  • Page 1 AcerNote Light User’s Manual...
  • Page 2 Copyright Copyright © 1996 by Acer Incorporated. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of Acer Incorporated.

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Read these instructions carefully. Save these instructions for future reference. Follow all warnings and instructions marked on the product. Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. Do not use this product near water.
  • Page 4 11. Do not attempt to service this product yourself, as opening or removing covers may expose you to dangerous voltage points or other risks. Refer all servicing to qualified service personnel. 12. Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions: When the power cord or plug is damaged or frayed If liquid has been spilled into the product...

  • Page 5: Battery Information

    Battery Disposal Instruction In the interest of environmental protection, please dispose of used Lithium batteries properly, at appropriate collection sites in your country. Finnish VAROITUS! Soujellaksesi luontoa ole hyvä ja toimita käytetty Litium-akku paristojen tai ongelmajätteiden keräyspisteeseen. Swedish VARNING! Explosionsfara vid felaktig batteribyte. batterityp eller apparattillverkaren.

  • Page 6: Canadian Department Of Communications

    Canadian Department of Communications Regulatory Statement This digital apparatus does not exceed Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications. Le présent appareil numérique n'émet pas de bruits radio-électriques dépassant les limites applicables aux appareils numériques de la classe B prescrites dans le Réglement sur le brouillage radioélectrique édicté...
  • Page 7 FCC Class B Radio Frequency Interference Statement Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 8: About This Manual

    About This Manual Purpose This manual discusses the features of the notebook and tells how to use and configure it. Manual Structure This manual consists of six chapters and four appendices: Chapter 1, Getting Started, discusses the features of the notebook and first- time operating instructions.
  • Page 9 Conventions The following conventions are used in this manual: Represent text input by the user, default C:\setup, [Enabled], etc. settings and recommended selections Denotes actual messages that appear on message displayed screen Represent the actual keys that you have to , etc press on the keyboard NOTE...

  • Page 11: Table Of Contents

    Getting Started Overview ... 1-1 Item Checklist ... 1-3 LCD Display ... 1-4 Rear Panel... 1-6 Left Panel ... 1-8 Right Panel ... 1-10 AC Adapter ... 1-12 Starting the System... 1-14 Interior Features... 1-15 1.10 Keyboard ... 1-17 1.11 Touchpad... 1-22 1.12 Using the Notebook for the First Time ...
  • Page 12 Power Management ... 2-6 2.4.1 Display Standby Mode ... 2-6 2.4.2 Fixed Disk Standby Mode ... 2-7 2.4.3 Suspend Mode... 2-7 2.4.4 System Standby Mode... 2-9 Advanced Power Management (APM)... 2-11 Battery-low Warning... 2-15 Hardware Options Additional Memory ... 3-2 Hard Disk Drive Upgrade ...
  • Page 13 4.3.3 Fixed Disk Drives ... 4-5 4.3.4 Enhanced IDE Features... 4-5 4.3.5 Num Lock After Boot ... 4-5 4.3.6 Memory Test ... 4-6 4.3.7 Math Coprocessor... 4-6 Advanced System Configuration ... 4-7 4.4.1 Power Management Mode ... 4-7 4.4.2 Battery-low Warning Beep ... 4-9 4.4.3 Standby/Suspend Upon Battery-low...
  • Page 14 Travel and Maintenance Traveling with the Notebook... 5-1 Caring for the System ... 5-3 5.2.1 System Hardware ... 5-3 5.2.2 AC Adapter... 5-3 5.2.3 Battery Pack ... 5-3 5.2.4 Diskettes... 5-4 5.2.5 Cleaning and Servicing... 5-5 Troubleshooting A Checklist... 6-1 Error Messages ...
  • Page 15 System Utilities Zero-Volt (Hibernation) Suspend Utility ... D-2 D.1.1 ASTDK ... D-2 D.1.2 Operating Environment... D-2 D.1.3 Installation Process... D-7 D.1.4 Important ASTDK Notes ... D-7 Touchpad Utility ... D-9 D.2.1 Installing the Touchpad Driver ... D-9 D.2.2 Configuring the Touchpad...D-10 Enhanced IDE Driver ...D-14 SVGA Drivers and Utilities ...D-16 PCMCIA Utility ...D-19...
  • Page 16 Opening the Display... 1-4 The LCD Display ... 1-5 Rear Panel... 1-6 Left Panel ... 1-8 Right Panel ... 1-10 AC Adapter ... 1-12 Turning On the Power ... 1-14 Interior Features... 1-15 Keyboard — U.S. Version ... 1-17 1-10 Keyboard — U.K. Version ... 1-17 1-11 Embedded Keypad...
  • Page 17 LCD Display Configurations ... 1-4 Lock Key Descriptions... 1-18 Hot Key Descriptions... 1-18 Windows 95 Key Descriptions ... 1-20 Using the Embedded Keypad ... 1-21 Touchpad Functions... 1-23 Course of Action for Battery-low Condition ... 2-16 Memory Configurations ... 3-2 Display Device Settings ...

  • Page 18: System Utilities

    System Utilities This appendix discusses the system utilities were not pre-loaded at the factory. The system utility diskette(s) include installation programs for the following utilities: 0V Suspend Touchpad Enhanced IDE driver (pre-loaded) SVGA Other applications include the following: PCMCIA Audio The following sections discuss these utilities and applications, how to install them, and how they work.

