- Page 1 / i40 Scanners User’s Maintenance Guide A-61512...
-
Page 2: Maintenance
“Supplies and consumables” at the end of this chapter provides a listing of the supplies required to clean your scanner. IMPORTANT: Use only non-flammable cleaners such as those provided through Kodak Parts Services. Do not use household cleaners. Do not use cleaners in confined areas, use with adequate ventilation. - Page 3 Cleaning the rollers 1. With a roller cleaning pad, wipe the feed roller from side to side. Rotate the feed rollers to clean the entire surface. IMPORTANT: The roller cleaning pad contains sodium lauryl ether sulfate which can cause eye irritation. Refer to the MSDS for more information.
- Page 4 Cleaning the calibration area 1. Remove dust and debris from this area by using a Staticide wipe or a small brush. Be careful not to scratch the glass when cleaning. IMPORTANT: Staticide wipes contain isopropanol which can cause eye irritation and dry skin. Wash your hands with soap and water after performing maintenance procedures.
-
Page 5: Replacing The Feed Module
Replacing the feed Degradation of feeder performance, multiple feeds, stoppages, etc. module indicate a need to change the feed module. Certain paper types such as carbonless paper or newsprint, or failure to clean regularly, and/or use of non-recommended cleaning solvents can shorten the feed module life. -
Page 6: Supplies And Consumables
Supplies and Contact your scanner supplier to order supplies. consumables Description CAT No. Kodak Feed Module / for i30/i40 Scanners 174 7849 Kodak Digital Science Roller Cleaning Pads 853 5981 Staticide Wipes for Kodak Scanners 896 5519 NOTE: Items and catalog numbers are subject to change. -
Page 7: Troubleshooting
6 Troubleshooting Occasionally you may encounter a situation with your scanner where it may not function properly. Refer to the information in this chapter to help you resolve the situation before calling Technical Support. Indicator lights and The indicator lights provide information on the current state of the scanner. -
Page 8: Problem Solving
• If you are scanning one side of a document, or if you have a Kodak i30 Scanner, be sure the side you want to scan is placed toward the feed tray (not facing you). - Page 9 If the scanned documents in a batch have more than a 25 degree skew, First image in a batch appears “washed out” the first image in the batch may appear washed out. Be sure that documents are placed in the input tray with the edges aligned and the side guides positioned correctly to accommodate the size documents you are feeding to avoid large skew angles.
- Page 10 2. Click on the Hardware tab and select Device Manager. 3. From the Device Manager screen, select Imaging devices. If the Kodak i30/i40 Scanner appears, with a ? before the name, you need to reinstall the driver software. A-61512 May 2006...
- Page 11 4. Double-click on the Kodak Scanner i40 (or i30). The Scanner Properties dialog box will be displayed. Select the Driver tab. 5. Click Update Driver. The Upgrade Device Driver Wizard will be displayed. 6. Click Next. A-61512 May 2006...
- Page 12 7. Click Next. 8. Insert the Installation CD in the CD-ROM drive and locate the kdssti.in file. 9. Click Open and proceed with the prompts to install the driver. A-61512 May 2006...
-
Page 13: Testing For A Usb Connection
Testing for a USB When the Kodak device drivers for the Kodak i30 and i40 Scanners are connection installed, a copy of the USB test software will also be installed. It will be located in this folder (by default) along with the Kodak Scan Validation Tool software: C:\program files\Kodak\Document Imaging\usbtst.exe... -
Page 14: Usb Connection Issues
Your operating system only supports USB 1.1 There are some host PC operating systems that will not support USB 2.0, but support USB 1.1 (e.g., Windows 98SE). The Kodak i30 and i40 Scanners are rated and designed to operate with USB 2.0, but will function in a USB 1.1 port, however, the scanner will only perform at a... - Page 15 You do not need to install any additional USB card(s) The host PC operating system will only support USB 1.1 and will not support USB 2.0, but did find a USB port. The Kodak i30 and i40 Scanners are rated and designed to operate with USB 2.0, but will function in a USB 1.1 port, however, the scanner will only perform at a...
