D V D / V I D E O C D / C D P L AY E R MENU PLAY SELECT DISPLAY OPEN/CLOSE DISC Grundig Service Hotline Deutschland..Mo.-Fr. 8.00-18.00 Uhr Technik: 0180/52318-41 0180/52318-49 Zusätzlich erforderliche Unterlagen für den Komplettservice...
Page 2
This service manual addition contains the spare parts lists for the sets Geräteserie Malaga SE 1210. Des Weiteren ist das Wiederherstellen of the Malaga SE 1210 series. It also describes how to recover the der Gerätefunktion nach Austausch des EEPROMs (U204) oder der functions of the set after replacing the EEPROM (U204) or the chassis Chassisplatte beschrieben.
Page 3
Explosionszeichnung und Ersatzteillisten Exploded View and Spare Parts Lists Ersatzteilliste Spare Parts List 12 / 2000 MALAGA SE 1210 MATERIAL-NR. / PART NO.: 758693100000 BESTELL-NR. / ORDER NO.: GMI6600 POS. NR. ABB. MATERIAL-NR. ANZ. BEZEICHNUNG DESCRIPTION POS. NO. FIG. PART NUMBER QTY.
Page 4
