- Page 1 FORM NO. 3318-241 GB Rev A OPERATOR’S 0001 MODEL NO. 04052TE—6 & UP MANUAL ® ® GREENSMASTER 1000 © 1996 The Toro Company...
-
Page 2: Table Of Contents
Authorized TORO Distributor. In addi- tion to genuine TORO replacement parts, the distribu- tor also has optional equipment for the complete line of TORO turf care equipment. Keep your Toro all TORO. Buy genuine TORO parts and accessories. -
Page 3: Safety
Safety Training Thoroughly inspect the area where the equipment is to be used and remove all objects which may be thrown by the machine. Read the instructions carefully. Be familiar with the controls and the proper use of the equipment. WARNING—Petrol is highly flammable. -
Page 4: Maintenance And Storage
care. To guard against overturning: • change into neutral and set the parking brake; • do not stop or start suddenly when going up or downhill; • stop the engine and remove the key. • engage the clutch slowly, and always keep 13. - Page 5 7. If the fuel tank has to be drained, this should be Sound & Vibration Levels done outdoors. Sound Levels 8. Be careful during adjustment of the machine to prevent entrapment of the fingers between moving This unit has an equivalent continuous A-weighted blades and fixed parts of the machine.
- Page 6 Symbol Glossary Caustic liquids, Poisonous Electrical shock, High pressure High pressure High pressure Crushing of Crushing of chemical burns to fumes or toxic electrocution fluid, injection spray, erosion of spray, erosion of fingers or hand, toes or foot, force fingers or hand gases, asphyxiation into body flesh...
- Page 7 Eye protection Head protection Hearing Caution, toxic First aid Flush with water Engine Transmission must be worn must be worn protection must risk be worn Fire, open light Hydraulic Brake system Coolant (water) Intake air Exhaust gas Pressure system & smoking prohibited Level Liquid level...
- Page 8 Engine coolant Engine coolant f Engine Engine intake/ Engine intake/ Engine intake/ Engine start Engine stop pressure ilter lubricating oil combustion air combustion air air filter pressure pressure n/min Engine failure/ Engine rotational Choke Primer (start aid) Electrical preheat Transmission oil Transmission oil Transmission oil malfunction speed/frequency...
-
Page 9: Specifications
Specifications Engine: Kawasaki, air cooled, overhead valve, 4 cycle, Bedknife and bedbar: Single edged high carbon steel 3.7 horsepower, 2.36” x 1.73” bore and stroke, 7.57 bedknife, induction hardened to Rc 48—55. Fastened cu. in. (124 cc) displacement, 8.4:1 compression ratio, to machined, cast iron bedbar. -
Page 10: Before Operating
(See chart below). Use any FILL THE FUEL TANK high-quality detergent oil having the American Petroleum Institute (API) “service classification”–MS, NOTE: THE TORO COMPANY STRONGLY REC- or SC. OMMENDS THE USE OF FRESH, CLEAN, UNLEADED REGULAR GRADE GASOLINE IN... - Page 11 LEVELING THE REAR DRUM TO Loosen the four roller bearing screws and the screw securing the idler pulley. Raise or lower THE REEL the right side of the roller assembly until the gap is reduced to less than .010”. Tighten the roller- Position the machine on a flat, level surface, bearing screws.
- Page 12 Should excessive reel drag be evident, it will be either necessary to backlap or regrind the cutting unit to achieve the sharp edges needed for precision cutting (see Toro reel sharpening manual). Fig. 7 WARNING: Use caution if removing the bedbar Gauge bar because the adjusting screw springs (Fig.
- Page 13 IMPORTANT: When set properly, the rear and front rollers will contact the gauge bar and the screw will be snug against the bed- knife. This assures height of cut is identical at both ends of the bedknife. Fig. 9 Support rod Shield The height of the shield from the support rod for normal cutting conditions should be 4 inches.
- Page 14 Note: The bar is adjustable to compensate for changes in turf conditions. The bar should be adjusted closer to the reel when turf is extremely wet. By contrast, adjust the bar further away from the reel when turf conditions are dry. The bar should be parallel to the reel to assure optimum performance and should be adjusted whenever shield height is adjusted or whenever...
-
Page 15: Controls
Controls Traction Engagement Lever (Fig. 12)—Located on the front right side of the control panel. The lever has two positions: NEUTRAL and FORWARD. Pushing the lever forward engages the traction drive. On/Off Switch (Fig. 12)—Located on the left rear side of control panel. Move switch to ON to start the engine and to OFF to stop the engine. - Page 16 Fig. 15 Recoil starter Kickstand...
-
Page 17: Operating
Operating Instructions STARTING AND STOPPING TRANSPORT OPERATION Note: Make sure the spark plug wire is installed on the Push the kick stand down with your foot and pull spark plug. up on the handle to raise the rear of the mower and install the transport wheels. - Page 18 AFTER MOWING by whipping the turf with a bamboo pole or by drag- ging a hose over the area. Be sure the mower is care- fully adjusted and is set evenly on both sides of the Drive off green, move the traction control lever to reel.
-
Page 19: Maintenance
LUBRICATION GREASE FITTINGS The (12) grease fittings on the mower should be greased at least every 25 hours. Lubricate using No. 2 multi-purpose lithium base grease. A hand operated grease gun is recommended for best results. Wipe each grease fitting with a clean rag. Figure 18 The grease fitting locations are: (2) on The front Roller (Fig. - Page 20 Fig. 20 Fig. 23 Spark plug Foam element Paper element Fig. 21 Fig. 24 Oil level gauge Drain plug Fig. 25 Shut-off valve Fig. 22 Bowl Air cleaner...
-
Page 21: Identification And Ordering
Note: Do not order by reference number if a parts cat- alog is being used; use the part number. To order replacement parts from an authorized TORO Distributor, supply the following information: Model and serial numbers. Part number, description, and quantity of parts...
