Summary of Contents for Skoda Yeti

  • Page 1 SIMPLY CLEVER OWNER´S MANUAL OWNER´S MANUAL ŠKODA Yeti...
  • Page 2 Documentation of vehicle delivery Date of vehicle delivery   ŠKODA Partner Stamp and signature of the vendor I confirm that I have taken delivery of the specified vehicle in good con- dition, have received information on how to operate it correctly, and have had the terms of the warranty explained to me.
  • Page 3 1. vehicle owner 2. Vehicle Operator This vehicle with the official registration This vehicle with the official registration number number (filled in by the vendor) belongs to: belongs to: Title, Name / Company: Title, Name / Company: Address: Address: Phone: Phone: ŠKODA Partner ŠKODA Partner...
  • Page 4 Preface You have opted for a ŠKODA – our sincere thanks for your confidence in us. This Owner's Manual contains instructions about the vehicle operation, im- portant information about safety, vehicle care, maintenance and self-help and technical vehicle data. For vehicles with Infotainment, the operation of some of the functions and vehicle systems is carried out via Infotainment.

  • Page 5: Table Of Contents

    Multifunction display (MFD) Table of Contents Driving MAXI DOT display Starting-off and Driving Service interval display materials defect liability and ŠKODA warranty Starting and stopping the engine for new cars SmartGate START-STOPsystem On-board literature Unlocking and opening Brakes and parking Unlocking and locking Notes Manual gear changing and pedals...
  • Page 6 Brake fluid Vehicle battery Wheels Wheels and tyres Operating in winter conditions Do-it-yourself Emergency equipment and self-help Emergency equipment Changing a wheel Breakdown kit Jump-starting Towing the vehicle Remote control and removable light - replacing the battery/batteries Emergency unlocking / unlocking of doors Replacing windscreen wiper blades Fuses and light bulbs Fuses...

  • Page 7: Materials Defect Liability And Škoda Warranty For New Cars

    If your ŠKODA vehicle was purchased from a ŠKODA Partner in a country of the materials defect liability and ŠKODA warranty for new European Economic Area (i.e. the countries of the European Union, Norway, cars Iceland and Liechtenstein) or in Switzerland, claims arising from the ŠKODA warranty must also be made through a ŠKODA Service Partner in one of these countries.
  • Page 8 ▶ Parts fitted on or in the vehicle, whose use has not been approved by ŠKODA Note AUTO, or modification of the vehicle in a manner not approved by ŠKODA The ŠKODA extended warranty is only available in some countries. AUTO (e.g.

  • Page 9: On-Board Literature

    ŠKODA brand. The Pictures in this Owner's Manual are for illustrative purposes only. The il- http://go.skoda.eu/owners-manuals lustrations can differ in minor details from your vehicle; they are only intended ▶...

  • Page 10: Notes

    Notes Terms used “Specialist” - Workshop - a workshop that carries out specialist service tasks for ŠKODA vehicles. A specialist can be a ŠKODA Partner, a ŠKODA Serv- ice Partner, or an independent workshop. “ŠKODA Service Partner” - A workshop that has been contractually authorised by ŠKODA AUTO or its sales partner to service ŠKODA vehicles and to sell ŠKODA Genuine Parts.

  • Page 11: Structure Of The Owner's Manual And Further Information

    Structure of the Owner's Manual and further information Structure of the Owner's Manual The Owner's Manual is hierarchically divided into the following areas. Section (e.g. Operating instructions) - the title of the section is shown down ■ in the left-hand corner Main chapter (e.g.

  • Page 12: Abbreviations

    Abbreviation Definition Abbreviations Newton meter, measuring unit for the engine torque Abbreviation Definition personal identification number Engine revolutions per minute ® Diesel engine for which the AdBlue solution is required Anti-lock brake system Diesel engine with turbo-charging and common rail injection TDI CR Multi-purpose vehicles system...

  • Page 13: Safety

    ▶ Protect children using a suitable child seat » page 22, Transporting children Safety safely. ▶ Adopt the correct seated position. Tell your passengers to assume the cor- Passive Safety rect seated position » page 11, Correct and safe seated position. General information Driving safety ...
  • Page 14 Adjust the steering wheel so that the distance between the steering WARNING  wheel and your chest is at least 25 cm » Fig. 2 The front seats and all head restraints must be adjusted to match the ■ Adjust the headrest so that the top edge of the headrest is at the same body size at all times and the seat belt must always be fastened properly to ...
  • Page 15 › Adjust the steering wheel to the desired position. The steering wheel can be Correct seating position for the passengers in the rear seats adjusted in direction of arrow ›  Pull the holder in arrow direction until the stop. Read and observe on page 12 first.

  • Page 16: Seat Belts

    WARNING Seat belts Information on the proper use of safety belts Adjust the height of the belt in such a way that the shoulder part of the Using seat belts ■ belt is roughly positioned across the middle of your shoulder - on no ac- ...
  • Page 17 Seat belt height adjusters for front seats Correct routing of seat belt › Push the return pulley upwards in the direction of arrow » Fig. 5 - . › Or: push together the mechanism in the direction of arrows and push the return pulley downwards in the direction of arrow »...

  • Page 18: Inertia Reels And Belt Tensioners

    › Insert the lock tongue into the belt buckle » Fig. 6 –  that is part of the seat WARNING until it clicks into place. After releasing the seat belt hold it tight and let it slowly reel up until ■...

  • Page 19: Airbag System

    WARNING Airbag system Any work on the belt tensioner system, including the removal and instal- ■ lation of system components because of other repair work, must only be Description of the airbag system carried out by a specialist garage. If the belt tensioners have been deployed, it is then necessary to replace ...
  • Page 20 Rear side airbags Airbag deployment Head airbags Front airbags - the forward thrust of the driver and of the front passenger is cushioned when they make contact with the fully-inflated airbag, and the risk of injury to head and chest is thus reduced. The front airbags can be identified by the lettering ...
  • Page 21 The following airbags will be deployed in the event of a severe side collision. WARNING (Continued) ▶ Front side airbag. If the airbag has been deployed, the airbag system must then be replaced. ■ ▶ Rear side airbag. In the area of the front airbag and the knee airbag, the surface of the ■...

  • Page 22: Airbag Deactivation

    WARNING Airbag deactivation Information about for side and head airbags  Introduction No objects (e.g. sun visors turned towards the windows) should be loca- ■ ted in the deployment area of the side and head airbags. No accessories This chapter contains information on the following subjects: (e.g.
  • Page 23 WARNING Deactivating the front passenger airbag The key cannot be inserted into the key switch while driving. Shocks can ■ cause the key to turn in the slot and trigger the airbag! The airbag can be triggered unexpectedly in an accident - it may result in injury or death! The driver is responsible for whether the airbag is switched on or switch- ■...

  • Page 24: Transporting Children Safely

    WARNING (Continued) Transporting children safely Children are exposed to an increased risk of injury in the event of an acci- ■ dent if they lean forward or adopt an incorrect seated position when the Child seat vehicle is moving. This particularly applies to children who are transported ...
  • Page 25 Adjust the height of the front passenger seat belt so that the belt does not Use of a child seat on the front passenger seat “jam” in the return pulley. In the event of an accident, there is the risk of in- Does not apply to Taiwan jury to the neck of the child carried due to the seat belt! WARNING...
  • Page 26 Child safety and the side airbag Classification of child seats  Read and observe on page 22 first. Fig. 13 Incorrect seated position of a Classification of child seats according to the ECE-R 44 standard. child who is not properly secured Group Weight of the child –...