  • Page 19: Zero-Volt (Hibernation) Suspend Utility

    Zero-Volt (Hibernation) Suspend Utility The notebook enters suspend mode when you press the standby/suspend button ( return to the status prior to entering suspend mode. If you do not run this program to allocate disk space, this function will not work.
  • Page 20 ASTDK is actually two programs but use the same execution file name, ASTDK.EXE: Running ASTDK from the DOS prompt (in real mode and not from a Windows 95 DOS window) launches the DOS program. Running ASTDK from Windows 95 by clicking on the icon or from the command line in Windows 95 (DOS window) always launches the ASTDK GUI (graphical user interface).
  • Page 21 ASTDK Command Line Syntax in Real Mode In real mode, the command line syntax of ASTDK is described below. ASTDK [/[option[=size]]] The following table lists and describes each option. Table D-1 ASTDK Parameter Descriptions Parameter Description /HELP or /? Shows a help screen briefly describing how to use the parameters.
  • Page 22 If you do not specify any option when you run ASTDK in real mode, ASTDK will show the file creation status and correct the CMOS value, if needed. ASTDK in Windows 95 Inherited with all functions of the real-mode ASTDK program, the graphical ASTDK designed for Windows 95 provides the alternatives for users to custom the ASTDK file size and the drive that holds the ASTDK file.
  • Page 23 Table D-2 ASTDK Functions Function Description Create Select this function to create the ASTDK file, which is created as a system, hidden and read-only file with a formatted file header. This function is further classified into basic and advanced. Basic creation automatically creates the ASTDK file. Advanced creation allows customization of the ASTDK file setting before the program creates it.

  • Page 24: Installation Process

    The main screen includes a check box that determines the presence of the tray icon in the task bar. suspend/resume feature, and is updated via polling of the APM status or via explicitly creating or removing an ASTDK file. Table D-3 Tray Icons and Indicated Status Tray Icon Normal Icon...

  • Page 25: Important Astdk Notes

    Run ASTDK.EXE found in the ASTDK subdirectory from system utilities disk 2, supplied with command parameters previously discussed (e.g., astdk /c ). Refer to the README.TXT file in the same subdirectory for details or Table D-1 for a list of the parameters. You may also choose to copy the ASTDK files to your hard disk drive.
  • Page 26 If the onboard memory size is changed since the last time you executed this program, please resize the allocated disk spaces by using either one of the following two methods: Using the /C parameter to release all allocated disk spaces and then reallocate the appropriate disk spaces automatically Using the /D parameter to reclaim the allocated disk spaces and then using the /C parameter to create the appropriate disk spaces...

  • Page 27: Touchpad Utility

    Touchpad Utility The touchpad works with most mouse drivers, but the bundled touchpad driver supports special functions that work uniquely with the touchpad. D.2.1 Installing the Touchpad Driver DOS and Windows 3.x Follow these steps to install the touchpad driver: Insert system utilities disk 2 in the diskette drive.

  • Page 28: Configuring The Touchpad

    Refer to the readme file in the touchpad driver disk for instructions. D.2.2 Configuring the Touchpad You can configure the touchpad through DOS or by using the Touchpad utility in Windows. To see a list of the parameter settings and their descriptions, type the following at the DOS prompt: C:\>...
  • Page 29 You can configure different aspects of the touchpad including the pointer, motion and orientation as well as touchpad shortcuts. Refer to the online help for details. Windows 95 Follow these steps to configure the touchpad: Click on the Start button, then select Settings... Select Control Panel to display the Control Panel Window.
  • Page 30 Double-click on the Mouse icon and select General. Select the Options... button to display the Synaptics Touchpad Control Panel dialog box. You can configure different aspects of the touchpad including the pointer, motion and orientation as well as touchpad shortcuts. Refer to the online help for details.
  • Page 31 Left-handed users may choose to swap left and right buttons. Swapping the two buttons, however, causes the touchpad to behave differently. Tapping now brings up the menu instead of selecting or executing the desired icon or button. In this case, enable the Cornerzone function found in the Touchpad category setting in the Synaptics Touchpad Control Panel dialog box.

  • Page 32: Enhanced Ide Driver

    Enhanced IDE Driver The notebook’s hard disk drive uses a PCI interface. This enhanced IDE driver improves your hard disk overall performance. DOS and Windows 3.x Follow these steps: Insert system utilties disk 2 into the diskette drive. Type the following at the DOS prompt: C:\>a:\ide\install The installation program copies the necessary files to your hard disk drive and displays the IDE setup main screen.
  • Page 33 The CPU/CLK parameter displays the correct CPU speed. example, if the parameter shows Pentium/ 75 MHz, then your PCI speed is 25 MHz (based on the previous table). Leave the BIOS Setup utility and make the correct selection. Do not change any other settings in the IDE DOS driver setup screen.

  • Page 34: Svga Drivers And Utilities

    SVGA Drivers and Utilities The SVGA display driver setup program installs the drivers and utility programs that allow you to take advantage of the onboard VGA chip’s capabilities. DOS and Windows 3.x Follow these steps to install the display drivers: Insert system utilities disk 1 into the diskette drive.
  • Page 35 Select the Control Panel icon. The Control Panel window appears. Double-click on the Display icon. The Display Properties dialog box appears. Click on the Settings tab. D-18 User’s Manual...
  • Page 36 Click on Change Display Type... The Change Display Type dialog box appears. Select Change... from the Adapter Type. Click on Have Disk... and insert system utilities disk 1 into the 3.5-inch diskette drive and set the path Follow the screen instructions to complete the installation. System Utilities A:\WIN_95\ D-19...

  • Page 37: Pcmcia Utility

    PCMCIA Utility PCMCIA cards give you the expansion capabilities that add-on cards provide for desktop PCs. modem cards, audio cards, memory cards, SCSI cards, etc. The PCMCIA utility initializes the PCMCIA slot (or slots if a PCMCIA slot module is installed) on your notebook. D.5.1 CardWizard for DOS and Windows 3.x If any PC card is currently installed in the PC card slots, remove them.

  • Page 38: Cardworks For Windows 95

    D.5.2 CardWorks for Windows 95 If any PC card is currently installed in the PC card slots, remove them. Then follow these steps to install CardWorks: Insert the CardWorks disk into the diskette drive. From Windows 95, select the Start button and click on Run. Then type: a:\setup Follow the screen instructions to complete the installation.

