GSM TELEPHONE
GSM TELEPHONE
GT-P1000
2. Specification
3. Product Function
7. Disassembly and Assembly
Instructions
8. Chart of Troubleshooting
9. Reference data
Notice :
All functionality, features, specifications and other
product information provided in this document inclu
ding, but not limited to, the benefits, design, pricing,
components, performance, availability, and capabiliti
- es of the product are subject to change without
notice or obligation. Samsung reserves the right to
make changes to this document and the product
described herein, at anytime, without obligation on
Samsung to provide notification of such change.
CONTENTS

Advertisement

Table of Contents
loading

Related Manuals for Samsung GT-P1000

Summary of Contents for Samsung GT-P1000

  • Page 1 - es of the product are subject to change without notice or obligation. Samsung reserves the right to make changes to this document and the product described herein, at anytime, without obligation on...
  • Page 2 China china.samsungportal.com Asia asia.samsungportal.com Mideast & Africa mea.samsungportal.com This Service Manual is a property of Samsung Electronics Co.,Ltd. Samsung Electronics Co.,Ltd. ⓒ Any unauthorized use of Manual can be punished under applicable International and/or domestic law. 2010. 09. Rev.1.0...

  • Page 3: Gsm General Specification

    2. Specification 2-1. GSM General Specification WC DMA WC DMA W C D M A GSM8 50 E G S M 9 0 0 DCS1 800 PCS1900 2 100 1 900 90 0 F r eq . B a n d [ M H z] 82 4~8 49 8 80 ~ 91 5 1 71 0~ 1 78 5...

  • Page 4: Gsm Tx Power Class

    Specification 2-2. GSM Tx Power Class TX Power TX Power TX Power TX Power control GSM850 control EGSM900 control DCS1800 control PCS1900 level level level level 33±2 dBm 33±2 dBm 30±3 dBm 30±3 dBm 31±2 dBm 31±2 dBm 28±3 dBm 28±3 dBm 29±2 dBm 29±2 dBm...

  • Page 5: Operation Instruction And Installation

    • Sensors: Accelation, Magnetic, Gyro, Light • Additional : - Application store / Voice & Motion UI - SMS/MMS/Email/Push Email (Exchange ActiveSync)/ Video Messaging Email - Multi-touch, Multi-task manager SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 6 JIG BOX (GH99-36900A)  RF Test Cable (GH39-00985A)  JIG Cable (GH39-09211A)  Adapter (GH99-38251A)  Data Link Cable  Binary files  Settings Data Link Cable SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 7  Load the binary download program by executing the "Odin3 v1.31.exe" Run this file.  1. Option Selection - Check Re-Partition, Auto Reboot and F. Reset Time, then select PIT File SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 8 Volume Down Button 3. Connect the Device to PC via Data Cable. Make sure ID:COM box highlighted yellow that the device is connected to the PC. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 9 4. Start Downloading PIT file by clicking Start Button. Then wait for "Pass" to be appear on the screen. Start Button 5. Click on Reset button, then unselect Re-Partition box. Then select PDA, PHONE and CSC Files. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 10 "Pass" to be appear on the screen. 9. Once the device boots up, confirm the downloaded version name and etc. : *#1234# Full Reset : *2767*3855# SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 11 ― QPSK: Quadrature Phase Shift Keying ― RS : Reed-Solomon ― SI : Service Information ― TDM : Time Division Multiplexing ― TS : Transport Stream SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 12: Safety Precautions

    ― Don't use as you pleases after change other material than replacement registered on SEC System. Otherwise engineer in charge isn't charged with problem that you don't keep this rules. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 13 ― You must maintain electric contact between ESD and place due to be set up until ESD is connected completely to the proper place or a circuit board. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 14: Exploded View And Parts List

    4-1. Cellular phone Exploded View QVK01 QLC01 QJK03 QJK07 QCR03 QME16 QCA02 QCR47 QMP01 QSP01 QCA01 QSP02 QAN02 QAN03 QMO01 QCR03 QBA01 QCK01 QVO01 QSD01 QRF07 QRE01 QCR103 QSC01 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 15: Main Electrical Parts List

