GSM TELEPHONE
GSM TELEPHONE
GT-P1010(GT-P1013 Common)
3. Product Function
9. Reference data
Notice :
All functionality, features, specifications and other
product information provided in this document inclu
ding, but not limited to, the benefits, design, pricing,
components, performance, availability, and capabiliti
- es of the product are subject to change without
notice or obligation. Samsung reserves the right to
make changes to this document and the product
described herein, at anytime, without obligation on
Samsung to provide notification of such change.
CONTENTS

Advertisement

Table of Contents
loading

Related Manuals for Samsung GT-p1010

Summary of Contents for Samsung GT-p1010

  • Page 1: Table Of Contents

    - es of the product are subject to change without notice or obligation. Samsung reserves the right to make changes to this document and the product described herein, at anytime, without obligation on...

  • Page 2: Safety Precautions

    ― Don't use as you pleases after change other material than replacement registered on SEC System. Otherwise engineer in charge isn't charged with problem that you don't keep this rules. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 3 ― You must maintain electric contact between ESD and place due to be set up until ESD is connected completely to the proper place or a circuit board. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 4: Operation Instruction And Installation

    • Sensors: Accelation, Magnetic, Gyro, Light • Additional : - Application store / Voice & Motion UI - Email/Push Email (Exchange ActiveSync) / Video Messaging Email - Multi-touch, Multi-task manager SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 5: Exploded View And Parts List

    4-1. Cellular phone Exploded View QVK01 QFR01 QJK03 QJK07 QCR03 QME16 QCA02 QCR47 QMP01 QCA01 QSP01 QSP02 QAN02 QAN03 QMO01 QCR03 QBA01 QCK01 QSD01 QVO01 QRF03 QRE01 QCR103 QSC01 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 6: Cellular Phone Parts List

    MEA FRONT-LCD ASSY(P1010 WIFI_W) GH97-12099A QRE01 ASSY CASE-REAR(GT-P1010) GH98-19465A QSD01 PMO COVER-SD_CARD_VZW GH72-60980A QCK01 PMO KEY-POWER GH72-61569A QRF03 ASSY DECO-EAR GH98-18306A QVO01 ASSY KEY-VOLUME GH98-18671A SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 7: Main Electrical Parts List

    C-CER,CHIP C247,C248 2203-006318 C-CER,CHIP C326,C622,C629,C732 2203-006190 C-CER,CHIP C344,C825 2203-007317 C-CER,CHIP C400,C401,C412,C413 2203-006562 C-CER,CHIP C404,C405,C419,C420 2203-000627 C-CER,CHIP C407,C411,C414,C436 C-CER,CHIP 2203-000425 C409,C728,C729,C735 2203-000386 C-CER,CHIP C421,C424,C427,C430 2203-006562 C-CER,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 8 C-CER,CHIP C720,C725 2203-007693 C-CER,CHIP C721,C743,C758,C764 2203-006399 C-CER,CHIP C726 2203-000725 C-CER,CHIP C727,C733,C751,C765 2203-006824 C-CER,CHIP C730,C731 2203-007240 C-CER,CHIP C734,C759,C760 C-CER,CHIP 2203-007133 C737,C741 2203-006890 C-CER,CHIP C742,C809 2203-007775 C-CER,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 9 DIODE-TVS D503 0404-001361 DIODE-TVS D504,D505 0404-001172 DIODE-TVS D700 0407-001007 DIODE-TVS D701,D702 0404-001250 DIODE-TVS D801,D802,D803,D804 0406-001375 DIODE-TVS F200 DUPLEXER-SAW 2911-000164 F201 4709-001967 FILTER-LC F803,F804,F805 2901-001470 FILTER-EMI/ESD SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 10 OSCILLATOR-VCTCXO OSC701 2801-004909 CRYSTAL-SMD OSC800 2801-004626 CRYSTAL-SMD Q700 0504-000168 TR-DIGITAL Q701 0505-002384 TR-DIGITAL R200 2007-008045 R-CHIP R201 R-CHIP 2007-008806 R202 2007-000153 R-CHIP R203,R204,R205,R206 2007-009171 R-CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 11 R-CHIP R547,R729,R810,R811 2007-000148 R-CHIP R548 2007-007092 R-CHIP R600,R601,R605,R606 2007-009408 R-CHIP R607,R608 2007-009408 R-CHIP R613,R616,R617,R715 2007-008055 R-CHIP R621,R630,R631,R632 R-CHIP 2007-008052 R622 2007-000142 R-CHIP R623,R627,R634,R635 2007-008516 R-CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 12 R-CHIP R839 2007-007316 R-CHIP R840 2007-007142 R-CHIP SC200 GH71-09660A SHIELDCAN TA400,TA402,TA701 2404-001572 C-TA,CHIP TA401 2404-001596 C-TA,CHIP TA700,TA800 C-TA,CHIP 2404-001381 TA702 2404-001572 C-TA,CHIP TH700 1404-001221 THERMISTOR-NTC SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 13 FUEL GAUGE U708 0505-002353 IC-LDO U709 0801-003016 GATE U710 0801-003079 GATE U711 1203-006346 IC-RESET U712 0801-003346 74AUP1G04GM U800 IC-DCDC 1203-006476 U801 1205-004036 LVDS U802 0903-001633 IC-TSP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 14 0403-001688 IC-TVS ZD506,ZD507,ZD508 0406-001375 IC-TVS ZD701 0406-001375 IC-TVS Please consult the GSPN website (Samsung Portal) for the most recent version of the product's part list. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 15: Level 1 Repair

