Troubleshooting Guide
- electrical -
R800i, R800a, R800x, R800at, Z1
1246-2437 rev 1
Page 1
©
Sony Ericsson Mobile Communications AB – Company Internal
Table of
Contents
Previous
Page
Next
Page
1
2
3
4
5
Advertisement
Table of Contents
Troubleshooting
troubleshooting guide
1
Troubleshooting Flow
3
Related Manuals for Sony Ericsson R800i
Cell Phone Sony Ericsson R800i Working Instructions
(88 pages)
Cell Phone Sony Ericsson Z1 Manual
(17 pages)
Cell Phone Sony Ericsson R800x Extended User Manual
(89 pages)
Cell Phone Sony Ericsson XPERIA PLAY R800x White Paper
Whitepaper (19 pages)
Cell Phone Sony Ericsson R300 User Manual
Sony ericsson cell phone user manual (43 pages)
Cell Phone Sony Ericsson R300 Environmental Declaration
Sony ericsson mobile phone (2 pages)
Cell Phone Sony Ericsson R300 White Paper
Energized radio experience (41 pages)
Cell Phone Sony Ericsson R306 User Manual
Sony ericsson cellphone user manual (43 pages)
Cell Phone Sony Ericsson R600 User Manual
Sony ericsson r600: user guide (76 pages)
Cell Phone Sony Ericsson R800AT Extended User Manual
User guide (103 pages)
Cell Phone Sony Ericsson R300a User Manual
Sony ericsson cell phone user's guide (43 pages)
Cell Phone Sony Ericsson R380 User Manual
Sony ericsson r380: user guide (257 pages)
Cell Phone Sony Ericsson Xperia PLAY Extended User Manual
Sony ericsson xperia play: user guide (105 pages)
Cell Phone Sony Ericsson R306c User Manual
(43 pages)
Cell Phone Sony Ericsson R306a User Manual
(85 pages)
Cell Phone Sony Ericsson Sony Ericsson W580i User Manual
Mobile phone (169 pages)
Summary of Contents for Sony Ericsson R800i
Page 1: Troubleshooting Guide
Troubleshooting Guide - electrical - R800i, R800a, R800x, R800at, Z1 1246-2437 rev 1 Page 1 © Sony Ericsson Mobile Communications AB – Company Internal...
Page 2: Table Of Contents
1.11 Memory Stick ..................14 1.12 Network & Signal ................15 2 Revision History ................16 For general information about troubleshooting, refer to 1220-1336: Generic Repair Manual - electrical 1246-2437 rev 1 © Sony Ericsson Mobile Communications AB – Company Internal 2(16)
Page 3: Troubleshooting Flow
Trouble Shooting Guide (elect) Troubleshooting Flow Display Symptom: Display problem Replace: X4300, if damaged vision check pin A4, A6, A7, A9 and B2-3, B5-6, B8-9 Z4300, Z4301 or Z4302 1246-2437 rev 1 © Sony Ericsson Mobile Communications AB – Company Internal 3(16)
Page 4: Illumination
L5600 or L5601, if more than 1 Ω C5606 or C5613, if short circuit V5600 N5600 Symptom: No Flash LED Replace: V4400 N4400 Symptom: R G B MMI LED s Replace: V4802 N5600 1246-2437 rev 1 © Sony Ericsson Mobile Communications AB – Company Internal 4(16)
Page 5: Keys & Sensors
Function Control (Right pad) A key problems Replace S5007 N4801 Symptom: Function Control (Right pad) B key problems Replace S5004 N4801 Symptom: Function Control (Right pad) C key problems Replace S5006 N4801 1246-2437 rev 1 © Sony Ericsson Mobile Communications AB – Company Internal 5(16)
Page 6
A21, A31 and B23 Symptom: Light Sensor problems Replace: X4300, if damaged vision check pin A2 ,A3 , A5 and A10 Symptom: Compass problems Replace: N5701 1246-2437 rev 1 © Sony Ericsson Mobile Communications AB – Company Internal 6(16)
Page 7: Alert
Trouble Shooting Guide (elect) Troubleshooting Flow Alert Symptom: Vibrator problems Replace: V5000, if short circuit B5000 1246-2437 rev 1 © Sony Ericsson Mobile Communications AB – Company Internal 7(16)
Page 8: Audio
L5402 or L5403 if more than 2 Ω N5400 N1200 Symptom: No Hands-free (PHF) Microphone – Phone not recognizes PHF set Replace: X5401, if damaged vision check pin 1 ,4 and 5 N5400 1246-2437 rev 1 © Sony Ericsson Mobile Communications AB – Company Internal 8(16)
Page 9: On/Off
Draws current when On/Off key is pressed, returns to zero L3900, L3903 , L3904 or L4001 , if more than 1 Ω Replace: N4003 Symptom: Other Replace: X3801, if damaged vision check all pins 1246-2437 rev 1 © Sony Ericsson Mobile Communications AB – Company Internal 9(16)
Page 10: Charging & Capacity
1 and 5 C5200, if X5200 pin 1 is short circuit to GND X3801, if damaged V3802, if short circuit N3803 , V3803 Symptom: Wrong Battery indicator Replace: N3802 1246-2437 rev 1 © Sony Ericsson Mobile Communications AB – Company Internal 10(16)
Page 11: Sim
Trouble Shooting Guide (elect) Troubleshooting Flow Symptom: SIM not detected Replace: X5100 , if damaged vision check all pins V5100 , if short circuit 1246-2437 rev 1 © Sony Ericsson Mobile Communications AB – Company Internal 11(16)
Page 12: Camera
X4500 , if damaged vision check all pins N4401 or N4402 Symptom: Sub Camera problems Replace: X4300 , if damaged vision check pin A11-A13, A17-A20, B16-B21 and B24-B25 N4700 1246-2437 rev 1 © Sony Ericsson Mobile Communications AB – Company Internal 12(16)
Page 13: Data Communication
X2500, if more than 1 Ω between term A and C Z2500 Symptom: No Bluetooth or WLAN connection Replace: N2501 N2500 N1200 Symptom: No GPS connection Replace: W2100, if damaged Z2101 N2100 Z2100 N1200 1246-2437 rev 1 © Sony Ericsson Mobile Communications AB – Company Internal 13(16)
Page 14: Memory Stick
Troubleshooting Flow 1.11 Memory Stick / Card Symptom: Memory stick / Card (micro SD) not detected Replace: X5101 , if damaged vision check pin all pins V5102 1246-2437 rev 1 © Sony Ericsson Mobile Communications AB – Company Internal 14(16)
Page 15: Network & Signal
N1700 ,N1902 or N1200 ,if WCDMA Tx band 1 fault N1701 ,N1902 or N1200 ,if WCDMA Tx band 2 or 4 or CDMA-2000 Tx band Class 14 fault 1246-2437 rev 1 © Sony Ericsson Mobile Communications AB – Company Internal 15(16)
Page 16: Revision History
Trouble Shooting Guide (elect) Revision History Rev. Date Changes / Comments 2011-03-09 Initial Release 1246-2437 rev 1 © Sony Ericsson Mobile Communications AB – Company Internal 16(16)