  • Page 27: Fastening Systems

     is a system for securing child seats quickly and safely. Fastening systems There are two fixing eyes between the seat backrest and the seat cushion of  Introduction the front passenger seat for fixing a child seat with the system. On the rear outside seats, the fixing eyes are located below the upholstery.
  • Page 28 Size class of Group Front passenger seat Outer rear seats Rear seat middle the child seat IL-SU 9-18 kg IL-SU 15-25 kg IL-SU 22-36 kg The size category is shown on the label attached to the child seat. If the front passenger seat is fitted with system attachment points, it is suitable for the installation of an  child seat with “Semi-Universal” approval. IL-SU The seat is suitable for the use of approved child seats in in the “Semi-Universal”category.
  • Page 29 Transporting children safely...
  • Page 30 Fig. 16 Cockpit example for LHD models Using the system...

  • Page 31: Using The System Cockpit

    Depending on equipment fitted: Using the system ▶ Ignition lock ▶ Starter button Cockpit Bar with keys depending on the equipment fitted: ▶  START STOP Overview ▶  Traction control TCS ▶  Electronic Stability Control ESC Door opening lever ▶...

  • Page 32: Instruments And Indicator Lights

    ▶ Displaying the distance and days until the next service interval Instruments and Indicator Lights » page 46 ▶ Show AdBlue range » page 41 Instrument cluster Coolant temperature gauge » page 31  Display » page 40 Introduction Fuel gauge »...
  • Page 33 On vehicles with MAXI DOT display, the brightness of the instrument lighting is set automatically. A manual brightness adjustment can therefore only have a The tank capacity is 55 litres or approximately 60 litres for Yeti 4x4. limited effect. If the fuel level reaches the reserve level »...
  • Page 34 If too much water is present in the separator, the following information ap- Auto Check Control pears on the instrument cluster display. Vehicle condition The indicator light is only shown in the MAXI DOTdisplay.  Certain functions and conditions of individual vehicle systems are checked continuously when the ignition is switched on.

  • Page 35: Warning Lights

    Airbag system WARNING  Tyre pressure If you have to stop for technical reasons, then park the vehicle at a safe  Windscreen washer fluid level distance from the traffic, switch off the engine and switch on the hazard  warning light system »...
  • Page 36 CAUTION Handbrake  If, in addition to the light the light lights up while driving, stop driving -    Read and observe on page 33 first. There is a risk of engine damage! Switch off the engine and seek assistance from a specialist garage.
  • Page 37 If, after the motor is restarted and a short drive, the indicator light does not go Power steering / steering lock (KESSY system)   out, there is a system error.  Read and observe on page 33 first. ▶ Continued driving is possible with appropriate caution.
  • Page 38 The vehicle will only be braked by the normal brake system without the ABS. Stability control (ESC) / Traction control (TCS)  ▶ Continued driving is possible with appropriate caution. Seek assistance from  Read and observe on page 33 first. a specialist garage immediately.
  • Page 39 Emission control system Diesel particle filter (diesel)     Read and observe on page 33 first. Read and observe on page 33 first. lights up – there is a fault in the emission control system. The system The diesel particulate filter separates the soot particles from the exhaust. The ...
  • Page 40 An audible signal sounds as a warning. Fuel reserve  ▶ Immediately reduce speed and avoid sudden steering and braking manoeu-  Read and observe on page 33 first. vres. ▶ Stop the vehicle, turn the ignition off and check the tyres and their inflation illuminates –...
  • Page 41 flashes – the hill descent assistant is engaged at the moment.  Windscreen washer fluid level   Read and observe on page 33 first. High beam   illuminates – the windscreen washer fluid level is too low. Read and observe on page 33 first.

  • Page 42: Information System

    Door alarm Information system Service interval display Outside temperature Driver information system Total distance travelled  Speed regulating system Introduction Distance travelled by resetting the memory (trip) This chapter contains information on the following subjects: Engaged gear / gear recommendation Display in the instrument cluster Selector lever positions for the automatic gearbox Setting the time...
  • Page 43 MAXI DOT display Setting the time The display of AdBlue range is part of the multi-function display » page Information overview. Fig. 22 Segment display Buttons in the instrument clus- › Press button » Fig. 22 on page 41 repeatedly until instead of total kilome- tres travelled, the AdBlue Range is displayed.

  • Page 44: Operation Of The Information System

     - Recommends that you change down to a lower gear Operation via the multifunction steering wheel ▶ On vehicles with a manual gearbox, the recommended gear and an ar- row symbol is displayed (e.g.   means that it is advantageous to change up from a lower gear to 4.

  • Page 45: Multifunction Display (Mfd)

    ® AdBlue range - drive distance in km which can be covered with the existing Multifunction display (MFD) ® AdBlue tank capacity and with the same driving style. If you drive more effi- ciently this value can increase.  Introduction Distance driven - distance driven since the memory was last cleared.

  • Page 46: Maxi Dot Display

    Memory MAXI DOT display  Introduction Fig. 26 Multi-function display - memory display This chapter contains information on the following subjects: Menu itemNavigation Menu itemAudio Menu itemPhone Menu itemAssistants Menu item Settings The MAXI DOT display is a user interface which, depending on the equipment The system stores data from the two memories described below, which are configuration, provides information about the Infotainment, the multifunction then displayed at position...
  • Page 47 Language Setting the language for the texts shown on the display. Menu itemAudio MFD dataSwitching on/off certain information of the multifunction display. The following information is displayed in the Audio menu item. Comfort-Turn on / off or adjust the following functions. Radio ▶...

  • Page 48: Service Interval Display

    Information regarding the service intervals » page 135. Activate/deactivate the travel mode fea- Travel mode ture» page Prompt in the MAXI DOT display Resetting Lights & Visionmenu item to the factory set- Factory setting. ting. Messages before reaching the scheduled service date Before the next service date has been reached, the symbol as well as a mes- Coasting -Enable / disable the idle position (coasting) for vehicles with automat- sage about the mileage or days until the next service event appears in the dis-...

  • Page 49: Smartgate

    For vehicles with variable service intervals, after resetting the oil change serv- ice display in a specialist garage, the values of the new service interval are dis- http://go.skoda.eu/connectivity-smartgate played, which are based on the previous operating conditions of the vehicle.
  • Page 50 Automatic connection connection to SmartGate using Wi-Fi If the communication device has already had a connection with SmartGate, This type of connection is intended for external devices running Android and then the connection is automatically restored under the following conditions. iOS operating systems.

  • Page 51: Unlocking And Opening

    SmartGate web interface Unlocking and opening SmartGate parameters can be set in the SmartGate web interface. Unlocking and locking The following address must be entered in the web browser of the external de-  Introduction vice that is connected with SmartGate. HTTP://192.168.123.1 This chapter contains information on the following subjects: The setting changes are only effective after tapping the buttons “Save”...

  • Page 52: Unlocking/Locking With The Remote Control Key

    WARNING Unlocking/locking with the remote control key Never leave the key in the vehicle when you exit the vehicle. Unauthor- ■ ised persons (e.g. children) could lock the car, turn on the ignition or start Fig. 30 the engine - There is risk of injury and accidents! Key with pop-out key bit When leaving the vehicle, never leave people who are not completely in- ■...

