- Page 1 TA1000 Tape Drive Array Reference Guide First Edition (June 2000) Part Number 189904-001 Compaq Computer Corporation...
- Page 2 The Open Group. All other product names mentioned herein may be trademarks or registered trademarks of their respective companies. Compaq shall not be liable for technical or editorial errors or omissions contained herein. The information in this document is subject to change without notice.
-
Page 3: Table Of Contents
Text Conventions.......................vii Symbols in Text....................... viii Symbols on Equipment.................... viii Important Safety Information ................ix Rack Stability ......................x Getting Help ........................x Compaq Technical Support ..................x Compaq Website ....................xi Compaq Authorized Reseller................xi Chapter 1 Tape Array Overview Introducing the Array ....................1-1 Tape Array Features .................... - Page 4 Tape Array Installation continued Connecting the SCSI Cables ..................2-9 SCSI Bus Speeds and Lengths................2-9 I/O Module Connections................. 2-10 Applying Power ..................... 2-10 Verifying Operation ....................2-11 Front Array Status LEDs ................2-11 Rear Array Status LEDs.................. 2-12 Driver Installation/Upgrade ................... 2-13 Storage Management Software Installation/Upgrade..........
- Page 5 Chapter 6 Power and Cooling Storage Array Power ....................6-2 Temperature Sensing ..................6-2 Blower Interface ...................... 6-2 Blowers........................6-3 Status Reporting ...................... 6-3 Replacing a Power Supply or Blower..............6-4 Chapter 7 Customer Replaceable Units Labeling ........................7-2 Electrostatic Discharge Protection................7-2 Basic Replacement Procedures................
-
Page 6: About This Guide
This guide is intended for use as step-by-step instructions for installation and as a reference for operation, troubleshooting, and future upgrades for the Compaq TA1000 Tape Drive Array. Text Conventions This document uses the following conventions to distinguish elements of text: Keys Keys appear in boldface. -
Page 7: Symbols In Text
Compaq TA1000 Tape Drive Array Reference Guide Symbols in Text These symbols may be found in the text of this guide. They have the following meanings. WARNING: Text set off in this manner indicates that failure to follow directions in the warning could result in bodily harm or loss of life. -
Page 8: Important Safety Information
About This Guide ix This symbol on an RJ-45 receptacle indicates a Network Interface Connection. WARNING: To reduce the risk of electric shock, fire, or damage to the equipment, do not plug telephone or telecommunications connectors into this receptacle. This symbol indicates the presence of a hot surface or hot component. If this surface is contacted, the potential for injury exists. -
Page 9: Rack Stability
Compaq Technical Support In North America, call the Compaq Technical Phone Support Center at 1-800-OK-COMPAQ. This service is available 24 hours a day, 7 days a week. For continuous quality improvement, calls may be recorded or monitored. Outside North America, call the nearest Compaq Technical Support Phone Center. -
Page 10: Compaq Website
About This Guide xi Compaq Website The Compaq website has information on this product as well as the latest drivers and Flash ROM images. You can access the Compaq website at http://www.compaq.com. Compaq Authorized Reseller For the name of your nearest Compaq authorized reseller: In the United States, call 1-800-345-1518. -
Page 11: Tape Array Overview
