SoundPoint
1 Connecting Handset and Headset
Headset
(Optional
accessory)
2 Connecting Network and Power
AC Power Option:
Network Port
Power over Ethernet Option:
IEEE 802.3af
compliant
Power over
Ethernet
Hub/Switch
(Terminal or
Midspan)
®
SoundPoint
IP 430 Quick Start Guide
IP 430 Installation
®
Handset
Power Adapter*
(24V DC)
*NOTE: Use only the
power adapter shipped
with the unit to ensure
correct functionality.
Optional PC
Connection
Optional PC
Connection