  • Page 53: Unlocking/Locking - Kessy

    If the boot lid is closed after locking the vehicle and the key with which the Unlocking/locking - KESSY vehicle was locked remains in the luggage compartment, the lid is automatical- ly unlatched (partially opened). After automatically unlocking, the turn signal lights will flash four times.

  • Page 54: Safelock

    All doors SafeLock The function allows you to unlock all doors, the boot lid and the fuel filler flap.  Read and observe on page 50 first. Single door The function allows you to unlock only the driver's door and the fuel filler flap SafeLock prevents opening the doors from inside as well as window operation.

  • Page 55: Anti-Theft Alarm System

    › To open from the inside pull the door opening lever and push the door Malfunctions away from you. ›  To the lock from the inside, grab the handle and close the door. Read and observe on page 50 first. WARNING Synchronise remote If the buttons on the remote control key have been depressed several times...

  • Page 56: Luggage Compartment Lid

     Read and observe on page 54 first. CAUTION Before leaving the vehicle, it must be checked that all of the windows, doors The interior monitor detects movements inside the locked vehicle and then and the sliding/tilting roof are locked in order to ensure the full functionality of triggers the alarm.

  • Page 57: Window Operation

    Opening / closing the boot lid Window operation  Introduction This chapter contains information on the following subjects: Mechanical windows Electric window Opening the windows in the front passenger door and in the rear doors Force limiter Window convenience operation Operational faults Fig.

  • Page 58: Read And Observe On Page 54 First

    Right rear door Mechanical windows Deactivate/activate the buttons in the rear doors (the deactivation may be advantageous if, for example, children are transported on the rear seats) › To open, lightly press the appropriate button and hold it until the window has moved into the desired position.

  • Page 59: Force Limiter

    › › or: press the buttonunderneath to the stop, the window automatically opens OrSwitch off the ignition, open the driver's door and hold the key until it fully. Renewed pressing of the button causes the window to stop. stops in the open position »...

  • Page 60: Panorama Sliding/Tilting Roof

    Panorama sliding/tilting roof Operation  Introduction This chapter contains information on the following subjects: Operation Force limiter Convenience operation of sliding / tilting roof Activate operation of the tilt / slide sunroof Sunshade with electric operation Activating operation of the sunshade Fig.
  • Page 61 WARNING Sunshade with electric operation If the tilt / slide sunroof is closed, by pulling on the recess of the switch in the direction of arrow » Fig. 40 on page 58 and the closing process is Fig. 41 hindered by an obstacle, then at the third attempt at closing, the force limi- Button for operating the sun- tation will cease to function (if less than 5 s passes between the individual shade...

  • Page 62: Lights And Visibility

    Lights and visibility Operating the lights Lights Fig. 42 Light switch and control dial for  Introduction the headlight beam range regu- lation This chapter contains information on the following subjects: Operating the lights Daylight running lights (DAY LIGHT) Turn signal and main beam Automatic driving light control ...

  • Page 63: Daylight Running Lights (Day Light)

    Note Turn signal and main beam If, with a low beam, the ignition is turned off, then the dipped beam will au- ■ tomatically switch off and the parking lights illuminate. The parking lights are Fig. 43 switched off when the ignition key is removed (for vehicles with the KESSY Operating lever: Turn signal and system, after opening the driver's door).

  • Page 64: Automatic Driving Light Control

    WARNING Automatic driving light control If there is a system malfunction the headlights are automatically lowered to the emergency position, which prevents a possible dazzling of oncoming Fig. 44 traffic. This reduces the cone of light in front of the vehicle. Seek help from Light switch: AUTO position a specialist garage.

  • Page 65: Fog Lights With The Corner Function

    Fog lights with the CORNER function Hazard warning light system  Read and observe on page 60 first. Fig. 46 Button for hazard warning light The CORNER function automatically switches on the fog lights on the respec- system tive side of the vehicle (e.g. when cornering), if the following conditions are ful- filled.

  • Page 66: Interior Lighting

    Switching on the side light on both sides  Front interior light › Switch on the ignition and turn the light switch to position» page 60, the parking lights are turned on. › Switch off the ignition and lock the car. After pulling out the ignition key and opening the driver's door, an audible warning sounds.

  • Page 67: Visibility

    Interior lighting, rear Windscreen and rear window heating Fig. 48 Interior lights at the rear Operation (by moving the lens » Fig. 48 Fig. 49 Button for the rear and front window heating: manual air condi- Switching on  tioning / Climatronic Automatic operation (centre position) ...

  • Page 68: Windscreen Wipers And Washers

    Front sun visors Windscreen wipers and washers  Introduction This chapter contains information on the following subjects: Windscreen wipers and washers Rear windscreen wipers and washers Headlight cleaning system The windscreen wipers and the wash system only operate if the ignition is switched on and the bonnet and boot are closed WARNING Do not use the windscreen washer system at low temperatures, without...
  • Page 69 Note WARNING Each time the ignition switches off for the third time, the position of the Automatic wiping during rain is only a support. The driver is not released ■ windscreen wipers changes. This counteracts an early fatigue of the wiper rub- from the responsibility to set the function of the windscreen wipers man- bers.

  • Page 70: Rear View Mirror

    Headlight cleaning system Interior mirror dimming  Read and observe on page 66 first. The headlights are cleaned with every first and after every fifth spraying of the windscreen under the following conditions. The ignition is switched on.  The low beam is switched on. ...
  • Page 71 Manual folding mirrors Mirrors The mirror can be manually folded in towards the side window. To put it back into its original position, it should be folded back from the side window until it Fig. 54 audibly clicks into place. Exterior mirror operation Folding-in both of the exterior mirrors using the remote control key ›...

  • Page 72: Seats And Head Restraints

    CAUTION Seats and head restraints Never manually fold in/out the electrically folding exterior mirrors - there is a ■ risk of damage to the mirror! Front seats When the mirror is swung by external influences (due to impact during ma- ■...

  • Page 73: Electrical Adjustment

    Adjusting the tilt of the backrest (do not lean on the backrest when ad- Note justing) If the inclination angle of the seat backrest relative to the seat surface is Setting the extent of the curvature of the lumbar support greater than 102 °, then it is not possible for safety reasons to save this setting in the memory of the electrically adjustable seats or the remote control key.

  • Page 74: Memory Function Of The Remote Control Key

    Retrieving the saved setting Deactivating the function › The retrieval is possible when turned the ignition is switched on and the vehi- Unlock the vehicle with the remote control key. › cle speed is less than 5 km/h or when the ignition key is inserted in the igni- Press and hold down the ...

  • Page 75: Rear Seats

    Folding the seat backrest forwards and folding the seat fully forwards WARNING (Continued) Unlock and removing the seat Do not adjust the seat back while driving - There is a risk of injury and ac- ■ Adjusting seats in crosswise direction cidents! When moving the seat backrest, keep limbs out of the area between the Folding back seats...
  • Page 76 › Secure the folded forward seat with the aid of the fixing belt B to a guide rod Folding the seat backrest forwards and folding the seat fully of the head restraint in the front seat » Fig. forwards WARNING The seat backs in occupied rear seats must be properly engaged.

  • Page 77: Headrests

    › Press the lever in direction of arrow » Fig. 66 and fold back the seat back- Note rest in the direction of arrow Check this by pulling on the seat backrest. The outer seats are not mutually interchangeable. In the rear area the left seat is marked with the letter L and the right seat with the letter R.