  • Page 39: Audio Driver And Audio Rack Setup (Option

    Audio Driver and Audio Rack Setup (Option) The optional onboard 16-bit stereo audio is the Ess1688 AudioDrive. Windows 3.x Follow these steps to install the audio drivers and utilities: Insert the audio driver installation disk (1 of 3) into the diskette drive. From the Program Manager, select Run from the File menu pull-down and type the following: a:\setup...
  • Page 40 Double-click on the Add New Hardware icon to run the Add New Hardware Wizard program. Click on Next>, the following dialog box appears. Select No and click on Next>. The following dialog box appears. System Utilities D-23...
  • Page 41 Select Sound, video and game controllers and click on Next>. The following dialog box appears. Select ESS Technology, Inc. from the Manufacturer list and select ESS ES1688 Plug And Play AudioDrive from the Model list. Then click on Have Disk... The following dialog box appears. Insert the audio driver installation disk (disk 3).
  • Page 42 Light Pentium Notebook User’s Manual...
  • Page 43 Copyright Copyright © 1996 by this company. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of this company.
  • Page 44 IMPORTANT SAFETY INSTRUCTIONS Read these instructions carefully. Save these instructions for future reference. Follow all warnings and instructions marked on the product. Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. Do not use this product near water.
  • Page 45 11. Do not attempt to service this product yourself, as opening or removing covers may expose you to dangerous voltage points or other risks. Refer all servicing to qualified service personnel. 12. Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions: When the power cord or plug is damaged or frayed If liquid has been spilled into the product...
  • Page 46 Battery Disposal Instruction In the interest of environmental protection, please dispose of used Lithium batteries properly, at appropriate collection sites in your country. Finnish VAROITUS! Soujellaksesi luontoa ole hyvä ja toimita käytetty Litium-akku paristojen tai ongelmajätteiden keräyspisteeseen. Swedish VARNING! Explosionsfara vid felaktig batteribyte. batterityp eller apparattillverkaren.
  • Page 47 Canadian Department of Communications Regulatory Statement This digital apparatus does not exceed Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications. Le présent appareil numérique n'émet pas de bruits radio-électriques dépassant les limites applicables aux appareils numériques de la classe B prescrites dans le Réglement sur le brouillage radioélectrique édicté...
  • Page 48 FCC Class B Radio Frequency Interference Statement Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 49 About This Manual Purpose This manual discusses the features of the notebook and tells how to use and configure it. Manual Structure This manual consists of six chapters and four appendices: Chapter 1, Getting Started, discusses the features of the notebook and first- time operating instructions.
  • Page 50 Conventions The following conventions are used in this manual: Represent text input by the user, default C:\setup, [Enabled], etc. settings and recommended selections Denotes actual messages that appear on message displayed screen Represent the actual keys that you have to , etc press on the keyboard NOTE...

  • Page 52: Overview

    Getting Started Overview ... 1-1 Item Checklist ... 1-3 LCD Display ... 1-4 Rear Panel... 1-6 Left Panel ... 1-8 Right Panel ... 1-10 AC Adapter ... 1-12 Starting the System... 1-14 Interior Features... 1-15 1.10 Keyboard ... 1-17 1.11 Touchpad... 1-22 1.12 Using the Notebook for the First Time ...
  • Page 53 Power Management ... 2-6 2.4.1 Display Standby Mode ... 2-6 2.4.2 Fixed Disk Standby Mode ... 2-7 2.4.3 Suspend Mode... 2-7 2.4.4 System Standby Mode... Advanced Power Management (APM)... Battery-low Warning... Hardware Options Additional Memory ... 3-2 Hard Disk Drive Upgrade ... 3-4 External Keyboard or Keypad...
  • Page 54 4.3.3 Fixed Disk Drives ... 4-5 4.3.4 Enhanced IDE Features... 4-5 4.3.5 Num Lock After Boot ... 4-5 4.3.6 Memory Test ... 4-6 4.3.7 Math Coprocessor... 4-6 Advanced System Configuration ... 4-7 4.4.1 Power Management Mode ... 4-7 4.4.2 Battery-low Warning Beep ... 4-9 4.4.3 Standby/Suspend Upon Battery-low...

  • Page 55: A Checklist

    Travel and Maintenance Traveling with the Notebook... 5-1 Caring for the System ... 5-3 5.2.1 System Hardware ... 5-3 5.2.2 AC Adapter... 5-3 5.2.3 Battery Pack ... 5-3 5.2.4 Diskettes... 5-4 5.2.5 Cleaning and Servicing... 5-5 Troubleshooting A Checklist... 6-1 Error Messages ...
  • Page 56 System Utilities Zero-Volt (Hibernation) Suspend Utility ... D-2 D.1.1 ASTDK ... D-2 D.1.2 Operating Environment... D-2 D.1.3 Installation Process... D-7 D.1.4 Important ASTDK Notes ... D-7 Touchpad Utility ... D-9 D.2.1 Installing the Touchpad Driver ... D-9 D.2.2 Configuring the Touchpad...D-10 Enhanced IDE Driver ...D-14 SVGA Drivers and Utilities ...D-16 PCMCIA Utility ...D-19...
  • Page 57 Opening the Display... 1-4 The LCD Display ... 1-5 Rear Panel... 1-6 Left Panel ... 1-8 Right Panel ... 1-10 AC Adapter ... 1-12 Turning On the Power ... 1-14 Interior Features... 1-15 Keyboard — U.S. Version ... 1-17 1-10 Keyboard — U.K. Version ... 1-17 1-11 Embedded Keypad...

  • Page 58: Error Messages

    LCD Display Configurations ... 1-4 Lock Key Descriptions... 1-18 Hot Key Descriptions... 1-18 Windows 95 Key Descriptions ... Using the Embedded Keypad ... Touchpad Functions... 1-23 Course of Action for Battery-low Condition ... Memory Configurations ... 3-2 Display Device Settings ... 4-10 Floppy Disk Drive Control Settings...

