Low Silhouette Ducted
(Type F1)
Model No.
INDOOR UNIT
Low Silhouette Ducted
S-60PF1R5A
S-71PF1R5A
S-100PF1R5A
S-125PF1R5A
S-140PF1R5A
Before operating the unit, read these operating instructions thoroughly and keep them for future reference.
(Type F1)
Panasonic Corporation
1006 Kadoma, Kadoma City, Osaka, Japan
Operating Instructions
OUTDOOR UNIT
Single Split
(Single-phase)
U-60PE1R5A
U-71PE1R5A
U-100PE1R5A
U-125PE1R5A
U-140PE1R5A
Single Split
(3-phase)
U-100PE1R8A
U-125PE1R8A
U-140PE1R8A
Air Conditioner
F569974
Advertisement
Table of Contents
Related Manuals for Panasonic S-60PF1R5A
Summary of Contents for Panasonic S-60PF1R5A
-
Page 1: Operating Instructions
Operating Instructions Air Conditioner Low Silhouette Ducted (Type F1) Model No. INDOOR UNIT OUTDOOR UNIT Low Silhouette Ducted Single Split (Type F1) (Single-phase) U-60PE1R5A S-60PF1R5A U-71PE1R5A S-71PF1R5A U-100PE1R5A S-100PF1R5A U-125PE1R5A S-125PF1R5A U-140PE1R5A S-140PF1R5A Single Split (3-phase) U-100PE1R8A U-125PE1R8A U-140PE1R8A Before operating the unit, read these operating instructions thoroughly and keep them for future reference. -
Page 2: Table Of Contents
Thank you for purchasing this Panasonic product. WARNING This product is a commercial air conditioner indoor unit. Installation Instructions attached. Contents Confirm to authorized dealer or specialist on usage of specified refrigerant type. Using of refrigerant other than the Safety Precautions ............2 specified type may cause product Precautions for Use ............ - Page 3 CAUTION This appliance is intended to be used Provide a power outlet to be used by expert or trained users in shops, exclusively for each unit, and a in light industry and on farms, or for power supply disconnect, Earth commercial use by lay persons.
-
Page 4: Precautions For Use
Precautions for Use Installation Operation Condition This air conditioner must be installed properly by qualified Use this air conditioner under the following temperature range. installation technicians in accordance with the Installation „ Indoor temperature range: Instructions provided with the unit. Cooling mode 14°C ~ 25°C (*WBT) / 18°C ~ 32°C (*DBT) Before installation, check that the voltage of the electric sup-... -
Page 5: Names Of Parts
Names of Parts INDOOR UNIT OUTDOOR UNIT Air intake Air outlet duct * Air intake Bolt anchor * Suspension bolt * Indoor unit Ceiling material * Air-outlet grille * * Field supplied Air outlet Air outlet Type F1 Type 60, 71 Type 100, 125, 140 (Low Silhouette Ducted) Optional... -
Page 6: Maintenance
Maintenance Do not attempt to clean inside the unit by yourself. Refer to the section “Care and Cleaning” in the Installation Instructions. WARNING CAUTION For safety, be sure to turn the air conditioner off and dis- Never use solvents or harsh chemicals. Also, do not wipe connect the power before cleaning. -
Page 7: Troubleshooting
Troubleshooting Check before consulting or requesting services. Symptom Cause / Action Sound like streaming water is heard • Sound of refrigerant liquid flowing inside unit during operation or after operation. • Sound of drainage water through drain pipe Noise Cracking noise is heard during operation Sound due to temperature changes of parts or when operation stops. -
Page 8: Specifications
Specifications Indoor unit Low Silhouette Ducted (Type F1) Model Name S-60PF1R5A S-71PF1R5A S-100PF1R5A S-125PF1R5A S-140PF1R5A Power source 230/240 V～ 50 Hz 10.0 12.5 14.0 Cooling capacity 20,500 24,200 34,100 42,700 47,800 BTU/h 11.2 14.0 16.0 Heating capacity 23,900 27,300 38,200... -
Page 9: Outdoor Unit
Outdoor unit Single Split Outdoor Unit Model Name U-60PE1R5A U-71PE1R5A U-100PE1R5A U-125PE1R5A U-140PE1R5A Power source 230/240 V～ 50 Hz 10.0 12.5 14.0 Cooling capacity 20,500 24,200 34,100 42,700 47,800 BTU/h 11.2 14.0 16.0 Heating capacity 23,900 27,300 38,200 47,800 54,600 BTU/h Sound pressure level (C/H) 48 / 50... - Page 10 MEMO...
- Page 11 MEMO...
- Page 12 Panasonic Corporation Website: http://www.panasonic.com © Panasonic Corporation 2015 F569974 Printed in China DC0115-0...