Chapter Tape Array Overview Introducing the Array The Compaq TA1000 Tape Drive Array™ supports up to 10 Compaq hot-pluggable tape drives. It supports Wide-Ultra and Wide-Ultra2 SCSI protocols. The internal bus supports only low voltage differential (LVD) drives. The external bus (the array to the host controller bus) supports either Wide-Ultra2 (LVD) or Wide-Ultra single-ended (SE) SCSI protocols. -
Page 12: Tape Array Features
A dual-bus Ultra2 I/O module A hot-pluggable tape drive in each bay The TA1000 Tape Drive Array supports up to ten 1.6-inch, Compaq hot- pluggable tape drives. The array is a rack-mountable device that requires a 3U vertical opening (5.25-inches) where a “U” is 1.75 inches. -
Page 13: Scsi Buses
Tape Array Overview 1-3 The hot-pluggable tape array elements are replaceable without stopping SCSI bus data transfers. The TA1000 Tape Drive Array is designed to support only Compaq hot-pluggable tape drives. A full description of the individual elements and their functions can be found in the following chapters, including removal and replacement procedures. -
Page 14: Tape Array Installation
Chapter Tape Array Installation This chapter describes: 1. Installing a TA1000 Tape Drive Array into a rack. 2. Connecting the SCSI cables. 3. Applying power to the array. 4. Verifying proper operation. 5. Installing/Upgrading drivers. Rack Installation Use the following procedures to install your tape array into the rack. -
Page 15: Tools Required
2-2 Compaq TA1000 Tape Drive Array Reference Guide Tools Required No. 2 Phillips screwdriver 3/8-inch nut driver Using the Template Use the rack template to mark the rail attachment points on the front and rear of the rack. Figure 2-1. Using the rack template... -
Page 16: Attaching The Mounting Brackets
Attaching the Mounting Brackets Attach the two mounting brackets. IMPORTANT: Some Compaq racks use a square-hole rail design, while others use a round-hole rail design. Where indicated, follow the steps for each rack type. 1. For square-hole racks only: Install two alignment clips 1 over the round tabs on the front of each mounting bracket. - Page 17 2-4 Compaq TA1000 Tape Drive Array Reference Guide 3. If necessary, loosen the three screws in the middle of the mounting bracket to adjust the length of the bracket to fit your rack. 4. For square-hole racks only: Position the left mounting bracket 1 just behind the front vertical rail, aligning the middle two mounting bracket holes with the rail holes previously marked using the template.
- Page 18 Tape Array Installation 2-5 5. For round-hole racks only: Extend the mounting bracket through the rear vertical rail holes. Be sure that the mounting bracket fingers are inserted into the corresponding vertical inner rail holes. Figure 2-4. Round-hole rack bracket alignment IMPORTANT: The mounting bracket must be parallel from front to rear before you secure it to the rack.
- Page 19 2-6 Compaq TA1000 Tape Drive Array Reference Guide 6. Secure the bracket to the rear vertical rail using two washers and two Kep nuts 1. 7. Secure the mounting bracket to the front vertical rail using two pan head SEMS screws 2 (10-32 x 5/8 in).
-
Page 20: Installing The Tape Array Into The Rack
Tape Array Installation 2-7 Installing the Tape Array Into the Rack CAUTION: Enclosure weight, with all elements installed exceeds 60 lbs (27.2kg). To prevent personal injury, at least two people are required to install the tape array safely. WARNING: To reduce the risk of personal injury or damage to the equipment: Observe local Occupational Safety guidelines for lifting heavy equipment. - Page 21 2-8 Compaq TA1000 Tape Drive Array Reference Guide 1. Position the tape array on the mounting brackets with the Compaq logo in the upper left corner, and slide it in until the tape array flanges 1 contact with the front vertical rails.