  • Page 59: Getting Started

    Getting Started This chapter introduces the notebook and gives first-time operating instructions. Overview Thank you for purchasing this notebook computer. enthusiastic beginner or a power user, this notebook has it all. On the road, at the office, or in the comfort of your home, this notebook is the ideal computing companion for all your personal and business needs.
  • Page 60 This system supports plug-and-play PCMCIA technology with a built-in type III slot that allows the simultaneous use of two type II or one type III PC card. The PCMCIA interface allows you to use credit-card-sized fax/data modem cards, SRAM cards, 1.8-inch removable hard disks, audio cards, SCSI interface cards and other devices.

  • Page 61: Item Checklist

    Item Checklist Remove all items from the carton and save the packing materials for future use. If any of the following items are missing or damaged, contact your dealer immediately. The notebook computer AC adapter (includes power cord) Battery pack (Duracell-standard) Documentation Optional accessories available include:...

  • Page 62: Lcd Display

    LCD Display This notebook supports four different LCD display configurations in Table 1-1. Table 1-1 LCD Display Configurations Type DualScan STN color (passive matrix) DualScan STN color (passive matrix) TFT color (active matrix) TFT color (active matrix) Open the display by sliding the cover latch to the right as shown in Figure 1-1.

  • Page 63: Opening The Display

    A microswitch, located near the LCD hinge, detects the opening and closing of the LCD display. The LCD backlight goes off when you close the display without turning off the system power. Reopening the display turns on the backlight again. Microswitch Figure 1-2 The LCD Display...

  • Page 64: Rear Panel

    Rear Panel The peripheral connectors are located in the rear panel as shown in Figure 1-3. Open the port cover to access the CRT, parallel and serial ports. Other ports include the audio (if it is equipped), external PS/2 and DC-in ports.
  • Page 65 parallel device. Getting Started...
  • Page 66 The following are optional ports: Line-in port This connects to the audio line-out port of an audio line-in device like a CD player, stereo walkman or synthesizer. Microphone in port This connects a microphone (3.5mm mini- jack). Line-out port This connects headphones or amplified speakers. See Chapter 3 for details on how to connect external devices.

  • Page 67: Left Panel

    Left Panel The left panel has a PCMCIA Type III slot and removable hard disk drive. PCMCIA Type III slot Removable hard disk drive (underside) Figure 1-4 Left Panel Left Panel Features Getting Started PCMCIA PCMCIA support enables you to use credit-card-sized PC cards similar to add-on cards for desktop computers, thus...
  • Page 68 The system supports PCMCIA cards such as fax/data modem, LAN, audio, SCSI cards and ATA drives. Memory cards include flash memory and SRAM. Before using the slot, you need to load the PCMCIA driver which initializes and prepares the slots for use. Refer to the PCMCIA driver utility information in Appendix D for more details.

  • Page 69: Right Panel

    Right Panel The battery and internal diskette drive are located in the right panel. Battery compartment Battery cover release latch Internal diskette drive Figure 1-5 Right Panel Getting Started 1-11...
  • Page 70 Right Panel Features The battery compartment houses a nickel metal-hydride (NiMH) battery pack. Follow these steps to install the battery pack: The notebook houses an internal 3.5-inch, 1.44MB diskette drive. For smoother diskette drive operation, do not block the drive slot when pressing the slot button to eject a floppy disk.

  • Page 71: Ac Adapter

    AC Adapter The AC adapter accepts input voltage ranging from 100V to 240V at a frequency range of 47Hz to 63Hz. Figure 1-6 AC Adapter The AC adapter LED lights up when power is supplied to the AC adapter. 1. Do not use the AC adapter or the battery pack with other notebooks or any other devices.
  • Page 72 Connecting the AC Adapter Follow these steps to connect the AC adapter: 1-14 1. Plug the power cord into the AC adapter. 2. Connect the power cord to a power outlet. 3. Connect the AC adapter to the notebook. User’s Manual...

  • Page 73: Starting The System

    Starting the System Figure 1-7 shows the location of the power on/off switch ( toggle switch to turn the notebook on and off. The power indicator (a green LED found to the left of the power switch) lights up when you turn on the notebook.

  • Page 74: Interior Features

    Interior Features Figure 1-8 shows the location of the control buttons, status indicators and other interior features. Standby/Suspend button No-reboot Setup button Battery charging indicator Power indicator Power switch Figure 1-8 Interior Features Control Buttons Power switch This toggles the system power on and off. No-reboot Setup button This enables you to access the Advanced Configuration screens of the Setup utility without rebooting.
  • Page 75 Status Indicators Battery charging indicator It lights up when the battery is charging. Power indicator This lights up when power is applied to the notebook, and flashes when the notebook is in a battery-low condition. Standby mode indicator This lights up when the system is in standby mode.

  • Page 76: Keyboard

    1.10 Keyboard The keyboard has full-sized keys, including an embedded keypad, separate cursor keys, twelve function keys and two Windows 95 keys. Figure 1-9 Keyboard — U.S. Version Figure 1-10 Keyboard — U.K. Version 1-18 User’s Manual...

  • Page 77: Lock Key Descriptions

    Lock Keys The keyboard has three lock keys which you can toggle on and off. When you activate a lock key, the corresponding LED lights up. Table 1-2 Lock Key Descriptions Description When the Caps Lock indicator is on, all alphabetic characters typed are in uppercase.
  • Page 78 Table 1-3 Hot Key Descriptions (continued) Description Contrast/Brightness Control Displays the LCD contrast/brightness control for STN models and LCD brightness control for TFT models. Contrast After pressing this key combination, press and decrease the current setting. Press For STN models, press brightness controls.

  • Page 79: Embedded Keypad

    Windows 95 Keys The keyboard has two Windows 95 keys that perform Windows 95 functions. Table 1-4 Windows 95 Key Descriptions Description Windows logo key Start button. Combinations with this key performs special functions. Below are a few examples: Application Key Opens the application’s context menu (same as right-click).