  • Page 78: Front Seat Heating

    The seat heating only operates when the engine is running. Removing/installing WARNING If you are sensitive to pain and/or temperature, e.g. through medication, paralysis or because of chronic illness (e.g. diabetes), we recommend not to use the seat heating. If the seat heating is used, we recommend to make regular breaks in your journey when driving long distances, so that the body can recuperate from the stress of the journey.

  • Page 79: Useful Features

    WARNING (Continued) Useful features Do not carry any objects on the front passenger seat except objects de- ■ signed for this purpose (e.g. child seats) – risk of accident! Interior fittings No objects should be placed in the storage compartments nor in the ■...

  • Page 80: Storage Compartment On The Dash Panel

     Read and observe on page 77 first. Storage compartment on the dash panel Storage compartments » Fig. 72 Fig. 71 Storage compartment Opening the storage compart- Bottle holder with a capacity of max. 1 l ment Bottle holder with a capacity of max. 0.5 l WARNING The storage compartment »...

  • Page 81: Usb And Aux Input

    USB and AUX input Cup holders Fig. 74 AUX input: underneath the armrest / above the storage compart- Fig. 76 Cup holders: in the front centre console / on the folding table in ment the centre backrest Fig. 75 USB input ...

  • Page 82: Cigarette Lighter

    WARNING Ashtray Do not use any cups or beakers which are made of brittle material (e.g. ■ glass, porcelain). This could lead to injuries in the event of an accident. Never put hot beverage containers in the cup holder. If the vehicle moves, ■...

  • Page 83: 12-Volt Socket

    › To removeGrasp the ashtray at handle and remove in direction of arrow WARNING Do not place anything on the dashboard. These objects might slide or fall ■ › To use Insert the ashtray in the console away from arrow and push in.

  • Page 84: Multimedia Holder

    Multimedia holder Fig. 84 Multimedia holder Fig. 83 Replacing bags  Read and observe on page 77 first.  Read and observe on page 77 first. Multimedia holder » Fig. 84 The waste container can be inserted into the slot in the door. Storage compartment for storing two coins Insert waste container Storage compartment for storing the vehicle key...

  • Page 85: Storage Net In The Front Centre Console

    ›  To close, turn the dial away from arrow until the stop. Read and observe on page 77 first. When the air inlet is opened, the air flows into the storage compartment with › To open, press the -- button. The compartment folds in the direction of the a temperature corresponding to the control dial settings on the A/C unit, de- arrow »...

  • Page 86: Storage Compartment Under The Front Passenger Seat

    WARNING Storage compartment under the front passenger seat Never leave any heavy or sharp-edged objects in the pockets of the items ■ of clothing hung up - There is a risk of injury. Fig. 89 Do not use hangers to hang up the clothes - there is a risk of restricting ■...

  • Page 87: Folding Table On The Front Seat Backrest

    › To close, swivel the compartment against the direction of the arrow. Folding table on the middle seat backrest CAUTION Fig. 94 Before folding forward the rear centre seat, the storage compartment must be Middle seat backrest already fol- closed - there is a risk of damage to the storage compartment. ded forward Folding table on the front seat backrest Fig.

  • Page 88: Tablet Holder

    › Place the empty through-loading bag in such a way that the end of the bag Attaching the rear headrests with the zip is in the boot. › Push the skis and poles with the tips backwards into the through-loading bag and secure the bag.

  • Page 89: Transport Of Cargo

    Handle holder Transport of cargo Luggage Storage and Transport  Introduction This chapter contains information on the following subjects: Fastening elements Fixing nets Multifunction pocket Fastening bar with sliding hook Flexible storage compartment Fig. 98 Tilt and rotate holder Floor covering on both sides Luggage compartment cover Fig.

  • Page 90: Fastening Elements

     Read and observe on page 88 first. WARNING Never exceed the maximum permissible load of the respective fasteners, ■ The fasteners are located on both sides of the luggage compartment. nets, hooks etc. If heavy objects have not been suitably secured, there is a Overview of the fastening elements »...

  • Page 91: Multifunction Pocket

     Read and observe on page 88 first. Multifunction pocket A fastening bar is located on both sides of the luggage compartment with two Fig. 102 moveable hooks each, in order to attach small items of luggage, such as bags, Securing the multifunction pock- etc.

  • Page 92: Floor Covering On Both Sides

    › › To use,insert the two ends of the storage compartment into the openings in Place the cover in the horizontal position. › the side trim of the luggage compartment and push the shelf down to lock. Press on the two sides to the underside of the cover in the region of the ›...

  • Page 93: Net Partition

    Installing and removing the net partition behind the rear seats with variable Net partition loading floor is carried out in the same way as behind the rear seats without variable loading floor. Use the lower fixing eyelets on the carrier rails in order to attach the carabines.

  • Page 94: Removable Storage Box

    Removable storage box Fig. 108 Storage box Fig. 110 Removable light: Removing / Inserting  Read and observe on page 88 first.  Read and observe on page 88 first. The storage box » Fig. 108 is placed under the variable loading floor and can be The light is located on the right side of the luggage compartment and is used taken out.

  • Page 95: Variable Loading Floor In The Luggage Compartment (Estate)

    Lamp charges Removing/fitting variable loading floor The lamp is supplied by three rechargeable type NiMH AAA batteries. The bat- teries are charged continuously with the engine running (to fully charge the battery takes approximately 3 hours). Replace batteries » page 166.

  • Page 96: Transportation On The Roof Rack

    The sides of the variable loading floor can be folded in the direction of arrow Removing/installing the carrier rails » Fig. 114 - . The room under the variable loading floor » Fig. 114 -  can be used to stow the load.

  • Page 97: Heating And Ventilation

    WARNING Heating and ventilation The blower should always be on to prevent the windows from misting. ■ Otherwise there is a risk of accident. Heating, manual air conditioning system, Climatronic Under certain circumstances, air at a temperature of about 5 °C can flow ■...
  • Page 98 Aux. heating and ventilation on / switch off » page 99 Adjust the blower speed   ▶  Increase speed Switch recirculation on/off » page 97  ▶  Decrease speed When the function is switched on, the indicator light in the button lights up. Switching the airflow to the windscreen on and off ...
  • Page 99 Controlling blower Air distribution control The Climatronic system controls the blower stages automatically in line with  the interior temperature. However, the blower stages can be manually adap- Read and observe on page 95 first. ted to suit your particular needs. The recirculation mode prevents contaminated outside air getting into the in- If the blower speed is reduced to a minimum, Climatronic is switched off.

  • Page 100: Auxiliary Heating (Auxiliary Heating And Ventilation)

     Read and observe on page 95 first. CAUTION We recommend not smoking in the vehicle when the recirculating air operation The direction of airflow can be adjusted using the air outlet vents 3, 4 » Fig. 117 is switched on. The smoke sucked from the interior is deposited on the evapo- and 6 »...
  • Page 101 The aux. heating heats the vehicle interior as well as the engine. For heating, Switch on / off fuel is consumed from the fuel tank. The auxiliary ventilation enables fresh air to flow into the vehicle interior with the engine switched off, whereby the interior temperature is effectively de- creased (e.g.
  • Page 102 System settings Remote control  Read and observe on page 99 first. Fig. 120 Radio remote control The following menu items can be selected from the Aux. heating menu item in the MAXI DOT display (depending on the vehicle equipment). Day of the wk.
  • Page 103 Display warning light Meaning The battery is weak, however the Lights up orange for 2 seconds, then switching on or off signal was re- green or red. ceived. The battery is weak, however the Lights up orange for 2 seconds, then switching on or off signal was not re- flashes green or red.