-
Page 22: Connecting The Scsi Cables
Tape Array Installation 2-9 Connecting the SCSI Cables To connect the enclosure to a host adapter or SCSI controller, connect the cables to the I/O module. The I/O module has 68-pin, very high density cable interconnect (VHDCI) connectors. SCSI Bus Speeds and Lengths The maximum bus and cable lengths are a function of the SCSI host controller or drives attached (LVD or SE). -
Page 23: I/O Module Connections
2-10 Compaq TA1000 Tape Drive Array Reference Guide I/O Module Connections Figure 2-7 shows the connections for a dual-bus configuration using the dual-port I/O module. Figure 2-7. Dual-port I/O module SCSI cable connectors 1 Latch 3 Status LEDs 2 SCSI Bus A connector... -
Page 24: Verifying Operation
Tape Array Installation 2-11 Verifying Operation All the devices in the tape array begin operating when power is applied. Check the tape array status LED indicators in the front, lower right corner. If the display is not exactly as shown there is an error condition. Check the drive status LEDs on the front, and the EMU, power supplies, blowers, and I/O module status LEDs on the rear to verify proper operation. -
Page 25: Rear Array Status Leds
2-12 Compaq TA1000 Tape Drive Array Reference Guide Table 2-2 Status LED symbols Symbol Meaning Tape array status (flashing – green LED) Tape array power (On – green LED) Tape array fault (Off – amber LED) Rear Array Status LEDs Figure 2-11 shows the location of the rear array status LEDs. -
Page 26: Driver Installation/Upgrade
Compaq Integration Management Display Utility Compaq SCSI Controllers To install or upgrade these software items: 1. Insert the Compaq SmartStart and Support Software CD, version 4.7 or greater (located in the Storage Utility Software kit that came with your unit). -
Page 27: I/O Module
Chapter I/O Module This chapter discusses the operation and function of the dual-bus tape array pluggable I/O module (commonly referred to as the “module”). Figure 3-1. Dual-bus I/O module Features The I/O modules are pluggable elements. Replacing either an I/O module or a cable requires stopping all data transfers to prevent the loss of data. -
Page 28: Scsi Bus Connectors
3-2 Compaq TA1000 Tape Drive Array Reference Guide The I/O module connects the tape array to the host controller through a 68-pin, VHDCI connector and a SCSI cable. This I/O module can support a maximum of 10 drives in a single tape array. -
Page 29: Dual-Bus Scsi Address Maps
I/O Module 3-3 Dual-Bus SCSI Address Maps The dual-port I/O module assigns a SCSI address to each drive bay in the enclosure (see Table 3-2). Table 3-1 Dual-Bus SCSI IDs SCSI ID SCSI Bus A SCSI Bus B I/O Module Power Protection A voltage sensor in the I/O module detects overcurrent conditions. -
Page 30: Dual-Port I/O Module Status Displays
3-4 Compaq TA1000 Tape Drive Array Reference Guide Dual-Port I/O Module Status Displays Table 3-1 describes the dual-port I/O module status displays. Table 3-2 Dual-Port I/O Module Status Displays LED is On LED is Off LED is Flashing When the I/O module is operational and the external SCSI bus is functional:... -
Page 31: Replacing An I/O Module
I/O Module 3-5 Replacing an I/O module To replace an I/O module, complete the procedures outlined in Chapter 7, “Customer Replaceable Units.”... -
Page 32: Environmental Monitoring Unit
Chapter Environmental Monitoring Unit This chapter discusses the Environmental Monitoring Unit (see Figure 4-1). The EMU is an integral part of every tape array enclosure. This element performs several functions, including monitoring the enclosure operation, detecting and indicating errors, and displaying the EMU and enclosure status. Figure 4-1. -
Page 33: Functions
4-2 Compaq TA1000 Tape Drive Array Reference Guide The EMU mounts in the bay at the left rear 1 of the enclosure (see Figure 4-2). Figure 4-2. EMU location Functions EMU functions include: Assigning device SCSI addresses (in conjunction with the I/O module) -
Page 34: Status Leds
EMU turns On the amber tape array Fault LED. A power supply automatically shuts down when the internal power supply temperature exceeds 85°C (180°F). When Compaq Insight Manager is installed, it can report an alarm condition when the internal temperature reaches 50°C (122°F). -
Page 35: Power Supplies And Blowers
4-4 Compaq TA1000 Tape Drive Array Reference Guide Power Supplies and Blowers The green LED on the power supply assembly is On when both the power supply and the blower are operational. When there is either a power supply or blower fault, the EMU turns Off both the green power supply and the enclosure power LEDs. -
Page 36: Replacing An Emu