    C-CER,CHIP C149,C153,C158,C300 2203-007271 C-CER,CHIP C151 2203-006620 C-CER,CHIP C152,C214 2203-006979 C-CER,CHIP C154,C231,C235,C239 2203-006305 C-CER,CHIP C155 2203-006693 C-CER,CHIP C156,C161 2203-006194 C-CER,CHIP C159,C221,C238,C247 C-CER,CHIP 2203-005683 C165 2203-005234 C-CER,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 16 C-CER,CHIP C315,C323,C324,C329 2203-006048 C-CER,CHIP C317,C320,C715,C739 2203-006681 C-CER,CHIP C325,C331,C336,C341 2203-006260 C-CER,CHIP C326,C327 2203-000812 C-CER,CHIP C328,C348,C349,C350 2203-000812 C-CER,CHIP C330,C337,C771 2203-007230 C-CER,CHIP C332,C333,C701 2203-007240 C-CER,CHIP C334,C335,C408,C418 2203-006048 C-CER,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 17 C-CER,CHIP C609,C612,C615,C617 2203-006048 C-CER,CHIP C614,C619,C703,C716 2203-006562 C-CER,CHIP C616,C852 2203-007317 C-CER,CHIP C618,C623,C625,C626 2203-006048 C-CER,CHIP C620 2203-005138 C-CER,CHIP C621,C622 2203-006133 C-CER,CHIP C627,C806,C809,C818 2203-002709 C-CER,CHIP C628 2203-000489 C-CER,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 18 C851 2203-000254 C-CER,CHIP C854 2203-007269 C-CER,CHIP CD300 3709-001575 CONNECTOR-CARD EDGE D100,D101,D600 0404-001250 DIODE-SCHOTTKY D301,D302,D303,D400 0406-001239 DIODE-TVS D401,D402,D403,D404 0406-001375 DIODE-TVS D500,D900 0407-001002 0407-001002 D501,D502,D804,ZD501 0406-001239 0407-001002 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 19 INDUCTOR-SMD L304,L804,L806 3301-001956 INDUCTOR-SMD L400,L401,L407,L409 3301-001756 INDUCTOR-SMD L408 3301-001885 INDUCTOR-SMD L410,L411,L412,L413 3301-001812 INDUCTOR-SMD L504,L801 2703-003502 INDUCTOR-SMD L701,L702,L703 2703-003913 INDUCTOR-SMD L704 2703-003907 INDUCTOR-SMD L705,L706 2703-001868 INDUCTOR-SMD SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 20 R-CHIP R216 2007-008043 R-CHIP R217 2007-009111 R-CHIP R218,R225,R428,R429 2007-008516 R-CHIP R300,R320,R322,R325 2007-000157 R-CHIP R306,R334,R360,R540 2007-000148 R-CHIP R307,R308,R309,R310 2007-007014 R-CHIP R311,R586,R602,R694 2007-000143 R-CHIP R314,R332,R595 2007-000167 R-CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 21 R-CHIP R637,R638,R640,R641 2007-000162 R-CHIP R645,R665,R666,R685 2007-000140 R-CHIP R646,R647,R651,R660 2007-000162 R-CHIP R657,R659 2007-009964 R-CHIP R667,R682,R705,R707 2007-000148 R-CHIP R680 2007-007009 R-CHIP R686,R692,R693,R695 2007-000140 R-CHIP R688,R689,R691,R743 2007-000162 R-CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 22 1205-003949 ;PMB5703 U102 1203-006199 ;AAT1171IUP-1-T1 U105,U705 0505-002353 IC-SENSOR U107 1209-002006 IC-SENSOR U200 1205-003966 IC-RECEIVER U201 1201-003129 IC-RF AMP U202 1205-004045 IC-TRANSCEIVER U203 1001-001536 IC-RF SWITCH SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 23 U807 1203-004776 IC-POSI.FIXED REG U808 0904-002596 IC-GRAPHIC CONT U809 1209-001997 IC-SENSOR U810 1203-006025 IC-DC/DC CONVERTER UCD400 1205-003943 IC-Codec UME300 1107-001937 IC-NAND FLASH ZD300 0406-001267 DIODE-TVS SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 24 0406-001375 ZD509,ZD702 DIODE-TVS 0406-001375 ZD510,ZD511 1405-001296 VARISTOR Please consult the GSPN website (Samsung Portal) for the most recent version of the product's part list. 5-10 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 25: Disassembly And Assembly