  • Page 104: Driving

    Note Driving Do not warm up the engine while the vehicle is stationary. If possible, start your journey as soon as the engine has started. Through this, the engine rea- Starting-off and Driving ches its operating temperature faster. Starting and stopping the engine Electronic immobiliser and steering lock ...
  • Page 105 Starting engine Switch on/off ignition › On vehicles with ignition lock, turn the key to position and the engine starts» Fig. 121 on page 103 . Then release the key, the engine will start au- tomatically. If the engine does not start within 10 seconds, turn the key to position .

  • Page 106: Start-Stopsystem

    The START STOPsystem (hereinafter referred to as the system) reduces Note emissions and harmful emissions, and saves fuel. The engine running noises may be louder at first for a short time after start- ■ ing the cold engine. If the system determine that the engine is not needed when the vehicle stops You should not switch on any major electrical components during the heat- ■...

  • Page 107: Brakes And Parking

    Requirements for the system to function correctly Note The following conditions must be met for the system to function correctly. If the driver's seat belt is removed for more than 30 seconds or the driver's ■ The driver's door is closed. ...
  • Page 108 The wear and tear on the brake pads is dependent on the operating condi- WARNING (Continued) tions and driving style. In difficult conditions (e.g. urban, sporty driving), the Do not depress the brake pedal if there is no requirement to slow down. ■...

  • Page 109: Manual Gear Changing And Pedals

    A warning signal sounds if the vehicle is inadvertently driven off with the Manual gear changing and pedals handbrake applied. The handbrake warning is activated if the vehicle is driven at a speed of over 5 km/h for more than 3 seconds. ...

  • Page 110: Automatic Transmission

    CAUTION WARNING (Continued) If not in the process of changing gear, do not leave your hand on the gearshift If the vehicle stalls, with engine running, in the D, S, R or Tiptronic mode, ■ lever while driving. The pressure from the hand can cause the gearshift mech- the vehicle must be prevented from rolling away by means of the brake anism to wear excessively.
  • Page 111 Driving forwards - In mode D, the forward gears are automatically Note changed according to the engine load, accelerator pedal actuation and To switch the selector lever from mode P to mode D/S or vice versa, move the driving speed selector lever quickly.

  • Page 112: Running In And Economical Driving

    Starting-off and driving Running in and economical driving  Read and observe on page 108 first.  Introduction Moving off and pausing temporarily This chapter contains information on the following subjects: › Firmly depress and hold the brake pedal. Running in the engine ›...

  • Page 113: Avoiding Damage To Your Vehicle

    Avoiding damage to your vehicle Driving through water  Introduction Fig. 130 Maximum permissible water lev- This chapter contains information on the following subjects: el when driving through water Driving Tips Driving through water Driving Tips Only drive on roads and terrain that are appropriate to the vehicle parameters »...

  • Page 114: Assist Systems

    WARNING Assist systems The general information relating to the use of assistance systems must be observed » page 112, in section General information. General information WARNING Stability Control (ESC) The assistance systems only serve to support and do not relieve the driv- ■...
  • Page 115 Traction control (TCS) Electronic Differential Lock (EDL)  Read and observe on page 112 first. EDL prevents the turning of the respective wheel of the driven axle. EDL brakes a spinning wheel if required and transfers the drive power force to the other drive wheel.

  • Page 116: Off Road Mode

    The HHC is active on gradients upwards up 5% if the driver door is closed. HHC WARNING is only ever active on slopes when in forward or reverse start off. The general information relating to the use of assistance systems must ■...
  • Page 117 The following functions are integrated in the OFF ROAD mode. By pressing the accelerator or brake pedal, the speed can be increased or re- ▶ Downhill Drive Support » page 115. duced. This is true even if the shift lever is in the neutral position and the se- ▶...

  • Page 118: Parking Aid (Parkpilot)

    The system is only available, if the front wheels are in the straight-ahead posi- WARNING (Continued) tion. External noise sources may affect the signals of the system sensors. ■ There is a danger that obstacles may not be recognised by the system sen- The system operates at speeds of up to 50 km/h.
  • Page 119 Note Fig. 134 If with Version 3 vehicles not all fields around the vehicle are active after ac- ■ Sampled areas and range of the tivation the vehicle should be moved forwards or backwards. sensors The signal tones for front obstacle recognition are factory-set to be higher ■...

  • Page 120: Reversing Camera

    Activation / deactivation Reversing camera  Introduction Fig. 136 System key (option 2, 3) This chapter contains information on the following subjects: Operation Guidelines and function keys The rear view camera (hereinafter referred to as system) helps the driver when parking and manoeuvring by displaying the area behind the vehicle in the Info- tainment display (hereinafter referred to as display).
  • Page 121 Operation Guidelines and function keys Fig. 137 Installation location of the camera / scanned area behind the ve- Fig. 138 Infotainment display: Orientation lines / functional interfaces hicle  Read and observe on page 118 first.  Read and observe on page 118 first.

  • Page 122: Park Assist

    CAUTION WARNING The objects shown in the display can be closer or even further away than they The general information relating to the use of assistance systems must ■ appear. This is especially the case in the following situations. be observed »...
  • Page 123 ▶ The display shows instructions and information before the start and during Parking space search the parking. ▶ Based on the calculated road surface, the front wheels will be automatically rotated during the parking. Conditions for the system function The system can look for a parking space only if the following basic conditions are met.
  • Page 124 › Depress the brake pedal and wait until the steering wheel automatically ro- Parking tates into the required position, the symbol  goes out. › Carefully drive forwards. › If the backwards arrow is flashing in the display - , select reverse gear again or move the selector lever into position R.

  • Page 125: Cruise Control System

    The Cruise Control System (CCS) maintains a set speed without you having to Automatic brake assist actuate the accelerator pedal. The state where the CCS maintains the speed is  Read and observe on page 120 first. referred to hereinafter as the control. Automatic brake assist when speeding WARNING If a velocity of 7 km / h is exceeded during the parking manoeuvre for the first...

  • Page 126: Fatigue Detection

    Note Operation description During control, speed can be increased by pressing the accelerator pedal. Re- leasing the accelerator pedal will cause the speed to drop again to the set Fig. 141 speed. Cruise control system controls Fatigue detection The fatigue detection system (hereinafter referred to as system) recommends the driver takes a break from driving when driver fatigue can be detected due to the driver's steering behaviour.

  • Page 127: Tyre Pressure Monitoring

    Note WARNING In some situations, the system may evaluate the driving incorrectly and thus The general information relating to the use of assistance systems must ■ ■ mistakenly recommend a break (e.g. sporty driving, adverse weather condi- be observed » page 112, in section General information.

