Quick Installation Guide

300Mbps Wireless N Gigabit Router
Please select your preferred con guration method:
Method 1 >> Con guration via CD Setup Wizard
For Windows users only
Method 2 >> Con guration via Web-based Quick Setup Wizard
For Mac OS/Linux users or Windows users who cannot run mini CD
TL-WR1042ND
MODEL NO.
Method 1 >> Con guration via CD Setup Wizard
This method is only for Windows users who can run the mini CD.
Insert the TP-LINK Resource CD into the CD-ROM drive.
1
Select TL-WR1042ND and click Easy Setup Assistant.
2
7106504468 REV1.2.0

Package Contents

TL-WR1042ND
Power Adapter
Ethernet Cable
Resource CD
300Mbps Wireless N Gigabit Router
Please select your preferred con guration method:
Method 1 >> Con guration via CD Setup Wizard
For Windows users only
Method 2 >> Con guration via Web-based Quick Setup Wizard
For Mac OS/Linux users or Windows users who cannot run mini CD
MODEL NO. TL-WR1042ND
QIG
Select your language from the drop-down menu.
3
Click START and the Easy Setup Assistant will
guide you step by step to set up the Router.
4 Follow the instructions until you see the screen
below. Click FINISH to complete the setup.
1

Hardware Connection

Wall Socket
Internet
Cable/DSL Modem
2
Power o your modem and disconnect your existing router if you have one. (If the modem has a backup battery, please remove it too.)
1
Use an Ethernet cable to connect the INTERNET port of the router to the modem's LAN port.
Use another Ethernet cable to connect your computer to one of the LAN ports labeled 1/2/3/4 on your router.
3
4 Turn on your modem and wait for 2mintues. (Replace the battery if you removed it previously.)
Plug the supplied power adapter into the POWER jack to turn on the router and wait for 1 minute.
5
To use the router to share les or printers, plug an external USB hard drive, USB ash disk or USB printer to the USB port.
Please refer to Appendix 1 for more details about USB features.
Method 2 >> Con guration via Web-based Quick Setup Wizard
This method is for Mac OS/Linux users or Windows users who cannot run the mini CD.
Open your web browser and type http://tplinklogin.net in
1
the address bar, then type admin both for user name and
password to log in.
If the login window fails
to pop up or you cannot
access the management
page after the login
window, please refer to
Troubleshooting-2.
2 Click Quick Setup in the main menu and click Next.
Select Auto-Detect to detect the Internet connection type and
3
click Next. Here we take connection type Dynamic IP for example.
Computer
POWER WPS RESET USB INTERNET 1 2 LAN 3 4
5
3
If Dynamic IP is detected, there will appear the MAC Clone
4
page. In most cases, there is no need to clone the MAC address.
You can select "No, I am..." and then click Next to continue.
You can rename your wireless network and create your own
5
password in this page. Then click Next to continue.
6 Click Finish to make your settings take e ect.
