Panasonic CS-ME5PKE Service Manual

Indoor unit
Hide thumbs Also See for CS-ME5PKE:
Table of Contents

Advertisement

Quick Links

Download this manual
Please file and use this manual together with the service manual for Model No. CS-E7PKEW CS-E9PKEW CS-E12PKEW
CS-E15PKEW CS-E18PKEW CS-E21PKEW CS-E24PKEW CS-E28PKES, Order No. PAPAMY1212045CE and CU-2E18PBE
CU-3E18PBE CU-4E23PBE, Order No. PAPAMY1301048CE.
This service information is designed for experienced repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to service
or repair the products dealt with in this service information by anyone else could result in serious injury or death.
In order to avoid frostbite, be assured of no refrigerant leakage during the installation or repairing of refrigerant circuit.
WARNING
PRECAUTION OF LOW TEMPERATURE
Order No: PAPAMY1303091AE
Indoor Unit
CS-ME5PKE
Destination
Europe
© Panasonic Corporation 2013.

Advertisement

Table of Contents
loading

Related Manuals for Panasonic CS-ME5PKE

Summary of Contents for Panasonic CS-ME5PKE

  • Page 1 PRECAUTION OF LOW TEMPERATURE In order to avoid frostbite, be assured of no refrigerant leakage during the installation or repairing of refrigerant circuit. © Panasonic Corporation 2013.
  • Page 2 CAUTION Before performing any of the electrical installation works, please verify on which of the intended connection use. Generally there are 2 types of indoor-outdoor connections: ○ Single Connection (Single Indoor Unit connects with Single Outdoor Unit) ○ Multiple Connection (Multiple Indoor Unit connect with Single Outdoor Unit) Both connections have different connecting methods.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS 1. Safety Precautions..........4 2. Specifications .............6 3. Wiring Connection Diagram......13 Indoor Unit..........13 4. Electronic Circuit Diagram ......14 Indoor Unit..........14 5. Installation Instruction........15 Select the Best Location ......15 Indoor Unit..........16 6. Exploded View and Replacement Parts List .22 Indoor Unit..........22...

  • Page 4: Safety Precautions

    1. Safety Precautions  Read the following “SAFETY PRECAUTIONS” carefully before perform any servicing.  Electrical work must be installed or serviced by a licensed electrician. Be sure to use the correct rating of the power plug and main circuit for the model installed. ...
  • Page 5 WARNING During pump down operation, stop the compressor before remove the refrigeration piping. (Removal of compressor while compressor is operating and valves are opened will cause suck-in of air, abnormal high pressure in refrigeration cycle and result in explosion, injury etc.) After completion of installation or service, confirm there is no leakage or refrigerant gas.

  • Page 6: Specifications

    2. Specifications Model Indoor CS-ME5PKE Performance Test Condition EUROVENT Phase, Hz Single, 50 Power Supply Min. Mid. Max. 1.30 1.60 2.30 Capacity BTU/h 4430 5460 7840 Running Current – 2.00 – Input Power Annual Consumption – – 3.59 4.00 5.20...
  • Page 7 Model Indoor CS-ME5PKE Height (I/D) mm (inch) 295 (11-5/8) Dimension Width (I/D) mm (inch) 870 (34-9/32) Depth (I/D) mm (inch) 255 (10-1/16) Weight Net (I/D) kg (lb) 10 (22) Pipe Diameter Piping mm (inch) 6.35 (1/4) / 9.52 (3/8) (Liquid / Gas) Inner Diameter 16.7...
  • Page 8 A single outdoor unit enables air conditioning of up to three separate rooms for CU-3E18PBE. A single outdoor unit enables air conditioning of up to four separate rooms for CU-4E23PBE. OUTDOOR UNIT CONNECTABLE INDOOR UNIT CU-2E15PBE CU-2E18PBE CU-3E18PBE CU-4E23PBE ROOM TYPE 1.6kW CS-ME5PKE ● ● ● ● ● ● ● ● ● ● ●...

  • Page 9: Indoor Unit Capacity

     Indoor Unit : CS-ME5PKE  Outdoor Unit : CU-2E15PBE 2Room 1Room Indoor Unit Capacity (kW) Total Indoor Capacity (kW) Indoor Unit Capacity (kW) Total Indoor Capacity (kW) 1.6+1.6 1.6+2.0 1.6+2.5 1.6+2.8 1.6+3.2 2.0+2.0 2.0+2.5 2.0+2.8 2.0+3.2 2.5+2.5 2.5+2.8 ...