  • Page 80: Palm Rest

    Table 1-5 tells how to use the embedded keypad. Table 1-5 Using the Embedded Keypad Desired Access Num Lock On Number keys on Type numbers in a normal embedded keypad manner. Cursor-control keys Hold on embedded keypad control keys. Main keyboard keys Hold letters on embedded keypad.
  • Page 81 Getting Started 1-23...

  • Page 82: Touchpad

    1.11 Touchpad The touchpad is a PS/2-type mouse-compatible pointing device that senses movement on its surface. This means the cursor responds as you move your finger on the surface of the touchpad. Its central location on the palm rest enables comfortable use for both left and right-hand users. Left button Figure 1-13 Touchpad...

  • Page 83: Touchpad Functions

    Touchpad Basics The following tips will help you use the touchpad: Move your finger across the touchpad to move the cursor. Press the left and right buttons below the touchpad to do selection and execution functions. These two buttons are similar to the left and right buttons on a mouse.

  • Page 84: Using The Notebook For The First Time

    1.12 Using the Notebook for the First Time Follow these steps when you use the notebook for the first time, to ensure top performance right from the start. Install the battery pack into the notebook. Connect the AC adapter. See section 1.7. Power on the notebook and condition the battery pack.
  • Page 85 Install the zero-volt suspend function. Zero-Volt (Hibernation) Suspend-to-Disk If you want to use the zero-volt suspend function, you have to create a suspend-to-disk file on the hard disk by installing ASTDK for DOS and Windows 3.x or ASTDK for Windows 95. Refer to section D.1 for more details.
  • Page 86 Table 1-3 Hot Key Descriptions (continued) Description Contrast/Brightness Control Displays the LCD contrast/brightness control for STN models and LCD brightness control for TFT models. Contrast After pressing this key combination, press and decrease the current setting. Press For STN models, press brightness controls.

  • Page 87: Battery Pack

    Operating on Battery Power This chapter contains the information you need to know to operate the notebook on battery power. Battery Pack Whenever possible, use the AC adapter. The battery will come in handy when you travel or during a power failure. It is advisable to have an extra fully-charged battery pack available for backup.
  • Page 88 Do not expose battery packs to temperatures below 0ºC (32ºF) or above 60ºC (140ºF). This may adversely affect the battery pack. If the notebook is to be stored for more than two weeks, we suggest that you remove the battery pack. In suspend mode or power-off condition, the battery power (from a fully-charged battery pack) depletes in one month.

  • Page 89: Charging The Battery

    Charging the Battery Place the battery pack inside the battery compartment and plug the AC adapter into the notebook and an electrical outlet. The adapter has three charging modes: Rapid mode The system uses rapid charging when the notebook (with a battery pack installed) is turned off and a powered AC adapter is connected to it.

  • Page 90: Optimizing Battery Life

    Optimizing Battery Life This section helps you get the most out of battery operation. Optimizing battery life prolongs the charge/recharge cycle and improves recharge efficiency. 2.3.1 Maximizing Battery Power Follow these suggestions to maximize battery power: Purchase an extra battery pack Use the system utility ASTDK to reserve hard disk space for the zero- volt suspend function.

  • Page 91: Conditioning The Battery Pack

    The batteries can be recharged about 500 times when used as directed. Excessive rapid recharging decreases battery life. 2.3.2 Conditioning the Battery Pack Conditioning the battery pack reduces the possibility of memory effect. We recommend that you condition the battery pack at least once every month, preferably twice a month.

  • Page 92: Power Management

    Power Management This notebook has a built-in power management unit that monitors system activity. System activity refers to any activity involving one or more of the following devices: keyboard, mouse, diskette drive, hard disk drive, peripherals connected to the serial and parallel ports, and video memory. If no activity is detected for a specified period of time (called an inactivity time-out), the system switches to one of the power-saving modes to conserve energy.

  • Page 93: Fixed Disk Standby Mode

    If the LCD backlight is too bright, the system automatically adjusts it to a manageable level; otherwise, the level stays the same. brighter picture, you can then adjust the brightness and contrast level using hotkeys ( If you reconnect AC power to the system, the system automatically adjusts the LCD backlight to its original level —...
  • Page 94 In this situation, there are four ways to enter suspend mode: Press the standby/suspend button ( If the notebook beeps but does not enter suspend mode after pressing the standby/suspend button, it means the operating system does not allow the notebook to enter the power saving mode.

  • Page 95: System Standby Mode

    2.4.4 System Standby Mode The notebook consumes very low power in system standby mode. Data remain intact in the system memory. The necessary condition for the notebook to enter system standby mode is that the reserved disk space size for saving system and video memory is insufficient so the notebook is unable to enter suspend mode.
  • Page 96 To leave system standby mode and return to normal mode, press the standby/suspend button ( system returns to normal mode. If the notebook is connected to a LAN environment or has a current modem connection, it may not resume connection after the notebook returns to normal operating mode.

  • Page 97: Advanced Power Management (Apm)

    Advanced Power Management (APM) This notebook supports the APM standard designed to further reduce system power consumption. defined jointly by Microsoft and Intel. An increasing number of software supports APM to take advantage of power saving features and allows greater system availability without degrading performance. You can use the APM feature under the DOS environment by including the POWER.EXE command in the CONFIG.SYS file.
  • Page 98 Double-click on the System icon in the Control Panel window. The System Properties dialog box appears. Select the Device Manager tab and double-click on System devices. 2-12 User’s Manual...
  • Page 99 Double-click on Advanced Power Management support. Its property dialog box appears. If the device is not working properly, select the Settings tab and verify if the check box for enabling power management support is selected. Operating on Battery Power 2-13...
  • Page 100 Refer to the Windows 95 user’s guide for details. If you enable the Power Management Mode parameter in Setup without installing the APM under DOS, Windows or Windows 95, the system time and date do not display the correct settings after the notebook returns to normal operation from system standby or suspend mode.

  • Page 101: Battery-Low Warning

    Battery-low Warning You never have to worry about battery power as long as you are using the AC adapter. However, when you operate the notebook on battery power, pay extra attention to the warning beeps and the power indicator. The power indicator flashes when the battery power is low.