  • Page 128: Towing Device And Trailer

    Towing device and trailer Description Hitch  Introduction This chapter contains information on the following subjects: Description Setting the ready position Check the setting of the standby position Assemble the ball rod Check proper mounting Fig. 143 Carrier for the towing device/tow bar Removing ball rod - Step 1 Removing ball rod - Step 2 ...
  • Page 129  Read and observe on page 126 first. Setting the ready position Correctly adjusted standby position » Fig. 145 The locking balls can be pushed fully into the tow bar.  The red marking on the hand wheel is located in the green box on the ...
  • Page 130 Check proper mounting Fig. 148 Correctly secured ball head Fig. 147 Locking the lock and removing the key/replacing the lock cap  Read and observe on page 126 first.  Read and observe on page 126 first. Correctly secured ball rod »...
  • Page 131 › Remover the cover from the handwheel lock in the direction of the arrow The ball rod must be cleaned before storing in the box with the vehicle tool » Fig. 149. always. › Insert the key into the handwheel lock. ›...

  • Page 132: Using The Towing Device

    Power supply of the trailer / accessory power system Note In the electrical connection between the vehicle and trailer (accessory), the We recommend that you use accessories from ŠKODA Original Accessories. trailer (accessories) is supplied with power from the vehicle (with ignition switched on and off).
  • Page 133 Trailer The permissible trailer load must not be exceeded under any circumstances. Permissible trailer load Permissible trailer load, braked (kg) Engine Transmission Permissible trailer load, unbraked (kg) Gradients of up to 12% Gradients of up to 8% 1200 1500 1.2 ltr./81 kW TSI 1200 1500 1300...
  • Page 134 Brakes Apply the brakes in good time! If the trailer is fitted with a trailer brake, apply the brakes gently at first, then brake firmly. This will avoid brake jolts resulting from the trailer wheels locking. On downhill sections shift down a gear in good time to also use the engine as a brake.

  • Page 135: General Maintenance

    General Maintenance Vehicle operating under different weather conditions  Read and observe on page 133 first. Care and maintenance If you would like to operate your vehicle in countries other than those with its Service work, adjustments and technical alterations intended weather conditions, you should contact a ŠKODA Partner.
  • Page 136 ŠKODA Original parts Spoiler   Read and observe on page 133 first. Read and observe on page 133 first. We recommend the use of ŠKODA Genuine Parts for your vehicle, as these WARNING parts are approved by ŠKODA AUTO. These parts comply wholly with ŠKODA If your vehicle is equipped with a Genuine Accessories spoiler on the front AUTO regulations and are identical to the parts used in series production.

  • Page 137: Service Intervals

    The completion of services can be verified through the printed verification WARNING from the digital service schedule and the respective receipts. No changes may be made to airbag system components, the front bump- ■ er and the bodywork. The specified service intervals are tailored to normal operating conditions. Any work on the airbag system including the installation and removal of ■...
  • Page 138 Inspection After the first 30 000 km or 2 years , then every Overview of service intervals Variant 1 30 000 km or every 1 year Inspection Fig. 153 QI1 - QI4 Every 15 000 km or every 1 year Variant 2 Vehicle data: Service Interval Inspection...

  • Page 139: Cleaning And Care

    WARNING WARNING The brake fluid must always be changed after the first 3 years and then ev- Vehicle care products may be harmful to your health if not used according ■ ery 2 years. Longer intervals between changing the brake fluid can cause to the instructions.
  • Page 140 If your vehicle is fitted with any particular attached parts (e.g. spoiler, roof rack Exterior car care system, aerial etc.) it is best to consult the operator of the car wash system be-  forehand. Read and observe on page 137 first. After an automatic wash with wax treatment, the wiper blades should be Vehicle compo- cleaned with cleaning agents specially designed for the purpose, and then de-...
  • Page 141 The towing device is maintenance-free. Coat the ball head of the towing de- Rubber seals ■ vice with a suitable grease whenever necessary. Do not treat the door seals and window guides deal with anything - the ■ protective varnish coating could be damaged. Protection of cavities Windows and door mirrors ■...
  • Page 142 CAUTION Caring for the interior ® Natural leather / leather / Alcantara / material ■  Read and observe on page 137 first. Avoid standing for lengthy periods in bright sunlight, and protect the mate- ■ rials by covering to prevent them from fading. Vehicle compo- Remove fresh stains (e.g.

  • Page 143: Inspecting And Replenishing

    Inspecting and replenishing Petrol and diesel refuelling Fuel  Introduction Fig. 154 Stickers showing the prescribed fuel Fig. 155 Open fuel filler flap / unscrew tank cap / place the tank cap on the fuel filler flap  Read and observe on page 141 first.
  • Page 144 Lower than 91 octane petrol should not be used, even in an emergency! ■ Unleaded petrol If a fuel other than unleaded fuel which complies to the above mentioned ■  Read and observe on page 141 first. standards (e.g. leaded petrol) is put in the tank by mistake, do not start the en- gine or switch on the ignition.

  • Page 145: Adblue ® And Its Refilling

    Operating under different weather conditions WARNING Use only diesel in accordance with the current or expected weather conditions. ® AdBlue can cause skin, eye and respiratory irritation. If your eyes or skin Ask the petrol station personnel whether the diesel fuel offered corresponds ®...

  • Page 146: Engine Compartment

    Refilling ® AdBlue refill › Fold up the flooring in the luggage compartment in the arrow direction » Fig. 156. › Remove the box for the vehicle tools in the direction of arrow › Open the filler cap in the direction of the arrow »...
  • Page 147 WARNING (Continued) Opening and closing the bonnet Firmly apply the handbrake. ■ For vehicles with manual transmission the lever into the neutral position. ■ For vehicles with automatic transmission, place the selector lever in the P position. Allow the engine to cool. ■...

  • Page 148: Engine Oil

     Read and observe on page 144 first. Engine compartment overview The windscreen washer fluid reservoir is located in the engine compart- ment » Fig. 160. The capacity of the reservoir A is about 3 litres or about 5.5 litres on vehicles that have a headlight cleaning system Use a suitable windscreen washer fluid for the current or expected weather conditions.
  • Page 149 WARNING CAUTION The following instructions must be followed at all times when working on If no prescribed engine oil is available, then max. 0.5 l oil of the following ■ the engine compartment » page 144. specifications can be refilled. Petrol engines: ACEA A3/ACEA B4 or API SN, (API SM);...

  • Page 150: Coolant

    CAUTION CAUTION The oil level must never be below range » Fig. 161 – risk of damage to the Do not cover the radiator and install any parts (e.g auxiliary lights.) in front of ■ engine as well as to the exhaust system. the air intakes - There is a risk of the engine overheating.

  • Page 151: Brake Fluid

    Specification - the brake fluid must comply with the standard VW 501 14 (this CAUTION standard meets the requirements of FMVSS 116 DOT4). If the expansion tank is empty, do not top up with coolant. The system could ■ aerate - There is a risk of engine damage! Stop driving! Switch off the en- ...
  • Page 152 Warning symbols on the vehicle battery CAUTION Symbol Meaning Ensure that battery acid does not come into contact with the bodywork – There is a risk of damage to the paintwork.  Always wear eye protection. Note Battery acid is severely caustic. Always wear gloves and eye pro- ...
  • Page 153 Battery discharge Disconnect/reconnect and change If frequent short journeys are made, the vehicle battery does not recharge suf-  ficiently. Read and observe on page 150 first. The battery capacity decreases at low temperatures. The new vehicle battery must have the same capacity, voltage, current and the same size as the original Battery.

