, these two questions yield the same answer;... -
Page 18: Setup And Alignment Procedure
SETUP AND ALIGNMENT PROCEDURE PROCEDURE OVERVIEW There are several situations to consider when performing the setup procedure for the PRO900X System. The setup procedure will vary depending on the required physical and signal configuration. The simplest setup is that of a “factory configured” projector which will use the preset conditions. -
Page 19: Setup Reference Illustrations
9 - 1505 Module 9 - 1510 Module 9 - 1509 Module Top Edge 3276-A SETUP REFERENCES Top View Setup Menus P A G E 1 9... -
Page 20: Physical Setup
EXAMPLES OF DISPLAY SETUP DISTANCES AND CENTER POINTS “A”* “B” Screen Projection Display Width Distance Center 48” 58 5/8” 26 3/8” 60” 72 7/8” 30 3/4” 80” 96 3/8” 38” 96” 115 1/4” 43 5/8” 120” 143 1/2” 52 3/8” 144”... - Page 21 SYSTEM ALIGNMENT Mount Bracket Center 11" from Front Panel Under the Green CRT Center P A G E 2 1 3276-A...
-
Page 22: Iii. Preliminary Alignment Setup
III. PRELIMINARY ALIGNMENT SETUP The following procedures are intended for complete “Geometry/Convergence” setup. Use the customer’s signal for doing phase, and size adjustments. You can use the internal pat- terns for shape and convergence if the customer signal sources do not have a cross-hatch pattern. - Page 23 focus procedure. See the figure above. a. Turn on the projector, project a cross-hatch pattern on the screen. Cover up both the Blue and Red lenses. Work only on the Green lens. b. Tighten all 4 lens mounting screws. c. Loosen all 4 lens mounting screws 3 full turns. d.
- Page 24 IV. Final Detailed Geometry/Convergence Setup Use the video patterns generated by the customer’s signal source for final alignment. If this is not possible, use the internal cross hatch pattern only to do the geometry and convergence. The cus- tomer’s signal must be used for blanking, size, centering and phase.
-
Page 25: Geometry Convergence
DIGITAL DISPLAY SETUP PROCEDURE GEOMETRY CONVERGENCE Geometry controls all three colors at the same time. January 1998 Remote Adjustment Goal 1. SIZE H. Size Set to fill screen at C and D. (Use external source not internal test pattern) 2. SIZE V. -
Page 26: Convergence Setup Controls
P A G E 2 6 3276-A... -
Page 27: Convergence Of Red And Blue Onto Green
DIGITAL DISPLAY SETUP PROCEDURE CONVERGENCE OF RED AND BLUE ONTO GREEN It is desirable to Mute color you are not adjusting. Select the color you want to adjust by pressing the RED or BLUE key Remote Adjustment Goal 1. SMALL H. -
Page 28: Notes
NOTES © Copyright 2000 Zenith Electronics Corporation 206-3634 1000 Milwaukee Avenue, Glenview, Illinois 60025-2495...