    JIG, disassembly Disassembly the FRONT Ass`y from REAR battery connector. (screw: 1.4 *3 Torque 1.1+-0.1) SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 26 PBA from the FRONT Ass`y take off the PBA from the FRONT Ass`y take off the PBA from the FRONT Ass`y take off the PBA from the FRONT Ass`y SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 27 7. Level 2 Repair disassembly the LCD con to con FPCB do not damage the FPCB, be careful. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 28 Place the PBA on the Front Ass`y assembly connector assembly connector and tighten the screw(7 points) Place the PBA on the Front Ass`y screw: 1.4 *3 Torque 1.1+-0.1 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 29 Assembly Front Ass`y and Rear screw code(6001-002656) screw driver code(2713577900) tighten screw(2points) check side gap screw:1.7 *3.5 (Torque 1.3 ± 0.1, star type) SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 30 7" TFT LCD TRANCEIVER Transmitter 2G/3G PMB5703 CODEC AP_SCL Tx/Rx WM8994 CP_PCM iNand Codec_I2S_CLK NAND_CLK AP_PMIC_SCL CHARGER_SCL_2.8V AP PMIC Charger IC 3.5 PI MAX8998 SMB136SET EAR JACK SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 31 Level 3 Repair 8-2. PCB Diagrams 8-2-1. Top SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 32 Level 3 Repair 8-2-2. Bottom SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 33: Chart Of Troubleshooting

    Level 3 Repair 8-3. Flow Chart of Troubleshooting Equipments Oscilloscope Digital Multimeter Power Supply + driver, Tweezer SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 34 Check the clock generation circuit related to OSC700 Check the Clock at OSC700(C740) that frequency (short, open, crack, etc.) is 32K if OSC700 has problem, change OSC700 check the initial operation SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 35 C721 R707 C723 C724 C725 C726 C727 C728 C729 C730 C731 C732 C733 C734 C735 C736 C739 D900 C740 OSC700 U700 R708 C718 C740 OSC700 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 36 OSC600(C621) and 26MHz wave forms at OSC100(C128) LCD display OK? Check the LCD part(short, crack, etc.) Check the Audio Part(short, crack, etc.) Sound is OK? SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 37 TX3G_L TX_3G_L TX3G_M1 TX_3G_M TX3G_M2 XO_SUP C129 C128 C_EXT AFC_DAC ALERT_N ALERT_N XTAL_24MHZ_OUT RESET_N RESET_N C130 TESTPIN1 TESTPIN2 TESTPIN3 TESTPIN4 TESTPIN5 C621 C622 TESTPIN8 TESTPIN9 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 38: Charging Part

    Check U501 output pin C503 Check U501 chip(crack, open, etc.) whether voltage reading is (if U501 has some problem, it is to be replaced) greater than 5V SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 39 JTAG_USB_ID ACCESSORY_ID ACCESSORY_INT MHL_DP MHL_DM MHL_ID R520 IF_RXD R521 IF_TXD R570 AP_TV_OUT REMOTE_SENSE EAR_L_CRADLE EAR_R_CRADLE R541 VCC_2.8V_PDA 3.5_INT_TEST R540 JTAG_TXD JTAG_RXD C504 D502 C513 8-10 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 40: Sim Part

    CP_VSIM R311 SIM300 R346 C8 C8 SIM_IO SIM_DETECT C6 C6 SIM_CLK SIM_RST C3 C3 C1 C1 2 NC NC 5 NC 4 C323 C328 8-11 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 41: Microphone Part

    (short, crack, etc) Check the voltage at Resolder or replace U402 C407 = 2.1V Check component soldering Resolder or replace C434, C435 statuses of C434, C435 8-12 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 42 CIFMODE MICBIAS1 CS|ADDR MICBIAS2 AP_SDA LDO1ENA CODEC_LDO_EN LDO2ENA TP406 C438 R428 R429 C439 C443 C444 C467 V_BAT MICBIAS_2.1V U402 VOUT MICBIAS_EN C411 C407 R407 8-13 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 43: Speaker Part