  • Page 154: Wheels

    The specified running direction must be strictly adhered to, otherwise the fol- Wheels lowing tyre characteristics may be degraded. ▶ Driving stability. Wheels and tyres ▶ Traction. ▶ Tyre noise and tyre wear. Advice on tyre/wheel usage WARNING During the first 500 km, new tyres do not offer optimum grip; appropriate care Never use tyres if you do not know anything about their condition and ■...
  • Page 155 The prescribed tyre inflation is on the sticker with pictograms » Fig. 165 (for Tyre wear and wheel change some countries, the pictograms are replaced with a text). Tyre pressure is always to match the load. Inflation pressure for half load Inflation pressure for environmentally friendly operation (slightly lower fuel consumption and emissions) Inflation pressure for full load...

  • Page 156: Operating In Winter Conditions

    Speed symbol - indicates the maximum permissible speed for a vehicle fitted Spare wheel with tyres in a given category Only use this emergency spare wheel to reach the nearest specialist garage, as Speed it is not intended for permanent use. symbol A warning label is always placed on the rim of the temporary spare wheel.
  • Page 157 place in the driver's field of vision. If necessary, the maximum value of the WARNING mounted tire speed rating must be adjusted in the MAXI DOTDisplay in the Do not use chains on snow and ice-free routes - the handling would be im- menu item winter tires paired and there is a risk of damage to the tyres.

  • Page 158: Do-It-Yourself

    WARNING Do-it-yourself Properly secure the first aid kit and the warning triangle - there is a risk of injury in the event of sudden braking or a vehicle collision. Emergency equipment and self-help Emergency equipment Location of reflective vest  Introduction Fig.

  • Page 159: Changing A Wheel

    WARNING WARNING Always properly secure the fire extinguisher - there is a risk of injury in the The factory-supplied lifting jack is only intended for your model of vehicle. ■ event of sudden braking or a vehicle collision. Under no circumstances attempt to lift other vehicles or loads with it – there is a risk of injury.
  • Page 160 › Jack up the vehicle until the wheel that needs changing is clear of the ground WARNING » page 160. Tightening torque which is too high can damage the threads and this can › Unscrew the wheel bolts and place them on a clean surface (cloth, paper, result in permanent deformation of the contact surfaces on the rim.
  • Page 161 Install trim Anti-theft wheel bolts › Press the wheel trim onto the wheel rim at the designated valve opening. › Then press the trim into the wheel rim until its entire circumference locks Fig. 173 correctly in place. Anti-theft wheel bolt and attach- The position of the anti-theft wheel bolt is indicated by means of a symbol on ment the back of the wheel trim supplied ex-factory or from the ŠKODA Original Ac-...
  • Page 162 Loosening/tightening wheel bolts Fig. 174 Loosening the wheel bolts Fig. 176 Attach lifting jack › Insert the wheel wrench onto the wheel bolt to the stop. Use the associated Before the vehicle is raised, please take note of the safety instructions »...

  • Page 163: Breakdown Kit

    CAUTION Description of the breakdown kit It is important to ensure that the jack is correctly positioned against the bar of the lower beam - otherwise there is a risk of damage to the vehicle. Breakdown kit  Introduction This chapter contains information on the following subjects: Description of the breakdown kit Preparing to use the breakdown kit Sealing and inflating tyres...
  • Page 164 › For vehicles with manual transmission, set the lever in the neutral position. Preparing to use the breakdown kit › On vehicles with automatic transmission, place the selector lever in the P  Read and observe on page 161 first. position.

  • Page 165: Jump-Starting

    If the tyre inflation pressure is 1.3 bar or more Jump-starting using the battery from another vehicle › Set the tyre pressure back to the correct value » page 152. › Continue driving carefully to the nearest specialist garage at a maximum speed of 80 km/h (50 mph).

  • Page 166: Towing The Vehicle

    The maximum towing speed is 50 km/h. WARNING  The vehicle must be transported on a special breakdown vehicle or trailer Never clamp the jump cable to the negative terminal of the discharged  ■ if it is not possible to tow in the vehicle in the way described or if the tow- battery -There is a risk of an explosion.
  • Page 167 Front towing eye Towing eye rear Fig. 180 Remove cap / install towing eye Fig. 181 Remove cap / install towing eye Cap removal/fitting Cap removal/fitting › › To remove, press down on the cap in the direction of arrow and remove it To remove, press down on the cap in the direction of arrow and remove it...

  • Page 168: Remote Control And Removable Light - Replacing The Battery/Batteries

    › Remove the discharged battery in the direction of arrow and install a new Remote control and removable light - replacing the battery. battery/batteries › Insert the battery cover and press it down until it clicks audibly into place.  Introduction Remote control of the auxiliary heating This chapter contains information on the following subjects:...

  • Page 169: Emergency Unlocking / Unlocking Of Doors

    › Lever off the cover for the rechargeable batteries with a narrow and pointed CAUTION object from the area of the lock clips Make sure you do not damage the paint when performing an emergency lock- › Replace the batteries. ing/unlocking.

  • Page 170: Replacing Windscreen Wiper Blades

    Selector lever-emergency unlocking Replacing the windscreen wiper blades Fig. 189 Setting the service position for the wiper arms Fig. 188 Remove / release the selector lever › Firmly apply the handbrake. › Insert a slot screwdriver or similar tool into the gap in the arrow area »...

  • Page 171: Fuses And Light Bulbs

    Attaching the windscreen wiper blade Fuses and light bulbs › Slide the windscreen wiper blade in the opposite direction to arrow until it locks into place. Check that the windscreen wiper blade is correctly attached. Fuses › Fold the windscreen wiper arm back to the windscreen. ›...

  • Page 172: Fuses In The Dashboard

     Read and observe on page 169 first. Fuses in the dashboard Consumer Fig. 193 Heating of the gearbox vent (diesel engine) Distribution board cover. Automatic gearbox Towing hitch - left light Trailer device - electrical outlet Instrument cluster control lever under the steering wheel, camera Air blower for heating, radiator fan, air conditioning system, Clima- tronic Rear window wiper...

  • Page 173: Fuses In The Engine Compartment

    CAUTION Consumer The cover of the fuse box in the engine compartment must always be used Panoramic tilt / slide sunroof, electric operation of sun blinds correctly, otherwise water may penetrate into the fuse box – there is a risk of ®...

  • Page 174: Bulbs

    ▶ Switch off the ignition and all of the lights before replacing a bulb. Consumer ▶ Faulty bulbs must only be replaced with the same type of bulbs. The designa- Music amplifier tion is located on the light socket or the glass bulb. Windscreen wipers We recommend having the headlight settings checked by a specialist garage Control valve for fuel pressure, high pressure pump...
  • Page 175 › Remove the connector to the bulb in the direction of arrow Bulb arrangement in the front headlights › Remove the connector. › Insert the connector with the new bulb so that the fixing lug fits on the Fig. 197 bulb»...
  • Page 176 Protective grille for removing fog lights- plug for Park Assist Changing light bulbs for fog lights sensor Fig. 202 Remove the number plate light / replace the bulb Fig. 200 Guard: Version 1/version 2  Read and observe on page 172 first. First remove the grille for the fog lights and before changing bulbs »...
  • Page 177 CAUTION Removing/installing taillights For vehicles with parking assistance, we recommend that after changing the light bulb in the fog lights, the system is checked by a specialist. Changing the bulb for the licence plate light Fig. 204 Remove light / pull out connector ...
  • Page 178 Light with LED diodes Replacing the bulbs in the taillight assembly › Unlock the bulb holder using the locking latches in the areas » Fig. 206 marked with arrows and remove the bulb holder from the light. › Turn the respective light bulb »...

