Pioneer fh-p4400 Service Manual
Multi-cd control high power cd cassette player with fm/am tuner
Hide thumbs
Also See for fh-p4400:
- Operation manual (112 pages) ,
- Installation manual (4 pages) ,
- Service manual (15 pages)
Advertisement
Quick Links
QQ
3 7 63 1515 0
Service
Manual
MULTI-CD CONTROL HIGH POWER CD CASSETTE PLAYER WITH FM/AM TUNER
FH-P4400
- This service manual should be used together with the following manual(s):
Model No.
Order No. Mech. Module Remarks
FH-P404/UC
CRT2247
CX-597
CRT1829
CX-631
CRT1640
TE
L 13942296513
www
.
PIONEER CORPORATION
PIONEER ELECTRONICS SERVICE INC.
PIONEER EUROPE N.V.
PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #04-01, Singapore 159936
C PIONEER CORPORATION 2000
http://www.xiaoyu163.com
S7
CD Mech. Module:Circuit Description, Mech.Description, Disassembly
2L
Cassette Mech. Module:Mech.Description
x
ao
u163
y
i
4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A.
Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium
http://www.xiaoyu163.com
2 9
8
Q Q
3
6 7
1 3
1 5
co
.
9 4
2 8
ORDER NO.
CRT2517
UC,ES
0 5
8
2 9
9 4
2 8
m
K-ZZS. MAR. 2000 Printed in Japan
9 9
9 9
Advertisement
Related Manuals for Pioneer fh-p4400
Summary of Contents for Pioneer fh-p4400
- Page 1 PIONEER ELECTRONICS SERVICE INC. P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A. PIONEER EUROPE N.V. Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #04-01, Singapore 159936 C PIONEER CORPORATION 2000 K-ZZS. MAR. 2000 Printed in Japan http://www.xiaoyu163.com...
-
Page 2: Http://Www.xiaoyu163.Com
FH-P4400 EXPLODED VIEWS AND PARTS LIST 3 7 63 1515 0 PACKING 13 14 L 13942296513 u163 http://www.xiaoyu163.com... -
Page 3: Http://Www.xiaoyu163.Com
See Contrast table(2) 6-4 Panel See Contrast table(2) 6-5 Polyethylene Bag CEG1116 (2) CONTRAST TABLE FH-P4400/UC and FH-P4400/ES are constructed the same except for the following: Part No. Mark No. Symbol and Description FH-P4400/UC FH-P4400/ES 1 Cord Assy CDE5793 CDE5788 L 13942296513 6-1 Owner’s Manual... - Page 4 FH-P4400 3 7 63 1515 0 GRILLE ASSY L 13942296513 u163 http://www.xiaoyu163.com...
-
Page 5: Cn1904
FH-P4400 3 7 63 1515 0 - GRILLE ASSY SECTION PARTS LIST Mark No. Description Part No. 1 Screw BPZ20P080FMC 2 Lever(SOURCE) CAC6539 3 Lever(VOLUME) CAC6540 4 Button CAC6660 5 Button(ATT) CAC6668 6 Button(EQ) CAC6663 7 Button(SEL) CAC6664 8 Button(CDEJ) - Page 6 FH-P4400 3 7 63 1515 0 SCHEMATIC DIAGRAM Note: When ordering service parts, be sure to refer to “EXPLODED VIEWS AND PARTS LIST” or “ELECTRICAL PARTS LIST”. SW UNIT CN801 L 13942296513 u163 http://www.xiaoyu163.com...
-
Page 7: Cn1904
FH-P4400 3 7 63 1515 0 SW UNIT CN1904 L 13942296513 u163 http://www.xiaoyu163.com... - Page 8 FH-P4400 3 7 63 1515 0 FL UNIT CN801 CN1901 TUNER DECK AMP UNIT L 13942296513 u163 http://www.xiaoyu163.com...
- Page 9 FH-P4400 3 7 63 1515 0 FL UNIT L 13942296513 DISPLAY CONTROL FL DRIVER u163 http://www.xiaoyu163.com...
- Page 10 FH-P4400 3 7 63 1515 0 PCB CONNECTION DIAGRAM FL UNIT NOTE FOR PCB DIAGRAMS FL UNIT 1. The parts mounted on this PCB include all necessary parts for several destination. For further information for respective destinations, be sure to check with the schematic dia- gram.
- Page 11 FH-P4400 3 7 63 1515 0 SIDE A L 13942296513 SIDE B u163 http://www.xiaoyu163.com...
- Page 12 FH-P4400 3 7 63 1515 0 SW UNIT SW UNIT MDEJ TI/ATT SOURCE DISP SOURCE L 13942296513 SW UNIT u163 http://www.xiaoyu163.com...
-
Page 13: Http://Www.xiaoyu163.Com
FH-P4400 3 7 63 1515 0 SIDE A RESET BAND VOL UP FUNC AUDIO VOL DN L 13942296513 SIDE B CN1904 CN801 u163 http://www.xiaoyu163.com... - Page 14 FH-P4400 3 7 63 1515 0 ELECTRICAL PARTS LIST NOTES: - Parts whose parts numbers are omitted are subject to being not supplied. - The part numbers shown below indicate chip components. Chip Resistor RS1/_S___J,RS1/__S___J Chip Capacitor (except for CQS..) CKS.., CCS.., CSZS..
- Page 15 FH-P4400 3 7 63 1515 0 =====Circuit Symbol and No.===Part Name Part No. ------ ------------------------------------------ ------------------------- 1919 Push Switch CSG1129 1920 Push Switch CSG1129 1921 Push Switch CSG1129 1922 Push Switch CSG1129 1924 Push Switch CSG1111 1925 Push Switch...