  • Page 102: Course Of Action For Battery-Low Condition

    Table 2-1 lists the recommended course of action when you encounter a battery-low condition. Table 2-1 Course of Action for Battery-low Condition Situation AC adapter and power outlet available An extra fully-charged battery pack available AC adapter or power outlet or fully-charged battery pack not available 2-16 Recommended Action...
  • Page 103 Hardware Options This chapter tells how to install hardware options such as additional memory, an external keyboard or keypad, VGA monitor, mouse and printer. For operating instructions, read the manual included with the accessories. Always turn off the notebook before you install additional devices.

  • Page 104: Additional Memory

    Additional Memory The system has optional onboard memory and two memory slots that let you install up to 40 MB of memory using 4/8/16MB industry-standard DIMMs (dual inline memory modules). Memory Configurations Table 3-1 lists the possible memory configurations. Table 3-1 Memory Configurations Onboard Slot I...

  • Page 105: Installing Memory

    Installing Memory Should you decide to add memory, we recommend that you seek the help of a qualified service technician. installation may damage the notebook or cause a malfunction. Consult your authorized dealer for assistance. The memory slots are accessible directly under the keyboard. unlatch and lift the keyboard to expose the memory slots.

  • Page 106: Hard Disk Drive Upgrade

    Hard Disk Drive Upgrade This notebook has a modular design that enables easy hard disk drive upgrades. The storage compartment accepts a high-capacity, 2.5-inch hard disk drive. See Appendix B for a list of the hard disk drives available. We recommend that you seek the help of a qualified service technician if you decide to perform an upgrade.
  • Page 107 Reverse the process to install a hard disk drive. automatically detects the hard disk drive type during power-on self test. If the hard disk drive capacity is greater than 528MB, enter Setup and enable the Large Disk Capacity parameter. section 4.3.4. Hardware Options 4.

  • Page 108: External Keyboard Or Keypad

    External Keyboard or Keypad This notebook has a keyboard with full-sized keys and an embedded keypad. If you do a lot of numeric data entry, you may want to use a 17-key numeric keypad for greater convenience. comfortable using a desktop keyboard, you can install a 101-/102-key, PS/2-type external keyboard.

  • Page 109: External Monitor

    External Monitor To show graphical effects on a larger display, you can connect an external VGA monitor to the CRT port ( manual for additional instructions. See Figure 3-3. Before you install a monitor, turn off the notebook. Always turn on the external monitor first before you turn on the notebook.

  • Page 110: External Mouse

    External Mouse This notebook accepts either a serial mouse or PS/2-compatible mouse or similar pointing device. If you use a serial mouse, plug it into the serial port ( panel. See Figure 3-3. If you use a PS/2-compatible mouse, plug it into the keyboard/ keypad/mouse connector ( The built-in touchpad works simultaneously with an external PS/2-compatible mouse if one is connected.

  • Page 111: Cpu Upgrade

    CPU Upgrade The notebook features a unique ZIF (zero insertion force) socket that allows you to easily upgrade your CPU. We recommend you have the CPU upgrade performed by a qualified service technician to prevent possible damage, because the CPU is sensitive to static electricity. Improper installation may cause a malfunction.

  • Page 112: Removing And Installing The Cpu

    After removing the heat sink, follow these steps to remove the CPU and install a replacement CPU. Refer to Figure 3-4. ΠInsert a flat-blade screwdriver into the opening at the right end of the socket and push towards the other end of the socket until the words OPEN and UNLOCKED show on both ends of the socket.
  • Page 113 Hardware Options 3-11...

  • Page 114: Cpu Speed Settings

    After installing the new CPU, set the following switches: CPU speed switch SW2 (found to the left of the CPU socket) CPU voltage switch SWY1 (found to the lower right of the CPU socket) A J4 jumper may appear in place of SWY1. You need to short this jumper when installing a Pentium 120MHz CPU.

  • Page 115: Connecting Audio Devices

    Audio Devices (Optional) To complement the 16-bit stereo audio option, there are microphone-in, line-in and line-out audio ports, besides the built-in speaker. Audio CD player Figure 3-7 Connecting Audio Devices Hardware Options Microphone Amplified speakers 3-13...

  • Page 116: When To Use Setup

    Setup This chapter tells how to use the Setup utility. This utility allows you to configure the notebook without setting any jumpers or switches. When to Use Setup This notebook is already correctly configured and you do not need to run Setup.

  • Page 117: Entering Setup

    Entering Setup To enter Setup, press m during POST or the no-reboot Setup button ( Pressing m during POST allows you to access the complete Setup utility. The system reboots when you exit Setup to make any changes take effect. Pressing the no-reboot Setup button ( Advanced System Configuration screens and the system does not reboot when you exit from Setup.
  • Page 118 Most of the Setup parameters are self-explanatory. Press l for help. When you press | to exit a Setup screen, the following prompt appears: Do you want to save CMOS data? [Yes] [No] Select to save the changes you made to the configuration values or [Yes] to abandon the changes and retain the current values.

  • Page 119: Basic System Configuration

    Basic System Configuration Basic System Configuration has a one-page screen display illustrated below. Date ---------------------------- [MM/DD/YY] Time ---------------------------- [HH:MM:SS] Floppy Disk A ------------------- [1.44 MB 3.5-inch] Floppy Disk B ------------------- [ Fixed Disk 0 (244 MB) ----------- [Auto] Fixed Disk 1 ( 0 MB) ----------- [None] Enhanced IDE Features Large Hard Disk Capacity ---- [Enabled]...

  • Page 120: Date And Time

    4.3.1 Date and Time The notebook displays the current date in MM/DD/YY format and the current time in HH:MM:SS format. It uses a 24-hour clock; for example, 6:25 PM displays as 18:25:00. 4.3.2 Floppy Disk Drives The default setting for Floppy Disk A is the notebook supports only one diskette drive, Floppy Disk B is set to and is not user-configurable.

