Connect Cables
1. Connect handset and headset, as shown below.
(Note: Headset is an optional accessory, and is not included with this package.)
2. Connect network and power, as shown below.
(Note: Choose either AC Power Option, or In-Line Power Option.)
AC Power Option
Attach Base Stand
Deskmount Method
Ensure all cables are
secured (as shown).
SoundPoint IP 560 Quick Start Guide
In-Line Power Option
Align base stand tabs
with their correspond-
ing insertion points on
the phone (as shown).
Snap base stand into
place (as shown).