    • Data Link Cable • JIG BOX (GH99-36900A) • RF Test Cable (GH39-00985A) • JIG Cable (GH81-09211A) • Adapter (GH99-38251A) • Binary files ※ Settings Data Link Cable SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 16 " Odin3 v1.61.exe " ← Run this file. 1. Option Selection - Check Re-Partition, Auto Reboot and F. Reset Time, then select PIT, PDA and CSC Files. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 17 Volume Down Button 3. Connect the Device to PC via Data Cable. Make sure ID:COM box highlighted yellow that the device is connected to the PC. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 18 "Pass" to be appear on the screen. 5. Once the device boots up, confirm the downloaded version name and etc. : *#1234# Full Reset : *2767*3855# SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 19: Level 2 Repair

    Loosen the screw, and use assembly JIG, disassembly Disassembly the FRONT Ass`y from REAR battery connector. (screw: 1.4 *3 Torque 1.1+-0.1) SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 20 PBA from the FRONT Ass`y take off the PBA from the FRONT Ass`y Take off the PBA from the FRONT Ass`y Take off the PBA from the FRONT Ass`y SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 21 7. Level 2 Repair disassembly the LCD con to con FPCB Do not damage the FPCB, be careful. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 22 Place the PBA on the Front Ass`y assembly connector Assembly connector and tighten the screw(7 points) Place the PBA on the Front Ass`y screw: 1.4 *3 Torque 1.1+-0.1 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 23 Assembly the Front Ass`y and Rear serew(screw: 1.4 *3 Torque 1.1+-0.1) Assembly Front Ass`y and Rear tighten screw(2points) Tighten screw(2points) Check side gap screw:1.7 *3.5 (Torque 1.35 +-0.15) SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 24: Level 3 Repair

    8. Level 3 Repair 8-1. Block Diagram SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 25 Level 3 Repair 8-2. PCB Diagrams 8-2-1. Top SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 26 Level 3 Repair 8-2-2. Bottom SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 27 Level 3 Repair 8-3. Flow Chart of Troubleshooting Equipments ↑ Oscilloscope ↑ Digital Multimeter ↑ Power Supply ↑ + driver, Tweezer SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 28 And if PMIC has problem, change U704) Check the Clock at Check the clock generation circuit OSC700(C701) that frequency is 32K (related to OSC700) check the initial operation SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 29 Level 3 Repair SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 30: Charging Part

    (U703 chip may not work) Check U703 output pin C738 Check U703 chip whether voltage is change (U702 chip may not work) when TA is connected SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 31 Level 3 Repair SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 32: Microphone Part

    Check the Voltage at the solder place of C717, 719 placed near U704 Resolder or replace U704 C717 = 0.75 V C719 = 0.75 V SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 33 Level 3 Repair 8-10 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 34: Speaker Part

    Check speaker function. Play MP3 with maximum volume level. Check the signals on Resolder or replace U704 L400, L401, L406, L407 Replace the speaker module 8-11 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 35 C heck the Voltage on C231 = Check AP PMIC U704 1.8V Check the Status of Resolder or Replace C226, ANT201 C226, ANT201 Resolder or Replace U204 8-12 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 36 FMAUDRIN TESTMODE FMAUDLOUT FMAUDROUT BT_WIFI_CLK32K < WIFI / BT > U805 L804 C238 OSC200 C222 ANT201 L205 C230 C245 C226 L207 ANT202 L208 BH106 8-13 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 37 1.8V → check the PMU Check the signal of Check the freq of Replace or resolder CMC_B(0), CMC_G(3), OSC800(19.2MHz) OSC800 CMC_R(7) Replace or resolder U810 Replace LCD Module 8-14 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 38 19.2M_OUT XTAL_PADY SPI_MISO CABC_PWM SPI_MOSI CMC623_PWM R827 LPA_PWM SPI_SCLK OSC800 TP_MON MON_CLK_DVI SPI_SEN R831 B_CSB_623 19.2M_IN I2CM_SEL 19.2M_OUT R829 C833 R832 R833 R830 C832 8-15 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 39 Resolder or Replace U800 and Pin8 = 2.8V(C810) Check the I2C signal of Resolder R803 R804 or Replace U802 Sensor IC(R803, R804) Replace LCD Module 8-16 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 40 Level 3 Repair 8-17 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 41 Check the Pin 21 of HDC802 Check R834 is 54MHz (Whether the Pin is Short with Pin 19, 23 or not) Replace the camera module 8-18 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 42 Level 3 Repair 8-19 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 43 Check the Pin 23 of HDC803 Check R834 is 24MHz (Whether the Pin is Short with Pin 21, 25 or not) Replace the camera module 8-20 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 44 Level 3 Repair 8-21 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 45 ― QPSK: Quadrature Phase Shift Keying ― RS : Reed-Solomon ― SI : Service Information ― TDM : Time Division Multiplexing ― TS : Transport Stream SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 46 This Service Manual is a property of Samsung Electronics Co.,Ltd. Samsung Electronics Co.,Ltd. ⓒ Any unauthorized use of Manual can be punished under applicable International and/or domestic law. 2011. 01. Rev.1.0...
  • Page 47 www.s-manuals.com...