  • Page 179: Technical Data

    Technical data Vehicle data Technical data Basic vehicle data  Introduction This chapter contains information on the following subjects: Vehicle data Operating weight Payload Fig. 207 Vehicle data sticker/type plate Measurement of fuel consumption and CO emissions according to ECE Vehicle data sticker Regulations and EU Directives The vehicle data sticker...
  • Page 180 Maximum permissible front axle load Operating weight Maximum permissible rear axle load Engine Transmission Operating weight (kg) Vehicle identification number (VIN) 1340 1.2 ltr./81 kW TSI The vehicle identification number - VIN (vehicle body number) is stamped into 1360 the engine compartment on the right hand suspension strut dome. This num- 1355 ber is also located on a sign on the lower left hand edge below the windscreen 1.4 l./92 kW TSI...
  • Page 181 Measurement of fuel consumption and CO emissions according to ECE Regulations and EU Directives The data on fuel consumption and CO emissions were not available at the time of going to press. The data on fuel consumption and CO emissions are given on the ŠKODA websites or in the sales and technical vehicle documentation.
  • Page 182 Dimensions Fig. 208 Vehicle dimensions Vehicle dimensions for operating weight without driver (in mm) » Fig. 208 Specification Yeti Yeti Outdoor Height 1691 Front track 1541 Width 1793 Rear track 1537 Width including exterior mirror 1956 Clearance Wheel base 2578...
  • Page 183 Angle and gradeability Overhang angle, rear Pitch angle / climbing ability The departure angle values indicate the maximum incline of a slope, up which the vehicle can drive at a slow speed without the bumper or underbody mak- ing contact with the slope. The values listed correspond to the maximum axle load, front or back.
  • Page 184 Slope angle (°) / climbing Engine Transmission Front overhang angle (°) Rear overhang angle (°) Ramp angle (°) ability (%) 19.6 41/86 2.0 l./110 kW TDI CR MG 4x4 19.6 39/80 DSG 4x4 19.6 38/77 Applies to vehicles with tyre size 205/55 R 16. Technical data...

  • Page 185: Vehicle-Specific Data Depending On The Engine

    Vehicle-specific data depending on the engine  Introduction This chapter contains information on the following subjects: 1.8 ltr./112 kW TSI engine 2.0 ltr./81 kW TDI CR engine 1.2 ltr. / 81 kW TSI engine 2.0 ltr./103 kW TDI CR engine 1.4 l/92 kW TSI engine 2.0 ltr./110 kW TDI CR engine 1.4 l/110 kW TSI engine...

  • Page 186: 1.4 L/110 Kw Tsi Engine

    1.4 l/110 kW TSI engine Output (kW/rpm) 110 / 5000-6000 Maximum torque (Nm at 1/min) 250 / 1500-3500 Number of cylinders/displacement (cm 4/1395 Transmission MG 4x4 DSG 4x4 Top speed (km/h) Acceleration 0-100 km/h (s) 1.6 l/81 kW MPI engine Output (kW/rpm) 81/5800 Maximum torque (Nm at 1/min)

  • Page 187: 2.0 Ltr./81 Kw Tdi Cr Engine

    2.0 ltr./81 kW TDI CR engine MG (EU4, EU5) 81/4200 Output (kW/rpm) MG (EU6), MG 4x4 81/3500 MG (EU4, EU5) 250 / 1500-2500 Maximum torque (Nm at 1/min) MG (EU6), MG 4x4 250 / 1750-3000 Number of cylinders/displacement (cm 4/1968 Transmission MG (EU4, EU5) MG (EU6)

  • Page 188: Index

    Alarm Belt tensioners Index Trailer Bluetooth All-year tyres See Owner's Manual Infotainment Alternator Bonnet Warning light Closing Operation Opening Anti-lock braking system (ABS) Warning light Boot Anti-theft alarm system Acceptance and recycling of used vehicles Class N1 vehicles Trailer Accessories See boot lid Anti-theft wheel bolts Adaptive headlight...

  • Page 189: Top Speed (Km/H)

    Checking Correct routing of seat belt Battery status Camera Coolant Correct seated position See reversing camera Checks Correct seating position Car battery Statutory checks Cruise control system Check condition Children and safety Warning light Cover Child safety lock Cruise Control System Disconnecting and reconnecting Child seat Cup holders...
  • Page 190 Door Towing the vehicle Child safety lock Towing the vehicle using the trailer device Fastening elements Emergency locking Tyre repair Fatigue detection Emergency locking of the driver's door Unlocking/locking the door Opening/Closing Unlocking / locking the door Films warning light door open Emergency equipment Fire extinguisher Door alarm...
  • Page 191 In an emergency Changing a wheel Gear change Lamp failure incline Gear recommendation Warning light Inertia reel Information on the selected gear Lamps Information about the towing process Gear changing Warning light Information system Gear stick LEAVING HOME Door alarm Genuine parts lever Gear recommendation...
  • Page 192 Lock MAXI DOT display Individual settings Main menu OFF ROAD Menu item assist systems Menu item Audio Locking Menu item navigation Central locking button hill descent assistant Menu item phone in case of emergency operation Operation KESSY Start-Off Assistant Settings Remote control Mechanical window Lock steering lock...
  • Page 193 Parking Replacing Park Assist Bulbs Radio Parking aid Fuses See Owner's Manual Infotainment/Radio Reversing camera Windscreen wiper blades Raising the vehicle Parking aid Rev counter Rear fog light Function Reversing camera Warning light Parking assistance Rims Rear seats Activation / deactivation Roof Display in the Infotainment display Rear view camera...
  • Page 194 Seatbelts SmartGate Steering lock (KESSY system) Inertia reels Connection via Wi-Fi warning light introductory information Seat belts Steering wheel Password/PIN code change Warning light Buttons Setting Correct posture Seat electrical adjustment Wi-Fi direct connection setting Seats SmartLink Stopping Electrical adjustment See Owner's Manual Infotainment See Parking Folding front passenger seat...
  • Page 195 Switch on ignition Trailer stabilization system (TSA) Unlock steering lock Trailer towing Transmission Used vehicles Warning messages Acceptance and recycling transport Useful equipment Table on the front seat backrest Luggage Storage Clothes hook Cup holders on the middle rear seat backrest Transport Glasses compartment Tablet holder...
  • Page 196 Vehicle length unidirectional tyres Winter tyres Vehicle tool kit Wi-Fi Vehicle width See Owner's Manual Infotainment Vest Wi-Fi direct Window Vehicle Identification Number operation Visibility Window operation Visors Windscreen - heating Voice Operation Windscreen and rear window heating See Owner's Manual Infotainment Windscreen washer fluid Refilling Warning light...
  • Page 197 Reprinting, duplicating, translating and any other use, either in whole or in Issued by: ŠKODA AUTO a.s. part, is not permitted without the written consent of ŠKODA AUTO a.s.. © ŠKODA AUTO a.s. 2016 ŠKODA AUTO a.s. expressly reserves all rights relating to copyright laws. Subject to change.
  • Page 200 Návod k obsluze Yeti anglicky 05.2016 S90.5610.26.20 5L0012720AL  5L0012720AL...

Table of Contents
