Omega FAR-2 Series Instruction Sheet

An O M EG A Tech n ol ogi es C om p an y
FAR-2 Series
Power Supply
INSTRUCTION
SHEET

Unpacking Instructions

Remove the Packing List and verify that you
have received all equipment, including the
following (quantities in parentheses):
FAR-2 Series Power Supply (1)
Instruction Sheet (1)
If you have any questions about the
shipment, please call the OMEGA Customer
Service Department.
When you receive the shipment, inspect the
container and equipment for signs of
damage. Note any evidence of rough
handling in transit. Immediately report any
damage to the shipping agent.
The carrier will not honor damage
claims unlees all shipping material
is saved for inspection. After
examining
contents, save packing material
and
reshipment is necessary.
Description
The FAR-2 Series power supply is for general
purposes, ideal for use with sensors, pressure
transducers, etc. This model does not
incorporate the excitation sense option. If you
want the sense option, order a FAR-1 power
supply.
M2303/0197
NOTE
and removing
carton in the event
Available Models
Table 1. Available Models
Part Number
FAR-2-5
FAR-2-9
FAR-2-12
FAR-2-15
FAR-2-18
FAR-2-24
Wiring
Figure 1. Connections Diagram
CJS0895JACB
Voltage (V) Max. Current (mA)
5
9
12
15
18
24
POWER SUPPLY
OUTPUT
-
3 4 5
1 2
_
_
+
~ ~
SENSE OUT SENSE OUT
AC
VOLTAGE
OUTPUT / SALIDA
POWER SUPPLY
FUENTE ALIMENTACION
225
225
200
100
100
150
+
6
+