  • Page 121: Memory Test

    4.3.6 Memory Test The notebook always tests the main memory for errors each time you turn it on. Select [Disabled] self-test procedure. 4.3.7 Math Coprocessor This parameter is non-user-configurable and indicates whether the notebook has a math coprocessor installed or not. coprocessor.

  • Page 122: Power Management Mode

    Advanced System Configuration The Advanced System Configuration section has a three-page screen display. The first two pages of this section are accessible with m as well as the no-reboot Setup button ( no-reboot Setup button. The following is page 1. Power Management Mode ---------------------- [Enabled] Display Standby Timer ------------------- [ 1] Minute(s) Hard Disk Standby Timer ----------------- [ 1] Minute(s)
  • Page 123 Power Management Timers Display Standby Timer The notebook shuts off the LCD backlight if there is no activity from the keyboard or external PS/2 mouse within the period specified by this timer. To turn the display back on, press a key or move the mouse. The valid values for this timer range from 1 to 15 minutes.

  • Page 124: Battery-Low Warning Beep

    4.4.2 Battery-low Warning Beep This parameter allows you to enable or disable the warning beep generated by the system when a battery-low condition occurs. The default setting is [Enabled] 4.4.3 Standby/Suspend Upon Battery-low This parameter enables the system to enter standby/suspend mode when a battery-low condition takes place.

  • Page 125: Display Device

    The following is page 2 of the Advanced System Configuration screens. Display Device ------------------------- [Auto] LCD Expand Mode ------------------------ [Enabled] = Move Hightlight Bar, PgDn/PgUp = Move Screen, F1 = Help, Esc = Exit 4.4.5 Display Device If you install an external VGA display, you can switch display between the LCD and external display (CRT).

  • Page 126: Lcd Expand Mode

    4.4.6 LCD Expand Mode If the LCD Expand Mode is enabled, the VGA subsystem replicates or paints in a few extra lines so that an output less than 640x480 resolution can fill up the entire LCD screen. Expanded mode gives a better and more balanced display.
  • Page 127 The following is page 3 of the Advanced System Configuration screens. This page lists a summary of the system settings currently configured. CPU/CLK : Pentium/75MHZ Base memory 640 KB Extended memory 7168 KB Shadow RAM 256 KB SMRAM 128 KB Hard Disk 0 244 MB QUANTUM GLS256A Security...

  • Page 128: System Security

    System Security Disk Drive Control Floppy Disk Drive ----------------- [ Normal ] Hard Disk Drive ------------------- [ Normal ] System Boot Drive ----------------- [Drive A Then C] On Board Communication Ports Serial Port Base Address ---------- [ 3F8h(IRQ 4) ] Parallel Port Base Address -------- [ 378h(IRQ 7) ] Parallel Port Operation Mode ------ [Standard] Setup Password ----------------------- [ None ]...

  • Page 129: Floppy Disk Drive Control

    4.5.1 Floppy Disk Drive Control This parameter allows you to enable or disable the read/write functions of the diskette drive. The following table summarizes the available options. Table 4-2 Floppy Disk Drive Control Settings Setting Description Normal (default) Diskette drive functions normally Write Protect Disables any diskette drive write function.

  • Page 130: System Boot Drive Control

    4.5.3 System Boot Drive Control This parameter determines which drive the notebook boots from when you turn it on. The following table lists the three possible settings. Table 4-4 System Boot Drive Control Settings Setting Description Auto Notebook boots from diskette drive A. If there is no system disk in drive A, the notebook boots from hard disk drive C.

  • Page 131: Parallel Port Base Address

    4.5.5 Parallel Port Base Address The parallel port can accomodate a parallel printer or other parallel devices. The default setting for the parallel port base address is . The other options for this parameter are: 278h(IRQ 5) 3BCh (IRQ 7) Disabled 4.5.6 Parallel Port Operation Mode...

  • Page 132: Passwords

    4.5.7 Passwords Two passwords are implemented in this notebook. The Setup Password prevents unauthorized access to the Setup utility, while the Power On Password prevents unauthorized access to the notebook. password, select the desired password (Setup and Power On) to set or edit, and press z or x .

  • Page 133: Load Setup Default Settings

    Load Setup Default Settings Selecting this option allows you to load all the default settings. The default settings are the values initially stored in CMOS RAM intended to provide high performance. If in the future, you change these settings, you can load the default settings again by selecting this option.

  • Page 134: Traveling With The Notebook

    Travel and Maintenance This chapter tells you what to do when traveling with the notebook. A section discusses notebook maintenance. Traveling with the Notebook Follow these steps to prepare the notebook for travel: Make diskette copies of important files on the hard disk. Turn off the notebook and all peripherals.
  • Page 135 When traveling in another country, check that the local AC voltage and the AC adapter power cord specifications are compatible. purchase a power cord that is compatible with the local AC voltage. Do not use converter kits sold for appliances to power the system. Check also if the PC card modem and connector used with your notebook is compatible with the telecom system of the country you are traveling in.

  • Page 136: Caring For The System

    Caring for the System This section tells you how to care for the system. important safety instructions at the beginning of this manual. 5.2.1 System Hardware Do not expose the notebook to rain, liquid or moisture. Do not place near sources of heat, such as a radiator. Do not expose to temperatures below 0ºC (32ºF) or above 50ºC (122ºF).

  • Page 137: Diskettes

    Dispose of used batteries according to local regulations. Recycle if at all possible. 5.2.4 Diskettes Always make backup copies of diskettes that contain important data or program files. Keep diskettes away from magnetic fields and sources of heat. Avoid removing a diskette from a drive when the diskette drive activity light is on.

  • Page 138: Cleaning And Servicing

    5.2.5 Cleaning and Servicing Turn the notebook off and remove the battery pack Disconnect the AC adapter. Do not use liquid or aerosol cleaners. Use a soft cloth moistened with water instead. Contact your dealer or see your service technician if any of the following occurs: Notebook has been dropped or the chassis has been damaged.