    Check speaker function. Play MP3 with maximum volume level. Check the signals on Resolder or replace UCD400 L410, L411, L412, L413 Replace the speaker module 8-14 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 44 Level 3 Repair SPK400 L410 SPK_OUTR_P L411 SPK_OUTR_N C401 C402 C404 C403 SPK401 L412 SPK_OUTL_P L413 SPK_OUTL_N C421 C422 C419 C420 8-15 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 45 Check the Voltage on L213 = Resolder or change L213 1.5V Check the Status of Resolder or Replace C296, ANT202 C296, ANT202 Resolder or Replace U202 8-16 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 46 R201 R112 R117 C248 L118 D802 C830 C828 D801 C829 TP213 TP216 U107 LED800 HDC401 R620 R848 R621 R851 D803 C826 R847 R850 C852 8-17 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 47 PMU Check the signal of Check the freq of Replace or resolder CMC_B(0), CMC_G(3), OSC800(19.2MHz) OSC800 CMC_R(7) Replace or resolder U808 Replace LCD Module 8-18 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 48 B_DB22_M DB23_L LCD_R(7) LCD_R(7) AGND R820 CMC_EN C831 C832 V_BAT VCMC623_3.3V U807 VOUT 1 CMC_EN C836 C837 R836 OSC800 R839 19.2M_IN 19.2M_OUT C841 C840 8-19 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 49 Resolder or Replace U801 and Pin8 = 2.8V(C812) Check the I2C signal of Resolder R805, R806 or Replace U802 Sensor IC(R805, R806) Replace LCD Module 8-20 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 50 R812 TSP_X(17) Y12|X17 TSP_Y(11) ADDR_SEL Y11|X18 TSP_Y(10) Y10|X19 TSP_Y(9) TSP_Y(8) TSP_Y(7) TSP_Y(6) TSP_Y(5) TP802 TSP_Y(4) TSP_Y(3) TSP_Y(2) TSP_Y(1) TSP_Y(0) U802 TP802 C804 TP804 TP800 8-21 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 51 Check the Pin 21 of HDC802 Check R818 is 54MHz (Whether the Pin is Short with Pin 19, 20 or not) Replace the camera module 8-22 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 52 21 21 CAM_PCLK CAM_VSYNC 23 23 CAM_HSYNC R819 25 25 CAM_MCLK CAM_SCL_2.8V CAM_SDA_2.8V L803 NC NC 31 32 C815 C824 C825 C826 C827 C816 8-23 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 53 Check the Pin 21 of HDC802 Check R818 is 24MHz (Whether the Pin is Short with Pin 19, 20 or not) Replace the camera module 8-24 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 54 NC NC 29 29 31 32 C815 C824 C825 C826 C827 C816 C817 C828 C829 C830 ground ground 1.3M_CAM & LUME CONN. 3M_CAMERA CONN. 8-25 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 55 & {C111,C112,C337 = 1.8V?} & {C102,C342 = 2.85V ?} Change or resolder Check the freq. at C128 OSC100 : 26MHz ? GSM850 Receiver is O.K? Change U302 8-26 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 56 C160 C114 L300 C314 L304 L110 U810 U300 C119 L301 C465 C144 U102 L105 U401 RP103K211D-TR RP103K211D-TR R438 C140 L805 PAM101 C136 C133 CN101 8-27 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 57 & {C111,C112,C337 = 1.8V?} & {C102,C342 = 2.85V ?} Check the freq. at C128 Change or resolder OSC100 : 26MHz ? GSM1800 Receiver is O.K? Change U302 8-28 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 58 C160 C114 L300 C314 L304 L110 U810 U300 C119 L301 C465 C144 U102 L105 U401 RP103K211D-TR RP103K211D-TR R438 C140 L805 PAM101 C136 C133 CN101 8-29 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 59 & {C111,C112,C337 = 1.8V?} & {C102,C342 = 2.85V ?} Check the freq. at OSC100 Resolder or change :26MHz ? OSC100 WCDMA BAND1 Receiver is O.K? Change U302 8-30 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 60 R315 C336 C332 C144 U102 C315 C316 L105 L300 C314 L304 U300 C140 L805 PAM101 L301 C465 U401 RP103K211D-TR RP103K211D-TR R438 C136 C133 CN101 8-31 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 61 & {C102,C342 = 2.85V ?