Feature

Processor
The motherboard uses an LGA1155 type of socket that carries the following
features:
• Accommodates the latest Intel
cessors
• Supports "Hyper-Threading" technology CPU
• DMI 5.0GT/s
• One PCI Express x16 slot
• Supports 22nm & 32nm Intel
"Hyper-Threading" technology enables the operating system into thinking
it's hooked up to two processors, allowing two threads to be run in parallel, both
on separate "logical" processors within the same physical processor.
Chipset
The Intel H61 Chipset is a single-chip with proven reliability and performance.
• Support two PCI Express x1 slots
• Integrated four SATA 3.0 Gb/s Host Controller
• Eight USB 2.0 ports supported
• Serial Peripheral Interface (SPI) support
• Integrated Graphics Support with PAVP 1.5
• Intel
Memory
• Supports DDR3 1600*/1333/1066 DDR3 SDRAM with Dual-channel ar-
chitecture
• Accommodates two unbuffered DIMMs
• Up to 8 GB per DIMM with maximum memory size up to 16 GB
Audio
• 5.1+2 Channel High Definition Audio Codec
• Meets Microsoft WLP3.x (Windows Logo Program) audio
requirements
• All DACs supports 44.1k/48k/96k/192kHz sample rate
• Software selectable 2.5V/3.2V/4.0V VREFOUT
• Direct Sound 3D. compatible
• Power Support: Digital: 3.3V; Analog: 5.0V
® High Definition Audio Controller
* The 3rd Generation CPU required.
Introducing the Motherboard
®
TM
Core Family/Pentium
®
TM
Core micro-architecture
® ®
/Celeron pro-