  • Page 139: Troubleshooting

    Troubleshooting This chapter tells how to deal with common system problems. Read it before calling a technician if a problem occurs. Solutions to more serious problems require opening up the notebook. Do not attempt to open the notebook by yourself. Contact your dealer or an authorized service center for assistance.
  • Page 140 If nothing appears on the screen Try adjusting the screen contrast/brightness control ( Is the LCD power-saving feature on? Press any key to turn the display back on. Is the notebook in system standby or suspend mode? See section 2.5 for a discussion of visible and audible indicators, including ways to exit these modes.
  • Page 141 If the parallel printer does not print Is the parallel port enabled? Check the Setup utility. Is there a conflict between the parallel ports selected in Setup and the software application? If the serial printer does not print Is the serial port enabled? Check the Setup utility. Is the printer connected to the port indicated in Setup.

  • Page 142: Error Messages

    Error Messages If you receive an error message, note the message and take corrective action. Table 6-1 lists the error messages in alphabetical order together with the recommended course of action. Table 6-1 Error Messages Error Message CMOS Battery Bad CMOS Checksum Error Disk Boot Failure Diskette Drive Controller Error...

  • Page 143: Troubleshooting

    Table 6-1 Error Messages (continued) Error Message Memory Size Mismatch Missing operating system Non-system disk or disk error. Replace and strike any key when ready Pointing Device Error Pointing Device Interface Error Protected Mode Test Fail RAM BIOS Bad RAM Parity Error Real-Time Clock Error Video RAM BIOS Bad Troubleshooting...

  • Page 144: Specifications

    Specifications Item Standard Microprocessor Intel Pentium™ 75/100/120 System memory 8MB (EDO RAM) 64-bit memory bus CMOS RAM 128 bytes, battery backup System BIOS 256KB Flash BIOS Data storage devices One 2.5-inch removable Enhanced-IDE hard disk drive (12.5mm) One 3.5-inch, 1.44MB diskette drive Audio/Video 1MB video RAM,...
  • Page 145 Item Standard Pointing device Touchpad I/O ports One 9-pin serial port (RS-232) One 25-pin parallel port (EPP/ECP-compliant) One 15-pin CRT port One 6-pin PS/2 keypad/keyboard/mouse connector One type III or two type II PCMCIA slot(s) (PnP) One buzzer AC adapter 100~240Vac, 50~60Hz autosensing AC adapter Battery pack...
  • Page 146 Hard Disk Types Type Cylinders Heads Reserved 1024 Hard Disk Types A p p e n d i x Write Landing Sectors Pre-comp Zone per Track None None None None None None None None 1023 Disk Size...
  • Page 147 Type Cylinders Heads 1023 1024 Write Landing Sectors Pre-comp Zone per Track None None 1023 None None None None None None None None None None None 1024 None None User’s Manual Disk Size...
  • Page 148 Type Cylinders Heads 1001 1011 1013 1017 1024 1010 1024 1024 Reserved 1024 1024 1024 1024 1024 Hard Disk Types Write Landing Sectors Pre-comp Zone per Track None None 1001 None None None None None None None None None None None None None...
  • Page 149 Type Cylinders Heads 1010 Reserved 1024 1001 1024 Reserved Reserved 1024 Reserved Reserved 1016 Auto User type 1 User-defined User type 2 User-defined The system supports the following 12.7mm, 2.5-inch hard disk drives: Write Landing Sectors Pre-comp Zone per Track 1010 1023 None...

  • Page 150: Hard Disk Types

    Vendor Seagate Hitachi Toshiba Use the space provided in the above table to record additional hard disks that will be available in the future. Hard Disk Types Model Capacity ST9420AG 420 MB DBOA2540 540 MB DSOA-2810 810 MB DK-222 540 MB DK223-81 810 MB MK1926F...

  • Page 151: Address And Interrupt Tables

    Address and Interrupt Tables System Memory Map Address Range Definition 000000 - 09FFFF 640 KB memory 0A0000 - 0BFFFF 128 KB video RAM 0C0000 - 0AFFFF 0E0000 - 0EFFFF 256 KB system ROM 0F0000 - 0FFFFF 100000 - 7FFFFF Extended memory 7 MB Address and Interrupt Tables A p p e n d i x...

  • Page 152: I/O Address Map

    I/O Address Map Address Range Device 000 - 00F DMA controller-1 020 - 021 Interrupt controller-1 040 - 043 Timer 1 048 - 04B Timer 2 060 - 06E Keyboard controller 8742 chip select 070 - 071 Real-time clock and NMI mask 080 - 08F DMA page register 0A0 - 0A1...

  • Page 153: Interrupt Levels

    Interrupt Levels Priority Interrupt Number IRQ 0 IRQ 1 IRQ 2 IRQ 8 IRQ 9 IRQ 10 IRQ 11 IRQ 12 IRQ 13 IRQ 14 IRQ 15 IRQ 3 IRQ 4 IRQ 5 IRQ 6 IRQ 7 A PCMCIA card can use IRQ 3, 4, 5, 7, 9 and 11 as long as it does not conflict with the interrupt address of any other device.

  • Page 154: Dma Channels

    DMA Channels Channel Page Register Cascade Function Spare Spare Diskette Spare Cascade Spare Spare Spare Width 8-Bit 8-Bit 8-Bit 8-Bit 16-Bit 16-Bit 16-Bit User’s Manual...
  • Page 155 Description Setup Accesses Setup during POST (power-on self test). Hotkey Help Displays a list and description of all hot keys. Hotkey Help <Fn><F1> <Fn><F2> <Fn><F3> <Fn><F5> Press <Fn><Left arrow> to decrease, <Fn><Right arrow> to increase, <Fn><Esc> to close. Press any key to exit hotkey help. Contrast/Brightness Control Displays the LCD contrast/brightness control for STN models and LCD brightness control for TFT models.

Table of Contents