Environmental Monitoring Unit 4-5 Table 4-1 EMU LED Status Displays LED is On LED is Off LED is Flashing When the EMU and the tape array are operational: When flashing once per second (see heartbeat in Figure 4-4) both the EMU and the tape array are operational. -
Page 37: Tape Drives
Chapter Tape Drives The storage array supports Compaq hot-pluggable, Wide-Ultra2 SCSI, LVD tape drives. This chapter describes the tape drive features, functions, and characteristics. The 10-tape array supports 1.6-inch, hot-pluggable drives (see Figure 5-1). CAUTION: Removing a drive significantly changes the airflow within the tape array and could cause overheating. -
Page 38: Status Reporting
5-2 Compaq TA1000 Tape Drive Array Reference Guide Status Reporting All drives have three status LEDs (see Figure 5-1) to define the operational status of the drive. To determine the drive status you must observe all three LEDs (see Table 5-1). -
Page 39: Power And Cooling
This chapter describes the functions and general operation of the tape array power supply and blowers. See Figure 6-1 for major component locations. NOTE: Compaq provides country-specific power cords with each array. Figure 6-1. Power and blower elements 1 Power supply element... -
Page 40: Storage Array Power
6-2 Compaq TA1000 Tape Drive Array Reference Guide Storage Array Power The power supply and blower assembly mount in the rear of the enclosure. The power supply is auto-ranging and operates on an AC input voltage of 100 to 242 VAC ±10%, 50 to 60 Hz ± 5% (90 to 264 VAC, 47 to 63 Hz). -
Page 41: Blowers
Power and Cooling 6-3 Blowers The power supply-mounted blowers cool the enclosure by circulating air through the enclosure and elements. The rate at which air moves (the airflow) determines the amount of cooling. This airflow is a function of blower speed (rpm). -
Page 42: Replacing A Power Supply Or Blower
6-4 Compaq TA1000 Tape Drive Array Reference Guide Replacing a Power Supply or Blower To replace a power supply or blower use the procedure described in Chapter 7, “Customer Replaceable Units.” NOTE: As long as there is one operational power supply, you can replace a defective power supply without stopping data transfers. -
Page 43: Customer Replaceable Units
Chapter Customer Replaceable Units Each replacement CRU (Customer Replaceable Unit) contains detailed replacement instructions. This chapter describes the general replacement procedures. Table 7-1 CRU Replacement Methods Device Method Drive Hot-pluggable Hot-pluggable Blower Hot-pluggable I/O Module Pluggable Replacing an I/O module requires stopping all data transfers Power Supply-Dual Hot-pluggable... -
Page 44: Labeling
7-2 Compaq TA1000 Tape Drive Array Reference Guide Labeling To order a CRU, you must use the Compaq spare part number that appears on the CRU product label (see Figure 7–1). The first six characters identify the CRU. The last three define the revision level. -
Page 45: Basic Replacement Procedures
Customer Replaceable Units 7-3 Basic Replacement Procedures The following procedures apply to all CRU replacement procedures. CAUTION: The hot-pluggable power supplies, blowers, EMU, and drives DO NOT require halting all data transfers on the SCSI bus. Replacing a pluggable I/O module or a SCSI cable always requires halting all data transfers on the SCSI bus. -
Page 46: Replacing A Drive
7-4 Compaq TA1000 Tape Drive Array Reference Guide Replacing a Drive If a tape drive fails, replace it using the following procedures. CAUTION: Never remove more than one tape drive at a time, as this can cause the enclosure to overheat. -
Page 47: Replacing A Variable Speed Blower
Customer Replaceable Units 7-5 Replacing a Variable Speed Blower NOTE: The power supply design ensures that removing a blower does not change the airflow within the enclosure. However, do not remove a blower until the replacement blower is available. WARNING: The blower blades rotate at a high speed and do not stop immediately when power is removed. -
Page 48: Replacing A Power Supply
7-6 Compaq TA1000 Tape Drive Array Reference Guide 2. Align the blower guide post 2 with power supply connector 1. Slide the replacement blower 3 into blower base until the tabs 4 snap into place. Figure 7-4. Blower replacement 3. Make sure that the blower starts operating immediately and the blower LED is On. - Page 49 Customer Replaceable Units 7-7 2. While lifting the power supply port-colored module latch 1 up, grasp the blower element 2 and pull the defective power supply out of the enclosure. Figure 7-5. Removing a power supply 3. Install the replacement supply by lifting the power supply module latch 1 up and pushing the blower base 2 in until the assembly is fully seated in the enclosure.
