Care and cleaning.

Cleaning the Outside
The stainless steel door and door handle can be cleaned with
a commercially available stainless steel cleaner. Cleaners with
oxalic acid such as Bar Keepers Friend Soft Cleanser™ will
remove surface rust, tarnish and small blemishes.
Cleaning the Condenser
The condenser has fins and tubes that can become clogged
with dirt and lint.
To clean:
1. Remove the kickplate and front service panel.
2. Locate the condenser surface.
Removing Scale from the Ice Making System
Cleaning the ice machine involves adding a solution of scale
remover and water to the ice machine and continuing to add
it as it makes ice. The scale remover must be diluted to the
correct ratio. A squirt bottle will make adding the scale remover
much easier when the unit is built in. If not built in, remove the
top panel for reservoir access.
You should use rubber gloves when using the scale remover.
To order scale remover, go to GEApplianceParts.com or call
877-959-8688. Order part number WX08X42872.
1. Scoop out discard all of the ice.
2. Press and release the ON/OFF button.
POWER
ICE
ON/OFF
MAKING
3. Open door and locate screws at the upper back wall of the
bin. Remove the 2 screws.
Remove screws
6
Condenser surface
CLEAN
CHECK TIME TO
RESET
WATER CLEAN
Use only a liquid cleanser free of grit and rub in the direction of
the brush lines with a damp soft sponge. Do not use appliance
wax or polish on the stainless steel.
3. Vacuum the surface to remove all dust and lint.
NOTICE
Do not dent the fins.
4. Return the kickplate and front service panel to their original
positions. Fasten them to the cabinet using the original
screws.
4. Remove the back panel of the bin by lowering it down past
the scoop holder. The scoop holder will rotate to allow the
panel to lower.
Reservoir cover
release tab
5. Push tab on front edge of reservoir cover and remove the
cover. NOTE: Adjacent wires are low voltage and are not
hazardous.
Float valve ON/
OFF Lever