  • Page 10: Indoor Unit Capacity

     Indoor Unit : CS-ME5PKE  Outdoor Unit : CU-3E18PBE 3Room 2Room 1Room Indoor Unit Total Indoor Indoor Unit Total Indoor Indoor Unit Total Indoor Capacity (kW) Capacity (kW) Capacity (kW) Capacity (kW) Capacity (kW) Capacity (kW) 1.6+1.6+1.6 1.6+3.2 1.6+1.6+2.0 1.6+4.0...

  • Page 11: 1Room

     Indoor Unit : CS-ME5PKE  Outdoor Unit : CU-4E23PBE 4Room 3Room 2Room 1Room Indoor Unit Total Indoor Indoor Unit Total Indoor Indoor Unit Total Indoor Indoor Unit Total Indoor Capacity (kW) Capacity (kW) Capacity (kW) Capacity (kW) Capacity (kW)

  • Page 12: Temperature Of 35°C Dry Bulb, 24°C Wet Bulb

    4Room 3Room 2Room 1Room Indoor Unit Total Indoor Indoor Unit Total Indoor Indoor Unit Total Indoor Indoor Unit Total Indoor Capacity (kW) Capacity (kW) Capacity (kW) Capacity (kW) Capacity (kW) Capacity (kW) Capacity (kW) Capacity (kW) 2.0+2.5+2.8+3.2 10.5 2.8+2.8+3.2 2.0+2.5+3.2+3.2 10.9 2.8+2.8+4.0 2.0+2.8+2.8+2.8...

  • Page 13: Wiring Connection Diagram

    3. Wiring Connection Diagram Indoor Unit...

  • Page 14: Electronic Circuit Diagram

    4. Electronic Circuit Diagram Indoor Unit...

  • Page 15: Installation Instruction

    5. Installation Instruction Select the Best Location 5.1.2 Indoor Unit Installation Diagram 5.1.1 Indoor Unit  Do not install the unit in excessive oil fume area such as kitchen, workshop and etc.  There should not be any heat source or steam near the unit.

  • Page 16: Indoor Unit

    Indoor Unit 5.2.1 How to fix the Installation Plate The mounting wall shall be strong and solid enough to prevent it from vibration. Dimension Model       ME5*** 490 mm 82 mm 439 mm 432 mm 43 mm 95 mm ○...
  • Page 17 5.2.3 Indoor Unit Installation 5.2.3.1 For the right rear piping 5.2.3.3 For the embedded piping 5.2.3.2 For the right and right bottom piping...
  • Page 18 (This can be used for left rear piping and bottom piping also.)

  • Page 20: Connect The Cable To The Indoor Unit

    5.2.4 Connect the Cable to the Indoor Unit The inside and outside connection cable can be connected without removing the front grille. Connection cable between indoor unit and outdoor unit shall be approved polychloroprene sheathed 4 × 1.5 flexible cord, type designation 60245 IEC 57 or heavier cord. Bind all the indoor and outdoor connection cable with tape and route the connection cable via the escapement.
  • Page 21 5.2.4.2 Cutting and flaring the piping Please cut using pipe cutter and then remove the burrs. Remove the burrs by using reamer. If burrs are not removed, gas leakage may be caused. Turn the piping end down to avoid the metal powder entering the pipe. Please make flare after inserting the flare nut onto the copper pipes.

  • Page 22: Exploded View And Replacement Parts List

    6. Exploded View and Replacement Parts List Indoor Unit Note The above exploded view is for the purpose of parts disassembly and replacement. The non-numbered parts are not kept as standard service parts.
  • Page 23 SAFETY REF. NO. PART NAME & DESCRIPTION QTY. CS-ME5PKE REMARK CHASSY COMPLETE CWD50C1730 FAN MOTOR ARW7667AC CROSS FLOW FAN COMPLETE CWH02C1137 BEARING ASS’Y CWH64K1010 SCREW - CROSS FLOW FAN CWH551146 GENERATOR COMPLETE CWH94C0048 EVAPORATOR CWB30C4016 FLARE NUT (LIQUID) CWT251030 FLARE NUT (GAS)
  • Page 24 SAFETY REF. NO. PART NAME & DESCRIPTION QTY. CS-ME5PKE REMARK INSTALLATION INSTRUCTION CWF615743 INSTALLATION INSTRUCTION CWF615744 INSTALLATION INSTRUCTION CWF615745 OPERATING INSTRUCTION CWF568895 INSTALLATION INSTRUCTION CWF615746 INSTALLATION INSTRUCTION CWF615747 INSTALLATION INSTRUCTION CWF615748 INSTALLATION INSTRUCTION CWF615749 SENSOR COMPLETE (ECO) CWA50C3005 AIR SWING (ECO) CWA981298 ELECTRONIC CONT.