- Page 50 7-8 Compaq TA1000 Tape Drive Array Reference Guide 4. Remove the operational blower from the defective power supply by pushing the two blower tabs 1 in and pulling the blower element to the rear. Figure 7-7. Removing the blower CAUTION: Pressing on the center section of the blower can damage the blades.
-
Page 51: Replacing The Emu
Customer Replaceable Units 7-9 6. Connect the AC power cord and observe the power supply for proper operation. The blower starts operating immediately. The blower LED is ON. The blower on the other supply no longer operates at high speed. Replacing the EMU NOTE: Removing an EMU significantly changes the airflow within the tape array and could cause overheating. -
Page 52: Replacing An I/O Module
7-10 Compaq TA1000 Tape Drive Array Reference Guide Replacing an I/O Module CAUTION: Connecting or disconnecting an I/O module or SCSI cable while data is being transferred causes the loss of data. To prevent errors, always stop all data transfers on the SCSI bus before removing or installing an I/O module or SCSI cable. - Page 53 Customer Replaceable Units 7-11 7. While grasping the I/O module handle, press the I/O module latch 1 down and push the I/O module into the enclosure until it is fully seated. 8. Connect the cable connector to the same connectors (see Step 4). 9.
-
Page 54: Agency Notices
Appendix Agency Notices Federal Communications Commission Notice Part 15 of the Federal Communications Commission (FCC) Rules and Regulations has established Radio Frequency (RF) emission limits to provide an interference-free radio frequency spectrum. Many electronic devices, including computers, generate RF energy incidental to their intended function and are, therefore, covered by these rules. -
Page 55: Class A Equipment
To identify this product, refer to the Part, Series, or Model number found on the product. Modifications The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Compaq Computer Corporation may void the user's authority to operate the equipment. -
Page 56: Cables
Agency Notices A-3 Cables Connections to this device must be made with shielded cables with metallic RFI/EMI connector hoods in order to maintain compliance with FCC Rules and Regulations. Canadian Notice (Avis Canadien) Class A Equipment This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. -
Page 57: Japanese Notice
A-4 Compaq TA1000 Tape Drive Array Reference Guide Japanese Notice Taiwanese Notice... - Page 58 A-3 address maps 3-3 SCSI, attaching 2-10 airflow 5-1, 5-2, 6-3 Canadian Notice (Avis alignment clips, attaching 2-3 Canadien) A-3 CE Marking A-3 Compaq authorized reseller xi blowers Insight Manager 4-3 element 6-1 website xi failure 6-3 connectors location of 1-2...
- Page 59 Compaq TA1000 Tape Drive Array Reference Guide help additional sources x electric shock Compaq authorized resellers, icon viii telephone numbers xi symbol viii Compaq website xi electrostatic discharge 7-2 technical support telephone numbers x functions 4-2 high availability features 1-3...
- Page 60 Index iii LEDs EMU 4-1 rack location of front 2-11 safety warning 2-1 rear 2-12 template, using 2-2 status displays replacement procedures blower 6-3 basic 7-3 I/O module 3-4 blower 7-5 power supply 6-3 EMU 7-9 tape drive 5-2 I/O module 7-10 symbols, defined 2-12 power supply 7-6 tape drive 7-4...
- Page 61 Compaq TA1000 Tape Drive Array Reference Guide troubleshooting blower TA1000 Tape Drive Array failure 6-3 features 1-2 LED Off 6-3 front view 1-1 speed 6-3 installation procedures 2-1 stopped 6-3 installing into the rack 2-7 data transfers 6-4 rear view 1-2...
- Page 62 RJ-45 receptacle ix warnings weight 2-7 blower blades 6-3, 7-5 weight electric shock viii tape array 1-2 heavy weight ix weight, tape array 2-7 hot surfaces ix www.compaq.com x installation requirements 1-2 multiple sources of power ix network interface connection ix...