} Check the freq. at OSC100 Change or resolder :26MHz ? OSC100 WCDMA BAND2, PCS1900 Receiver is O.K? Change U302 8-32 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 62 TP609 C140 L805 PAM101 R31 4 R315 C336 C332 C315 C316 L300 C314 L304 C136 C133 U300 L301 C465 CN101 U401 RP103K211D-TR RP103K211D-TR R438 8-33 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 63 & {C102,C342 = 2.85V ?} Check the freq. at OSC100 Change or resolder :26MHz ? OSC100 WCDMA BAND8, GSM900 Receiver is O.K? Change U302 8-34 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 64 R315 C336 C332 C316 C315 C144 U102 L105 C314 L300 L304 U300 C140 L805 L301 C465 PAM101 U401 RP103K211D-TR RP103K211D-TR R438 C133 C136 CN101 8-35 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 65 & {C111,C112,C337 = 1.8V?} & {C102,C342 = 2.85V ?} Check the freq. at C128 Change or resolder : 26MHz ? OSC100 GSM850/900 Transmitter is O.K? Change U302 8-36 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 66 & {C111,C112,C337 = 1.8V?} & {C102,C342 = 2.85V ?} Check the freq. at C128 Change or resolder : 26MHz ? OSC100 DCS/PCS Transmitter is O.K? Change U302 8-37 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 67 R315 C336 C144 U102 C332 C315 C316 L105 L300 C314 L304 C140 L805 U300 PAM101 L301 C465 U401 RP103K211D-TR RP103K211D-TR R438 C136 C133 CN101 8-38 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 68 & {C102,C342 = 2.85V ?} Check the freq. at C128 Change or resolder : 26MHz ? OSC100 WCDMA 2100 Transmitter is O.K? Change U302 8-39 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 69 R31 4 R315 C336 C332 L105 C315 C316 L300 C314 L304 C140 L805 U300 PAM101 L301 C465 U401 RP103K211D-TR RP103K211D-TR R438 C136 C133 CN101 8-40 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 70 & {C102,C342 = 2.85V ?} Check the freq. at C128 Change or resolder : 26MHz ? OSC100 WCDMA 1900 Transmitter is O.K? Change U302 8-41 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 71 L105 R31 4 R315 C336 C332 C315 C316 L300 C314 C140 L805 L304 PAM101 U300 L301 C465 U401 RP103K211D-TR RP103K211D-TR C136 C133 R438 CN101 8-42 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 72 & {C102,C342 = 2.85V ?} Check the freq. at C128 Change or resolder : 26MHz ? OSC100 WCDMA 900 Transmitter is O.K? Change U302 8-43 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 73 U810 C315 C316 L110 C119 C144 U102 L300 C314 L105 L304 U300 L301 C465 C140 L805 U401 PAM101 RP103K211D-TR RP103K211D-TR R438 C136 C133 CN101 8-44 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 74 Level 3 Repair 8-4. Service Schematics - NC Point(Top View) U806 TST1 RSTN CAD1 CAD0 TST3 UME300 : NC 8-45 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 75 NO12 NO1 1 VICH G BUCK SAFE SAFE OUT 1 OUT2 PGND LX 3 BATT NC12 NC11 CS 1 DCIN PGND PGND BATT DCIN 8-46 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 76 RTS_N MMCI3 MMCI3 USIF3_ MMCI3 T_OUT SYSCL I2C_IN I2C1_S I2C2_S USIF3_ GPIO_0 GPIO_0 GPIO_0 GPIO_0 GPIO_0 GPIO_0 GPIO_0 GPIO_0 _DAT[1 _DAT[3 RXD_M _CLK CTS_N 8-47 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 77 Level 3 Repair U601 : NC 8-48 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 78 Level 3 Repair U702 : NC 8-49 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 79 - This Document can not be used without Samsung's authorization - 5-2. Cellular phone Parts list : GT-P1000CWAFTM Design LOC Description SEC CODE QAN02 INTENNA-GT_P1000 GH42-02645A QAN03 INTENNA-GPS(GT-P1000) GH42-02695A QBA01 SOFT BATTERY PACK-4000MAH,UNI,BLACK,MAIN GH43-03457A QCA01 ASSY CAMERA-MODULE(GTP1000_3M) GH96-04944A QCA02 ASSY CAMERA-MODULE(P1000_1.3M)
